One overnight test, then the right fix.
As an Amazon Associate I earn from qualifying purchases. How this site earns
Updated November 18, 2026

Rising pressure with no water running points to heater expansion, a leaking PRV or street swings. Catch the overnight peak with a max-pointer gauge on a cold tap after the PRV. Get the Watts 0950200, or a Reotemp for a 0–160 dial.

Answer from the overnight test. This checker ranks the three causes on Watts’ troubleshooting list. A missing or unsure answer never earns a single-cause verdict: it routes to the next measurement instead.
Ranking follows the Watts IS-LF25AUB troubleshooting list (thermal expansion, pressure creep, debris on the seat), IPC 2024 section 604.8 (80 psi static limit) and A. O. Smith guide 100341465 (the highest pressures often show up at night).
Start with a gauge. Buy a tank or a valve only after the test points to the cause.

Shown for comparison only.
Shown for comparison only.
Sold through plumbing dealers. A licensed plumber sizes and installs it, per Amtrol’s instructions.
Shown for comparison only.
Sold through plumbing dealers. A licensed plumber sizes and installs it, per Amtrol’s instructions.
Shown for comparison only.
Product prices and availability are accurate as of the date/time indicated and are subject to change. Any price and availability information displayed on Amazon.com at the time of purchase will apply to the purchase of this product.
| Tool | Key specs | Pick it if | Skip it if |
|---|---|---|---|
| Watts 0950200 test gauge | 0950200, 0–200 psi, Max-hold hand, ASME Type B, 3/4 in. HT, 40–140°F | You want one gauge that sits on a cold hose-thread tap overnight and keeps the highest reading for you to read in the morning. | You only want a quick daytime reading, or the only tap you can use is a hot one. This gauge is rated to 140°F. |
| Reotemp PD25H (reference) | PD25H, 0–160 psi, Max pointer, 3-2-3%, 2.5 in. dial, 3/4 in. FHT | You want a gauge sold by its maker, with a published accuracy figure and clear steps for setting the max pointer. | You’d rather have a dial that reads past 160 psi, or a listed temperature range. Get the Watts. |
| Amtrol ST-5 (reference) | ST-5, 2.0 gal, 0.9 gal acceptance, 50 psig pre-charge, 150 psig, 3/4 in. NPTM | The overnight test points to thermal expansion, and sizing to the 80 psi limit in IPC 607.3 with Amtrol’s formula calls for a tank of 2.0 gallons or less, with 0.9 gallons or less of expanded water. | The formula calls for more than 2.0 gallons, or the expanded water tops 0.9 gallons. By my math, a 50 gallon heater at 140°F on 50 psi supply already needs about 2.4. |
| Amtrol ST-12 (reference) | ST-12, 141N43, 4.4 gal, 3.2 gal acceptance, 50 psig pre-charge, 3/4 in. NPTM | The test points to thermal expansion, and sizing to the 80 psi limit with Amtrol’s formula calls for more than 2.0 gallons of tank, up to 4.4, with no more than 3.2 gallons of expanded water. | The formula calls for more than 4.4 gallons, as it does for any 40 to 80 gallon heater at 140°F on 70 psi supply by my math. |
| Watts LF25AUB-Z3 (reference) | LF25AUB-Z3, 3/4 in., 25–75 psi, Preset 50 psi, 300 psi max inlet, 33–180°F | There’s no PRV and your static reading is over 80 psi, or your old 3/4 in. valve creeps and needs replacing. | Static pressure is fine and the spike only shows when the heater runs. That points to thermal expansion; look at a tank first. |
The tap you pick decides what the gauge measures. Test after the pressure reducing valve, on a cold tap.
A. O. Smith’s water heater guide says to connect a pressure gauge to an outside faucet and measure the highest pressure through the day, adding that the highest pressures often occur at night. That’s the right test. The catch is which outside faucet.
The 2024 International Plumbing Code, section 604.8, requires a pressure reducing valve (PRV) when static pressure in the building is over 80 psi. Its exception covers service lines to sill cocks and outside hydrants. So on some houses, the hose bibb is teed off before the PRV and sees full street pressure.
Find the PRV first. It’s usually where the main enters the house, a brass valve with an adjusting bolt on its spring cage. Then pick a cold tap that’s clearly downstream of it: a laundry box, a utility sink with hose threads, or an outside faucet you’ve traced back past the valve.
No PRV? A meter check valve or backflow preventer can trap the heater’s expansion. Open a cold tap briefly to let it out, as Watts describes; the reading after that is close to street pressure. The overnight peak can still climb past it, and the code limit for static pressure is 80 psi either way.
One gauge, one cold tap, one night. Plan it for a night when the water heater will run, such as after evening showers.
Look where the main enters the house. Note whether there’s a PRV and an expansion tank near the water heater.
Use a laundry box, utility sink or traced outside faucet with 3/4 in. hose threads. Use the cold side only. The Watts gauge is rated 40 to 140°F, so test indoors on a night that may drop below 40°F.
Rest the red pointer just above the black one, as Reotemp describes, so the black hand pushes it up.
Thread the gauge on hand-tight and open the tap fully. With no water running anywhere else, the black needle is your static pressure.
Note the reading and the time. If it’s over 80 psi already, you’ve found a problem before the night even starts. If a needle ever reaches the top of the dial (200 psi on the Watts, 160 on the Reotemp), stop the test and call a plumber; don’t run another heating cycle.
Let the water heater run a cycle. A. O. Smith says to measure the highest pressure through the day, since the highest often comes at night.
In the morning, before anyone runs water, write down the black needle (now) and the red one (the peak). A needle stuck at the top of the dial (200 psi on the Watts, 160 on the Reotemp) isn’t a measured peak. Call a plumber.
If the peak was high, watch the black needle after a heating cycle. When it’s above the baseline, briefly open a cold tap, per Watts.
Close the tap, then unscrew the gauge slowly over a bucket, since a little water stays trapped behind it. Turn the red pointer back to zero before the next night.
Two tools to find the cause and three parts that fix one. Specs come from the makers’ sheets and listings.
| Pick | Photo | What it’s for | Range or size | Key spec | Top pressure | Temperature | Buy |
|---|---|---|---|---|---|---|---|
| Watts 0950200 Test gauge | ![]() | Find the peak | 0–200 psi | Red max-hold hand | 200 psi max working | 40–140°F | Check it on Amazon |
| Reotemp PD25H Test gauge | Find the peak | 0–160 psi | 3-2-3% accuracy | 160 psi dial top | Not listed | Reference (not linked) | |
| Amtrol ST-5 Expansion tank | Thermal expansion | 2.0 gal | 0.9 gal acceptance | 150 psig max | Up to 200°F | Reference (not linked) | |
| Amtrol ST-12 Expansion tank | Thermal expansion | 4.4 gal | 3.2 gal acceptance | 150 psig max | Up to 200°F | Reference (not linked) | |
| Watts LF25AUB-Z3 PRV, 3/4 in. | Street pressure | 25–75 psi | Bypass, strainer | 300 psi max inlet | 33–180°F | Reference (not linked) |
Compare the black needle (pressure now) with the red one (the highest since you reset it). Then match your result to a row.
| What you see | Follow-up check | Points toward | Next step |
|---|---|---|---|
| Peak about the same as now; both under 80 psi | Repeat on a night the heater runs | No spike caught this time | Test again through a full heating cycle |
| Peak well above the PRV setting, after the heater ran | Crack a cold tap during a spike; Watts says expansion pressure drops right back to the setting | Thermal expansion | Check for an expansion tank, its size and its pre-charge |
| Needle climbs above the setting with no flow while the heater is idle | Open and close a cold tap, then watch whether it climbs again | PRV creep or debris on the seat | Clean the strainer; service or replace the PRV |
| No PRV, and the static reading is over 80 psi | Open a cold tap briefly to release trapped expansion, then re-read; ask your utility for its range | Street pressure | Have a PRV installed; Watts presets 50 psi |
| Outside faucet reads higher than an indoor tap | Trace that faucet’s pipe back to the PRV | The faucet may be ahead of the PRV | Retest on a cold tap after the PRV |
| Relief valve drips a little, or the peak nears the pressure on its tag | Note whether it happens after heating | High pressure or expansion | Call a plumber; never cap or plug the relief valve |
| Relief valve releases a lot of very hot water | Stay clear of the discharge pipe | Tank overheating, not a pressure reading | On an electric heater, A. O. Smith says turn the power off until it’s fixed; call a plumber |
Causes and the cold tap test from Watts’ LF25AUB troubleshooting section; 80 psi from IPC 2024 section 604.8; 50–60 psi from A. O. Smith’s residential electric water heater guide; relief valve drip, overheating discharge and warning from the same guide. Read Oct 20, 2026.
Watts’ troubleshooting section is the key. It says when pressure after the PRV is higher than the set pressure with no water flowing, the cause could be thermal expansion, pressure creep or dirt and debris on the seat.
It also gives a simple way to tell the first one apart. Briefly open a cold water tap. If the extra pressure came from thermal expansion, Watts says it’s relieved immediately and the system returns to the set pressure.
To run that check, you need to catch the spike while it’s there: right after the water heater finishes heating, with nobody using water. If the black needle is above your static reading, crack a cold tap and see where it settles.
A drop back to the setting points to expansion, but it doesn’t clear the PRV. Close the tap and keep watching with nothing running. If the needle climbs again while the heater is idle, suspect the valve too. Two causes can stack, so fix one and test again.
Four numbers frame every reading: the PRV’s factory setting, the recommended working range, the code limit and the relief valve’s setting.
| Reading | What it means | Source |
|---|---|---|
| About 50 psi | Normal; it’s where Watts presets its PRV | Watts LF25AUB installation sheet |
| 50 to 60 psi | A. O. Smith’s recommended working pressure | A. O. Smith guide 100341465 |
| 60 to 80 psi | Under the code limit, above A. O. Smith’s range | A. O. Smith; IPC 604.8 |
| Over 80 psi static | Code calls for a PRV | IPC 2024 section 604.8 |
| 100 psi | Too high; A. O. Smith says some homes now exceed it | A. O. Smith guide 100341465 |
| 140 psi | Close to a 150 psi relief setting; check your valve’s tag | Amtrol MC8520; A. O. Smith |
Most codes allow up to 80 psi of incoming pressure, A. O. Smith’s guide says, but it recommends a working pressure no higher than 50 to 60 psi. It adds that many utilities have raised supply pressure over the years, and some homes now see more than 100 psi.
Those numbers are static, with no water running. A running shower drops the reading, so take the baseline with everything off. The peak on the red needle is a different number again, and the table above is for both.
| Tool | Photo | Why | Buy |
|---|---|---|---|
| CARBO D25-P-W-200 gauge Alternate, 0–200 psi | Red max pointer and a listed ±2-1-2% accuracy (ASME B40.1 Grade A). Teflon tape included. | Reference (not linked) | |
| Milton S60XA tire gauge 0–60 psi, ANSI B40.1 Grade B | Reads an expansion tank’s air valve when the tank is empty of water. It tops out at 60 psi, so it only fits supply pressures up to that. | Reference (not linked) |
A 24-hour test samples one day. If your toilet sometimes runs briefly at night but the gauge caught nothing, test again on a night with heavier hot water use. More gauge choices are in my water pressure gauge guide.
Heated water takes up more room. In a closed system, that extra volume has nowhere to go but up in pressure.
A one-way device between the heater and the main, so expanded water can’t push back to the street. IPC 607.3 names check valves, PRVs and backflow preventers.
A. O. Smith says backflow preventers are often built into water meters and may not be visible, so almost all homes now need an expansion tank.
Amtrol says expanded water enters the tank once pressure passes the pre-charge, and the air pushes it back when you use hot water.
It can fit a night pattern. After evening showers the heater recovers with no tap open, and in a closed system the expanded water has nowhere to go but up in pressure.
A. O. Smith’s guide names what’s at stake. It says an expansion tank helps avoid damage to the water heater, washing machine, dishwasher, ice maker and even toilet valves. It adds that a toilet that runs briefly at night for no reason may be thermal expansion raising the pressure for a moment.
A PRV doesn’t stop it. A. O. Smith says thermal expansion causes large pressure increases despite a PRV on the main. The 2024 IPC, section 607.3, calls for an expansion control device when a storage heater’s cold water passes through a check valve, PRV or backflow preventer.
Georgia went further in 2026. Its amendment puts the device downstream of shutoff valves too, and at least 18 in. of pipe from the heater’s cold inlet. My water heater expansion tank guide covers installation.
Amtrol sizes by three things: heater gallons, the heater’s temperature setting and your static supply pressure.
Read across from your heater’s size to your static pressure, in the panel for your temperature setting. For a 50 gallon heater at 140°F, the chart lists an ST-5 at any supply pressure from 40 to 80 psi. Set the same heater to 160°F with 60 psi supply, and the chart moves to the ST-12.
Higher settings and higher supply pressure both push you up a size. Hotter water expands more, and a tank pre-charged to a higher pressure has less room left for water. At 180°F, the chart lists an ST-12 even for a 40 gallon heater.
Amtrol’s chart starts from 40°F incoming water and a 150 psi relief valve. Its sheet sends anything beyond the chart to its app or technical support line, such as heaters over 120 gallons.
One limit to know: IPC 607.3 says expansion tanks are sized to the maker’s instructions and so the house stays within section 604.8, which is 80 psi static. The chart’s 150 psi basis doesn’t promise that, so the table below works the same heaters to 80 psi.
The 140, 160 and 180°F panels are the chart’s sizing conditions, not suggested settings. A. O. Smith warns that a water heater can make water hot enough to cause severe burns instantly.
| Heater at 140°F | Expanded water | 40 psi supply | 50 psi supply | 60 psi supply | 70 psi supply |
|---|---|---|---|---|---|
| 40 gal | 0.60 gal | 1.4 gal: ST-5 | 1.9 gal: ST-5 | 2.8 gal: ST-12 | 5.7 gal: larger |
| 50 gal | 0.75 gal | 1.8 gal: ST-5 | 2.4 gal: ST-12 | 3.6 gal: ST-12 | 7.1 gal: larger |
| 60 gal | 0.90 gal | 2.1 gal: ST-12 | 2.8 gal: ST-12 | 4.3 gal: ST-12 | 8.5 gal: larger |
| 80 gal | 1.20 gal | 2.8 gal: ST-12 | 3.8 gal: ST-12 | 5.7 gal: larger | 11.4 gal: larger |
My math with Amtrol’s sizing method MC10007: tank volume = expanded water × (80 + 14.7) ÷ (80 − supply pressure), using 1.5% expansion for 40°F to 140°F and pre-charge equal to supply. Amtrol says a tank must meet both numbers: ST-5 is 2.0 gal with 0.9 acceptance, ST-12 is 4.4 gal with 3.2. Have your plumber confirm the size.
The gap between the two numbers drives the size. At 70 psi supply there’s only 10 psi of room below the 80 psi line, so even a 40 gallon heater needs about 5.7 gallons of tank. Amtrol’s formula divides by that gap, which is why a PRV that brings supply down to 50 psi also shrinks the tank you need.
A. O. Smith says a tank that’s already installed can be pressurized wrong, or its internal bladder may be defective. A tank that’s too small can’t take all the heater’s expansion either.
| Check | What Amtrol says | What goes wrong if it’s off |
|---|---|---|
| Pre-charge | Equal to cold water supply pressure, set with the tank empty of water | Set low, it takes on water at supply pressure and has less room left; set high, water stays out until pressure passes the pre-charge |
| When to adjust | Only during installation or regular inspection, with the tank isolated and empty of water | Amtrol says to replace, not re-pressure, a corroded, damaged or weakened tank; tanks under pressure may weaken and burst or explode |
| Mounting | Water connection up is best; inverted or horizontal is allowed if the tank body is fully and rigidly supported | An unsupported tank puts stress where it isn’t built to take it |
| Placement | Cold supply, between the heater and any check valve, backflow preventer or PRV | Ahead of the check valve, it does nothing |
| Service | A licensed professional installs, periodically inspects and services it | Amtrol says tanks under pressure may corrode, weaken and burst or explode |
From Amtrol’s Therm-X-Trol ST installation and operating instructions, read Oct 20, 2026. The “what goes wrong” column is my reading of those instructions.
Amtrol ships the ST-5 and ST-12 at 50 psig. If your house runs at 70 psi and nobody raised the pre-charge, the tank starts the night partly full. Amtrol says to match it to the cold supply before installation. A tank already in service is your plumber’s call at Amtrol’s periodic inspection, not a tire-gauge job.
Zurn says a PRV reduces pressure with water flowing or not. With nothing running, its seat has to seal, and wear or debris there lets street pressure creep through.
Watts lists pressure creep and dirt or debris on the seat as the other two causes of high pressure with no water flowing. One clue is a black needle that climbs above your PRV’s setting with no water running and the heater idle.
A cold tap may pull the needle down for a moment either way. What matters is whether it climbs back once the tap closes. Zurn’s 70XL sheet describes a working PRV as protecting the house from inlet pressure changes; a valve that leaks through stops doing that job.
| Watts step | What it involves | Who |
|---|---|---|
| Clean the strainer | Shut off inlet pressure and depressurize the valve, remove the strainer plug, clean the strainer | Plumber, or a handy owner following Watts’ steps |
| Check the setting | Factory preset 50 psi static; clockwise raises pressure; always verify with a gauge | Handy owner or plumber |
| Replace seat disc or diaphragm | Shut off supply and take the spring cage and stem apart | Plumber |
| Test the valve | At least once a year, or more as service conditions warrant | Plumber |
| Replace the valve | Installed by a licensed contractor to local codes | Plumber |
From Watts’ LF25AUB installation, maintenance and adjustment instructions, read Oct 20, 2026. IPC 2024 section 604.8.2 requires PRVs and strainers to be repairable without breaking the pipeline.
Don’t just turn the bolt down to hide a creep. A valve that leaks through will climb again overnight. Watts also warns not to bottom out the adjusting screw on the spring cage.
If cleaning the strainer doesn’t hold, Watts also gives steps to replace the seat disc and diaphragm. A plumber can judge whether servicing or a new valve makes more sense. My PRV replacement by brand guide matches a new valve to the old one, and my water pressure regulator guide compares more models.
Street pressure isn’t fixed. The plumbing code expects it to swing, and with no PRV your house rides along.
IPC 2024 section 604.6 says that where street main pressures fluctuate, the house system is designed for the minimum pressure available. It doesn’t say when the swings come. A. O. Smith’s guide only notes that the highest pressures often show up at night.
With a working PRV, that swing mostly stays outside. With no PRV, your house sees whatever the street delivers. A. O. Smith notes that many utilities have raised supply pressure to serve more homes, and some homes now exceed 100 psi.
Your test shows a high static reading on a tap with no PRV ahead of it, after a cold tap was opened briefly to release trapped expansion. Over 80 psi static, IPC 604.8 calls for a PRV listed to ASSE 1003 or CSA B356 with a strainer. Your water utility can tell you its normal range on your street.
| Cause | Shows up as | Fix | Pick |
|---|---|---|---|
| Thermal expansion | Spike after heating; cold tap brings it straight back | Expansion tank, sized and pre-charged | Amtrol ST-5 or ST-12 |
| PRV creep or debris | Pressure above the setting with no flow | Clean, service or replace the PRV | Watts LF25AUB-Z3 |
| Street pressure | High static reading with no PRV, even after a cold tap is opened briefly | PRV set to 50–60 psi | Watts LF25AUB-Z3 |
Five ways the test or the fix goes wrong, and what the makers say instead.
IPC 604.8 lets sill cocks skip the PRV, so that faucet can read street pressure. Trace the pipe or use an indoor cold tap.
The black needle shows now. The red one holds the peak. A morning check of one needle misses the spike you’re testing for.
A. O. Smith warns that an explosion could occur if the relief valve or its discharge pipe is blocked. Don’t cap or plug either one.
Watts says to use a pressure gauge every time a reducing valve is adjusted, and never bottom out the adjusting screw.
Watts says the bypass won’t keep the relief valve from opening above 150 psi. IPC 607.3 still calls for expansion control after a PRV.
Banging pipes when a valve shuts fast are water hammer, a separate problem. IPC 604.9 handles it with flow velocity and arrestors at quick-closing valves; see my water hammer arrestor guide. A leaking relief valve after a spike is covered in my T&P relief valve replacement guide.
Check three things. Thermal expansion from the water heater can raise pressure in a closed system, a worn PRV can creep, and street pressure can swing. Watts’ troubleshooting lists expansion, creep and seat debris for high pressure with no water flowing, and A. O. Smith says the highest pressures often show up at night.
Yes. Watts presets its LF25AUB pressure reducing valve to 50 psi, and A. O. Smith recommends a working pressure no higher than 50 to 60 psi.
No. The 2024 IPC, section 604.8, calls for a pressure reducing valve when static pressure in a building is over 80 psi. A. O. Smith says some homes now exceed 100 psi and that high pressure can damage water heaters.
Yes, far too high. It’s close to the 150 psi relief setting Amtrol’s sizing chart assumes; your own valve’s tag gives its number. A reading like that calls for a plumber, and the relief valve and its discharge pipe must never be capped or plugged.
House size doesn’t change the limits. The IPC limit is 80 psi static, and A. O. Smith recommends 50 to 60 psi for any home. Section 604.6 says the system is designed for the minimum street pressure available.
At least overnight, through one water heater heating cycle. A. O. Smith says to measure the highest pressure through the day, since the highest often comes at night. Repeat if one night catches nothing.
A. O. Smith says a toilet that runs briefly at night for no reason may be thermal expansion raising pressure for a moment. An overnight max-pointer test will show whether pressure climbs.
Not your static pressure. Amtrol says water enters the tank only when system pressure exceeds its pre-charge. It absorbs the rise from heating, so the peak stays lower than it would without the tank.
Yes. Watts lists pressure creep and debris on the seat as causes of high pressure with no water flowing. If pressure climbs above the setting again after a cold tap is opened and closed, with the heater idle, suspect the valve.
A second, usually red, needle that the main needle pushes up and leaves behind at the highest reading. Reotemp says to set it just above the black needle before testing and turn it back to zero to reset.
The test steps, sizes and limits here come from Watts, Amtrol, A. O. Smith, Reotemp and Zurn documents and from the 2024 International Plumbing Code with Georgia’s 2026 amendments, all named below.
