Delta shower cartridge replacement

I match your Delta shower cartridge replacement by series to the valve body, then check the repair and temperature limit.

As an Amazon Associate I earn from qualifying purchases. How this site earns

Updated November 18, 2026

Amazon product photo of the Delta RP47201 TempAssure 17T thermostatic cartridge.
Delta RP47201. Product photo: Amazon. Match the valve series before choosing a cartridge.

The short answer

Older Monitor 1300/1400 valves take RP19804; standard MultiChoice 13/14 takes RP46074. A confirmed TempAssure 17T takes RP47201; other separate-control valves need the checks below. Shut off both supplies before removal, and match the valve before buying. Before you pay for a cartridge, ask Delta whether its faucet warranty covers your valve; the terms depend on the faucet and who bought it.

Older Monitor 1300/1400
Delta RP19804. Shorter lower housing; single-function pressure balance.
Standard MultiChoice 13/14
Delta RP46074. Longer lower housing; single-function pressure balance.
Confirmed TempAssure 17T
Delta RP47201. Thermostatic, with separate volume and temperature control.
Separate controls, not confirmed 17T
No pick yet. Monitor 1700 and MultiChoice 17 take other cartridges; run the identification chart first.
Not sure? Answer two questions

Find your cartridge by series

Start with the controls on the wall. The cartridge comes last.

The finder routes by control arrangement first, then the physical clue Delta's reference sheet uses. The valve's parts list is still the deciding check.

1How many controls does the shower have?

Start with question 1: how many controls the shower has.

Picks by valve family

Three cartridges from Delta, each matched to one confirmed valve family. Each one fits only the family Delta assigns it, so the valve decides, not a score. Specs and repair paths come from Delta's own instructions and product records for that exact part.

  1. For standard MultiChoice 13/14

    Delta RP46074

    RP46074 · MultiChoice 13/14 · Single-function pressure balance

    Best for
    Your valve and its parts drawing identify a standard MultiChoice 13/14 cartridge, with the longer lower housing shown in Delta’s reference sheet.
    Skip it if
    You have the shorter Monitor 1300/1400 housing, separate volume and temperature controls, or a ceramic part identified by your model’s parts list.

    Comparison only, not linked: no verified Amazon price for this exact Delta part is on file, so this card carries no Amazon link and no substitute part. Confirm the Delta part number before buying.

    Full specs and the tradeoff
  2. For Monitor 1300/1400

    Delta RP19804

    RP19804 · Monitor 1300/1400 · Single-function pressure balance

    Best for
    The existing valve is confirmed as the Monitor 1300/1400 family that Delta assigns to RP19804, and a complete cartridge replacement is appropriate.
    Skip it if
    Your valve is standard MultiChoice 13/14, Monitor 1700, MultiChoice 17 or TempAssure 17T. Those families require their own identification paths.

    Comparison only, not linked: no verified Amazon price for this exact Delta part is on file, so this card carries no Amazon link and no substitute part. Confirm the Delta part number before buying.

    Full specs and the tradeoff
  3. Amazon product photo of the Delta RP47201 TempAssure 17T thermostatic cartridge.

    Product photo: Amazon

    For TempAssure 17T

    Delta RP47201 TempAssure 17T thermostatic cartridge

    RP47201 · MultiChoice 17T · Thermostatic

    Best for
    Your model is confirmed as MultiChoice 17T thermostatic trim, as Delta’s product page and your valve’s documents describe.
    Skip it if
    Your valve is MultiChoice 17, Monitor 1700 or a single-handle 13/14; Delta says 17 and 17T cartridges aren’t interchangeable.
    $263.99 at AmazonPrice as of Nov 22, 2026, 9:30 AM EST
    See today’s price on Amazon (opens in a new tab)

    New, sold by Amazon.com. In stock when checked November 17, 2026. Stock and seller can change.

    Full specs and the tradeoff

The 17, Monitor 1700 and ceramic branches use other parts. If your controls or old cartridge differ from these three, start at the valve identification chart before ordering.

Product prices and availability are accurate as of the date/time indicated and are subject to change. Any price and availability information displayed on Amazon.com at the time of purchase will apply to the purchase of this product.

Each pick, up close

The fit evidence, the repair path and what each Delta document says, per cartridge. Where two of Delta's own references differ, both readings stay on the page.

For standard MultiChoice 13/14

Delta RP46074 cartridge

Reference (not linked). This part isn’t linked here. Confirm the Delta part number before buying on Amazon.

RP46074 is the fit choice for a confirmed standard MultiChoice 13/14 valve. Delta describes it as a single-function pressure-balance cartridge. The handle controls temperature at full output flow; it does not give you a separate volume adjustment. That control arrangement helps narrow the search before the trim comes off.

The useful physical clue is underneath the cap. Delta’s 68881 Rev. M reference sheet shows RP46074 with a longer lower housing than RP19804. Compare that section against the old part and the maker’s drawing. A similar-looking cap or a matching handle outside the wall is weaker evidence than the valve’s parts list.

Do not order RP46074 simply because somebody calls the shower a 1400. The older Monitor 1300/1400 family takes RP19804. Delta also identifies a ceramic MultiChoice 13/14 branch with RP74236 in select models. Confirm the exact application if your model suffix or existing parts point to that branch.

Where it does well

  • Delta specifies standard MultiChoice 13/14 fit
  • Single-function pressure balance
  • Integrated rotational limit stop

What to watch

  • Does not replace the shorter-housing RP19804 family
  • Separate-control 17 and 17T use other cartridges
  • Check ceramic applications against the exact parts list

For RP46074 installation, match the cartridge markings to the instructions. Delta’s 68881 Rev. M, printed page 3, shows tubes and O-rings seated in the base holes, with keys engaged in body slots. Shut off both supplies first. Use that sheet’s reverse-installation drawing if the supplies are reversed.

Delta’s 107528 Rev. I, printed page 6, instead shows HOTTER COLDER on top and a cartridge key engaged in the brass-body slot. Keep that drawing separate from the older seating description. If your RP46074 does not match either illustration, ask Delta to confirm the correct instructions before installing it.

The rotational limit stop needs a measured check after the cartridge is installed. A factory position cannot account for your incoming water temperatures. Delta shows more than one stop design, including a version with a removable disc that must be fully seated again. Keep the applicable instructions beside the valve during that adjustment.

Choose RP46074 after the valve record and lower housing agree. If they disagree, pause and ask Delta to identify the valve from photographs. That check also matters when a new trim box includes RP46074 but the body inside the wall is from the older Monitor family.

Part
RP46074
Confirmed fit
Standard MultiChoice 13/14
Control
Single-function pressure balance
Physical clue
Longer lower housing (Delta 68881 Rev. M reference)
Overall height
4-7/16 in. (Delta product record)
Partial repair path
RP4993 seats and springs, RP14414 lower O-ring inspection, on covered valves

For Monitor 1300/1400

Delta RP19804 cartridge

Reference (not linked). This part isn’t linked here. Confirm the Delta part number before buying on Amazon.

RP19804 belongs to the older Monitor 1300/1400 family. Delta calls it a single-function pressure-balance cartridge, with temperature control at full output flow. Its reference sheet shows a shorter lower housing than RP46074. Those two parts answer similar searches, but they are separate fit choices for different valve bodies.

The old cartridge may not look exactly like today’s product photo. Delta’s reference sheet shows different historical colors within the RP19804 family and assigns the same replacement number to them. Match the shorter lower housing and the valve record. Treat the white or blue appearance as supporting evidence, not a complete identification.

A shutoff drip does not always require a full RP19804. For the Monitor valves covered by manual 38265 Rev. B, Delta starts with RP4993 seats and springs and an inspection of the lower RP14414 O-rings. If leakage persists, the manual gives a cap-assembly or complete-cartridge replacement path. Confirm that manual applies before choosing the partial repair.

Where it does well

  • Delta specifies Monitor 1300/1400 fit
  • Single-function pressure balance
  • Documented seats-and-springs repair path

What to watch

  • Not the longer-housing standard MultiChoice cartridge
  • RP4993 alone cannot fix every shutoff drip
  • Installation year alone is inconclusive

Removal needs care around the brass valve body. Delta’s 38265 Rev. B instructions prohibit prying RP19804 out with a screwdriver. They give a handle-assisted removal procedure after the water supplies are shut off and the bonnet is removed. If the bonnet is seized or the body moves in the wall, have a plumber take over.

The replacement also needs the correct cap orientation and a temperature-limit check. Record the existing arrangement before removal, then follow the applicable instructions. Verify that cold water comes first. Use a thermometer for the maximum-temperature check instead of judging it with your hand or reusing the old handle position without measurement.

Choose RP19804 for a confirmed legacy Monitor body, even if a recently purchased trim kit contains a different cartridge. Decide between seats-and-springs service and full replacement from the valve’s maintenance instructions and the actual fault. A new exterior handle does not identify the cartridge hidden behind it.

Part
RP19804
Confirmed fit
Monitor 1300/1400
Control
Single-function pressure balance
Physical clue
Shorter lower housing (Delta 68881 Rev. M reference)
Partial repair path
RP4993 seats and springs, RP14414 lower O-ring inspection, on covered valves (38265 Rev. B)
Removal
Handle-assisted per 38265 Rev. B; screwdriver prying prohibited

For TempAssure 17T

Delta RP47201 TempAssure 17T thermostatic cartridge

Delta RP47201 TempAssure 17T thermostatic cartridge
Delta RP47201 TempAssure 17T cartridge. Product photo: Amazon.

RP47201 is Delta’s TempAssure dual-function thermostatic cartridge. Delta’s product page lists it for MultiChoice 17T Series trim produced after March 2016, with separate volume and temperature control and ASSE 1016 certification. Its overall height is 5-5/8 in. Delta’s cartridge identifier gives an earlier start, 2007 onward, so take an older 17T to Delta before you order.

A thermostatic cartridge works differently from the two pressure-balance parts above. Delta says it measures and controls the outlet temperature like a thermostat, holding it within ±3.6°F when the inlet water temperature is set correctly, and it may need seasonal adjustment. The volume lever and the temperature knob each do one job.

Separate controls alone don’t prove 17T. MultiChoice 17 and Monitor 1700 also have a volume lever and a temperature knob. Delta’s answer on its product page is plain: 17 and 17T cartridges aren’t interchangeable, and the 17T cartridge is longer, so it needs larger handles to cover it.

Where it does well

  • Thermostatic control, ASSE 1016 certified
  • Separate volume and temperature control
  • Adjustable handle limit stop

What to watch

  • Fits 17T trim only; not a 17 or 1700 cartridge
  • Delta’s two date references differ (2016 vs 2007)
  • Both supplies must be on, with H and C aligned

Installation follows Delta’s 17T manual, 107530 Rev. F. The H mark lines up with the hot supply and C with the cold; reversed inlets stop it working properly. Both supplies need to be pressurized, since one supply alone can leave only a trickle. Low flow after service often points to clogged inlet screens, and Delta has you reset the temperature limit after cleaning them.

Links go to listings sold by Amazon.com. Confirm your 17T model before you order.

Part
RP47201
Confirmed fit
MultiChoice 17T Series trim (Delta product page: produced after March 2016; Delta cartridge identifier gives 2007 onward)
Control
Thermostatic, separate volume and temperature
Certification
ASSE 1016 (Delta product page)
Overall height
5-5/8 in. (Delta product page)
Temperature hold
Within plus or minus 3.6 degrees F when inlet temperature is set correctly (Delta)

Compare RP46074, RP19804 and RP47201

Part and photoConfirmed fitControl and clueTrade-offBuy
RP46074Standard MultiChoice 13/14Single-function pressure balance; longer lower housingNot the legacy shorter-housing matchReference (not linked)
RP19804Monitor 1300/1400Single-function pressure balance; shorter lower housingSome shutoff drips have a partial-repair pathReference (not linked)
Delta RP47201 shower cartridgeRP47201MultiChoice 17TThermostatic; separate volume and temperatureNot interchangeable with a 17 cartridgeCheck it on Amazon

For RP19804 vs RP46074, start with the body family, then compare the lower housing against Delta’s reference drawing. A model-specific parts list is the best tie-breaker. Do not use the listing’s overall dimensions to decide which one slides into your valve.

The Amazon title for the linked RP46074 includes “3.00 x 6.00 x 4.00 Inches.” Delta’s product record gives an overall height of 4-7/16 inches. Those figures do not provide the same fit evidence as the maker’s lower-housing drawing. Use the RP46074 model number and confirmed valve family.

Listing wordingMaker evidenceWhat to use
RP46074 title: 3.00 x 6.00 x 4.00 InchesDelta RP46074 record: overall height 4-7/16 in.Do not interpret the listing dimensions as insertion dimensions; match the valve and cartridge reference.
RP19804 title: 1300/1400 Series; “Small”68881 Rev. M: shorter lower housing for Monitor 1300/1400“Small” is listing wording, not a measured compatibility specification.

Match the cartridge, then choose the repair

A Delta shower with one rotating temperature handle belongs on a different branch from a shower with a separate volume lever and temperature knob. But separate controls alone do not distinguish Monitor 1700, MultiChoice 17 and thermostatic 17T. Check the model and the cartridge details before choosing any of those parts.

Use the family names in both charts together. The first chart establishes the replacement route. The second adds the repair check and the final test. Ceramic 13/14 and legacy 1500 or 1600 valves have explicit exits so an unfamiliar part is never forced into the RP19804/RP46074 choice.

One temperature handleMonitor 1300/1400: RP19804Confirm the shorter lower housing.One temperature handleStandard MultiChoice 13/14: RP46074Confirm the longer lower housing.Separate volume and temperatureMonitor 1700: RP32104Confirm the legacy notch and tab.Separate volume and temperatureMultiChoice 17: RP46463Confirm the adapter and body family.Separate volume and temperatureTempAssure 17T: RP47201Confirm the thermostatic model.
Identification routes from Delta’s 68881 Rev. M, 107529 Rev. G and 107530 Rev. F cartridge references. Ceramic and other legacy valves require the exception checks below.
Valve familyControl arrangementPhysical or model confirmationReplacement route
Monitor 1300/1400One temperature controlShorter lower housing in 68881 referenceRP19804
Standard MultiChoice 13/14One temperature controlLonger lower housing; exact standard modelRP46074
Ceramic MultiChoice 13/14Confirm exact trimSelect -CER model in the parts diagramRP74236; confirm application
Monitor 1700Separate volume and temperatureReference drawing: white upper cap, square notch, longer tabRP32104
MultiChoice 17Separate volume and temperatureReference drawing: gray cap, V-notch, shorter tab; adapterRP46463
TempAssure 17TSeparate volume and temperatureExact T17T/thermostatic model identificationRP47201; confirm early applications
Legacy 1500Confirm exact trimMatch the valve to the RP32104 conversion sheetRP32104 conversion route; additional parts
Legacy 1600 or unidentifiedDo not infer from handle countDelta identifies RP1991 for confirmed 1600Exact-model identification before purchase

Carry the family through to the repair

FamilyAdditional assembly or first actionRequired final checkSource or uncertainty
Monitor 1300/1400Covered shutoff drips: RP4993 seats/springs and RP14414 O-ring inspectionCorrect orientation, cold first, measured temperature and leak test38265 Rev. B; use the actual valve’s limit-stop instructions
Standard MultiChoice 13/14Covered shutoff drips: check RP4993 and RP14414 before full RP46074 replacementMatch cartridge markings to the installation sheet; measure the stop setting68881 Rev. M, pp. 3, 9; 107528 Rev. I, pp. 6, 12; CPSC 07-505
Ceramic 13/14Confirm -CER parts drawing; do not use color as proofUse that exact cartridge’s installation and temperature procedure68881 Rev. M ceramic exception; confirm exact model with Delta
Monitor 1700Check legacy cartridge identity and the model’s sealsCorrect seating and controls; measured limit and leak test107529 Rev. G reference; confirm exact model with Delta
MultiChoice 17Correctly seat the adapter/seal assembly; RP46073 is the separate assemblyKey engaged, bonnet secured, temperature control adjusted107529 Rev. G; Delta cartridge identifier
TempAssure 17TCheck both supplies, H/C alignment and screens for low flowReset temperature limit after service; test for continuing leakage107530 Rev. F; early date boundary needs confirmation
Legacy 1500Conversion needs the specified adapters and seals, not just the cartridgeRestore the correct stop position and verify cold/hot behavior64655 Rev. A conversion instructions
Legacy 1600 or unidentifiedIdentify through Delta rather than substituting a Monitor partFollow exact model instructions after identificationDelta cartridge identifier; RP1991 is a separate family

Why the year and cap color can mislead

Delta’s 68881 reference shows multiple appearances that share RP19804, plus multiple standard MultiChoice appearances that share RP46074. The useful difference between those two families is the shorter versus longer lower housing. A white or gray cap by itself cannot establish every detail of the assembly underneath.

The same caution applies to RP46463. Delta’s cartridge identifier says its gray cap changed shade in 2016. The 17 Series reference also shows a V-notch and shorter tab for MultiChoice, against a square notch and longer tab for the older Monitor cartridge. Use the combination of features and the valve record.

An installation date is a clue, not proof. A bathroom remodel can change trim without documenting which valve body remains. Delta’s own date labels also differ around the MultiChoice transition. If the dates disagree with the physical match, ask Delta to resolve the model before buying.

Date or appearance clueWhy it is limitedDecision
RP19804 heading: 04/2006 and earlierIts product features use before March 2006; reference illustrates later shipment tooConfirm family and lower housing
RP46463 cap shadeDelta notes a lighter gray before 2016Match notch, tab and adapter as well
RP47201 production datesProduct page says after March 2016; identifier says 2007 onwardAsk Delta to confirm earlier 17T applications
Black or unfamiliar capA color alone does not establish a full assembly matchUse model and maker identification; no resin-change dates assumed

When you need help, send Delta the full trim model if available and clear photos of the old cartridge beside the valve opening. Include the lower housing, notch and tab rather than only the handle. Keep the water isolated if the retaining bonnet or cartridge has been removed.

For a valve with no readable model number, use Delta’s product identifier to reach a parts diagram. If the diagram does not match the part in your hand, stop there. Guessing from a home’s age is especially unhelpful when the controls could be either pressure-balanced 17 or thermostatic 17T.

Pressure balance, volume and thermostatic control

FamilyWhat the user adjustsWhat establishes the repair
RP19804 / RP46074Temperature at full output flowDifferent body and housing fit despite similar operation
RP32104 / RP46463Separate volume and temperatureLegacy Monitor versus MultiChoice reference details
RP47201Separate volume and thermostatic temperatureConfirmed TempAssure 17T model and H/C orientation

Delta calls RP19804 and RP46074 single-function pressure-balance cartridges. On the standard arrangement, turning the control changes the temperature at full flow. Buying the MultiChoice version does not add a separate volume control to an older Monitor shower. The control function and the valve fit are different questions.

RP46463 is dual-function pressure balance, while RP47201 is a TempAssure thermostatic cartridge. Both allow separate volume and temperature control. That is why a volume lever with a temperature knob is only a starting clue. The thermostatic label, trim model and maker’s parts drawing must settle the 17 versus 17T branch.

With RP46463, the adapter and seal assembly is another part of the fit check. Delta lists RP46073 as the separate assembly. Its 17 Series instructions require the adapter to sit correctly and fully down inside the body before the cartridge is installed. Do not discard an unfamiliar rear assembly because a cartridge photograph leaves it out.

A confirmed RP46074 valve

Use the standard MultiChoice 13/14 route and its rotational limit-stop instructions.

Two controls marked Monitor

Identify older 1700 versus MultiChoice 17 versus TempAssure 17T before selecting a cartridge.

A 1500 conversion

Use the RP32104 conversion sheet to identify adapters and seals as well as the cartridge.

Can seats and springs stop the drip?

For the legacy Monitor valves covered by 38265 Rev. B, Delta starts a tub-spout or showerhead shutoff leak with RP4993 seats and springs. It also directs inspection of the lower RP14414 O-rings. This is a specific maintenance path for a confirmed valve, rather than a promise that a small repair kit cures every Delta drip.

Delta also specifies RP4993 seats and springs for covered standard MultiChoice 13/14 shutoff drips in 68881 Rev. M, printed page 9, and 107528 Rev. I, printed page 12. Both call for inspecting RP14414 lower O-rings. If leakage persists, they specify RP46074 replacement. Shut off both supplies before service and confirm the exact valve’s maintenance sheet.

For a legacy Monitor valve covered by 38265 Rev. B, persistent leakage leads to RP19806 cap assembly or RP19804 cartridge replacement. Temperature instability follows a different maintenance branch. Match both the symptom and valve family; a leaking showerhead and unstable mixed temperature do not establish the same failed component.

What you observeFirst distinctionAppropriate route
Drip with the legacy Monitor shut offConfirmed model covered by 38265 Rev. B?RP4993 seats/springs; inspect RP14414 lower O-rings; follow persistent-leak branch
Drip with standard MultiChoice 13/14 shut offConfirmed model covered by 68881 Rev. M or 107528 Rev. I?RP4993 seats/springs; inspect RP14414 lower O-rings; RP46074 if leakage persists
17T showerhead drips brieflyStored water draining or continuing valve leakage?Follow Delta’s showerhead-removal diagnostic before deciding on RP47201
17T only trickles after serviceAre both supply lines pressurized?Restore correct supplies before condemning the cartridge
Water escapes at the wall or bodyVisible repair may not explain the leakIsolate supplies and have a plumber inspect concealed piping

The partial-repair procedure also begins with both water supplies shut off. In the covered legacy cartridge, Delta describes separating the cap from the housing and seating the larger spring end in its pocket first. Use that valve’s diagram for reassembly and restore the documented cap orientation. If the body or seals are damaged, get help.

A repair kit for another Delta faucet is not proof of shower compatibility. RP4993 is a part number in a specific maintenance sequence here. Check the exact shower instructions before ordering it, and keep the old seals separate so the replacement arrangement can be checked against the drawing.

Replace only the confirmed cartridge

Delta recommends a professional plumber for installation and repair. If you cannot isolate the hot and cold supplies, leave the bonnet in place and call one. After closing the applicable stops or main, open the shower control to check that sustained flow stops before loosening a pressurized retaining part.

Take photographs of the existing arrangement and keep the model’s instructions within reach. On Monitor 1300/1400, Delta’s legacy manual specifically forbids screwdriver prying against the body. A seized bonnet, moving valve body or concealed leak is a stop condition. Do not cut the bonnet or twist the hidden piping to force access.

  1. 1
    Confirm the isolation and valve family

    Shut off both supplies as Delta instructs. Verify the shower no longer has sustained flow. Match the model and lower housing before removing the cartridge; call a plumber if the isolation cannot be proved.

  2. 2
    Remove the trim for that model

    Follow the handle and sleeve instructions for the actual trim. Record the stop and hot-side orientation. A handle that looks like another Delta model does not make its removal and adjustment instructions interchangeable.

  3. 3
    Release the cartridge as specified

    After the bonnet is removed, use the applicable maintenance procedure. For the legacy valves covered by 38265 Rev. B, Delta describes handle-assisted removal and expressly prohibits screwdriver prying. Stop if the body moves or the cartridge cannot be released safely.

  4. 4
    For RP46074, match the cartridge markings

    68881 Rev. M, printed page 3, shows tubes and O-rings seated in base holes, keys engaged in slots and the hot-side marking left for normal supplies. With both supplies off, follow its reverse-installation drawing when applicable and hand-tighten the bonnet securely.

  5. 5
    Keep the newer RP46074 drawing separate

    107528 Rev. I, printed page 6, instead shows HOTTER COLDER on top and the cartridge key engaged in the brass-body slot. Follow its reverse-supply and bonnet instructions when that drawing matches your cartridge. Ask Delta if the markings or seating differ.

  6. 6
    For MultiChoice 17, check the rear adapter

    107529 Rev. G requires the adapter assembly to be fully seated, followed by the correctly oriented cartridge with its key engaged in the brass-body slot. Follow the retainer step in the manual before installing the cartridge and securing the bonnet.

  7. 7
    For 17T, use its own procedure

    Confirm the thermostatic model and align H with the hot inlet and C with cold. RP47201 maintenance is separate from the single-function cartridges. If supply identification or the early-model application is uncertain, have Delta and a plumber resolve it before reassembly.

  8. 8
    Restore water and inspect before use

    After the assembly is secured, restore the supplies and check for leakage at the valve and outlet. Keep people clear of the spray during the initial temperature check. Any uncontrolled hot flow, body leak or concealed water calls for isolation and professional repair.

RP32104 conversion on a legacy 1500 is a separate procedure. Delta’s 64655 Rev. A sheet calls for the corresponding handle adapters, seats and seals as well as the cartridge. Do not assume that a cartridge-only purchase completes that conversion.

Do not run an open, unretained valve to improvise a flush. Flushing steps belong to the specific rough-in or trim installation instructions and need a controlled discharge path. If debris cleaning or body work goes beyond the cartridge maintenance shown for your valve, keep the supplies isolated and have a plumber handle it.

A solvent soak, heat or improvised cutting method is outside this cartridge replacement sequence. The selected repair paths do not require those actions. For a stuck bonnet, arrange controlled removal with a plumber rather than adding chemical or heat exposure around an unidentified valve and concealed piping.

Set and measure the temperature limit

The final temperature check is part of the cartridge job. Delta’s 13/14 manual sets a maximum of 120°F, or the lower temperature required by local plumbing rules. That is a ceiling for this commissioning check, not a promise that every person can safely tolerate water at that temperature.

107528 Rev. I shows a thermometer in a plastic tumbler held in the water stream. Let the hot and cold supplies reach their operating temperatures as instructed, keep people out of the shower, and follow the stop diagram for the cartridge you installed. Hand-feel does not provide the measurement Delta calls for.

1. Match the stop designUse the exact cartridge instructions.Do not copy a universal turn direction.2. Verify cold firstMeasure the hottest permitted setting.Use the maker’s thermometer procedure.3. Refit all stop componentsFully seat any removable disc.Repeat the temperature and leak checks.
Commissioning checklist based on 107528 Rev. I. The 17 and 17T families require their own handle and temperature-setting instructions.
Stop or familyRequired actionReason to stop
13/14 with removable discFollow the matching diagram and fully seat the disc after adjustmentDisc missing, damaged or unable to seat
13/14 with another stop designUse the section for that actual design; remeasure after adjustmentDesign cannot be identified or cold does not flow first
17 with separate controlsFollow its temperature-handle setup and measured maximumControl or adapter does not match the trim instructions
17T after screen serviceReset its temperature limit before using the valveH/C alignment or both supply pressures cannot be confirmed

Do not generalize clockwise or counterclockwise advice across generations. Delta’s older 38265 instructions and the later 107528 stop instructions are not a single interchangeable diagram. Identify the actual stop first, make the specified adjustment, and verify the result with a thermometer after each change.

On the removable-disc version, Delta warns that leaving the disc out after setting the limit can create a scald hazard. Reinstalling the handle without that component does not complete the repair. If a stop component is missing, keep the shower out of use and get the correct part and installation help.

Recheck the limit when inlet temperatures change, including seasonal changes or a change to the hot-water supply setting. Delta explicitly warns that these changes can require further adjustment. Leave the applicable instructions and the recorded setting information for whoever maintains the shower next.

Still dripping, cold or barely flowing?

Problem after replacementCheck before buying another partWhen to escalate
17T gives only a trickleBoth hot and cold supplies must be pressurizedBoth supplies available but flow still restricted
17T cannot hold mixed temperatureH marking to hot inlet; C marking to coldSupply mapping uncertain or alignment cannot be corrected safely
17T low flowIts maintenance sheet identifies clogged cartridge screensScreen access or brass-flats support is uncertain
13/14 reaches hot water firstOrientation and the actual stop/handle assemblyDo not use until corrected and commissioned
A continuing outlet dripSeparate stored showerhead drainage from a valve leakFollow the confirmed family’s persistent-leak repair path
Water inside the wallStop the supplies and inspect the concealed systemProfessional repair before returning the shower to use

For 17T low flow, Delta’s maintenance instructions describe cleaning the cartridge screens. They begin with the water supplies shut off and require holding the brass section securely by its flats during the specified access procedure. Omitting that support can damage the cartridge. Have a plumber do this if you cannot follow the exact drawing.

The 17T sheet also requires resetting the limit stop after screen service. Restored flow alone is not the final check. Verify the correct hot and cold behavior and the measured maximum before anybody uses the shower again. Do not transfer that screen-access procedure to RP19804 or RP46074.

For a showerhead that continues to drip after shutoff, Delta’s 17T instructions distinguish slow drainage from continuing cartridge leakage. Their diagnostic removes the head and checks the outlet behavior. Keep the outlet directed away from people during any water-on check; hot water and an open outlet still require controlled testing.

Check early MultiChoice recall history

Historical scald recall: CPSC 07-505

The October 25, 2006 notice covers certain Universal MultiChoice valves whose hot-water limit device could disengage after adjustment. If an early installation may be affected and its corrective-kit history is unknown, contact Delta and keep the shower out of use until Delta confirms it is safe.

Isolation fails or the body moves

Leave retaining parts in place when supply isolation fails. Stop if the valve moves inside the wall, water appears behind the trim, or the temperature cannot be controlled. A plumber needs to resolve those conditions.

The recall notice lists sales from March through May 2006 nationwide, plus October 2005 through May 2006 in Indiana and Ohio. It announced a free corrective upgrade kit. Those sale periods identify a historical population; buying a current RP46074 does not, by itself, prove that an installed valve is affected or that its recall work was completed.

Ask Delta to check an uncertain early MultiChoice installation against the recall and its corrective-kit record. A limit-stop adjustment is not a substitute for that check. If you cannot establish that the installed assembly is safe, leave the shower out of use and arrange professional help before further operation.

Delta cartridge questions

How do I identify a Delta shower cartridge without a model number?

Start with the control arrangement, then compare the cartridge with Delta’s reference sheet after the supplies are safely isolated. RP19804 has the shorter lower housing; standard RP46074 has the longer one. Separate controls require the Monitor 1700, MultiChoice 17 or TempAssure 17T checks. If the features disagree, send photographs to Delta rather than guessing.

What is the difference between RP19804 and RP46074?

RP19804 fits the confirmed older Monitor 1300/1400 family. RP46074 fits standard MultiChoice 13/14. Both are single-function pressure-balance cartridges, but the body fit and lower housing differ. The similar shower-control function does not make the cartridges interchangeable.

Can I identify the cartridge from its cap color?

Use color only as a clue. Delta shows more than one historical appearance for RP19804 and RP46074 and notes a gray-shade change for RP46463. Compare the lower housing or notch and tab, and confirm the exact valve family against its parts diagram.

Does my home’s construction year prove which cartridge fits?

No. The valve needs its own identification. Delta’s reference sheets distinguish cartridge families and historical shipments, while some product-page date labels differ. A home date cannot resolve those details or show whether trim was changed. Match the valve record and the physical cartridge instead.

What is the difference between RP32104 and RP46463?

Delta’s 17 Series reference assigns RP32104 to the older Monitor 1700 pattern, with a square notch and longer tab. It assigns RP46463 to the MultiChoice 17 pattern, with a V-notch, shorter tab and adapter. A legacy 1500 conversion needs the additional parts specified in the separate conversion instructions.

Is a Delta 17T cartridge the same as a 17 Series cartridge?

No. RP47201 is the TempAssure thermostatic route; RP46463 is the MultiChoice 17 pressure-balance route. Both allow separate volume and temperature adjustment, so the controls alone are inconclusive. Confirm the T17T model and ask Delta to resolve uncertain early applications.

Can seats and springs fix a drip without a new cartridge?

Delta specifies RP4993 seats and springs plus RP14414 lower O-ring inspection for covered legacy Monitor valves in 38265 Rev. B and standard MultiChoice 13/14 valves in 68881 Rev. M and 107528 Rev. I. Shut off both supplies first. Persistent leakage needs the exact model’s further-repair branch; this is not a universal Delta shower fix.

Why does the shower still drip after cartridge replacement?

Distinguish retained showerhead water draining from continuing leakage through the valve. Delta’s 17T maintenance sheet gives a diagnostic for that distinction. If water continues through the valve, isolate the supplies and follow the confirmed family’s maintenance path. Water behind the trim or inside the wall needs professional inspection.

Why is the shower cold or barely flowing after replacement?

For 17T, Delta requires both supply lines to be pressurized and H/C markings to match the hot and cold inlets. Its low-flow maintenance also addresses clogged screens. For 13/14, check the actual orientation and limit-stop setup against its own instructions. Stop use if temperature control is uncertain.

How do I check the temperature limit after installing the cartridge?

Use the instructions for the installed stop design and measure the outlet temperature with a thermometer as Delta specifies. Verify cold water first and keep the measured maximum within 120°F or the lower local limit. On the removable-disc version, fully seat the disc again. Stop and call a plumber if the limit cannot be set safely.

How I choose parts and why trust me

Why trust PlumbingPicks

Isaac Daniels, a licensed journeyman plumber in Georgia, is the responsible editor for PlumbingPicks. I read Delta’s cartridge references and maintenance instructions and checked the RP19804, RP46074 and RP47201 model numbers against Amazon listings.

For standard 13/14, older Monitor and thermostatic 17T valves, the model’s parts drawing takes priority over the handle’s appearance or the bathroom’s age.

How I choose repair parts

I select by confirmed valve compatibility, genuine Delta model, New condition and a listing sold by Amazon.com. RP19804, RP46074 and RP47201 each fit a different valve family, so the valve decides, not a score.

Manufacturer documents establish fit and repair steps. Search and forum questions help identify the problems to answer. No service-life estimate, repair-time promise or customer-rating comparison is part of the selection.

CheckSelection rule
Valve fitExact parts diagram and cartridge-reference match come before an offer
Repair needDistinguish partial seal repair, complete cartridge replacement and supply faults
Offer identityGenuine Delta model; New condition; dated Amazon availability check
SafetyIsolation, correct orientation and measured temperature commissioning
ConflictsMaker fit details take priority over ambiguous listing dimensions; unresolved early models go to Delta

Sources
