First pick: adjustable wide-angle float

Liberty Pumps 283: exact model and tradeoff
The tradeoff. Its adjustable float suits different dose settings, but those settings still come from the system design. Don’t set them by guesswork. [2]
Open the 280-Series performance curve. Use the required gallons per minute at the system’s total head. I haven’t turned the curve into an estimated flow table. [2]
- Exact model
- 283, 115 V, single phase, ½ hp [2]
- Control
- Adjustable wide-angle float with piggyback plug [2]
- Factory on / off
- 13 in. / 7 in.; adjustable. Installer must set the required dose. [10] For effluent, the installer must keep the whole pump below the water line to prevent corrosion. The factory numbers alone aren’t an effluent setup; the operating levels must also match the manual and system plan. [10]
- Cord
- 10 ft standard; these picks are the base model, not a cord-length suffix [2]
- Effluent basin
- 18 in. inside diameter and 24 in. deep; follow the system plan [10]
- Discharge / solids
- 1½ in. discharge; ¾ in. solids [2]
