American Standard Toilet Fill Valve: Which Part Fits?
This American Standard toilet fill valve replacement guide covers the one fill valve American Standard names for Cadet, VorMax and Champion tanks, the overnight test that tells you it is the part to replace, and the maker’s own install steps.
As an Amazon Associate I earn from qualifying purchases. Disclosure.
American Standard 7381125-400.0070A fill valve. Product photo from Amazon.
Quick answer
American Standard names one fill valve for its Cadet, VorMax and Champion toilets: the Universal Toilet Water Fill Valve, part number 7381125-400.0070A (its store calls it the “Fill Valve Universal 400A-Repair Part”). Before you buy it, run American Standard’s overnight leak test: a level that does not drop means the fill valve; a level that drops means the flapper or flush valve, and those parts do change by line. Then flush the valve with a cup of water; replace it only if it still runs.
American Standard’s Cadet and VorMax support page starts with the diagnosis, and its Champion pages follow the same order: a running toilet is “most likely due to one of the following four components that must be replaced: flapper/seal, flush valve, fill valve, and/or trip lever,” and “Determining which component is faulty will depend on a simple leak test you can conduct.” The VorMax page spells the test out: “Allow the tank to fill to approximately ½” below the overflow tube on the flush valve, then close the water supply shutoff valve to turn the water off. Mark the water level inside the tank, let it sit overnight, and check the water level in the morning.”
Read the result the way American Standard does. Level dropped to the flapper: the flapper or seal. Level dropped to the bottom of the flush valve: the flush valve. “The water did not drop at all. The issue is most likely the water control (fill) valve.” Its fill valve symptoms: “The water continues to go over the top of the overflow tube on the flush valve. The water control valve is hissing or continually dripping water through the refill tube into the overflow tube on the flush valve. Water is not filling at all into the tank, or starts and stops erratically.”
Step 2: One Fill Valve for Cadet, VorMax and Champion
Unlike the flappers and flush valves, which differ by line, American Standard names the same fill valve on every one of those pages: the Universal Toilet Water Fill Valve, part number 7381125-400.0070A. The Cadet/VorMax page says “For either of the American Standard Cadet or VorMax toilets,” check the flush-out article “before replacing The Universal Toilet Water Fill Valve part number 7381125-400.0070A,” and the Champion pages (the general one and the versions for the 3280.040 one-piece and 7381983-400 two-piece flush valves) point to the same part.
Its product page calls it the “Fill Valve Universal 400A-Repair Part” and says it “includes valve, shank washer, lock, coupling nuts, coupling washer, refill tube and refill tube clip.”
Toilet line
Fill valve (American Standard)
Flapper / seal (for the leak test)
Flush valve
Cadet (not the pressure-assisted version)
7381125‑400.0070A
3-inch Toilet Tank Flapper Valve Set 7381193‑200.0070A
The part:American Standard Toilet Fill Valve, Universal 400A Tank Repair Part. The Amazon listing title now prints the 7381125-400.0070A number, and its bullets repeat American Standard’s own description (“includes valve, shank washer, lock, coupling nuts, coupling washer, refill tube and refill tube clip”) and add “Check your model toilet for compatibility.” American Standard’s own store still showed the part as not available for sale on its website when I checked on November 11, 2026.
Step 3: Flush It Out Before You Replace It
American Standard’s standing advice is to clear the valve first: “Sometimes debris can get stuck inside the fill valve causing it to run continuously.” Its method: “if the fill valve will not turn off, remove the cap assembly and inspect for debris in the valve body seat. Use an inverted cup over the uncapped valve body and turn the water on all the way for three or four seconds then turn off. Do this twice to rinse out the valve. Remove and clean the seal and the cap assembly then reinstall.” If it still runs after that, replace it.
Step 4: Replace the Fill Valve
American Standard’s own steps for the 7381125-400.0070A, in its order: “Turn off the water supply and disconnect the hose from the bottom of the tank. Remove as much water from the tank as possible by flushing continuously. Remove all remaining water in the tank by using a cup and/or a sponge. Unfasten the plastic nut from the inlet valve. Remove the tank lid from the tank. Disconnect the refill tube from the overflow tube on the flush valve. Remove the old fill valve and replace it with the new fill valve. Attach the fill tube to the overflow tube on the flush valve. Fasten the plastic nut securely to the bottom of the fill valve. Reconnect the hose to the bottom of the tank, turn the water supply on, and return the lid to the tank.” Then: “It may be necessary to adjust the water level for the fill valve after installation.”
Check the chain first on a Champion: American Standard says “Before replacing any toilet parts, first check the flush valve chain. It is set correctly if the flush valve opens instantly when you push the handle and closes securely the moment you let go. The chain should be taut with no slack, but still long enough to allow the valve to form a complete seal.”
Finding the Model Number
The fill valve is universal, but the flapper, flush valve and especially the trip lever are not; American Standard says “trip levers are unique to the specific toilet tank, so locating the toilet model number will be necessary.” Its directions: “Carefully remove the tank lid, and place it gently on the floor. You’ll notice a four-digit number located on the back of the tank, near the water level mark. This number will be stamped into the china or as a stamp with a barcode. This is the tank model number. If the number starts with a two, it is a one-piece toilet. If the number starts with a four, it is a two-piece toilet.” With that number you can search its parts store, and American Standard also publishes a ‘Toilet Replacement Parts Service Guide.’
American Standard’s parts store also lists a second fill valve, the 7381334-400.0070A “FILL VALVE – WDI,” with no description of which toilets it fits. None of the support pages I read name it, so if your tank came with a WDI-marked valve, confirm the part against your tank number before ordering.
One alternative worth knowing about: Fluidmaster 400H Universal Toilet Fill Valve, if you would rather fit a generic universal valve. Fluidmaster lists it for 2 in. and 3 in. flush valve toilets that use 1.28 to 3.5 gallons per flush; its 400A is the Fluidmaster pick for toilets made before 1994 that use 3.5 to 7 gallons. My Korky vs Fluidmaster comparison covers the universal options.
The Two Fill Valves on This Page
These are the two fill valves this page links. For a Cadet, VorMax or Champion, American Standard names its own part first.
Product photo from Amazon.
American Standard 7381125‑400.0070A fill valve
The part American Standard names for Cadet, VorMax and Champion
The genuine American Standard universal fill valve, the one its Cadet, VorMax and Champion support pages all name. The Amazon listing carries the 7381125-400.0070A number and lists the valve, shank washer, lock, coupling nuts, coupling washer, refill tube and refill tube clip in the box.
Fluidmaster’s universal valve for 2 in. and 3 in. flush valve toilets that use 1.28 to 3.5 gallons per flush, with a height that adjusts from 9 to 14 in., tank and bowl water level dials, and a 7-year limited warranty. Fluidmaster warns that in-tank drop-in cleaners with bleach or chlorine damage tank parts and void the warranty.
Turn the supply off first and confirm it is off before you loosen anything. If a shutoff valve will not close, or the tank or pipe is cracked, stop and call a licensed plumber.
This page covers every Cadet except the pressure-assisted version, which American Standard leaves out of its Cadet and VorMax repair list. If the tank holds a sealed pressure vessel instead of an open flapper, confirm the parts with American Standard or a plumber before ordering.
FAQ
What fill valve does an American Standard Cadet 3 use?
American Standard names the Universal Toilet Water Fill Valve, part number 7381125-400.0070A, for all Cadet models except the pressure-assisted version, and for the VorMax and Champion lines as well.
What fill valve does an American Standard Champion use?
The same 7381125-400.0070A universal fill valve. American Standard’s Champion pages for both the 3280.040 one-piece flush valve and the 7381983-400 two-piece flush valve point to it.
How do I know if the fill valve is bad on an American Standard toilet?
Do its overnight leak test: fill the tank, shut the supply, mark the level and check in the morning. If the level did not drop, the fill valve is the likely fault, especially if water runs over the overflow tube, the valve hisses, or the tank fills in fits and starts.
Where is the model number on an American Standard toilet?
Inside the tank, on the back wall near the water level mark: a four-digit number stamped into the china or on a barcode stamp. A number starting with 2 is a one-piece toilet; 4 is a two-piece.
Can I fix a running American Standard fill valve without replacing it?
Sometimes. American Standard says to remove the cap assembly, check the seat for debris, hold an inverted cup over the open valve body and turn the water on full for three or four seconds, twice, then clean the seal and cap and reinstall. Replace the valve if it still runs.
Why Trust Plumbing Picks
I’m Isaac Daniels, a licensed Georgia journeyman plumber, and I write Plumbing Picks. In my 7 years of experience, these are the products I’d install. Every part number, model list, size, setting and fit on this page comes from the manufacturer pages and documents listed below, which I opened and read; product details come from those makers and from the Amazon listings. Each linked product was sold by Amazon, new and in stock, when I checked on November 11, 2026.
Where a link goes to Amazon I may earn a commission at no extra cost to you. Nobody pays to be included here. More on who writes this and how I pick. Picks follow the method in How I pick: maker documents, parts availability and fit, never commission rates.
Part details for the 7381125-400.0070A and Fluidmaster 400H listings, read from Amazon’s product data on Nov 11, 2026.
U.S. Consumer Product Safety Commission recall search for American Standard, Fluidmaster and toilet fill valves (Nov 11, 2026): no recall on either part.
Bottom Line
Leak test first, cup of water second, new valve third. For a Cadet, VorMax or Champion, the fill valve is the 7381125-400.0070A universal; the flapper and flush valve are line-specific, and the trip lever needs the four-digit tank number from inside the tank. So does the tank-to-bowl kit; my tank-to-bowl gasket guide lists it by tank.
