For one hole, pick the Delta Saylor 535; for 4-inch centers, the 2535; for a widespread, the 3535. For a shower, the T14235 for simple control or the T17235-SS-I for separate volume and a hand shower.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares five Delta Saylor products using Delta’s own spec sheets.
Delta Saylor compared (Delta spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Type | Holes and spacing | Controls | Valve |
|---|---|---|---|---|
| 535-SSMPU-DST | Single-handle | 1 or 3 | One lever | Built in |
| 2535-SSMPU-DST | Two-handle centerset | 3, 4-in. centers | Two levers | Built in |
| 3535-MPU-DST | Two-handle widespread | 3, 4 to 16-in. centers | Two levers | Built in |
| T14235-CZ | 14 Series shower trim | Wall | One handle, temperature only | Needs MultiChoice R10000 |
| T17235-SS-I | 17 Series shower trim, In2ition | Wall | Volume lever plus temperature dial | Needs MultiChoice R10000 |
Saylor is a Delta bath collection with bathroom faucets and shower trim. The three bathroom faucets list Delta’s diamond-coated ceramic cartridge and a metal push pop-up drain. Each Delta sheet lists a lifetime limited warranty on parts and finish for homeowners; commercial purchasers get 10 years in multifamily housing and 5 years for other commercial uses.
Delta Saylor 535-SSMPU-DST: single-handle
Choose the 535 for a one-hole sink; Delta also lists three-hole mounting. Delta’s spec sheet (media.deltafaucet.com) lists one or three-hole mounting, a 1.2 gpm maximum flow, the diamond-coated ceramic cartridge, 1/4-inch PEX supply tubes, and a metal push pop-up drain with a plated flange and no lift rod hole. An optional red and blue indicator ring comes with it.
The sheet lists a 1-1/8 to 1-1/2-inch hole and recommends 2 inches of clearance to the backsplash. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 535-SSMPU-DST, stainless finish.
Check Delta Saylor 535-SSMPU-DST single-handle bathroom faucet on Amazon →
Delta Saylor 2535-SSMPU-DST: two-handle centerset
Choose the 2535 for three holes on 4-inch centers. Delta’s spec sheet (media.deltafaucet.com) lists a three-hole centerset on 4-inch centers, a 1.2 gpm flow, quarter-turn handle stops, the diamond-coated ceramic cartridge, interchangeable hot and cold stems, 3/8-inch PEX supply tubes, and a metal push pop-up drain.
The maximum deck is 2-1/4 inches, holes are 1 to 1-1/2 inches, and the drawing lists a 1-1/4-inch minimum clearance to the backsplash. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 2535-SSMPU-DST, stainless finish.
Check Delta Saylor 2535-SSMPU-DST centerset bathroom faucet on Amazon →
Delta Saylor 3535-MPU-DST: two-handle widespread
Choose the 3535 for three holes spread anywhere from 4 to 16 inches apart. Delta’s spec sheet (media.deltafaucet.com) lists a three-hole widespread for 4 to 16-inch centers, a 1.2 gpm flow, DIAMOND Seal technology with the diamond-coated ceramic cartridge, 3/8-inch PEX supply tubes, quarter-turn stops and a metal push pop-up drain with overflow.
Because the range starts at 4 inches, the 3535 can also fit a 4-inch three-hole sink if you prefer a separate spout and handles. The maximum deck is 2-1/4 inches. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model 3535-MPU-DST, chrome.
Check Delta Saylor 3535-MPU-DST widespread bathroom faucet on Amazon →
Delta Saylor T14235-CZ: 14 Series shower trim
Choose the T14235 for a stall shower on a Delta MultiChoice valve with one simple handle. Delta’s spec sheet (media.deltafaucet.com) covers the T14035 valve-only, T14235 shower-only and T14435 tub/shower trims for the MultiChoice universal rough valve body, R10000 series, which is not included. It lists Monitor 14 Series pressure-balanced trim with temperature controlled by the handle only, a 120-degree handle, a field-adjustable limit on rotation into hot, a 5-setting showerhead and a 1.75 gpm maximum flow.
The shower arm is 5-1/2 inches long including threads, and Delta lists the RP77991 stem extension for an extra 1-3/4 inches of wall. On October 15, 2026, the standard new offer sold by eFaucets showed limited stock with model T14235-CZ, champagne bronze.
Check Delta Saylor T14235-CZ shower trim on Amazon →
Delta Saylor T17235-SS-I: 17 Series with In2ition
Choose the T17235-I if you want to set volume and temperature separately. Delta’s spec sheet (media.deltafaucet.com) lists Monitor 17 Series pressure-balanced trim for the MultiChoice R10000 valve, with a lever for volume and a dial for temperature, a maximum dial rotation adjustable between 90 and 180 degrees, back-to-back installation capability and parts replaceable from the front. The -I version adds the In2ition two-in-one showerhead and hand shower.
Flow is 1.75 gpm at 80 psi, the arm is 5-1/2 inches including threads, and Delta lists the RP77992 stem extension for thick walls. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model T17235-SS-I, stainless finish.
Check Delta Saylor T17235-SS-I shower trim with In2ition on Amazon →
Picking the bathroom faucet: measure first
Count the holes in your sink and measure from the center of the left hole to the center of the right. One hole fits the 535. Three holes 4 inches apart fit the 2535, the 3535, or the 535, which Delta lists for one or three-hole mounting. Three holes more than 4 inches apart, up to 16, fit only the 3535. All three share the same cartridge type and metal push pop-up drain, so the choice is about the look and the spacing.
14 Series or 17 Series?
Both trims fit the same MultiChoice R10000 valve. The difference is the handle. Delta lists the 14 Series handle as controlling temperature only. The 17 Series separates the two: a lever for how much water and a dial for how hot, so you can turn the water down without changing the temperature. If you are swapping trim on an existing MultiChoice valve, either can work, and our Delta MultiChoice trim guide covers what fits which valve.
Tub versions. Each sheet also covers a tub and shower version: the T14435 for the 14 Series and the T17435 or T17435-I for the 17 Series. Delta lists a 1/2-inch CWT slip-on spout adapter, and a tub port flow of 6.0 gpm (14 Series) or 6.2 gpm (17 Series) at 60 psi with the R10000-UNBX valve. The non-In2ition 17 Series trims use Delta’s 52668 five-function H2Okinetic showerhead.
For escutcheon screws in a non-chrome finish when using a stem extension kit, Delta says to order RP12630 screws in your finish, because the kits ship with chrome screws.
Check these before you order
- Bath holes. One hole, 4-inch centers or 4 to 16-inch centers.
- Deck. 2-1/4 inches maximum on the two-handle models.
- Shower valve. Both trims need a MultiChoice R10000 valve.
- Controls. 14 Series is temperature only; 17 Series adds volume control.
- Finish. SS is stainless, CZ champagne bronze; the widespread link is chrome.
- Sellers. The 14 Series link is eFaucets with limited stock.
Which Delta Saylor should you buy?
For one hole, the 535. For 4-inch centers, the 2535. For a widespread, the 3535. For a stall shower with simple one-handle control, the T14235; for separate volume and temperature plus a hand shower, the T17235-SS-I. For other Delta options, see our Delta bathroom faucet guide and Delta shower head guide.
Frequently asked questions
Does Delta Saylor shower trim include the valve?
No. Both trims list the MultiChoice universal rough valve body, R10000 series.
What is the difference between Delta 14 and 17 Series?
Delta lists 14 Series as temperature-only control and 17 Series as a volume lever plus a temperature dial.
What spacing fits the Delta Saylor widespread?
4 to 16-inch centers, per the 3535 sheet.
What drain comes with Delta Saylor bathroom faucets?
A metal push pop-up with a plated flange.
What flow rate are Delta Saylor bathroom faucets?
1.2 gpm maximum at 60 psi.
How we chose
This document-based guide makes no hands-on testing claim. We read Delta’s spec sheets for the Saylor 535, 2535, 3535, T14035 series and T17035 series. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Delta 535-MPU-DST spec sheet (media.deltafaucet.com): single-handle.
- Delta 2535-MPU-DST spec sheet (media.deltafaucet.com): centerset.
- Delta 3535-MPU-DST spec sheet (media.deltafaucet.com): widespread 4-16 in.
- Delta T14035 series spec sheet (media.deltafaucet.com): 14 Series trim.
- Delta T17035 series spec sheet (media.deltafaucet.com): 17 Series trim.
