Hole Saw Arbors and Extensions

For hole saws 1-1/4 inches and larger, the Milwaukee 49-56-7240 is a pull-back quick-change arbor with a 7/16-inch shank for 1/2-inch drill chucks and right-angle drills; it fits any hole saw with the standard 5/8-18 thread. The 49-56-7250 is the same style with a 3/8-inch shank for smaller chucks. Pull-back arbors let you swap saws without tools. An extension adds reach but not cutting depth.

Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.

Check every connection in the assembly. “Quick-change” and a familiar fractional size do not establish that all the components work together.

Check each connection in the assembly

Then check the hole saw, pilot bit and any extension against the exact instructions. A compatible shank alone does not establish that the full assembly suits the cut.

Milwaukee 49-56-7240: 7/16-inch pull-back arbor

Choose 49-56-7240 for its specified threaded hole-saw system when you have the appropriate drill. The maker lists a 7/16-inch shank (milwaukeetool.com), a minimum 1/2-inch chuck and 5/8-18 saw-thread compatibility.

Skip it for a smaller chuck, a different saw interface or a drill whose hole-cutting capacity does not cover the intended work.

The checked standard new Amazon.com offer showed stock and exact 49-56-7240 model and part fields.

The maker lists the large-saw category as 1-1/4 inches and larger. That describes arbor compatibility; it is not permission to run any diameter in any material with any drill.

Check Milwaukee 49-56-7240 arbor on Amazon →

Milwaukee 49-56-7250: 3/8-inch pull-back arbor

Choose 49-56-7250 when its 3/8-inch shank and large-thread saw connection suit the drill and cutter. The maker lists a minimum 3/8-inch chuck (milwaukeetool.com) and 5/8-18 thread.

Skip it if the saw needs another arbor system, the planned cut exceeds the drill’s capacity or the complete assembly cannot be controlled in the available space.

The checked standard new Amazon offer showed stock from Global Trade Hub LLC with 49-56-7250 in the model and part fields. Confirm the delivered attachment and pilot configuration.

The maker’s assembly sheet (milwaukeetool.com) has a page specifically labeled for this model, including its pins, collar and pilot-bit arrangement. Use the matching instructions rather than those for another arbor pictured nearby.

Check Milwaukee 49-56-7250 arbor on Amazon →

Quick-change names do not establish interchangeability

Identify the actual coupling rather than choosing by “quick-change” in the title. Different systems can use direct threads, pins, adapters and separate release mechanisms.

Milwaukee’s 2025 QUIK-LOK arbor sheet (milwaukeetool.com) describes a newer adapter-based family, including 49-56-7545 and 49-56-7555 sets. Those set numbers and supplied adapters are different from the featured pull-back arbors.

The newer sheet separates small-thread, large-thread and large-thread-with-pins adapters. Keep the required adapter and its stated size limits with the selected arbor.

Do not transfer a whole-family compatibility claim to one bare adapter or an incomplete used kit. Check what the exact new package contains and which components the saw actually requires.

Pilot bits belong to the selected cutting system

Check the required pilot-bit material, dimensions, retention and projection for the arbor and saw. A bit that enters the holder is not automatically the specified replacement.

For example, Milwaukee has a separately identified BIG HAWG carbide-teeth arbor (milwaukeetool.com). Its application and pilot arrangement should not be inferred from a generic bi-metal hole-saw listing.

Use the current model-specific assembly procedure. Verify that retaining components are sound and correctly engaged before the drill is connected to power.

A pilot bit can guide the cut, but it does not establish that there are no pipes, wires or other services behind the surface. Confirm the work area and intended path separately.

An extension adds reach, not cutting depth

A hole-saw extension moves the arbor farther from the drill. It does not increase the cutter’s cup depth or remove the need to clear a plug according to the saw instructions.

Check the extension’s input and output connection, retention method and usable reach. The collar can be wider than the shaft and may become the limiting part of a passage.

For drilling through a thick or layered assembly, plan the cutting sequence and access for removing waste. Do not assume a longer shaft makes a single continuous cut possible.

Our right-angle drill guide covers another way to address restricted access. Compare the complete working envelope rather than buying reach that leaves no room for control.

The 48-28-2020 extension needs a current detail check

The maker’s 2021 accessory catalog (milwaukeetool.com) identifies 48-28-2020 as a 12-inch, 3/8-inch QUIK-LOK extension. Its current US page (milwaukeetool.com) has inconsistent size fields and unrelated descriptive copy.

Obtain confirmed current dimensions and compatibility from the maker before ordering this model for a particular arbor. There is no extension affiliate pick here while those details remain unresolved.

Keep the shank families separate: a 3/8-inch connection is not a 7/16-inch connection. Do not assume the extension intended for one fits the other.

Also check the complete assembly’s permitted operating method. An extension’s impact rating does not independently authorize impact operation for a hole saw, pilot bit or drill.

Match the cutter and drill to the actual material

Record what you intend to cut: wood, nail-embedded wood, sheet metal, tile or another material. Then select the cutter, pilot and operating instructions for that task.

The arbor does not change a saw’s material rating. A familiar thread can join components that are still inappropriate for the intended cut.

Follow the cutter’s speed and operating requirements and the drill’s capacity limits. Do not select speed or force from the arbor’s shank size alone.

Before drilling, assess both the entry and exit side. Our stud-finder guide covers related locating tools, but no single scan should be treated as a complete guarantee that the drilling route is clear.

Control the work and stop before adjustments

The CCOHS drill guidance (ccohs.ca) calls for suitable attachments, secure work, eye protection and disconnecting power before changing or adjusting tooling. Follow the exact drill and cutter instructions too.

Confirm that the attachment is seated and retained and that it turns correctly before starting the planned operation. Do not use a bent or damaged component to gain reach.

Arrange the required handle and a stable working position. A long extension can change the access available to the operator, so check the assembly where it will actually be used.

Stop and isolate the tool before dealing with a jam, changing a component or removing a plug. Allow for a hot saw and sharp waste; do not reach around a running cutter to manage debris.

Keep a simple compatibility record

#ad Buying for a shop? Amazon Business (opens in a new tab) accounts are free to create, with business-only prices and bulk quantity discounts.

1. Drill: chuck size, permitted capacity and operating method.
2. Saw: model, diameter, material and mounting interface.
3. Arbor: complete model, shank and saw-thread or adapter system.
4. Pilot: specified replacement and retention arrangement.
5. Extension: confirmed connections, length and passage clearance.
6. Job: clear route, support, operating instructions and plug-removal plan.

Keep components labeled in the case so a small-thread adapter or pilot from another system does not get mistaken for the correct part.

Check the record when replacing one piece. A new arbor with the same nominal shank can still use a different coupling or supplied pilot, so compare the actual model and instructions before reusing the rest of the kit.

For recurring work, keep the successful approved configuration documented with the material and hole size. That gives the next person a useful starting point while preserving the need to inspect the tool and work area for the current job.

Frequently asked questions

Does a 7/16-inch arbor fit a 3/8-inch drill chuck?

The featured 49-56-7240 maker page requires a minimum 1/2-inch chuck. Check the exact arbor and drill combination.

Is shank size the same as hole-saw thread?

No. The shank connects toward the drill; the saw thread or adapter connects the cutter to the arbor.

Does an extension increase hole-saw cutting depth?

No. It adds reach. The cutter’s cup depth and permitted plug-removal method still apply.

Are all quick-change arbor systems interchangeable?

No. Match exact arbors, adapters, threads, pins and pilot bits using the current system instructions.

Does an impact-rated extension make any hole saw suitable for impact use?

No. Every component and the operating method must be permitted for the actual assembly and task.

How we chose

This document-based comparison makes no hands-on testing claim. We checked exact maker arbor descriptions, the model-specific assembly sheet, the 2025 adapter-system sheet and CCOHS drill guidance. On October 14, 2026, both linked standard new unpowered accessory offers showed stock with matching model and part identities. Confirm current delivered configuration and instructions. Read our selection method and about Plumbing Picks.

Primary sources

• Milwaukee 49-56-7240 (milwaukeetool.com): 7/16-inch pull-back arbor and required chuck/saw interface.
• Milwaukee 49-56-7250 (milwaukeetool.com): 3/8-inch pull-back arbor and separate identity.
• Milwaukee arbor assembly sheet (milwaukeetool.com): page 2 explicitly covers 7250; diagram visually checked.
• Milwaukee QUIK-LOK system sheet, 2025 (milwaukeetool.com): adapter-based system and limits; table visually checked, not transferred to olderarbors.
• Milwaukee 48-28-2020 US page (milwaukeetool.com): current inconsistent fields require maker confirmation; not an affiliate pick.
• Milwaukee accessory catalog, 2021 (milwaukeetool.com): dated extension identity/length table, not a current compatibility approval.
• Milwaukee BIG HAWG arbor (milwaukeetool.com): separate cutting-system example; no universal pilot compatibility.
• CCOHS drills, revised April 2025 (ccohs.ca): capacity, retention, support and power isolation; no US compliance claim.
