Kohler toilet fill valve replacement
Match the tank and refill setup.
As an Amazon Associate I earn from qualifying purchases.
On this page
- Identify the tank before choosing a valve
- Remove the old valve without losing its settings
- Fit the replacement and restore the refill route
- Choose the kit that matches the original valve
- GP1083167
- GP1138930
- GP1068030
- GP1083167 vs GP1138930 at a glance
- Use the tank model when names overlap
- Keep these refill settings separate
- If it still runs after replacement
- Where listing wording needs a closer check
- When to stop and call a licensed plumber
- Questions about Kohler fill-valve replacement
- How we choose these parts
- Related toilet guides
Quick answer
Match the tank model and original stem: black GP1083167, gray GP1138930. Low-profile one-piece tanks (Rialto, San Raphael, Revival) take GP1068030.
Identify the tank before choosing a valve
Take a photo of the tank markings and the valve before disconnecting anything. A collection name such as Wellworth is a starting point, not a complete parts match.
GP1083167 is the black-stem Silent Fill route. Confirm the tank’s service-parts sheet before using the kit.
GP1138930 is the gray-stem Silent Fill route. The cap may be a different color.
Use the tank number and its parts diagram. An aftermarket valve’s color cannot establish the original Kohler part.
Check the one-piece model and access instructions first. Do not assume either adjustable kit fits merely because it enters through the tank bottom.
The stem is the long body and shank below the valve head. The cap is the cover on top. Kohler’s common service-parts brochure identifies the all-black and all-gray stems separately and explicitly sets cap color aside. Photograph both areas so you can compare the right feature.
If the visible valve is already a Korky or Fluidmaster, its color tells you about that installed part. It does not recover the original Kohler specification. Read the toilet number imprinted on the inside back of the tank, then match its service diagram instead of copying the replacement’s appearance.
Keep the full model marking, including letters after the number. Kohler explains that suffixes can identify a series or variation. A receipt’s collection name alone leaves out that distinction. The model lookup matters most when several toilets share a collection name but have different tank arrangements.
- 1Read the inside back of the tank
Lift the lid carefully and set it on a secure surface. Read the toilet number imprinted on the inside back of the tank. Photograph the full marking, including any suffix; the number under the lid may identify the lid instead.
- 2Find the matching parts diagram
On Kohler’s website, open Support, then Find a service part. Search the full toilet model, then open its parts diagram under Installation and Service Parts on the product page, or below the search-result image. The Kohler toilet service-parts catalog also indexes toilet model numbers. Match the fill-valve drawing and part number, not just the collection name.
- 3Confirm one of these two kits
This guide recommends only GP1083167 and GP1138930 after the model and original stem agree. If the diagram calls for another assembly or a revision is unclear, confirm it with Kohler before choosing a kit.
Remove the old valve without losing its settings
These steps follow Kohler service instructions 1083168-9-G for the adjustable kits. Keep the old valve and refill parts beside the new one until you have compared them.
- 1Confirm the water is off
Close the toilet’s water supply, then flush and drain the tank. If the stop fails to isolate the supply, leave the connection intact and call a licensed plumber. Put a container beneath the supply connection for retained water.
- 2Photograph the refill arrangement
Record the valve height, hose route and restrictor type and color. Kohler tells you to retain the refill hose and other parts during the swap. This photo is especially useful when the hose connects to a canister port.
- 3Disconnect at the tank
Remove the supply hose without bending or kinking it. Unclip the refill hose from the flush valve, remove the retaining nut and lift out the old fill valve. Keep the supply connection supported rather than pulling sideways on it.
- 4Clean the seating area
Clean around the fill-valve opening. Compare the old restrictor with the new kit’s choices before discarding the valve. If porcelain is cracked or the opening is damaged, stop the repair and have a licensed plumber assess it.
Do not loosen the fill-valve nut while the supply is pressurized. Kohler begins the procedure with the water off and the tank drained; a towel cannot replace a working shutoff.
Fit the replacement and restore the refill route
Before reconnecting: do not use a rigid supply with a cone fitting. Kohler prohibits this connection. Rigid-supply hardware replacement is outside these steps; leave the water off and have a licensed plumber handle that installation.
- 1Set valve height
Match the old valve’s length with the threaded shank adjustment. Keep the old assembly beside the replacement so you can compare its height and arm position before discarding it.
- 2Check the arm position
If needed, reposition the arm relative to the refill port to match the old valve. With the water off, lift the arm and turn the cap counterclockwise to remove it. Reposition the arm, then lift it while turning the cap clockwise to secure it, as Kohler directs.
- 3Match the restrictor and attach the hose
Use the new restrictor that matches the old color, as Kohler directs. If the old restrictor is absent or unidentified, confirm the model’s setup instead of guessing. Attach the refill hose to the fill valve; snap the tabs into place where fitted, or secure the hose as the kit directs.
- 4Seat and secure the valve
Put the rubber washer on the valve bottom if it is not already fitted. Insert the valve through the tank opening, allow clearance around moving parts and hand-tighten the retaining nut. Follow the current sheet supplied with your kit.
- 5Reconnect the refill hose
If the old valve had a refill hose, clip the new hose inside the overflow tube so water flows into it. If it had none, clip the new hose outside the overflow so water flows into the tank. For a canister connection, follow the model’s port instructions; never submerge a loose hose end.
- 6Reconnect a flexible supply and check
For a flexible supply, hand-tighten the supply connection at the tank without overtightening. Follow the connector’s own directions at the stop. Turn on the water, inspect the connections and adjust tank water level with the valve’s threaded rod. Shut the supply off again if a connection leaks.
A successful refill has two destinations: the tank and the bowl. Look inside the tank during a flush rather than judging the repair only by the sound. A hose that came loose during the swap can leave the refill path different even when the valve itself shuts off.
Never reconnect a rigid supply with a cone fitting. Kohler requires different sealing hardware for its rigid-supply arrangement. Have a licensed plumber handle that connection rather than forcing it to fit or applying the flexible-supply steps to it.
When the tank has refilled, dry the underside around the shank and supply nut so a new drop is easy to see. Observe a flush and refill, then check again after the toilet sits. A dry floor immediately after tightening does not show whether the tank is losing water internally.
Choose the kit that matches the original valve
These are separate fit routes. A black-stem kit does not become the right part for a gray-stem tank because its listing mentions the same collection.


Kohler GP1138930

Kohler GP1068030
Product prices and availability are accurate as of the date/time indicated and are subject to change. Any price and availability information displayed on Amazon.com at the time of purchase will apply to the purchase of this product.
| Valve | Key specs | Pick it if | Skip it if |
|---|---|---|---|
| Kohler GP1083167 | GP1083167, Original black stem, Cap color does not decide fit, Retain the refill setting | Your tank’s parts information and original black stem identify this kit. | The tank specifies a different valve, the current part is unidentified, or a low-profile assembly has not been checked. |
| Kohler GP1138930 | GP1138930, Original gray stem, Cap color does not decide fit, Retain the refill setting | Your tank’s parts information and original gray stem identify this kit. | The tank specifies a different valve, the current part is unidentified, or a low-profile assembly has not been checked. |
| Kohler GP1068030 | GP1068030, Low-profile one-piece, Rialto, San Raphael, Revival, Plastic shank | Your Kohler one-piece tank is a Rialto, San Raphael or Revival, or its parts page names GP1068030 or 1068030, and the supply connection matches. | Your tank uses a gray- or black-stem Silent Fill valve, or its parts page names 1068033 or another valve. |
Kohler GP1083167 for a black stem
Two Silent Fill kits and a one-piece valve: the tank and the original valve decide, so none of the three is scored. All three were new and in stock on Oct 22, 2026, 12:13 PM EDT.
The GP1083167 is Kohler’s Silent Fill route for an original all-black stem. Its Amazon title emphasizes Class Five toilets, but the stem identification in Kohler’s common service-parts brochure is the clearer check when you are standing over an open tank. Cap color is not the deciding feature.
Start with the tank’s model number and its service-parts diagram. Then compare the original valve. A toilet may already contain an aftermarket replacement, so a black plastic part by itself is not enough to establish that GP1083167 was the specified original. A photo of the current assembly helps you separate those questions.
The package title includes dimensions, but those numbers are not a model-specific height setting. Kohler’s service instructions tell you to match the replacement’s length to the old valve with the threaded shank adjustment. Keep the removed assembly until the new valve is seated and its moving parts clear the tank.
Where it does well
- Identified by Kohler for the black-stem route
- Adjustable length in Kohler’s shared service procedure
- Single genuine kit, new in the latest offer read
What to watch
- Tank model still needs confirmation
- Prior aftermarket valve color cannot identify the original
- Unknown restrictor setting needs a model check
The restrictor deserves its own check before installation. Kohler tells you to record the old type and color and install the matching new restrictor. Do not choose by the cap color or assume the fastest-looking refill is the correct setup. An unknown insert is a reason to check the tank’s instructions.
Buy the single genuine kit, not a listing that only repeats the number. It was new and in stock when checked on Amazon on October 22. Check the offer and condition again on Amazon, since one product page can also carry a used offer.
The important limit is the one-piece exception. Kohler’s service-parts brochure treats low-profile one-piece valves separately, and lists GP1068030 for them. A familiar brand name on the tank does not erase that difference. If the tank is unusually shallow, resolve its model and valve drawing before treating GP1083167 as a substitute.
My call: choose GP1083167 when the tank’s documentation and original black stem agree. Keep the old restrictor visible until setup is complete. If either the model or the existing valve’s identity is uncertain, settle that question before opening the kit.
Kohler GP1138930 for a gray stem
The GP1138930 is the Silent Fill kit identified for an original gray stem in Kohler’s common service-parts brochure. Kohler also calls it a 400A Series fill-valve service kit on its current product page. That wording names the service-kit family; it does not establish that every generic 400A listing is the same kit.
This is the alternative to GP1083167 when the original stem is gray. You do not need the cap to be gray as well. That distinction keeps you from treating a different cap color as evidence of a different fit. Identify the stem and tank rather than matching the cover.
Use the tank number to check the service diagram before buying. Collection names on product pages can be broad, and an earlier repair may have changed the valve. If a Fluidmaster or Korky is already installed, treat its color as a feature of that part, then work back from the Kohler tank identification.
Where it does well
- Identified by Kohler for the gray-stem route
- Adjustable length in Kohler’s shared service procedure
- Single genuine kit, new in the latest offer read
What to watch
- Tank model still needs confirmation
- Prior aftermarket valve color cannot identify the original
- Unknown restrictor setting needs a model check
Kohler’s shared replacement sheet covers the refill hose and restrictor as part of the job. Keep the old arrangement intact long enough to record it. For the new valve, match the restrictor as directed and restore the hose connection. A valve that fills the tank can still leave an incorrect bowl-refill setup.
Do not turn a low bowl-water level into a reason to keep raising the tank level. First check whether the refill hose returned to its intended location. Kohler’s hose-position guidance also warns that a submerged hose end can siphon water out of the tank and make the valve restart later.
The selected single kit was new and in stock when checked on Amazon on October 22. Select the named GP1138930 kit rather than a listing that merely repeats the number after the words replacement for Kohler.
My call: use GP1138930 for a tank confirmed to need the gray-stem kit. Before calling the replacement faulty, check the hose position and whether water is escaping through the flush seal. Those checks separate an inlet problem from water leaving the tank after filling.
Kohler GP1068030 for a one-piece tank
The GP1068030 is Kohler’s fill valve for low-profile one-piece toilets, the tanks the two Silent Fill kits don’t cover. Kohler’s page says it’s designed for Rialto, San Raphael and Revival one-piece toilets, and its common service-parts brochure lists it apart from the gray-stem and black-stem kits.
Check the supply connection before you order. Kohler’s 2015 toilet service-parts catalog lists GP1068030 for a rigid connection and 1068033 for a flex connection on its one-piece toilets. The Amazon listing says “with flex connections”. When the two disagree, go by the catalog line for your tank and look at what feeds the valve now.
The GP in the number marks the retail blister pack. Kohler’s catalog says a GP part is the same part as the number without it, so 1068030 on an older parts list points to this valve.
Where it does well
- Kohler names Rialto, San Raphael and Revival
- Genuine low-profile one-piece valve
- GP1068030 and 1068030 are the same part
What to watch
- Not a substitute for the Silent Fill stem kits
- Catalog and listing disagree on rigid vs flex
- No length or flow figures on the listing
Model first, as with the other kits. Read the model number inside the tank, find its service-parts page, and confirm GP1068030 is the valve shown before you shut off the water. A low-profile tank needs the low-profile valve, which is why Kohler lists this one on its own.
Record the old setup while it’s still in place: the water level, how the refill tube reaches the overflow, and any clip that holds it. Keep the old valve until the new one fills, shuts off at the right level and sends refill water down the overflow.
The listing names a plastic shank and the three collections, and gives no length or flow figures. There’s nothing to set from a chart, so match what you removed.
My call: I’ve used the GP1068030, and on a Rialto, San Raphael or Revival tank whose parts list shows it, with the connection type checked, it’s the genuine one-piece swap.
GP1083167 vs GP1138930 at a glance
| Kit | Use label | Maker identification | Useful feature | Limit | Buy link |
|---|---|---|---|---|---|
GP1083167 | Original black stem | All-black stem; cap color ignored | Adjustable replacement length | Confirm tank and restrictor | Check it on Amazon |
GP1138930 | Original gray stem | All-gray stem; cap color ignored | Shared Kohler replacement procedure | Not identified by cap or collection alone | Check it on Amazon |
GP1068030 | Low-profile one-piece tank | Low-profile one-piece valve in Kohler’s brochure | Named for Rialto, San Raphael and Revival | Check rigid vs flex connection | Check it on Amazon |
Use the tank model when names overlap
| What you can identify | What it establishes | Next check |
|---|---|---|
| Kohler tank number and suffix | The model to look up | Find the corresponding service-parts diagram |
| Original all-black Silent Fill stem | GP1083167 route in Kohler’s brochure | Confirm the diagram and old refill arrangement |
| Original all-gray Silent Fill stem | GP1138930 route in Kohler’s brochure | Confirm the diagram and old refill arrangement |
| Only a collection name | A family, not the whole configuration | Record the actual tank marking |
| Low-profile one-piece tank | Separate valve family in Kohler’s brochure | Check GP1068030 against the tank’s parts page |
| Korky or Fluidmaster already installed | The brand of a prior replacement | Identify the Kohler tank independently |
The model-first route also avoids confusing the fill valve with the flush valve. The inlet assembly brings water into the tank. The center flapper or canister controls water leaving it during a flush. A parts diagram may name both assemblies beside each other; compare the pictured location before copying a number.
For a concealed or skirted model, check how the maker expects you to reach the supply connection and retaining nut before starting. If those connections are inaccessible, do not assume that pulling on the valve from inside will release it. Arrange safe access with a licensed plumber rather than forcing the porcelain or fittings.
Keep these refill settings separate
| Setting | What you are changing | What to record before removal |
|---|---|---|
| Valve length | The installed assembly’s height | Old valve length and clearance |
| Tank shutoff level | Where the float stops incoming water | Tank’s specified water level |
| Flow restrictor | The matched insert in the refill arrangement | Original type and color |
| Refill-hose position | Where the hose discharges | Clip or canister-port connection |
Matching the old height is the starting instruction in Kohler’s kit sheet, not proof that every old adjustment was correct. If the toilet already overflowed before the repair, finish by setting the tank level to its specified mark. Copy the physical fit, then verify the water level separately.
Photograph the hose before removal. Kohler’s kit sheet routes the new hose inside the overflow when the original had a hose, and outside into the tank when it did not. For a canister, Kohler’s hose-position guidance restores its top-port connection. Keep a loose hose end out of the tank water.
If a prior valve is missing its restrictor, there is no reliable old color to match. Do not turn that missing information into a universal color recommendation. Use the tank’s service information or ask Kohler to identify the correct setup from the model and photos. A parts number alone does not reveal the previous adjustment.
If it still runs after replacement
| What you see | Check next | Why a second fill valve may not help |
|---|---|---|
| Water keeps entering the overflow | Tank level and valve shutoff | The level may still be adjusted too high |
| Tank fills, then valve restarts later | Flapper or canister seal and hose position | Water can leave the tank between flushes |
| Bowl level differs after the swap | Refill hose connection | Tank refill and bowl refill have separate paths |
| Water appears under the tank | Supply coupling and fill-valve mounting seal | An external leak needs isolation and inspection |
| Flow remains slow or valve will not stop | Debris and model-specific cleaning directions | Sediment can interfere with the valve |
Kohler separates constant running from occasional refilling. That is a useful observation to make before buying another part. Watch a complete refill: does water keep entering the overflow, or does the tank stop filling and lose water later? The sound alone cannot tell you which assembly needs attention.
When water escapes past a flapper or canister seal, the fill valve may simply be replacing it. Check for a chain that prevents the seal from closing and inspect the correct flush-seal type. The Kohler canister seal guide explains that separate assembly.
For slow or constant filling, Kohler’s support article directs readers to cleaning before replacement where debris is involved. Use the cleaning procedure for the identified valve; low-profile and two-piece assemblies have separate demonstrations. Shut the water off before disassembly and do not remove an unfamiliar cap while the line is pressurized.
Where listing wording needs a closer check
| Listing wording | Maker instruction | How to use it |
|---|---|---|
| GP1083167 title: for all Kohler Class Five toilets | Common service-parts brochure separates black and gray stems | Use the tank diagram and original stem, not all by itself |
| GP1083167 title: 12.5 × 3.5 × 3 inches | Kit sheet says to match old valve length | Do not treat the listing dimensions as an installed height |
| GP1138930: multiple fill-rate inserts | Kit sheet says match the old restrictor color | Do not choose a color solely to increase speed |
| GP1068030: “with flex connections” | Kohler’s 2015 catalog: GP1068030 rigid, 1068033 flex | Check the supply connection and the tank’s parts page |
Use the tank’s parts diagram to select the kit and the installation sheet to set its height and restrictor. Listing dimensions do not replace those checks.
When to stop and call a licensed plumber
Follow the matching kit sheet with the water off, the tank drained and the old settings recorded.
Resolve identification before changing the restrictor or fitting an assumed equivalent.
Keep the supply connection and retaining nut intact. A licensed plumber needs to establish isolation before removal.
Shut off the water if you can do so safely and stop using the toilet until the damage or leak is assessed.
Questions about Kohler fill-valve replacement
What is the difference between GP1083167 and GP1138930?
Kohler’s common service-parts brochure identifies GP1083167 for an all-black stem and GP1138930 for an all-gray stem. It says cap color does not matter. Confirm the tank model, especially when the installed valve has already been replaced.
Can I use any fill valve in a Kohler toilet?
Do not assume that a universal label covers every Kohler tank. The maker lists low-profile one-piece assemblies separately from the two Silent Fill stem routes. Check the tank model, the parts diagram and the replacement maker’s stated fit.
How do I identify my Kohler toilet fill valve?
Read the toilet number imprinted on the inside back of the tank. In Kohler’s Support section, choose Find a service part, search the full model and open its parts diagram. Keep the suffix even if the K prefix is absent; photograph the stem, refill connection and restrictor too.
Which restrictor color should I use?
Kohler’s kit sheet tells you to install the new restrictor that matches the old one. Record the old type and color before removal. If the old piece is missing or the existing valve is aftermarket, confirm the model-specific setup instead of guessing.
Why does my Kohler toilet still run after replacing the fill valve?
Watch whether it runs constantly into the overflow or restarts after the tank has filled. Kohler identifies different checks for those symptoms, including tank level, debris, a worn flush seal and hose position. Replacing the inlet again does not repair a leaking canister seal.
Can a refill hose make the toilet run by itself?
Yes. Kohler explains that a hose end below the tank waterline can siphon water into the bowl. Restore the correct overflow clip or canister-port connection for your model. Do not leave a loose hose end submerged.
Do I need to remove the tank to replace the valve?
The adjustable-kit sheet removes the supply connection and retaining nut, then lifts the valve through the tank opening. It does not establish access for every concealed model. If you cannot reach the connections safely, use the toilet’s own access instructions and call a licensed plumber when needed.
How tight should the new fill valve be?
Kohler’s shared kit sheet specifies hand-tightening the valve’s retaining nut and the supply coupling at the tank, with no overtightening. Follow the connector instructions at the stop. If it leaks after correct assembly, shut the water off and inspect the seal and fit.
How we choose these parts
Why trust this guide
Isaac Daniels is a licensed journeyman plumber in Georgia. We read Kohler’s service instructions, parts brochure and troubleshooting guidance to separate inlet-valve fit from flush-seal and hose problems.
How we pick
We match the maker’s part identification to the named kit, then check the Amazon offer’s brand, New condition and stock status. We re-read the three single-kit offers on Amazon on Oct 22, 2026, 12:13 PM EDT: all three were new and in stock.
These are fit recommendations drawn from documents. We assign no performance score, measured refill time or noise figure. The old valve’s color is useful only after its identity and the tank model are understood.
On Oct 22, 2026, 12:13 PM EDT, CPSC’s seven Kohler recalls covered generators, engines, transfer switches and shower or bath doors; none named a fill valve.
| Check | Rule used here |
|---|---|
| Fit | Tank model and original stem before a kit recommendation |
| Refill setup | Record restrictor and hose arrangement before removal |
| Offer | Named genuine kit, new and in stock in the October 22 API read |
| Score | None; unlike-for-like fit parts are not ranked for measured performance |
Sources
- Kohler, Service Kit Instructions 1083168-9-G, ©2023, pages 1–4. techcomm.kohler.com/techcomm/pdf/1083168-9.pdf. Read October 20, 2026.
- Kohler, Common Service Parts brochure JOB019705-02, toilet fill-valve panel. resources.kohler.com/webassets/kpna/brochures/JOB019705-02_Common_Service_Parts_Brochure.pdf. Read October 20, 2026.
- Kohler Assist: Toilet Constantly Leaking or Running; Toilet Occasionally Leaking or Running; Tank Leak: Fill Valve Hose Position. assist.kohler.com, read October 20, 2026.
- Kohler Assist: Finding a KOHLER or STERLING Product Model Number or Serial Number. assist.kohler.com, read October 20, 2026.
- Kohler, Toilet Service Parts catalog, model-identification panel and model index. resources.kohler.com/onlinecatalog/pdf/toiletserviceparts.pdf. Read October 20, 2026.
- Kohler, Find a Service Part, How to Find a Service Part steps 1–2. kohler.com/en/support/find-a-service-part. Read October 20, 2026.
- Kohler product identification pages for K-GP1083167 and K-GP1138930. kohler.com, read October 20, 2026.
- Kohler, K-GP1068030 Fill Valve For One-Piece Toilets product page (Rialto, San Raphael and Revival), kohler.com; and Toilets Service Parts, March 2015, one-piece toilet panels (GP1068030 rigid, 1068033 flex; GP prefix note), resources.kohler.com. Read Oct 22, 2026, 12:13 PM EDT.
- Amazon offers, Oct 22, 2026, 12:13 PM EDT: the GP1083167, GP1138930 and GP1068030 kits; all new and in stock. No Amazon rating or hand-entered price used.
- CPSC recall search (saferproducts.gov), Oct 22, 2026, 12:13 PM EDT: Kohler 7 (generators, engines, transfer switches, shower and bath doors), none for fill valves.
