Updated November 15, 2026

Pentair’s examples: VT-11-01 (9×48), 1.0 ft³; VT-17-01 (10×54), 1.5 ft³; VT-23-01 (12×52), 2.0 ft³. Your manual sets the fill and grade. On chlorinated city water, ResinTech CNS10 is the grade to ask your softener’s maker about.
Start with the resin or media tank, not the salt tank. A 10×54 label describes nominal vessel dimensions. It does not tell you which resin grade, distributor or support bed the assembled softener uses. Look for a second label that identifies the complete system.
A Fleck 5600SXT valve label alone does not identify a Pentair VT-17-01 system. Assemblers can use the same valve on different equipment. If your paperwork gives a different charge for a 10×54 tank, resolve that difference with the system maker before opening the bags.
All three are shown for comparison only; none is linked. None of them automatically replaces your softener’s original media, so match the grade to its manual first. Aldex lists C-800 for professional use, with gloves and eye protection, and recommends chlorine below 1.0 ppm.
Shown for comparison only.
Shown for comparison only.
Shown for comparison only.
Product prices and availability are accurate as of the date/time indicated and are subject to change. Any price and availability information displayed on Amazon.com at the time of purchase will apply to the purchase of this product.
Shown for comparison only.
ResinTech CNS10 is a sodium-form softening resin with 10% crosslinking, sold here as a 1.0 cubic foot bag. ResinTech, in Camden, New Jersey, calls it a highly crosslinked gel strong acid cation resin. The bag in the listing photo is printed CNS10.
The crosslinking is the reason to pick it. ResinTech says CNS10 is particularly resistant to oxidation by chlorine or chloramines and lists it as chlorine tolerant. Aldex’s bulletin explains why that matters: every cation resin is attacked by chlorine and degrades and swells over time.
Its sheet lists 2.10 meq/mL total capacity, a little more than the 1.9 that Purolite and Aldex publish for C100E and C-800. That’s total capacity, not the grains your softener gives per regeneration. Your salt setting and controller decide that.
Beads run 16 to 50 US mesh (297 to 1190 µm) with a 1.60 uniformity coefficient. ResinTech asks for a 24-inch minimum bed depth and 25 to 50% backwash expansion. Those are the numbers to hold against your tank, distributor and drain-line flow control.
The sheet says CNS10 meets NSF/ANSI/CAN 44, 61 and 372. Aldex’s C-800 bulletin goes further and says tested and certified by the WQA. If your inspector wants a listing number, ask the seller for ResinTech’s certificate before you order.
For salt, ResinTech gives 4 to 15 lb per cubic foot at a 10 to 15% brine. It doesn’t publish grains at each salt dose the way Aldex does, so set the controller from your softener’s manual, not from the bag.
Shown for comparison only.
Purolite C100E is a sodium-form cation resin intended for potable-water softening. The listing here specifies a one-cubic-foot bag. That makes the order arithmetic straightforward when your approved charge is 1.0 or 2.0 cubic feet. A 1.5-cubic-foot refill needs two bags, with half a cubic foot left over.
The useful fit check is the full grade name: C100E. Purolite lists beads from 300 to 1200 micrometers for this grade. Its C100EFM is a different product with smaller beads. Do not let a similar name or a softening claim substitute for a check of the required grade.
Purolite offers C100E in both one-cubic-foot and 25-liter sacks. Those packages contain different volumes. If you change to a 25-liter offer, change the bag size in the calculator as well. The photograph and product name are not enough to establish the volume of a different listing.
For a partial refill, measure volume by the system maker’s loading procedure. Purolite gives an approximate shipping weight of 50.0 to 52.5 pounds per cubic foot. That range is useful for planning how to handle a bag. It is not a precise conversion for weighing out half a charge.
The backwash guidance also matters. C100E needs expansion space above its settled bed, and Purolite warns that excessive expansion can send resin out of the vessel. Keep the correct drain-flow control and startup procedure for your approved system. Pouring in the unused half-bag removes space the system may need.
Choose this bag when C100E is the confirmed replacement, then order by the required volume. The Pentair examples establish charge quantities only. Their performance sheet names another original resin, so a matching bag count does not establish that C100E preserves those systems’ certified performance.
Aldex C-800 is for professional use only. Wear protective gloves, protective clothing, eye and face protection when handling it.
Shown for comparison only.
Aldex C-800 is another sodium-form softening resin, sold here in a one-cubic-foot listing. Its maker describes black beads and one-cubic-foot packaging. Use the C-800 grade name when you ask the system maker about a replacement. Aldex also sells similarly named grades that should not be treated as the same material.
Aldex’s published particle range is 16 to 50 mesh. Its operating guidance calls for a minimum bed depth of 24 inches and a normal depth of 36 inches. Those figures are checks for a system designer or service professional. They do not authorize you to increase the charge in an existing tank.
The capacity information is unusually useful because Aldex states the salt dose with it. Its examples give 20,000 grains at six pounds of sodium chloride per cubic foot, and 30,000 grains at fifteen pounds. Those are different operating points for the same volume of resin, rather than instructions to change the fill.
This is why a 30,000-grain resin description cannot tell you how many bags your tank needs. Confirm the resin volume in the softener’s manual first. Set the controller from the approved system instructions afterward. Copying the largest capacity number into the controller can leave the regeneration schedule out of step with the actual setup.
Aldex lists a shipping weight of 50 pounds per cubic foot for C-800. Plan for that load before you start the job, and use the loading method specified for your softener. Do not use Purolite’s shipping-weight range to portion this product, or assume two grades with similar weights have identical hydraulic requirements.
Keep C-800 on the shortlist for professional use when that exact grade is specified. Aldex recommends chlorine below 1.0 ppm; ask the maker to confirm suitability at or above that level. Confirm the one-cubic-foot pack before ordering. A matching volume alone does not approve substitution for another sodium-form resin.
| Resin and offer | Spec score | Maker specification | Useful fit | Limit before purchase |
|---|---|---|---|---|
| ResinTech CNS10 Reference (not linked) | , | 16–50 mesh; 10% crosslinked; 2.10 meq/mL; 1 ft³ offer | Chlorinated or chloramine city water | System approval required |
| Purolite C100E Reference (not linked) | , | 300–1200 µm; sodium form; 1 ft³ offer | An approved C100E charge | System approval required; not C100EFM |
| Aldex C-800 Reference (not linked) | , | 16–50 mesh; sodium form; 1 ft³ offer | A specified C-800 charge for professional use only | Protective gloves, protective clothing, eye and face protection required. Chlorine below 1.0 ppm recommended; confirm suitability with the maker at or above that level. Not C-800x10. |
The C-800 listing calls it “8% Crosslinked” and the CNS10 listing says 10%. ResinTech’s own sheet calls CNS10 highly crosslinked. A percentage alone doesn’t make a resin fit your system; match the grade and its limits to your manual.
| Pentair system / item | Tank | Install resin | Equivalent liters | Buy 1 ft³ bags | Unused resin |
|---|---|---|---|---|---|
| VT-11-01 / 4005289 | 9×48 | 1.0 ft³ | 28.32 L | 1 | 0 |
| VT-17-01 / 4005290 | 10×54 | 1.5 ft³ | 42.48 L | 2 | 0.5 ft³ |
| VT-23-01 / 4005291 | 12×52 | 2.0 ft³ | 56.63 L | 2 | 0 |
For a documented 1.5 ft³ charge, buying two one-cubic-foot bags supplies enough resin. It does not mean the tank should receive two cubic feet. Install the specified 1.5 and keep the unused 0.5 out of the vessel. An extra purchase unit is a packaging consequence, not an installation allowance.
The liters above use 28.316846592 liters per cubic foot, with the displayed result rounded to two decimals. Use the original specified charge when you measure the refill. Rounded display values help compare packages; they do not replace the maker’s loading procedure.
| Required charge | Buy 25 L bags | Purchased volume | Unused volume |
|---|---|---|---|
| 1.0 ft³ | 2 | 50 L | 21.68 L |
| 1.5 ft³ | 2 | 50 L | 7.52 L |
| 2.0 ft³ | 3 | 75 L | 18.37 L |
Round up the purchase quantity, never the installed charge. These examples compare packaging volumes; they do not approve either replacement resin for a Pentair system.
Enter a charge already specified by your system maker. Tank dimensions alone cannot set this number. This calculator compares package volumes; it does not approve a replacement grade.
Install the specified 1.5 ft³ (42.48 L). Buy 2 bags of 1 ft³. Keep the unused 0.5 ft³ (14.16 L) out of the tank.
One cubic foot = 28.316846592 liters. Converted quantities and leftovers display two decimals; the specified charge is preserved. Calculations use the full conversion. Do not round the installed charge up to a whole bag.
Choose a documented Pentair example only if its complete model matches your equipment. Otherwise select “My manual gives another charge” and enter that volume. The calculator converts a known charge into a purchase quantity. It cannot determine a charge from tank dimensions or a household’s water use.
Check the package volume on the current offer before using its bag count. A sack marked 25 liters is smaller than one marked one cubic foot. For a hypothetical half-cubic-foot package, enter 0.5 ft³ as the package size. The number to install stays tied to your manual.
Record the softener maker and model, such as VT-17-01. Photograph the resin tank label and valve label separately. A 5600SXT valve can appear on more than one assembled system.
Look for resin grade, charge volume and any support-gravel requirement. If these are absent, ask the system maker using the model and serial number. Do not infer the charge from the brine tank.
Compare the vessel label and the maker’s drawing. Include the base style when you compare measured heights. Avoid treating the valve and bypass height as part of the nominal tank size.
| Structural nominal tank | Overall height, standard base | Overall height, extended base |
|---|---|---|
| 9×48 | 48.3 in. | 54.0 in. |
| 10×54 | 54.3 in. | 59.8 in. |
Pentair’s Structural sheet shows why a tape measurement can be misleading. The same nominal 9×48 vessel has different overall heights with standard and extended bases. A measurement near 54 inches does not, by itself, establish that the resin tank is a nominal 10×54.
The Structural sheet used here does not contain a 12×52 row. There is no sound reason to interpolate its capacity from 12×48 and 13×54. A label that says 12×52 needs its own vessel documentation, plus the complete softener specification for the resin charge.
The vessel’s internal capacity includes space that the softener needs above the settled resin bed. During backwash, water lifts and expands that bed. The distributor and any specified support media also occupy space. This is why a vessel-capacity number is not a resin-order quantity.
Clack lists a 9×48 mineral vessel at 1.54 ft³, a 10×54 at 2.14 ft³ and a 12×52 at 3.1 ft³. Those are capacities of Clack vessels. They cannot replace the complete-system resin charge, and they do not establish that a particular Pentair system uses a Clack vessel.
| Number on the paperwork | What it describes | Can it set the resin fill? |
|---|---|---|
| 1.5 ft³ resin charge | Media volume specified for a particular system | Yes, when it is your complete system |
| 2.14 ft³ vessel capacity | Internal capacity of Clack’s 10×54 vessel | No; it includes space other than the settled resin |
| 50–70% bed expansion | Purolite C100E backwash guidance | No; this percentage is relative to the resin bed |
Purolite’s C100E guidance describes expansion of 50 to 70 percent of the settled bed volume. It does not say to leave 50 to 70 percent of every tank empty. Backwash performance depends on the water flow and temperature. Use the hydraulic setup approved for the complete softener.
For example, a hypothetical one-cubic-foot bed expanded by 50 percent occupies 1.5 cubic feet. That arithmetic explains the need for headroom. It is not a loading design: tank shape, internals and the actual backwash conditions still need to be checked by the maker or a treatment professional.
| Calculation | Correct relationship | Limit |
|---|---|---|
| Cylinder volume | π × (diameter ÷ 2)² × height | Requires internal dimensions in consistent units |
| Cubic inches to cubic feet | Divide by 1,728 | Conversion only; does not choose a media charge |
| Bag count | Round required volume ÷ bag volume upward | Round the purchase units, not the installed volume |
A cylinder formula uses radius squared. If you square the full diameter instead, the result is four times too large. Dividing by four corrects that particular geometry error, but it does not make an external tank measurement into an approved resin charge.
A softener vessel also has domed ends rather than the flat ends of a simple cylinder. An outside diameter includes the vessel wall. The distributor and base geometry add further differences. Use dimensional arithmetic to check a calculation, then return to the system’s documented charge for the refill.
Use the documented grade and volume together. A C100E instruction does not automatically include C100EFM, and C-800 does not include every Aldex variant.
Confirm distributor retention and hydraulic compatibility with the system maker first. A smaller bead range is not a universal replacement approval.
Ask for the support-bed requirement for your tank and distributor. Do not add a generic gravel quantity or subtract a guessed gravel volume from the resin charge.
The Pentair VT performance sheet names General Technologies C108DQ(Na), with eight-percent crosslinking, as the tested resin. That matters even though the system’s charge is conveniently stated in cubic feet. Volume tells you how much material the system uses; it does not prove that any sodium-form resin preserves the same performance.
For a manufacturer-approved substitution, keep a record of the resin grade and the setup instructions that go with it. Ask whether the backwash flow control, distributor or controller settings change. A recommendation based only on the tank diameter leaves those questions unanswered.
| Same Pentair VT-11-01 resin volume | Salt dose | Rated capacity |
|---|---|---|
| 1.0 ft³ | 3 lb | 11,900 grains |
| 1.0 ft³ | 9 lb | 31,100 grains |
| 1.0 ft³ | 15 lb | 35,400 grains |
Pentair’s performance sheet gives these operating points for the same VT-11-01 system. The resin amount stays at one cubic foot while the salt dose and rated capacity change. A grain number therefore needs its salt-dose context before it can help with programming.
Do not choose the resin charge from an advertised grain count. Get the installed charge right first. Then follow the system manual for capacity, hardness and regeneration settings. If the previous owner changed those settings, have the maker or a treatment professional check them against the actual media and water conditions.
Pentair’s VT service instructions require turning off the water supply or using the bypass, then relieving system pressure. Confirm the tank is depressurized before loosening the control valve. If bypass or pressure relief is uncertain, stop and call a plumber.
Pentair directs unplugging the power cord before component service. Keep water away from the electrical supply. Call an electrician if the installation has a damaged outlet or uncertain grounding continuity.
Aldex C-800 is for professional use only. Its SDS requires protective gloves, protective clothing, eye and face protection when handling the resin, including a refill without cleaning chemicals. If you cannot meet these conditions, leave C-800 handling to a qualified professional.
Obtain the specific system’s resin, gravel and distributor instructions. Protect and seat the distributor as directed. Do not improvise an internal layout from a tank-size chart.
Confirm an appropriate air gap under the locally adopted plumbing code. The model-code reference is 2024 UPC 611.2. A hose pushed into a drain is not a substitute for the required separation.
Pentair warns to fill slowly to prevent media leaving the tank. Follow the model’s backwash, rinse and disinfection directions before service. Stop if resin escapes or the tank leaks.
A replacement-resin sheet is not the assembled softener’s installation manual. C100E’s material properties do not establish safe pressure, hot-water limits or electrical procedures for your valve and tank. Use the equipment’s own limits, and do not introduce hot water as a cleaning shortcut.
For chemical cleaning or disinfection, use only the treatment and dose approved by the softener maker. Aldex warns that acidic and basic regenerants can injure eyes and skin and advises specialist guidance before strong oxidizers contact resin. Follow the chemical label’s PPE and ventilation directions. Leave an uncertain procedure to a treatment professional.
Stop before loosening the valve. A plumber must establish safe isolation and pressure relief if the bypass does not work or its position is unclear.
Disconnect power safely and call an electrician for a damaged supply or questionable grounding. Do not work on energized controls with wet hands.
Pause the refill and contact the system maker. A 9×48 tank size and a valve model are not enough to approve a replacement charge.
Pentair specifies 1.0 ft³ for its VT-11-01, item 4005289, with a 9×48 tank. Treat that as a documented system example. Another assembler can specify a different charge for a vessel with the same nominal dimensions. Your complete system’s instructions control.
The Pentair VT-17-01, item 4005290, uses 1.5 ft³. With one-cubic-foot packages, buy two and install only 1.5. Do not add the leftover half-cubic-foot unless the maker explicitly specifies a different charge for your system.
Pentair lists 2.0 ft³ for VT-23-01, item 4005291. That is about 56.63 liters. Check that model against your paperwork; a 12×52 vessel-capacity figure from a tank maker measures something different from the softener’s resin charge.
The 9×48 label identifies nominal vessel dimensions, not every internal component or operating condition. Confirm that the manual belongs to your complete system and ask its maker to resolve the difference. Do not replace a documented charge with a generic online chart.
You need two one-cubic-foot bags and will have 0.5 ft³ left over. Two 25-liter bags also supply enough, with about 7.52 liters left over. The calculator rounds the purchase quantity up while keeping the installed charge at 1.5 ft³.
No. One cubic foot equals 28.316846592 liters. A 25-liter sack contains about 0.883 ft³, so one sack does not supply a full one-cubic-foot charge. Read the package volume before you compare bag counts.
Only when the system maker approves the grade, distributor and hydraulic setup. Purolite lists C100E and C100EFM as different grades. A smaller bead range alone does not establish that your distributor will retain the resin or that the original backwash settings remain suitable.
No. Pentair’s VT-11-01 has different rated capacities at different salt doses while keeping its one-cubic-foot charge. Set the resin volume from the complete system specification and use its operating instructions for the controller settings.
Use the support-bed instructions for your exact tank, distributor and assembled system. There is no universal gravel amount established by the three tank sizes here. If the instructions are missing, get them from the maker before loading either gravel or resin.
Follow the maker’s safe bypass procedure and stop using the softener until it is checked. Purolite warns that excessive backwash expansion can lose resin, but beads downstream do not identify a single cause. Have a treatment professional inspect the distributor, internal assembly and startup settings.
I checked Pentair’s model specifications and compared the resin makers’ published properties. The tank chart identifies the system behind each fill instead of assigning one universal quantity to a vessel size.
I compare exact resin grades with documented softening use. The system maker must approve the grade. No purchase offers are linked on this page.
| Check | Rule used |
|---|---|
| Quantity | Complete-system model and maker-specified resin volume |
| Purchase arithmetic | Required volume divided by stated package volume; purchase units rounded upward |
| Grade | Exact grade matched to maker documents; system substitution needs approval |
