Gerber Toilet Fill Valve and Flapper Replacement

Gerber makes one fill valve for all its gravity toilets. Flappers and seals follow the tank number, so find that first, run Gerber’s dye test, then buy the part it points to.

Gerber GA711048 Universal Fill Valve for Gerber toilets
Gerber GA711048 Universal Fill Valve. Product photo: Amazon.

Quick answer

For the fill valve, Gerber makes one part for all its gravity toilets: the GA711048 Universal Fill Valve. You set its height and flow restrictor for your tank number. Flappers are model-specific: Gerber’s parts list for the Viper 1.6 gpf (tank GVP38590) names flapper GA715067, and Gerber’s dual flush toilets have no separate flapper at all. Find the tank number on the back wall inside the tank, near the water line.

Replacing a Gerber fill valve? Gerber’s own universal part is the GA711048.

Check price on Amazon
Any Gerber gravity toilet fill valve
GA711048 Universal Fill Valve
Viper 1.6 gpf flapper (tank GVP38590)
Gerber GA715067
Aftermarket 3-inch flapper
Fluidmaster 5403
Gerber dual flush tank
Seal, not a flapper

As an Amazon Associate I earn from qualifying purchases. Disclosure.

On this page
  1. Gerber Toilet Parts at a Glance
  2. Step 1. Find the Tank Item Number
  3. Step 2. Test the Flapper Before You Buy
  4. Step 3. Replacing the Fill Valve
  5. Slow Fill? Check These First
  6. What to Buy
  7. When to Call a Licensed Plumber
  8. FAQ
  9. Why Trust Plumbing Picks
  10. Bottom Line

Gerber Toilet Parts at a Glance

PartWhat Gerber saysGerber part number
Fill valveOne universal valve, height-adjustable, for all Gerber gravity-fed, lever-operated toilets; includes all the flow restrictorsGA711048 Universal Fill Valve
Flapper, Viper 1.6 gpf (tank GVP38590)Listed on the Viper GVP31502-series parts listGA715067
Flush valve, Viper 1.6 gpf (tank GVP38590)Same parts list; the Viper has a 3″ flush valveGA712032
Dual flush toilets“Dual Flush (flapper is part of the flush valve)”: a canister-type valve with a gasket seal at the bottomBy tank number

The fill valve is the easy part: Gerber makes one universal valve for its gravity toilets. Flappers are model-specific. The Viper’s product page on gerber-us.com links an Illustrated Parts List that names the exact flapper, so look for the same document on your model’s page. Gerber Support also notes that not every replacement part is listed on its website. One answer on the GA711048 page confirms that the Maxwell GMX20918 ships with the GA711044 fill valve, a part the site does not list.

Step 1. Find the Tank Item Number

Gerber says the model number of a two-piece tank is “on the back wall inside the tank, near the water line,” along with the cast date and a bar code and serial number (the D & S code). On a one-piece toilet it is in the same place. The bowl has its own number under the rim, so do not mix the two up: the parts you need for a running toilet follow the tank.

If the cast number has worn off, Gerber’s Fill Valve Info page says the tank item number is also printed on the item’s specification sheet and on the product carton. Gerber Support can help you find it at 1-888-648-6466, Monday to Friday 8 a.m. to 8 p.m. ET and Saturday 9 a.m. to 6 p.m. ET.

Older Gerber 1.6 gpf tanks have numbers in this style, per Gerber:

CollectionTank numbers (12″ / insulated 12″ / 14″ / 10″ rough-in)
Aqua Saver28-790 / 28-792 / 28-794 / 28-795
Maxwell28-490 / 28-492 / 28-494 / 28-495
Viper28-590 / 28-592 / 28-594 / 28-595
Avalanche28-890 / 28-892 / 28-894 / 28-895

Step 2. Test the Flapper Before You Buy

Gerber’s test: first make sure the chain has a little slack and is hooked to the tank lever so it lifts the flapper fully. Then “pour a bit of food coloring into the toilet tank water” and check back in 15 minutes. If the bowl water has changed color, the flapper most likely needs replacing. If a new flapper does not stop it, Gerber says the whole flush valve may need replacing.

Gerber also says to look at what the flapper seals against. With the flapper off, check the flush valve’s seat for damage or warping; if the seat is damaged, a new flapper will not seal and the flush valve assembly has to be replaced. If you are not sure the flush valve is 3 inches, my 2-inch vs 3-inch flapper guide shows how to measure the opening before you buy.

Dual flush Gerber toilets do not have a separate flapper: Gerber says the flapper is part of the flush valve on its dual flush toilets. Their canister-type valve has a gasket seal at the bottom; Gerber says you unlock and twist off the top canister to reach it, and that the gasket seal, or in some cases the whole flush valve, is the replacement part.

Step 3. Replacing the Fill Valve

Gerber’s Universal Fill Valve, GA711048, is the one to buy for a Gerber gravity toilet. Gerber says it fits Viper, Avalanche, Maxwell and more, and it comes with every flow restrictor. The two settings that are specific to your tank are the valve height and the refill restrictor color. Gerber’s Fill Valve Info page on gerber-us.com takes your tank item number and gives both.

Gerber’s product page adds that the valve uses its pilot design to hold a steady water level across a wide range of incoming pressures, has an anti-siphon design and a screw-adjustable water level, and includes all parts and hardware for the swap.

  1. 1

    Shut off and drain

    Close the shutoff, flush and sponge out the tank. Gerber says to turn the shut-off valve clockwise and hold the lever down until the tank empties.

  2. 2

    Take out the old valve

    Disconnect the refill tube from the overflow tube, remove the coupling nut and the locking nut, and lift out the old valve.

  3. 3

    Set height and float

    Set the new valve’s total height and float position to the dimensions for your tank. Gerber says to loosen the lock ring, set the total height, then lock it before you place the float.

  4. 4

    Install and tighten

    Install it and tighten the locking nut; Gerber gives 5 to 8 ft-lbs (60 to 96 in-lbs). Then reinstall the coupling nut on the supply line.

  5. 5

    Restrictor and refill tube

    Fit the colored refill restrictor for your tank model and clip the refill tube so it flows directly into the overflow tube.

  6. 6

    Fill and set the level

    Turn the water on and adjust so the tank fills to the water line marked on its back wall. Gerber Support says the level is set with a small thumb screw with a Phillips slot: clockwise raises the float and the water level, counter-clockwise lowers it.

  7. 7

    Flush and check

    Press the lever for a full flush. Gerber says to check that the toilet flushes and refills without trouble and that the flapper seals when the cycle ends.

Slow Fill? Check These First

Gerber says a single flush 1.6 or 1.28 gpf tank generally fills in 30 to 60 seconds. If yours takes longer, Gerber’s list is: the supply valve fully open, the water level set to the line, the flapper sealing (“a flapper that is not meant to go with your toilet tank may cause your toilet tank to take longer to fill”), and debris in the fill valve. On some valves Gerber shows pulling a small filter out of the fill valve shaft with needle-nose pliers to clean it, for example the GA711044 used in certain Maxwell tanks.

For slow fills on any brand, my toilet fills slowly guide walks through the same checks.

What to Buy

The genuine Gerber fill valve, plus a flapper option. In my 7 years of experience, these are the products I’d install.

Gerber GA711048 Universal Fill Valve for Gerber toilets
Product photo: Amazon

Fill valve for any Gerber gravity toilet

Gerber GA711048 Universal Fill Valve

Gerber’s own part, new and in stock on Amazon as of November 11, 2026. Its listing says one valve is designed to fit all Gerber gravity-fed toilets.

Check price on Amazon
Fluidmaster 5403 universal 3-inch toilet flapper with chain
Product photo: Amazon

Flapper for a 3-inch Gerber flush valve

Fluidmaster 5403 universal 3-inch flapper

New and in stock on Amazon as of November 11, 2026. Its listing says it “fits most 3-inch flush valve toilets” and is not for 2-inch valves. The listing also gives a silicone seal, an adjustable dial for the flush, a kink-free chain and a 10-year warranty, and says it suits 1.28 to 1.6 gpf toilets.

It is not a Gerber part and Gerber does not list it, so compare it with your old flapper. I could not find the genuine GA715067 new on Amazon when I checked on November 11, 2026, so for the exact part call Gerber’s parts line at 1-888-648-6466.

Check price on Amazon

For a Gerber Dual Flush Tank

Only for the dual flush tanks Korky names.

Korky 444 Dual Flush Seal D replacement seal
Product photo: Amazon

Seal for a Gerber dual flush tank on Korky’s chart

Korky 444 Dual Flush Seal D

New and in stock on Amazon as of November 11, 2026. Korky’s listing says it fits Gerber tank models DF-29-530, DF-28-528 and DF-28-190 with flush valve model B4200. It is a Korky part, not a Gerber part.

Check price on Amazon

When to Call a Licensed Plumber

  • Gerber’s test says the flush valve itself is the leak, which means taking the tank off the bowl.
  • Both the toilet and the tub fill slowly. Gerber says that means your bathroom water system has low pressure, not a toilet problem.
  • The shutoff valve will not close.

FAQ

What fill valve does a Gerber toilet use?

Gerber makes one Universal Fill Valve, GA711048, that it says fits all Gerber gravity-fed toilets, including Viper, Avalanche and Maxwell. Set its height and refill restrictor color for your tank using Gerber’s Fill Valve Info page.

Where is the model number on a Gerber toilet tank?

On the back wall inside the tank, near the water line, per Gerber, with the cast date and a bar code and serial number. The bowl’s number is separate, under the rim.

What flapper does a Gerber Viper use?

Gerber’s parts list for the Viper 1.6 gpf GVP31502 series, tank GVP38590, lists flapper GA715067, with fill valve GA711048 and flush valve GA712032. Other Viper tanks may differ, so check your tank’s parts list.

How do I test a Gerber flapper for a leak?

Put a little food coloring in the tank and wait 15 minutes, per Gerber. If the color shows up in the bowl, the flapper most likely needs replacing. Check that the chain has slack and lifts the flapper fully before you test.

How long should a Gerber toilet take to refill?

Gerber says a single flush 1.6 or 1.28 gpf tank generally takes 30 to 60 seconds. Longer than a minute points to a partly closed supply valve, a leaking or wrong flapper, debris in the fill valve or low house pressure.

Does a Fluidmaster 5403 flapper fit a Gerber toilet?

Fluidmaster’s listing says the 5403 fits most 3-inch flush valve toilets and is not for 2-inch valves. Gerber’s parts list gives the Viper a 3″ flush valve, but the 5403 is not a Gerber part, so compare it with your old flapper first.

How do I raise the water level on a Gerber GA711048?

Turn the small Phillips thumb screw on the valve, per Gerber Support: clockwise raises the float and the water level, counter-clockwise lowers it. Set it to the water line marked on the back wall of the tank.

Why Trust Plumbing Picks

Plumbing Picks is written by me, Isaac Daniels, a licensed Georgia journeyman plumber. In my 7 years of experience, these are the products I’d install. Every part number, size and fit on this page comes from the manufacturer pages and documents listed below, which I opened and read; product details come from those makers and from the Amazon listings. Each linked product was new and in stock on Amazon when I checked on November 11, 2026.

Nobody pays to be included here. Where a link goes to Amazon I may earn a commission at no extra cost to you. More on who writes this and how I pick.

How I pick

  • Gerber’s own support articles, product pages and parts list for every part number and fit.
  • New and in stock on Amazon, with the listing matching the part number named here, checked November 11, 2026.
  • Checked against the CPSC recall list on November 11, 2026: no recalls for Gerber, Fluidmaster or Korky toilet parts.
  • Each part’s price comes from Amazon, shown with the time it was read.

My picks follow the method in How I pick: maker documents, parts availability and fit, never commission rates. Questions or corrections? Reach me through the contact page.

Sources

Bottom Line

Read the tank number, run Gerber’s food-coloring test, and buy the part it points to: the GA711048 fill valve for any Gerber gravity toilet, or the flapper named on your tank’s parts list. Dual flush tanks take a seal, not a flapper.
