Well pressure switch 30/50 vs 40/60
Match the switch, pump and tank before buying.

As an Amazon Associate I earn from qualifying purchases.
On this page
- Standard switch picks
- Read the pressure numbers
- Square D J21
- Square D J24 kit
- Pressure comparison
- Tank drawdown matrix
- Pump approval
- Tank precharge and condition
- M4 protection options
- J21M4 two-pack
- Square D J24M4
- All switch options
- Listing and maker differences
- Choose the next step
- Safe service scope
- Common questions
- Method and trust
- Related guides
SHORT ANSWER
Choose the Square D 9013FSG2J21 for an approved standard 30/50 replacement. Choose the J24 kit for an approved 40/60 system; changing settings needs a professional pump and tank assessment.

Match the existing approved setting
Both options need the right motor rating and connection. A standard switch must not replace a required low-pressure cutoff.


Square D 9013FSG2J24 standard 40/60 kit
Product prices and availability are accurate as of the date/time indicated and are subject to change. Any price and availability information displayed on Amazon.com at the time of purchase will apply to the purchase of this product.
| Switch | Key specs | Pick it if | Skip it if |
|---|---|---|---|
| Square D J21 (reference) | 9013FSG2J21, 30/50 psi, 20 psi nominal differential, NEMA 1, IP20 | The system approves a standard J21 at 30/50, its electrical ratings and fluid connection match, and no M4 cutoff is required. | The old control has M4 protection, the pump calls for a different OEM kit, or the operating problem has not been diagnosed. |
| Square D J24 kit (reference) | 9013FSG2J24, 40/60 psi, Kit listing, Quarter-inch internal NPSF switch | The system is approved for a standard 40/60 J24 and the installer separately approves any kit accessories used. | The maker specifies a fixed 30/50 control or an M4 protective switch, or the pump and tank have not been assessed for the higher setting. |
What 30/50 and 40/60 mean
The first number is cut-in: pressure falls to that point and the switch calls for the pump. The second is cut-out: the pump raises pressure to that point and stops. A 30/50 system therefore operates between nominal 30 and 50 psi at the control location.
Both pairs have a 20 psi differential. Moving from 30/50 to 40/60 raises each endpoint by 10 psi; it does not narrow the swing. The higher pair alone cannot promise constant pressure or a particular shower flow.
Read the actual pump and switch model before treating either pair as a choice. Telemecanique documents adjustable Pumptrol controls, while Wayne calls its CWS factory switch non-adjustable. Similar covers do not give those two systems the same adjustment permission.
Square D J21 for a standard 30/50 system
Your pump’s approved setting and protection decide, not a score.
The maker names the 9013FSG2J21 as a fresh-water pump control. Its fluid connection is quarter-inch internal NPSF. That is a specification to match against the existing approved fitting, not a promise that every quarter-inch part or installation will suit it.
Check motor voltage as well as horsepower. The data sheet gives 1.5 hp at 115V AC and 2 hp at 230V AC for single-phase motors. A blanket statement that this switch is only for pumps below 1.5 hp would lose that voltage distinction.
Where it does well
- Maker setting is 30/50 psi
- Quarter-inch internal NPSF connection
- Documented single-phase motor ratings
What to watch
- Standard J21 does not add M4 protection
- NEMA 1 and IP20 enclosure limits apply
- Not a verified substitute for an OEM assembly
The standard J21 model has no M4 suffix. If the system relies on low-pressure shutdown, keep that protective function in the replacement specification. A matching 30/50 setting alone does not make the plain J21 equivalent to a J21M4.
Its enclosure is NEMA 1 and IP20. Ask the installer to check the location against those ratings, especially in a damp pump area. A cover that resembles the old one is not evidence of suitable protection against the conditions at your installation.
The listing shown for reference is for one J21 pressure switch. Compare the full 9013FSG2J21 model on the received control with the approved replacement specification before installation. A similar cover or a 30/50 label alone cannot establish the correct connection, motor rating or protective function for an existing pump system.
Have qualified personnel handle the replacement. Telemecanique requires disconnection before service and the cover secured before power returns. Pressure must also be released before opening the water connection. Keep the control covered; comparing the label does not require access to exposed electrical contacts.
Square D J24 kit for a standard 40/60 system
The maker gives the J24 a nominal 40/60 setting and the same quarter-inch internal NPSF connection as the J21. Its published single-phase motor ratings are also 1.5 hp at 115V AC and 2 hp at 230V AC. The higher setting does not raise those electrical ratings.
The offer is a kit rather than a bare control. Its title lists a quarter-inch by 3-inch brass nipple, pressure gauge and tape. Those are listing descriptions of included items. I have no maker data establishing their pressure ratings, gauge accuracy or suitability for your drinking-water installation.
Where it does well
- Names the standard 9013FSG2J24
- Maker setting is 40/60 psi
- Listing bundles a gauge and connection accessories
What to watch
- Kit accessories need their own fit check
- Standard J24 does not add M4 protection
- Does not approve converting a 30/50 pump
Let the installer decide which supplied accessories belong in the system. A gauge in the box does not establish that the existing gauge is faulty, and the brass nipple is not automatically the correct replacement length. The documented J24 specifications describe the switch, not every item packed alongside it.
Keep the pump approval separate from the purchase. A switch can request 60 psi without proving the pump can reach it under the actual well conditions. Wayne CWS is a useful warning: its manual specifies a preset, non-adjustable 30/50 control despite the availability of other pressure switches.
Confirm the complete Square D 9013FSG2J24 model on the received switch before installation and retain the maker instructions. Match the control itself to the approved specification, even when it arrives in a kit. Do not substitute an unbranded control merely because its title includes the J24 model number.
Electrical service belongs to qualified personnel with power disconnected and water pressure released. Telemecanique requires the cover installed and secured before restoring power. This kit is a purchasing option for an approved configuration; it is not a shortcut around the pump, tank or wiring checks.
30/50 and 40/60 side by side
| Factor | 30/50 standard | 40/60 standard | Ahead |
|---|---|---|---|
| Candidate | J21 single Reference (not linked) | J24 kit Reference (not linked) | Depends on approved fit |
| Pump starts / stops | 30 / 50 psi | 40 / 60 psi | Even: different settings |
| Nominal differential | 20 psi | 20 psi | Even |
| Tank precharge example | 28 psi for the applicable 30/50 tank | 38 psi for the applicable 40/60 tank | Even: follow tank instructions |
| WX-202 published drawdown | 6.2 gallons | 5.4 gallons | 30/50 for more stored drawdown |
| Single-phase contact rating | 1.5 hp at 115V; 2 hp at 230V | 1.5 hp at 115V; 2 hp at 230V | Even |
| Existing approved 30/50 system | Keeps approved setting | Needs approval for a pressure change | 30/50 for a like-for-like repair |
| Existing approved 40/60 system | Changes configuration | Keeps approved setting | 40/60 for a like-for-like repair |
| Low-pressure shutdown | Requires the separate J21M4 model | Requires the separate J24M4 model | Even: match required protection |
The precharge examples are not instructions to add air to an existing tank. Amtrol reserves tank assessment and precharge work to licensed professionals; loss of air or corrosion can make repressurization dangerous.
What the extra 10 psi changes in your tank
A tank’s gallon label describes vessel volume, not the water available between pump starts. Amtrol lists the WX-202 as a 20-gallon tank, but its published drawdown is 6.2 gallons at 30/50. At 40/60, the same model’s drawdown is 5.4 gallons.
That is 0.8 gallon less stored delivery between the nominal endpoints, about a 12.9% reduction from the 30/50 figure. This comparison uses Amtrol’s properly configured tank data; it does not predict the behavior of a damaged tank or one with the wrong precharge.
| Tank | 30/50 drawdown | 40/60 drawdown | Less | 30/50 pump-off at 2 GPM | 40/60 pump-off at 2 GPM |
|---|---|---|---|---|---|
| WX-202 (20 gal) | 6.2 gal | 5.4 gal | 12.9% | 3.10 min | 2.70 min |
| WX-203 (32 gal) | 9.9 gal | 8.6 gal | 13.1% | 4.95 min | 4.30 min |
| WX-205 (34 gal) | 10.5 gal | 9.1 gal | 13.3% | 5.25 min | 4.55 min |
| WX-250 (44 gal) | 13.6 gal | 11.8 gal | 13.2% | 6.80 min | 5.90 min |
PlumbingPicks calculations: reduction = (30/50 drawdown minus 40/60 drawdown) divided by 30/50 drawdown. Pump-off minutes = drawdown divided by an assumed constant 2 gallons per minute. Start with a functioning tank at cut-out; values are not measured pump runtime, shower duration or starts per hour.
For the WX-203, the example changes from 4.95 to 4.30 minutes before the stored drawdown is used at 2 GPM. Those intervals describe the pump-off part only. Once the pump starts, its delivery and the continuing demand determine how long it runs.
Do not convert the 13.1% drawdown reduction for WX-203 into a 13.1% electricity increase or a fixed number of extra starts. Those need a demand pattern and pump performance data. A household with intermittent draws will not reproduce one continuous 2 GPM scenario.
Ask for a sizing review if the pressure change would leave too little drawdown for the pump’s required run time. Buying a 40/60 switch first can hide a second decision about tank size. The appropriate tank depends on delivery and the motor’s operating requirements.
| Published sizing-card example | 30/50 entry | 40/60 entry | What it shows |
|---|---|---|---|
| Approx. 10 GPM; pumps up to 3/4 hp; one-minute run-time column | WX-203 | WX-250 | Different model entries at the two pressure pairs |
| WX-250 vessel / drawdown | 44-gallon vessel; 13.6-gallon drawdown | 44-gallon vessel; 11.8-gallon drawdown | Vessel gallons and usable drawdown are different |
Amtrol’s quick-sizing card changes from WX-203 to WX-250 in its approximate 10 GPM, up-to-3/4-hp, one-minute column. That row is an example of the higher setting affecting tank choice. It is not a sizing instruction for every pump labeled 10 GPM.
The WX-250 is a 44-gallon vessel, not 44 gallons of usable drawdown. Its published drawdown is 13.6 gallons at 30/50 and 11.8 gallons at 40/60. Those figures describe storage between pressure endpoints; a larger tank cannot supply the pump’s missing pressure capability.
Check the pump before raising pressure
| Information to collect | Why the professional needs it |
|---|---|
| Exact pump model and manual | Identify the approved control and performance information |
| Actual well and piping arrangement | Apply the correct performance chart and friction allowances |
| Existing switch model and protection suffix | Separate an approved replacement from a configuration change |
| Tank model, condition and cycling history | Assess drawdown, precharge restrictions and sizing |
| Motor voltage and phase | Match switch contact ratings to the electrical application |
A motor horsepower label answers a different question from a pump performance chart. The J24’s 2 hp rating at 230V is a contact-switching rating. It does not say that every 2 hp pump can deliver useful water at a 60 psi cut-out in your well.
Wayne’s CWS manual illustrates that distinction. It specifies a 30/50 control and calls it non-adjustable. Its performance table includes pressures through 50 psi; it does not document a 60 psi operating point. Do not extrapolate an approval from the next pressure row you wish it had.
Long pipe runs and many fittings can reduce pressure through friction loss, as Wayne explains. Before proposing 40/60, give the professional the actual installation details. A higher control setting alone does not establish that a weak fixture complaint starts at the pressure switch.
| Control or pump family | Maker instruction | Compatibility limit |
|---|---|---|
| Pumptrol J21 / J24 | Adjustable controls; qualified personnel only | Setting range does not authorize every pump conversion |
| Wayne CWS50 / CWS75 / CWS100 | Factory switch preset and non-adjustable | Manual lists 30/50 kit 64031-WYN1 |
| Unknown pump or missing manual | No approved pressure change established | Identify equipment before selecting another pair |
Wayne lists 64031-WYN1 as its 30/50 pressure-switch kit for CWS50, CWS75 and CWS100. The manual’s fixed 30/50 setting applies to these pump models. A universal-looking J21 or J24 listing is not a verified substitute for the OEM kit.
For an unknown pump, photograph only labels you can reach without opening an electrical cover or touching equipment in standing water. Send the pump model, tank model and visible gauge information to the service professional. Leave exposed wiring, pressure testing and adjustment to qualified personnel.
Why 28 and 38 psi are conditional numbers
| Nominal switch pair | Applicable precharge example | Condition that comes first |
|---|---|---|
| 30/50 | 28 psi | Follow the tank maker’s procedure and confirm tank integrity |
| 40/60 | 38 psi | Licensed professional confirms the tank is suitable |
| Tank already lost air or has visible corrosion | Do not add pressure | Stop and have a licensed professional assess it |
Amtrol’s pre-installation procedure places precharge 2 psi below pump cut-in and gives 38 psi for 40/60 as its example. Wayne specifies 28 psi with an empty tank for its 30/50 installation. These numbers concern air precharge under the specified conditions, not the water pressure during normal operation.
The number on a running water-system gauge is not an empty-tank precharge reading. Wayne’s precharge-check procedure starts with power off and water pressure at zero. On an Amtrol tank, the maker reserves even checking precharge to licensed professionals. Use the procedure for your exact tank.
Do not add air simply because the pump now cycles quickly. Amtrol warns against repressurization after air loss, visible exterior corrosion, or a reduction in pump cycle time or precharge. Internal deterioration may not be visible from the outside. A 38 psi target does not override those restrictions.
Amtrol MC10185 warns that adding pressure to a compromised tank can cause rupture or explosion. Arrange a licensed assessment before any higher precharge.
MC10185 includes an initial-installation restriction and conditional in-service instructions. Have the maker or licensed installer determine what applies to the particular tank.
For a confirmed suitable tank, the professional matches the approved cut-in, precharge and drawdown. The switch setting is one part of that decision.
Keep the low-pressure protection your system needs
An M4 suffix adds a low-pressure cutoff with an AUTO–START–OFF lever. Telemecanique describes the cutoff as roughly 10 psi below cut-in. At factory settings, that means about 20 psi for J21M4 and 30 psi for J24M4. These are approximate protective thresholds, not ordinary pump-start settings.
After a loss of system pressure, the M4 may stop the pump rather than continue calling for it. The maker requires correcting the system fault before using the Start position. Do not bypass a low-pressure shutdown to make the pump run through an unresolved water-supply problem.

Square D 9013FSG2J21M4 30/50 two-pack

Square D 9013FSG2J24M4 40/60 cutoff switch
| Protective function | 30/50 M4 | 40/60 M4 |
|---|---|---|
| Candidate | J21M4 two-pack Reference (not linked) | J24M4 single Reference (not linked) |
| Normal start / stop | 30 / 50 psi | 40 / 60 psi |
| Approximate low-pressure cutoff | 20 psi at factory settings | 30 psi at factory settings |
| After a protective stop | Correct fault before maker-directed restart | Correct fault before maker-directed restart |
| Switch | Key specs | Pick it if | Skip it if |
|---|---|---|---|
| J21M4 two-pack (reference) | 9013FSG2J21M4, 30/50 psi, Approx. 20 psi low-pressure cutoff, Two-pack listing | The system calls for the J21M4 protective function at 30/50 and a two-pack is appropriate for the purchase. | Only a standard approved control is needed, the required setting is 40/60, or the low-pressure fault is still unresolved. |
| Square D J24M4 (reference) | 9013FSG2J24M4, 40/60 psi, Approx. 30 psi low-pressure cutoff, NEMA 1 / IP20 | The approved system uses 40/60 and requires the M4 low-pressure cutoff, with motor ratings and connection verified. | The system needs standard automatic control, a different OEM assembly or an unresolved conversion from 30/50. |
Square D J21M4 two-pack for 30/50 with cutoff
The maker describes the M4 cutoff as roughly 10 psi below cut-in. For factory 30/50 settings, the arithmetic gives about 20 psi. That threshold is approximate. It is below the normal 30 psi start point, so the normal pressure cycle and a protective stop are different operating events.
The reference listing is explicitly a two-pack of 9013FSG2J21M4 switches. Do not read its quantity as two parts that must both be installed. A single failed switch calls for one approved replacement; the second unit is a separate purchasing decision rather than an installation requirement.
Where it does well
- J21M4 retains a low-pressure cutoff
- Nominal 30/50 pressure pair
- Listing explicitly identifies a two-pack
What to watch
- Two switches may exceed a single repair need
- Restart follows correction of the underlying fault
- Pressure sensing is not a water-level measurement
The AUTO–START–OFF lever changes the restart question. Telemecanique says the system fault must be corrected before the lever is held at Start until pressure can sustain contact closure. A recurring shutdown needs diagnosis. Holding or defeating the mechanism is not a fix for the pressure-loss cause.
This is pressure-based protection. It does not directly measure the water level in the well and should not be described as universal dry-run protection. Ask the pump professional what protection the particular pump requires, especially if the original installation includes other controls.
Compare the complete 9013FSG2J21M4 model on the received units with the approved control specification. The 30/50 setting and the M4 suffix both matter for this replacement. The listing’s tank-protection wording does not replace the maker’s description of what the M4 actually detects: low system pressure rather than water level.
Use a qualified installer for the switch and a licensed professional for tank work. Before service, disconnect power and release water pressure. Restore power only with the cover secured. Those steps still apply to an M4 even though its external lever can make the control appear simple to operate.
Square D J24M4 for 40/60 with cutoff
The model data sheet gives the normal 40/60 pressure pair and identifies the factory low-pressure modification. The cutoff operates roughly 10 psi below cut-in, which gives an approximate 30 psi protective threshold at factory settings. That differs from a standard J24 calling for the pump as pressure falls.
The M4 lever is marked AUTO–START–OFF. Following a protective trip, correct the pressure-loss fault before attempting restart under the maker’s instructions. If water supply or priming has not been restored, repeated attempts to hold the control in Start do not establish safe pump operation.
Where it does well
- J24M4 combines 40/60 with M4 cutoff
- Single-switch listing
- Maker documents the AUTO–START–OFF function
What to watch
- Can need attended restart after pressure loss
- Does not approve a higher system setting
- Approximate cutoff is pressure-based
The J24M4 does not become a constant-pressure controller because it has another safety function. Its normal endpoints still differ by 20 psi. For complaints about pressure variation, ask the professional to assess the complete control system rather than assume the M4 suffix changes that operating band.
Check the electrical application independently. The maker lists 1.5 hp at 115V AC and 2 hp at 230V AC for single-phase motors. Neither figure is a pump performance claim. The switch needs the correct contact rating even when the hydraulic system is already approved for 40/60.
The listing shown for reference is for one J24M4 switch. Its title calls it an air-pump pressure switch; the maker’s 9013FSG2J24M4 sheet identifies fresh-water pump control. Use the complete model and official application, not that broad retailer wording, to establish the intended part before installation in an approved 40/60 system.
Qualified personnel must install and service the control with power disconnected and system pressure released. The enclosure is NEMA 1 and IP20; location still matters. Have the installer secure the cover before restoring power and verify the approved normal cycle and protective function under the applicable maker procedure.
Compare the four purchase options
| Switch and pack | Use | Cut-in / cut-out | Main advantage | Main limit | Buy |
|---|---|---|---|---|---|
J21 single | Approved standard 30/50 | 30 / 50 psi | Keeps a standard 30/50 setting | No M4 cutoff; not a universal OEM substitute | Reference (not linked) |
J24 kit | Approved standard 40/60 | 40 / 60 psi | Names the required J24 control | Accessories need separate approval | Reference (not linked) |
J21M4 two-pack | Approved 30/50 with low-pressure cutoff | 30 / 50 psi | Retains M4 shutdown | Two units; fault correction before restart | Reference (not linked) |
J24M4 single | Approved 40/60 with low-pressure cutoff | 40 / 60 psi | Single protective control | Fault correction before restart | Reference (not linked) |
Where listing language needs a closer check
| Item | Listing or other wording | Maker or controlling evidence | Decision |
|---|---|---|---|
| J24M4 | Title says air-pump pressure switch | 9013FSG2J24M4 sheet says fresh-water pump control | Match the exact model and maker application |
| J24 kit | Title names accessories and lead-free wording | J24 sheet specifies the switch, not the accessory bundle | Confirm accessory pressure ratings and drinking-water suitability separately |
| Connection wording | Retail titles may say quarter-inch NPT | J21/J24 sheets specify quarter-inch internal NPSF | Use maker connection specification |
| Tank relief protection | MC10185 p.2 refers to 125 psig or more | MC4400 printed p.4 gives a maximum relief setting of 125 psig | Maker or installer must resolve applicable specification; no universal setting given |
A listing title is useful for identifying the offered model, but it cannot approve a 40/60 conversion. Where the retailer uses air-pump language for J24M4, I use the maker’s fresh-water application. Where a kit adds a gauge, I do not transfer the switch’s specifications to that gauge.
The Amtrol relief documents also need care. I do not turn their differing wording into a generic valve-setting instruction. The licensed installer must establish relief protection for the particular tank and every affected component. A pressure switch is not a substitute for a pressure-relief valve.
Replace, investigate or change the setting?
Keep the approved pressure pair, complete model requirements and protective functions. Confirm motor rating and connection before ordering a J21, J24 or M4.
Collect the pump model and visible pressure behavior. A 40/60 switch purchase does not establish the cause of low flow at one fixture.
Have the professional confirm pump capability, tank condition and drawdown, component limits and relief protection before moving from 30/50 to 40/60.
Do not open electrical covers or approach flooded pump equipment. Wayne directs flooded electrical isolation to the utility or a qualified licensed electrician.
A like-for-like repair starts with proof that the existing specification is approved, not simply a memory that the old gauge reached 50 psi. The complete model, motor application and required protection belong on the order. An unreadable label or a history of previous changes is a reason to identify the system first.
For an older house, age alone does not approve or prohibit 40/60. The useful questions concern the actual pump, tank integrity and component limits. A corroded or air-losing tank requires assessment regardless of whether the requested pressure increase is only 10 psi.
| Observation | Useful next question | Avoid this shortcut |
|---|---|---|
| Only one fixture is weak | Does the pressure issue occur elsewhere under similar demand? | Assuming the well switch must change |
| Pump starts much more often | Has tank drawdown, precharge or system leakage changed? | Adding air without checking tank condition |
| Pump does not stop | Can the approved system reach cut-out and is the control operating correctly? | Raising the setting again |
| M4 will not restart | Was the cause of low pressure corrected? | Bypassing the protective mechanism |
What a qualified service visit should establish
- 1Identify the approved configuration
Use the pump manual, full switch model and tank instructions. Check whether the job is a failed-control repair or a proposed pressure change.
- 2Isolate electricity and release pressure
Wayne requires disconnecting power, locking and tagging the disconnect against unexpected energization, and releasing system pressure. It also calls for safety glasses. Wiring belongs to a licensed or certified electrician.
- 3Assess the tank before precharge work
Amtrol reserves precharge checks and changes to licensed professionals. Air loss, corrosion or reduced cycle time are stop conditions for adding pressure, not an invitation to top up the tank.
- 4Verify operation with the cover secured
Telemecanique requires its cover installed before power returns. Qualified personnel set range before differential where adjustment is authorized, then verify operation over repeated cycles. No fixed number of spring turns applies to every system.
For a Pumptrol control that is approved for adjustment, the maker specifies range first and differential second. I do not provide exposed-contact adjustment steps or a turn count. A user cannot establish a safe setting by copying a spring position from a different control.
Ask the professional to record the final cut-in and cut-out, tank specification and any protective suffix. Those details make the next replacement easier to identify. Amtrol also calls for professional system inspection annually and more often as the system ages; keep that maintenance separate from a switch purchase.
Questions about 30/50 and 40/60 switches
What does 30/50 mean on a well pressure switch?
The pump normally starts when pressure at the control falls to 30 psi and stops when it rises to 50 psi. Those are nominal cut-in and cut-out settings, with a 20 psi differential. Check actual approved operation through a qualified service professional if the gauge and label disagree.
Is 40/60 better than 30/50?
It has endpoints 10 psi higher, but the same 20 psi swing. It is appropriate only when the pump and system are approved for that range. Amtrol’s WX-202, for example, has less published drawdown at 40/60: 5.4 gallons instead of 6.2 at 30/50.
For an approved 30/50 system with a failed control, a matching replacement avoids an unnecessary pressure change. For an already approved 40/60 installation, keep its correct control and protective features. There is no universal winner based on the larger numbers alone.
Can I replace my 30/50 switch with a 40/60?
Only after a professional confirms the proposed configuration with the pump and tank instructions, component limits and relief protection. Wayne CWS factory switches are specifically preset and non-adjustable. An adjustable Pumptrol replacement does not cancel that pump-specific restriction.
Tank assessment comes before changing precharge. Amtrol warns against adding pressure after air loss, visible corrosion or reduced cycle time or precharge. Do not treat the common 38 psi example as permission to recharge an existing tank.
Can I replace a 40/60 switch with a 30/50?
A lower pair still changes the approved configuration and its precharge relationship. Have the professional confirm the pump controls, required protection and tank procedure. A 38 psi factory precharge is not automatically suitable for a 30 psi cut-in; the applicable maker instructions control the setup.
Should the tank precharge be 28 or 38 psi?
For the applicable precharged tank setup, 28 psi corresponds to 30 psi cut-in and 38 psi to 40 psi cut-in. Amtrol’s pre-installation rule is 2 psi below cut-in. Tank integrity and its exact procedure come first, and Amtrol reserves checking and adjustment to licensed professionals.
Do I check precharge while the tank has pressurized water?
Do not interpret the running water-pressure gauge as precharge. Wayne’s procedure requires power off and zero water pressure for that check. On Amtrol tanks, use a licensed professional even for precharge checking; adding air to an impaired in-service tank can cause rupture or explosion.
Why does my switch say 40/60 but the gauge shows 30/50?
A printed factory setting does not establish the current measured endpoints. Qualified personnel should verify the gauge, actual switch behavior and approved system configuration. Do not adjust exposed contacts to force a match; isolate power and pressure for service and keep the cover secured before operation.
Why will my pump not restart after an outage?
If the control is an M4, a loss of system pressure can cause a protective stop. Telemecanique requires correction of the fault before its Start procedure. Identify the full model first; an outage alone does not prove the switch failed or that a standard switch would be an appropriate replacement.
Why is the pump short cycling after a switch change?
The setting may have changed drawdown or exposed another system problem. Wayne lists incorrect tank pressure, a damaged bladder or diaphragm, leaks and control problems among frequent-cycling causes. Have the system diagnosed rather than repeatedly replacing switches.
A reduced cycle time is also an Amtrol warning against casually adding pressure. Arrange a licensed tank assessment. The 2 GPM examples above describe stored-water delivery intervals only and cannot diagnose motor run time or predict starts per hour.
Does the M4 switch protect against every dry-well problem?
No. Its documented trigger is low system pressure, roughly 10 psi below cut-in. It is not a direct well-water-level sensor or a substitute for all pump protection. Ask the pump professional which controls the particular installation needs, and never bypass an unresolved protective shutdown.
Will a 40/60 switch fix low flow at one shower?
The higher pressure pair does not establish the cause of a single-fixture complaint. Wayne notes that pipe length and fittings affect pressure through friction loss. Compare the complaint with pressure behavior elsewhere and have the restriction or system issue identified before changing the well control.
How I pick and why trust PlumbingPicks
Why trust PlumbingPicks
I am a licensed journeyman plumber in Georgia. Recommendations here follow the exact pump-control models, tank instructions and published drawdown figures. A J21, J24 and M4 suffix answer different fit questions; none is treated as universally suitable.
How I pick
I read Telemecanique’s model sheets and instruction sheet, Wayne’s CWS manual and Amtrol’s tank documents. I match the complete setting and protective function before recommending a switch, so none of the four is scored. The 2 GPM intervals are calculations from published drawdown, not measured household results.
| Check | Selection rule |
|---|---|
| Approved application | Pump manual and control specification take priority over retailer wording |
| Electrical suitability | Use the voltage- and phase-specific motor rating |
| Tank suitability | Condition, maker restrictions and drawdown considered together |
| Protection | Retain required low-pressure cutoff or other specified control function |
| Product identification | Match the full Square D model and pack quantity; photos come from Amazon |
| Scoring | None: the approved setting and the M4 cutoff are requirements, not points to average |
| Offer |
Sources
- Telemecanique Sensors: 9013FSG2J21 and 9013FSG2J24 product data sheets, July 30, 2024, pages 1–2. Factory settings, fluid connection, motor ratings and enclosure.
- Telemecanique Sensors: 9013FSG2J21M4 and 9013FSG2J24M4 product data sheets, July 30, 2024, pages 1–2. Low-pressure cutoff and operating lever.
- Telemecanique Sensors: Pumptrol instruction sheet 65013-005-39, September 2025, pages 1–2. Isolation, secured cover, qualified personnel, adjustment order and M4 restart.
- Amtrol: Well-X-Trol installation and operation instructions 9015-868 MC10185, 07/25, pages 1–3 and 6. Professional service, tank-condition warnings, precharge and inspection.
- Amtrol: Well-X-Trol specifications and ESP quick-sizing card MC7025, 03/24, pages 1–2. Drawdown, vessel volumes and sizing examples.
- Amtrol: WX-100, 200 and 300 series submittal MC4400, 04/24, printed page 4. Vessel volumes, factory precharge and relief specification.
- Wayne: CWS Series operating instructions and parts manual 640003W-001 E, 06/24, pages 1, 3–5, 8 and 14–15. Fixed control, precharge, safety, OEM part and troubleshooting.
- Product images read October 20, 2026. Availability may change.
