For a widespread sink, pick the Delta Nicoli 35749LF for an arched spout or the 35849LF for a squared one. For one hole, pick the 15849LF. For the kitchen, pick the 19868LF U-spout pull-down.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares four Delta Nicoli faucets using Delta’s own spec sheets.
Delta Nicoli faucets compared (Delta spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Use | Spout | Height / outlet | Max deck |
|---|---|---|---|---|
| 35749LF | Widespread bath, 6 to 16 in. | Arched, 5 in. reach | 8-5/8 in. / 5-13/16 in. | 2-3/8 in. |
| 35849LF | Widespread bath, 6 to 16 in. | Squared, 5-1/4 in. reach | 8-3/16 in. / 5-7/8 in. | 2-3/8 in. |
| 15849LF | Single-handle bath | 9-1/16 in. overall length | 8-1/16 in. / 4-7/8 in. | 3 in. |
| 19868LF | Pull-down kitchen | 9-1/8 in. reach | 15-1/4 in. / 8-7/8 in. | 2-1/2 in. |
Nicoli is a Delta collection with bath and kitchen faucets. The pull-down 19867LF is already in our Delta kitchen faucet guide, so this page covers four other Nicoli models. Every sheet here lists a lifetime limited warranty on parts and finish for home use, 10 years for multifamily and 5 years for other commercial use, and 2-1/2 inches of recommended clearance to the back splash.
Delta Nicoli 35749LF-SS: widespread with arched spout
Choose the Nicoli 35749LF for a widespread sink and a tall arched spout. Delta’s spec sheet (media.deltafaucet.com) lists a solid brass spout, a three-hole mount on 6- to 16-inch centers, interchangeable hot and cold stems, 1/4-turn handle stops, a rotating cylinder control with a stainless steel plate and 90-degree rotation, 1.2 gpm, 1/2-14 NPSM connections and a plastic push pop-up with overflow (RP100766). The drawing shows a 5-inch reach, an 8-5/8-inch height, 5-13/16 inches from deck to outlet, holes of 1-1/4 to 1-1/2 inches and a 2-3/8-inch maximum deck.
Both widespread drawings show the same RP100766 drain, so the drain part is shared between them. On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model 35749LF-SS, stainless.
Check Delta Nicoli 35749LF-SS widespread faucet on Amazon →
Delta Nicoli 35849LF-CZ: widespread with squared spout
Choose the Nicoli 35849LF for the same widespread fit with a squared spout. Delta’s spec sheet (media.deltafaucet.com) lists a solid brass spout body, three-hole mounting on 6- to 16-inch centers, interchangeable stems, 1/4-turn stops, the same rotating cylinder control with replaceable non-metallic seats, 1.2 gpm and a plastic push pop-up drain with overflow. The drawing shows a 5-1/4-inch reach, an 8-3/16-inch height, 5-7/8 inches from deck to outlet, holes of 1-3/16 to 1-1/2 inches and a 2-3/8-inch maximum deck.
One small note: the file is labeled Rev E but the sheet inside prints Rev D. Delta’s 35849LF-CZ product page links this sheet. On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model 35849LF-CZ, Champagne Bronze.
Check Delta Nicoli 35849LF-CZ widespread faucet on Amazon →
Delta Nicoli 15849LF-CZ: single handle
Choose the Nicoli 15849LF for one lever on a single-hole sink. Delta’s spec sheet (media.deltafaucet.com) lists 1.2 gpm, one- or three-hole mounting with the escutcheon included, 1/4-inch O.D. staggered PEX supply lines with 3/8-inch compression fittings, a ceramic disc cartridge and a plastic push pop-up drain (RP101631) with no lift rod hole. The drawing shows an 8-1/16-inch overall height, a 5-1/2-inch spout height, 4-7/8 inches from deck to outlet, a 9-1/16-inch overall length, holes of 1-1/8 to 1-1/2 inches, a 6-inch escutcheon and a 3-inch maximum deck.
On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model 15849LF-CZ, Champagne Bronze.
Check Delta Nicoli 15849LF-CZ single-handle faucet on Amazon →
Delta Nicoli 19868LF-SS: U-spout pull-down kitchen
Choose the Nicoli 19868LF for a kitchen faucet that matches the squared bath spout. Delta’s spec sheet (media.deltafaucet.com) lists 1.8 gpm, one- or three-hole mounting with the escutcheon included as an option, a ceramic disc cartridge, polymer braided supply hoses with 3/8-inch compression fittings, a 360-degree spout, a two-function wand (aerated stream or spray), Touch-Clean spray holes and MagnaTite docking.
The drawing shows a 15-1/4-inch height, a 9-1/8-inch reach, 8-7/8 inches from deck to outlet, a 10-3/4-inch escutcheon on 8-inch centers, holes of 1-5/16 to 1-1/2 inches and a 2-1/2-inch maximum deck. A second drawing shows it mounted on the optional escutcheon, which adds about 1/2 inch, bringing the height to 15-3/4 inches and the outlet to 9-7/16 inches. Use those figures if you cover three holes.
On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model 19868LF-SS, stainless.
Check Delta Nicoli 19868LF-SS kitchen faucet on Amazon →
Controls, cartridges and connections
The Nicoli sheets show two kinds of control. The two widespread faucets use what Delta calls a rotating cylinder type control with a stainless steel plate and 90-degree rotation, with replaceable non-metallic seats and 1/4-turn handle stops. Delta says the hot and cold stems are interchangeable, which keeps spare parts simple. The single-handle 15849LF and the 19868LF kitchen faucet list a ceramic disc cartridge instead, with one lever for both temperature and volume.
The connections differ too. The widespread drawings show 1/2-14 NPSM inlets on the valves, so plan supply lines that thread onto those and reach your shutoff valves. The 15849LF comes with 1/4-inch O.D. PEX supply lines drawn about 27 to 28 inches long, ending in 3/8-inch compression fittings. The 19868LF uses polymer braided hoses with 3/8-inch compression fittings, drawn about 28 inches long.
Check the outlet size on your shutoff valves before you start so the connections match on install day. If you are swapping a faucet in an older vanity, also check the deck thickness: the widespread models top out at 2-3/8 inches, the single-handle at 3 inches and the kitchen faucet at 2-1/2 inches.
Check these before you order
- Spout shape. The 35749LF has an arched spout and the 35849LF a squared one; the kitchen 19868LF matches the squared look.
- Hole size. The 35749LF needs 1-1/4-inch minimum holes; the 35849LF accepts 1-3/16 inches.
- Drain. All three bath faucets list a plastic push pop-up; there is no lift rod.
- Cabinet clearance. The kitchen faucet stands 15-1/4 inches tall.
- Back splash. Every sheet recommends 2-1/2 inches behind the faucet.
Which Nicoli faucet should you buy?
For a widespread bathroom sink, choose between the arched 35749LF and the squared 35849LF; they share the same centers, control and deck range. For a single-hole sink, the 15849LF fits as is, and its included plate covers a three-hole sink. In the kitchen, the 19868LF U-spout continues the squared shape. The Amazon listings we checked show Nicoli in stainless (SS), Champagne Bronze (CZ), chrome and matte black (BL); match the suffix across rooms. For other Delta collections, see our Delta Trinsic guide and Delta Ashlyn guide.
Frequently asked questions
What is the flow rate of Delta Nicoli bathroom faucets?
1.2 gpm at 60 psi on the 35749LF, 35849LF and 15849LF sheets.
What spacing do Nicoli widespread faucets fit?
6 to 16 inches center to center.
Does the Nicoli single-handle faucet include a deck plate?
Yes. Delta lists the escutcheon as included.
What is the reach of the Nicoli U-spout kitchen faucet?
9-1/8 inches on the 19868LF drawing.
What is the difference between 35749LF and 35849LF?
Mainly the spout: arched on the 35749LF, squared on the 35849LF, with slightly different heights and hole sizes.
How we chose
This document-based guide makes no hands-on testing claim. We read Delta’s spec sheets for the 35749LF, 35849LF, 15849LF and 19868LF in a browser and viewed each drawing. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Delta Nicoli 35749LF spec sheet (media.deltafaucet.com): arched widespread, RP100766.
- Delta Nicoli 35849LF spec sheet (media.deltafaucet.com): squared widespread.
- Delta Nicoli 15849LF spec sheet (media.deltafaucet.com): single handle, escutcheon included.
- Delta Nicoli 19868LF spec sheet (media.deltafaucet.com): U-spout pull-down, 15-1/4 in.
