Find your pump’s rule
I start with the model on the nameplate, then check whether the discharge has a check valve. This helper cannot replace the supplied manual or an in-person inspection.
On this page
Does your sump pump need a weep hole?
A weep hole is a small hole in the discharge pipe between the pump and the check valve. It lets trapped air out of the pump so the impeller can catch water. Whether you need one depends on the pump, so start with its manual.
Sources: Zoeller FM2676, Liberty 7108000L, Wayne manual and Boshart- Liberty 230, 240 and 450 series
Liberty builds an anti-airlock hole into the volute. For extra help, it recommends a 1/8 in. hole in the pipe, and says no bigger than that. [4]
- Wayne CDU980E
Wayne says this pump needs no weep hole. Its intake is on top, a design Wayne says prevents air lock. A check valve is still required.
- High-head jobs on a Zoeller
Zoeller says a hole on a high-head install can cause too much turbulence, so you may skip it. Then the pump case and impeller must be under water before you connect the check valve.
- A pump you can’t identify
Read the nameplate, then find that model’s manual on the maker’s site. Some makers don’t want a hole, and a few use a check valve with one already molded in.
Signs your pump is air locked
Air lock happens when air gets trapped in the impeller area and can’t escape past the column of water held by the check valve. The impeller spins in air and can’t prime. Here’s how it shows up, and what each maker says to do.
Sources: Zoeller FM2676, Liberty 7108000L, Wayne manual and Boshart- Pump runs or hums, but the water doesn’t drop
Air lock, or a closed valve or clog in the line. Liberty’s fix: turn it off for several minutes, restart, and clear the anti-airlock hole. Make sure any gate or ball valve is open.
- Pump runs and moves little water
Air in the pump chamber, a clogged vent hole, or too much lift. Zoeller says to make sure the vent hole is clear, then check the strainer and discharge pipe.
- Pump will not move water after the pit ran dry
I check power and float travel if the motor will not start. If the motor runs without moving water, Liberty’s air-lock guidance is to turn it off for several minutes, then restart and clear the anti-airlock hole.
- Sputtering spray from the hole as it starts
That’s trapped air bleeding out, and it’s normal. Liberty says it can take from several seconds to more than a minute.
- Pump runs when no water is coming in
Not an air lock. Liberty points to a check valve that’s stuck open or leaking. Pull and check it, or see my sump pump check valve guide.
Zoeller names the usual cause plainly: trapped air comes from agitation or a dry basin. A pit that sits dry for weeks, then fills in a storm, is where air lock tends to bite. If your pump has quit for some other reason, my sump pump troubleshooting guide covers power, floats and switches.
Fix 1: drill the hole the right size, in the right spot
If my pump’s manual calls for a hole and there isn’t one, I start by disconnecting power and checking safe access. The size matters more than people think, and the makers don’t agree, so use your pump’s number.
Sources: Zoeller FM2676, Liberty 7108000L, Wayne manual and Boshart- 1Disconnect power safely
Cut power only from a dry, safe location. Never unplug a pump while standing in water or with wet hands. If reaching the panel means stepping in water, stay out and call the utility or an electrician.
- 2Find your spot
It has to sit between the pump and the check valve, and below the basin cover. Liberty: low, just above the threaded connection. Zoeller: level with the top of the pump.
- 3
- 4Drill straight in
Go through one wall of the PVC only. Clean off the shavings so none fall into the pump intake.
- 5Test it
Plug in, fill the pit with a bucket or hose, and watch a full cycle. You should see a stream from the hole while it runs, which Zoeller says is normal.
Some check valves thread straight into the pump with no pipe in between. Boshart says those get the hole in the valve body, above the threads and below the flapper. Boshart also sells valves with the hole molded in.
Fix 2: clear a clogged weep hole
A hole only works while it’s open. Zoeller says to check it periodically for clogging, and lists a clogged vent hole as a reason a pump runs but moves little water.
Sources: Zoeller FM2676, Liberty 7108000L, Wayne manual and Boshart- 1Disconnect power safely
Cut power from a dry, safe location before reaching into the pit. If you cannot reach the panel without standing in water, stay out and call the utility or an electrician.
- 2Look at the hole
Silt and grit can close a hole this small. If you can’t see light through it, it’s blocked.
- 3Clear it gently
Push a stiff wire or the same size drill bit through by hand. Don’t drill it larger than your maker’s size.
- 4
- 5Run a cycle
Refill the pit and watch for the spray, then the water level dropping.
Why is my weep hole spraying water?
Because it’s working. While the pump runs, the pipe is under pressure, so some water squirts out of the hole. Zoeller says a stream will be visible during pump runs, and Liberty calls a small spray normal.
Sources: Zoeller FM2676, Liberty 7108000L, Wayne manual and Boshart- A thin stream into the pit while it runs
Normal. The pipe is under pressure, and the water falls back into the pit to be pumped again.
- Air and water sputtering for the first seconds
Normal. That’s the trapped air leaving, which Liberty says can take more than a minute.
- Spray hitting the cover, the float or the cord
With power disconnected, I check the discharge assembly so the stream stays inside the pit and clear of the float. I do not loosen a sealed connection to redirect spray.
- Water spraying outside the pit
The hole may be above the cover, or the stream may be misdirected. Zoeller says it must be below the cover. Replace the affected pipe section and put the new hole at the maker’s specified location.
- A big gush that slows the pump
Often a hole drilled larger than the maker’s size. Liberty caps it at 1/8 in. Replace the affected pipe section and drill the maker’s specified size. [4]
The stream is a small leak in the pipe, so it costs a little flow. That’s the trade the makers accept for a pump that won’t air lock. It’s also why a bigger hole isn’t better: more water goes back into the pit and less leaves the house.
Parts that fix weep hole and air lock problems
Most weep hole fixes cost nothing but a drill bit. These are the parts for when the check valve is worn, or you’d rather have a pump that handles air its own way.

Product photo from Amazon.
Zoeller 30-0181 check valve
Specs: 1-1/4 or 1-1/2 in. pipe, Slip x slip unions, PVC body, 4.3 psi, 10 ft head at 130°F, Vertical or horizontal, 1-year warranty [2]
Buy it if: Your old valve slams, leaks back or is cracked, and your discharge pipe is 1-1/4 or 1-1/2 in. PVC with less than 10 ft of rise above the valve. [1] [4] [5] [6] [7]
Skip it if: Your pipe climbs more than 10 ft above the valve. Zoeller’s full-flow cast iron Unichecks are the heavier choice there. [1] [4] [5] [6] [7]
The tradeoff: The 10 ft static-head limit rules this valve out of taller discharge runs. [1] [4] [5] [6] [7]

Product photo from Amazon.
Wayne CDU980E, 3/4 HP
Specs: 3/4 HP, 1-1/2 in. NPT discharge, ON about 9 in., OFF about 4 in., 11-1/2 in. tall, 8 ft cord, 15 A circuit, 5-year warranty [1] [4] [5] [6] [7]
Buy it if: Your current pump keeps air locking, you’re replacing it anyway, and your basin is at least 11 in. across. [1] [4] [5] [6] [7]
Skip it if: Your pump is fine and just needs a hole. Drilling the right size costs nothing; a new pump is a big step for an air bubble.
The tradeoff: Replacing a pump costs more than clearing or adding the vent its manual specifies.

Product photo from Amazon.
Zoeller M53 Mighty-mate
Specs: 3/10 HP, 1-1/2 in. NPT discharge, 1/2 in. solids, Cast iron, Vortex impeller, Automatic float switch [3]
Buy it if: You want a cast iron pump with a vortex impeller, and you’re fine drilling one small hole to Zoeller’s spec.
Skip it if: You want no hole at all, or your line climbs high. Look at the Wayne CDU980E or a larger pump. [5] [6]
The tradeoff: Replacing a pump costs more than clearing or adding the vent its manual specifies.

Product photo from Amazon.
Liberty Pumps 237
Specs: 1/3 HP, 1-1/2 in. NPT discharge, Vertical magnetic float, 10 in. basin minimum, Don’t reduce below 1-1/4 in., Hand-tighten the pipe [1] [4] [5] [6] [7]
Buy it if: Your basin is narrow, you want a vertical magnetic float, and you’ll follow Liberty’s 1/8 in. rule while keeping the float clear of the wall. [4]
Skip it if: You want cast iron. Liberty’s 240 series is the cast iron version in the same manual, at 1/4 HP. [4]
The tradeoff: Replacing a pump costs more than clearing or adding the vent its manual specifies.
Product prices and availability are accurate as of the date/time indicated and are subject to change. Any price and availability information displayed on Amazon.com at the time of purchase will apply to the purchase of this product.
On a phone, each row is shown as a separate spec sheet.
| Tool | Key specs | Pick it if | Skip it if |
|---|---|---|---|
| Zoeller 30-0181 check valve | 1-1/4 or 1-1/2 in. pipe, Slip x slip unions, PVC body, 4.3 psi, 10 ft head at 130°F, Vertical or horizontal, 1-year warranty [2] [3] | Your old valve slams, leaks back or is cracked, and your discharge pipe is 1-1/4 or 1-1/2 in. PVC with less than 10 ft of rise above the valve. [2] [3] | Your pipe climbs more than 10 ft above the valve. Zoeller’s full-flow cast iron Unichecks are the heavier choice there. [2] [3] |
| Wayne CDU980E, 3/4 HP | 3/4 HP, 1-1/2 in. NPT discharge, ON about 9 in., OFF about 4 in., 11-1/2 in. tall, 8 ft cord, 15 A circuit, 5-year warranty [5] [6] | Your current pump keeps air locking, you’re replacing it anyway, and your basin is at least 11 in. across. [5] [6] | Your pump is fine and just needs a hole. Drilling the right size costs nothing; a new pump is a big step for an air bubble. |
| Zoeller M53 Mighty-mate | 3/10 HP, 1-1/2 in. NPT discharge, 1/2 in. solids, Cast iron, Vortex impeller, Automatic float switch [3] | You want a cast iron pump with a vortex impeller, and you’re fine drilling one small hole to Zoeller’s spec. | You want no hole at all, or your line climbs high. Look at the Wayne CDU980E or a larger pump. [1] [4] [5] [6] [7] |
| Liberty Pumps 237 | 1/3 HP, 1-1/2 in. NPT discharge, Vertical magnetic float, 10 in. basin minimum, Don’t reduce below 1-1/4 in., Hand-tighten the pipe [4] | Your basin is narrow, you want a vertical magnetic float, and you’ll follow Liberty’s 1/8 in. rule while keeping the float clear of the wall. [4] | You want cast iron. Liberty’s 240 series is the cast iron version in the same manual, at 1/4 HP. [4] |
The 30-0181’s 10 ft head limit
Every weep hole rule starts with the check valve. The hole goes below it, because the valve holds the column of water that traps the air. If you’re replacing a worn valve, it’s the right time to check that the hole is there, the right size and clear.
With its slip unions, Zoeller rates the 30-0181 at 4.3 psi, or 10 ft of head, at 130°F, and says to avoid more than 10 ft of static head above the valve. I measure the actual rise above the valve before choosing it, rather than assuming a basement layout is inside that limit. [2] [3]
For a taller run, Zoeller lists the solvent-weld 30-0182, rated to 25 psi and 57 ft of head at 130°F, and its cast iron Unichecks. [2]
Which part fixes which problem
On a phone, each row is shown as a separate spec sheet.
| Part | Fixes | Weep hole? | Sold by |
|---|---|---|---|
| Zoeller 30-0181 check valve | A slamming, leaking or cracked check valve | Drill below it, to your pump’s spec | Amazon.com |
| Wayne CDU980E | A pump that keeps air locking | None needed, per Wayne | Amazon.com |
| Zoeller M53 | Replacing a worn pump with a cast iron one | About 3/16 in., recommended [1] [3] | Amazon.com |
| Liberty 237 | A narrow basin, or a worn float assembly | 1/8 in. max, recommended [4] | Amazon.com |
How Wayne’s CDU980E skips the hole
Most sump pumps pull water in from the bottom, where air gets trapped. The CDU980E takes water in from the top, and Wayne says that design reduces clogging and prevents air lock, so the pump needs no weep hole. [5] [6]
Two things don’t change. Wayne’s manual says a check valve is still required, and it wants a 15 A circuit with the 8 ft cord in a GFCI outlet. [5] [6]
The product page asks for a basin 11 in. or wider; the pump is 11-1/2 in. tall on a 9-3/4 in. base. Set it on a solid, level surface, or on a brick if the pit bottom is clay, gravel or sand. [1] [4] [5] [6] [7]
Each maker’s weep hole rules, side by side
The forums give one answer. The makers give three. Here’s what each one actually printed.
Sources: Zoeller FM2676, Liberty 7108000L, Wayne manual and BoshartOn a phone, each row is shown as a separate spec sheet.
| Rule | Zoeller | Liberty | Wayne CDU980E |
|---|---|---|---|
| Hole needed? | Recommended with a check valve, even on vented pumps | Recommended, on top of the volute hole | No |
| Size | About 3/16 in. (5 mm) [1] [4] [5] [6] [7] | 1/8 in., no larger [1] [4] [5] [6] [7] | None |
| Height | Level with the top of the pump | Low, just above the threaded connection | None |
| Must be below | The check valve and the basin cover | The check valve, since it sits just above the pump | None |
| Spray while running | Visible stream, normal | Small spray, normal | None |
| Exception | High head: may skip it if the pump is primed first | None listed | Check valve still required |
| Where it says so | FM2676, caution 3 and sketch note 4 [1] [4] [5] [6] [7] | 7108000L, Anti-Airlock [1] [4] [5] [6] [7] | CDU980E page; manual 600002W-001 J [1] [4] [5] [6] [7] |
The M53’s vent, and the hole Zoeller still wants
Zoeller’s install sheet says the 53, 57 and 98 series have a vent in the pump housing, opposite the float. Zoeller still recommends an extra hole whenever there’s a check valve: about 3/16 in., or 5 mm, in the discharge pipe, below both the check valve and the basin cover. [1] [4] [5] [6] [7]
On a true high-head job, Zoeller says the hole can cause too much turbulence and you may skip it. Then the pump case and impeller must be under water before you connect the pipe to the check valve.
Weep hole myths, checked against the manuals
Sources: Zoeller FM2676, Liberty 7108000L, Wayne manual and BoshartOn a phone, each row is shown as a separate spec sheet.
| What you’ll hear | What the makers say |
|---|---|
| “Every sump pump needs a weep hole.” | No. Wayne says the CDU980E needs none, and Boshart notes some pumps use an impeller or casting design instead. [5] [6] |
| “Bigger is better, so use a 1/4 in. bit.” | Liberty caps it at 1/8 in. A bigger hole sends more water back into the pit. [4] |
| “Put it above the check valve.” | Every maker puts it below. Above the valve, the trapped air still can’t get out. |
| “The housing vent means you can skip it.” | Zoeller says its vented pumps still benefit from an additional hole. |
| “Drill it above the water line.” | No maker sets it by water level. The rules are below the check valve and, for Zoeller, below the cover. |
| “Angle it at 45 degrees.” | None of the three manuals asks for an angle. Aim the stream down into the pit. |
How the Liberty 237 bleeds air
Liberty’s manual for the 230, 240 and 450 series says each has an anti-airlock hole built into the volute. On top of that, Liberty recommends a hole no bigger than 1/8 in. in the discharge pipe, drilled low, just above the threaded connection to the pump. That’s the smallest hole any maker on this page calls for. [4]
Liberty says a small spray from the hole is normal while the pump runs, and bleeding the air can take from several seconds to more than a minute. If it air locks anyway, turn it off for several minutes, restart it and clear the anti-airlock hole. The 237’s vertical magnetic float fits a basin as small as 10 in. across. [4]
How to decide what your pit needs
Sources: Zoeller FM2676, Liberty 7108000L, Wayne manual and BoshartOn a phone, each row is shown as a separate spec sheet.
| Your situation | What to do |
|---|---|
| Your pump has no hole and has never air locked | Check the manual. If it calls for a hole, drill it to that size; otherwise leave it. |
| Your pump air locks after the pit runs dry | Clear or drill the hole to spec. If it still happens, look at a top-suction pump. |
| Water sprays out of the pit | The hole may be above the cover, or the stream may be misdirected. Replace the affected pipe section and put the new hole at the maker’s specified location. |
| You’re replacing the check valve | Drill the hole below the new valve if your pump calls for one. |
| Your check valve threads straight into the pump | Boshart says the hole goes in the valve body, below the flapper. |
| Your discharge pipe rises very high | Read your maker’s high-head note. Zoeller allows skipping the hole if the pump is primed first. |
When to call a licensed plumber
Sources: Zoeller FM2676, Liberty 7108000L, Wayne manual and Boshart- The pit is flooding and the pump won’t run
Don’t reach into a full pit with the pump plugged in. Cut the power at the breaker first, then call. Liberty and Zoeller both say to disconnect power before any service.
- The cord is cut, spliced or on an extension cord
Zoeller says not to cut the cord, to splice only inside a watertight junction box, and never to use an extension cord. Have it fixed properly.
- The pump runs but the line won’t clear
If the hole is clear and the pump still moves little water, the line may be frozen, clogged or too high. See frozen discharge lines.
- You’re adding a second pump or alarm
Zoeller says to consider a two-pump system with an alarm wherever a pump failure would cause damage. See my sump pump alarm picks.
Questions people ask
Is a sump pump weep hole necessary?
Only if your pump’s maker calls for one. Zoeller and Liberty recommend one whenever there’s a check valve. Wayne says its top-suction CDU980E needs none.
What size weep hole should a sump pump have?
Use your maker’s size. Zoeller says about 3/16 inch (5 mm). Liberty says 1/8 inch and no larger. If your manual gives no size, ask the maker before drilling.
Where should the weep hole be on a sump pump?
In the discharge pipe, between the pump and the check valve. Liberty puts it low, just above the threaded connection. Zoeller puts it level with the top of the pump and below the basin cover.
Why is my sump pump weep hole spraying water?
Because the pipe is under pressure while the pump runs. Zoeller says a visible stream is normal, and Liberty calls a small spray normal. If it sprays outside the pit, I check the hole’s height and direction with power disconnected. The stream must stay inside the pit.
Do all sump pumps have a weep hole?
No. Some have a vent built into the pump, like Zoeller’s 53 series and Liberty’s volute hole. Wayne’s CDU980E uses a top-suction design instead. Many installs also have a hole drilled in the pipe.
Should the weep hole be above or below the water line?
None of the three manuals sets it by water level. The rules are below the check valve and, for Zoeller, below the basin cover. In practice that puts it low in the pit.
What is an air lock in a sump pump?
Air trapped in the impeller area that can’t escape past the water held by the check valve. The impeller spins in air and can’t prime. Liberty’s fix is to turn the pump off for several minutes, restart it and clear the anti-airlock hole.
Why is my sump pump running but not pumping water?
Air lock is one cause. Others are a closed gate or ball valve, a clogged line, a stuck check valve or more lift than the pump can handle. Clear the weep hole, then check the line.
Can I drill a weep hole in the check valve?
Only if the valve threads straight into the pump. Boshart says then the hole goes in the valve body, above the threads and below the flapper. Boshart also sells valves with the hole molded in.
Does a weep hole reduce how much water the pump moves?
A little, since some water squirts back into the pit while it runs. That’s why Liberty caps the size at 1/8 inch. A bigger hole costs more flow without helping the air escape any better.
How I put this together
Why trust my guidance
I’m Isaac Daniels, a licensed journeyman plumber in Georgia. The rules on this page come straight from the pump makers’ printed manuals, named below, not from forum threads.
How I pick parts
- Each part answers one problem on this page: a worn check valve, or a pump that handles air its own way.
- I matched each exact model to its Amazon listing and checked new-condition availability on November 17, 2026. These are separate solutions, not a kit to buy together.
- Specs from the makers’ own documents.
- I show Amazon prices with the time they were read; check the listing for the current price.
The Amazon listing calls the Zoeller M53 1/3 HP; Zoeller’s FM0532 catalog specifies 3/10 HP. I use the maker’s figure here. The 30-0181 listing’s warranty field says no warranty; Zoeller’s product information describes a one-year limited warranty. I check coverage with Zoeller before relying on it.
