For a 4-inch bathroom sink, pick the Delta Foundations B501LF. In the kitchen, pick the B1310LF for three holes or the B4410LF for four holes with a side spray. For the tub and shower on a MultiChoice valve, pick the BT13410.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares four Delta Foundations pieces using Delta’s own spec sheets.
Delta Foundations faucets compared (Delta spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Use | Flow | Fits | Max deck |
|---|---|---|---|---|
| B501LF | Bath, single handle | 1.2 gpm | 3 holes, 4 in. centers | 1-1/4 in. |
| B1310LF | Kitchen, single handle | 1.8 gpm | 3 holes, 8 in. centers | 1-7/16 in. |
| B4410LF | Kitchen, side spray | See sheet | 4 holes, 8 in. centers | 1-3/8 in. |
| BT13410 | Tub and shower trim | 1.75 gpm head | Delta MultiChoice R10000 valve | n/a |
Foundations is a Delta collection with bathroom, kitchen and shower pieces. The sink and kitchen faucets here use Delta’s rotating stainless steel ball control with replaceable non-metallic seats, and the sheets say all operating parts can be replaced from the top. Each sheet lists a lifetime limited warranty on parts and finish for home use, with shorter terms for commercial use. The B510LF, a sister single-handle bath faucet on the same sheet, is in our bathroom faucet guide.
Delta Foundations B501LF: single-handle centerset
Choose the Foundations B501LF for a three-hole bathroom sink with 4-inch centers and one lever. Delta’s spec sheet (media.deltafaucet.com) covers the B501LF and B510LF and lists a solid brass body, 1.2 gpm for the B501LF, exposed mounting on three-hole sinks with 4-inch centers, a metal pop-up drain, 1/4-inch O.D. copper supply tubing with 1/2-14 NPSM connections, and a handle that returns to neutral when the valve is off. The drawing shows a 4-1/4-inch reach, a 7-1/8-inch overall height to the handle, holes of 1-1/8 to 1-1/2 inches and a 1-1/4-inch maximum deck, with 2-1/2 inches recommended to the back splash.
On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model B501LF, chrome.
Check Delta Foundations B501LF bathroom faucet on Amazon →
Delta Foundations B1310LF: single-handle kitchen faucet
Choose the Foundations B1310LF for a basic three-hole kitchen sink with no sprayer. Delta’s spec sheet (media.deltafaucet.com) lists 1.8 gpm, a spout that swings 360 degrees, interchangeable hot and cold stems, 1/2-14 NPSM threaded male inlet adapters and a lever on the ball-type control. The drawing shows a 9-7/16-inch spout, 5-1/2 inches from deck to the spout outlet, 8-3/8 inches to the top of the handle, a 10-3/4-inch deck plate on 8-inch centers, holes of 1-5/16 to 1-1/2 inches and a 1-7/16-inch maximum deck.
On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model B1310LF, chrome.
Check Delta Foundations B1310LF kitchen faucet on Amazon →
Delta Foundations B4410LF: kitchen faucet with side spray
Choose the Foundations B4410LF if your sink has a fourth hole for a side spray. Delta’s spec sheet (media.deltafaucet.com) lists an 8-inch centerset, a 9-1/2-inch-long spout that is 6-5/8 inches high and swings 360 degrees, 1/2-14 NPSM threaded inlet adapters, the lever ball-type control and a side spray. The drawing shows holes of 1-5/16 to 1-1/2 inches and a 1-3/8-inch maximum deck, with 2-1/2 inches recommended to the back splash. This older sheet shows a flow chart rather than a single flow figure, so check the rating printed on the faucet.
On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model B4410LF, chrome.
Check Delta Foundations B4410LF kitchen faucet with spray on Amazon →
Delta Foundations BT13410: tub and shower trim
Choose the Foundations BT13410 for a matching tub and shower on a Delta MultiChoice valve. Delta’s spec sheet (media.deltafaucet.com) covers the Monitor 13 Series trims: BT13010 valve only, BT13210 shower only and BT13410 tub and shower. It lists a 1.75 gpm at 80 psi shower head, use with the MultiChoice Universal rough valve body (R10000 series), back-to-back installation capability, a temperature-only handle with a field-adjustable limit into the hot zone, 120 degrees of handle rotation, parts replaceable from the front, and a 1/2-14 threaded tub spout. Delta describes the Monitor 13 trim as pressure balanced.
The valve is sold separately. Delta lists an RP77991 stem extension kit for an extra 1-3/4 inches of wall. On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model BT13410, chrome. See our Delta MultiChoice trim guide for valve checks.
Check Delta Foundations BT13410 tub and shower trim on Amazon →
Check these before you order
- Hole count. The B501LF needs three holes on 4-inch centers; the B1310LF needs three on 8-inch centers; the B4410LF needs four, including the spray.
- Deck thickness. All three sink faucets top out between 1-1/4 and 1-7/16 inches, so thick stone tops may be too deep.
- Shower valve. The BT13410 needs a Delta MultiChoice R10000 rough valve in the wall.
- Tub spout. The BT13410 spout threads onto a 1/2-inch pipe; check the stub coming out of your wall, and note whether it is threaded or plain copper before install day.
- Back splash. Delta recommends 2-1/2 inches behind the B501LF and B4410LF.
Service parts and repairs
The Foundations sink and kitchen sheets describe a control that is built to be serviced: the sheets say all operating parts can be replaced from the top, and the rotating stainless steel ball sits on replaceable non-metallic seats. So a worn seat can be replaced from above the counter without changing the whole faucet. On the B501LF and B510LF sheet, Delta notes that models with PPU have a plastic pop-up and models with LH have no drain and no lift rod hole, so check the suffix if you order a replacement drain.
The shower trim sheet lists its own parts by number, including the RP102064 1.75 gpm shower head, and says the face of the valve’s plaster guard should be flush with the finished wall. If your wall is thicker, Delta’s RP77991 kit adds 1-3/4 inches of stem; for special finishes, Delta says to also order RP12630 escutcheon screws.
Which Foundations piece should you buy?
In the bathroom, the B501LF fits the common 4-inch sink. In the kitchen, pick the B1310LF for three holes or the B4410LF if a fourth hole is waiting for a sprayer. In the shower, the BT13410 dresses a MultiChoice valve. The Amazon listings we checked show Foundations pieces in chrome and in stainless, marked with an SS suffix, such as B1310LF-SS and BT13410-SS, so you can match the kitchen and bath to the same tone.
Quote the full model number with its suffix when you order, because the finish is part of the part number. For more Delta options, see our Delta kitchen faucet guide and our Delta bathroom faucet guide.
Frequently asked questions
What control does the Delta Foundations faucet use?
A rotating stainless steel ball with replaceable non-metallic seats, per the sheets.
What valve does the Delta Foundations shower trim need?
The Delta MultiChoice Universal rough valve body, R10000 series.
Does the Foundations kitchen faucet have a sprayer?
The B4410LF has a side spray; the B1310LF does not.
What is the flow rate of the Foundations bathroom faucet?
1.2 gpm at 60 psi for the B501LF.
Does the B501LF include a drain?
Yes, a metal pop-up drain, per Delta.
How we chose
This document-based guide makes no hands-on testing claim. We read Delta’s spec sheets for the B501LF, B1310LF, B4410LF and BT13010 series in a browser and viewed the drawings. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Delta Foundations B501LF/B510LF spec sheet (media.deltafaucet.com): 4 in. centers, ball control, 1.2 gpm.
- Delta Foundations B1310LF spec sheet (media.deltafaucet.com): 3-hole kitchen, 1.8 gpm, 360 spout.
- Delta Foundations B4410LF spec sheet (media.deltafaucet.com): 4-hole kitchen with spray.
- Delta Foundations BT13010 series spec sheet (media.deltafaucet.com): Monitor 13 trims, R10000.
