For a 4-inch sink, pick the Delta Ashlyn 2564. For a widespread sink, pick the 3564. For one hole, pick the 564. For the shower on a MultiChoice valve, pick the T14264 trim.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares four Delta Ashlyn pieces using Delta’s own spec sheets.
Delta Ashlyn faucets compared (Delta spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Fits | Reach / height | Max deck | Back splash clearance |
|---|---|---|---|---|
| 2564 centerset | 3 holes, 4 in. centers | 5-1/16 in. / 5-9/16 in. | 2-1/4 in. | 1-1/4 in. |
| 3564 widespread | 3 holes, 4-1/2 to 16 in. centers | 5-1/8 in. / 5-1/4 in. | 2-1/2 in. | 1-1/4 in. |
| 564 single-handle | 1 hole, or 3 with included plate | 5-1/8 in. / 7-3/4 in. | 2-7/8 in. | 2-1/2 in. |
| T14264 shower trim | Delta MultiChoice R10000 valve | Arm 5-1/2 in. long | n/a | n/a |
Ashlyn is a Delta bath collection with sink faucets and tub and shower trim. Every sheet here lists a lifetime limited warranty on parts and finish for home use, with 10 years for multifamily and 5 years for other commercial use. The sink faucets use diamond-coated ceramic cartridges and PEX supply lines, and each sheet lists a metal pop-up drain on the models covered here.
Delta Ashlyn 2564-SSMPU-DST: 4-inch centerset
Choose the Ashlyn 2564 for a three-hole sink with 4-inch centers. Delta’s spec sheet (media.deltafaucet.com) lists a two-handle three-hole mount, 1.2 gpm, a diamond-coated ceramic cartridge, 3/8-inch O.D. PEX supply lines with 3/8-inch compression fittings, and a metal pop-up drain on models without the TP suffix. The drawing shows a 9-inch overall width, a 5-1/16-inch reach, a 5-9/16-inch height, holes of 1 to 1-1/2 inches and a 2-1/4-inch maximum deck, which Delta says can be extended by 1-1/4 inches with RP76691.
It needs only 1-1/4 inches of clearance to the back splash, half of what the single-handle 564 asks for. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 2564-SSMPU-DST, stainless.
Check Delta Ashlyn 2564-SSMPU-DST centerset faucet on Amazon →
Delta Ashlyn 3564-MPU-DST: widespread
Choose the Ashlyn 3564 for a widespread sink, including narrow 4-1/2-inch spacing. Delta’s spec sheet (media.deltafaucet.com) lists a two-handle widespread three-hole mount on 4-1/2- to 16-inch centers, 1.2 gpm, diamond-coated ceramic cartridges, 1/4-turn handle stops, 3/8-inch PEX supply tubes and a metal push pop-up drain with overflow. The drawing shows a 5-1/8-inch reach, a 5-1/4-inch height, 4-1/8 inches from deck to outlet, 1-1/4-inch minimum holes and a 2-1/2-inch maximum deck.
On October 15, 2026, the standard new offer sold by eFaucets showed limited stock with model 3564-MPU-DST, chrome.
Check Delta Ashlyn 3564-MPU-DST widespread faucet on Amazon →
Delta Ashlyn 564-BLMPU-DST: single handle
Choose the Ashlyn 564 for one lever on a single-hole sink, or on three holes with the plate. Delta’s spec sheet (media.deltafaucet.com) lists 1.2 gpm aerated flow, one- or three-hole mounting with the escutcheon included, a diamond-coated ceramic cartridge, 1/4-inch O.D. staggered PEX supply lines, an optional red and blue indicator ring and a metal push pop-up drain. The drawing shows a 5-1/8-inch reach, a 7-3/4-inch spout height, an 8-1/8-inch overall height, 3-7/16 inches from deck to outlet, holes of 1-1/8 to 1-1/2 inches, a 6-inch escutcheon and a 2-7/8-inch maximum deck.
On October 17, 2026, the matte black 564-BLMPU-DST sold by Amazon.com showed “Temporarily out of stock” and was still taking orders. The Champagne Bronze version, 564-CZMPU-DST, showed stock sold by Amazon.com; confirm the finish code on the box when it arrives.
Check Delta Ashlyn 564-BLMPU-DST single-handle faucet on Amazon →
Check Delta Ashlyn 564-CZMPU-DST (Champagne Bronze) on Amazon →
Delta Ashlyn T14264-BL: shower trim
Choose the Ashlyn T14264 to match the shower to Ashlyn sink faucets, on a Delta MultiChoice valve. Delta’s spec sheet (media.deltafaucet.com) covers the Ashlyn Monitor 14 Series trims: T14064 valve only, T14164 tub only, T14264 shower only and T14464 tub and shower. It lists a 1.75 gpm Touch-Clean raincan shower head (RP64859), use with the MultiChoice Universal rough valve body (R10000 series), a 6-inch square escutcheon, a temperature-only handle with a field-adjustable hot limit, 120 degrees of rotation and a 5-1/2-inch shower arm. Delta describes the Monitor 14 trim as pressure balanced.
The valve is sold separately; Delta lists RP77991 for an extra 1-3/4 inches of wall. On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model T14264-BL, matte black. Our Delta MultiChoice trim guide covers valve checks.
Check Delta Ashlyn T14264-BL shower trim on Amazon →
Check these before you order
- Hole spacing. 4-inch centers take the 2564; 4-1/2 to 16 inches take the 3564; one hole takes the 564.
- Hole size. The 3564 needs 1-1/4-inch minimum holes; the 2564 accepts 1 to 1-1/2 inches.
- Back splash. The two-handle models need 1-1/4 inches; the 564 needs 2-1/2 inches.
- Shower valve. The T14264 needs a Delta MultiChoice R10000 rough valve.
- Drain suffix. On the 2564 sheet, TP models have a polypropylene pop-up body with a metal flange and cap; MPU models have a metal drain.
Parts, supply lines and tub options on the sheets
The Ashlyn sheets name the parts you may need later. The 2564 drawing shows two drains by suffix: RP26533 for MPU models and RP38958 for TP models, and lists RP76691 to extend the deck range. The 3564 and 564 drawings both show the RP101630 drain. Supply lines come attached and are drawn at different lengths: about 32 inches on the 2564, 39 inches on the 3564 and 35 to 36 inches on the 564, all ending in 3/8-inch compression fittings. Measure from the faucet to your shutoff valves if the sink sits high above them.
On the shower side, the same Ashlyn trim sheet covers a tub and shower version, the T14464, and lists two tub spouts: RP77091 with a pull-up diverter and RP77092 without one. Delta notes the tub port flows up to 6.0 gpm at 60 psi with the R10000-UNBX valve, and that LHD models come without a shower head if you want to use your own.
The sheet also lists back-to-back installation capability, a solid brass forged body, red and blue temperature marks on the handle, and all parts replaceable from the front of the valve, which matters when the back of the wall is finished.
Which Ashlyn piece should you buy?
Match the sink first. A 4-inch three-hole sink takes the 2564, which also needs the least room behind it. A widespread sink takes the 3564, which fits spacing as close as 4-1/2 inches. A one-hole or three-hole sink can take the 564 with its included plate. Then finish the shower with the T14264 on a MultiChoice valve. The Amazon listings we checked show Ashlyn in chrome, stainless (SS) and matte black (BL); the model suffix tells you which. For other Delta collections, see our Delta Cassidy guide and our Delta Trinsic guide.
Frequently asked questions
What is the flow rate of Delta Ashlyn faucets?
1.2 gpm at 60 psi on the 2564, 3564 and 564 sheets.
Does the Ashlyn single-handle faucet include a deck plate?
Yes. Delta lists the escutcheon as included for one- or three-hole mounting.
What spacing does the Ashlyn widespread fit?
4-1/2 to 16 inches center to center.
What valve does the Ashlyn shower trim need?
A Delta MultiChoice Universal rough valve body, R10000 series.
What does TP mean on an Ashlyn faucet?
On the 2564 sheet, TP models have a polypropylene pop-up drain body with a metal flange and cap.
How we chose
This document-based guide makes no hands-on testing claim. We read Delta’s spec sheets for the Ashlyn 2564, 3564, 564 and T14064 series in a browser and viewed the drawings. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Delta Ashlyn 2564-MPU-DST spec sheet (media.deltafaucet.com): centerset, RP76691, TP drain.
- Delta Ashlyn 3564-MPU-DST spec sheet (media.deltafaucet.com): widespread 4-1/2 to 16 in.
- Delta Ashlyn 564-MPU-DST spec sheet (media.deltafaucet.com): single handle, escutcheon included.
- Delta Ashlyn T14064 series spec sheet (media.deltafaucet.com): Monitor 14 trims, R10000, RP64859.
