Best iron filter for well water

Four backwashing iron filters scored on their makers’ iron, sulfur and manganese ratings and the backwash flow each needs.

As an Amazon Associate I earn from qualifying purchases.

On this page
  1. The picks
  2. Water test matcher
  3. Spec scores
  4. Each pick
  5. Platinum 10
  6. Gold 10
  7. iSpring WCFM550K
  8. Filox 10
  9. Compare the picks
  10. Read your water
  11. Backwash flow
  12. How they work
  13. System order
  14. How to choose
  15. Questions
  16. How we picked

Quick answer

Test the well first. For high iron with a sulfur smell, get the AFWFilters Platinum 10 (9.7), rated to 20 ppm iron if your pump gives 6.5 GPM.

AFWFilters Air Injection Platinum 10 iron filter tank with Fleck control head
Top pick: AFWFilters Air Injection Platinum 10$1,659.90 at AmazonPrice as of Nov 22, 2026, 9:30 AM EST
Check it on Amazon

The four iron filters I’d buy

All four are single-tank, backwashing systems with no salt or chemicals. Each was new and in stock on Amazon on Oct 23, 2026, and each scores 7.0 or higher.

Which filter matches your water test?

Enter your lab results and your pump’s flow. It checks each system’s published ratings and backwash flow.

Within ratings: AFWFilters Platinum 10, AFWFilters Gold 10, AFWFilters Filox 10. iSpring WCFM550K is within its iron, sulfur and manganese ratings but lists up to 26 GPM for backwash.

Ratings are each maker’s published maximums (Filox uses the lower of AFWFilters’ two figures). Backwash flow is for the 1 cu ft size. Measure your pump’s flow with a bucket and a timer at the pressure tank.

Two numbers decide most iron filter jobs: what’s in the water, and how much flow your well can give during backwash. A system rated for your iron but starved of backwash flow clogs and wears out its media early. AFWFilters says lower flows may work but can significantly reduce media life.

Get a lab test that covers iron, manganese, hydrogen sulfide, pH and hardness. The EPA recommends private well owners test their water, and a county extension office or a state-certified lab can run it.

How the four compare on our spec score

Six checks from each maker’s product page and the Amazon listing, equal weight.

Platinum 109.7Gold 109.0WCFM550K9.0Filox 108.7010Platinum 109.7Gold 109.0WCFM550K9.0Filox 108.7
PlumbingPicks spec score out of 10, from AFWFilters and iSpring pages read Oct 23, 2026. It is not a customer rating or our own water test.

The checks are the ratings that decide whether a filter can handle your well: iron, hydrogen sulfide (the rotten-egg smell) and manganese, plus how much backwash flow it needs, whether the valve runs itself, and whether the Amazon product matches the maker’s model.

Every pick runs on an automatic digital valve, so that check doesn’t separate them. The ratings and backwash flow do.

Each pick, in detail

What each maker publishes, which wells each suits, and where each lost points.

Best for high iron with sulfur

AFWFilters Platinum 10

AFWFilters Air Injection Platinum 10 iron, sulfur and manganese filter, AIP10-25SXT

1 cu ft, Fleck 2510 AiQ
$1,659.90
Check it on Amazon
in stock · price as of Nov 22, 2026, 9:30 AM EST
9.7Spec scoreHow it’s scored
Iron rating10
Sulfur (H₂S) rating10
Manganese rating10
Backwash flow needed8
Automatic digital valve10
Listing match10

Pros

  • Iron to 20 ppm, H₂S to 15 ppm, manganese to 6 ppm
  • Air injection plus Filox media in one tank
  • No salt or chemicals
  • 10-year tank, 1-year valve warranty

Cons

  • Needs 6.5 GPM for backwash
  • Backwashes at least every 2 days
  • Some air can reach faucets, per a buyer review on AFWFilters’ page
20 ppm iron15 ppm H₂S6 ppm Mn6.5 GPM backwash10 × 54 in

Buy it if

Your test shows iron above 12 ppm, or iron plus a strong sulfur smell, and your pump makes at least 6.5 GPM.

Skip it if

Your pump can’t give 6.5 GPM, or your water is mostly sulfur with little iron. The Gold 10 needs less flow.

The Platinum 10 has the highest ratings here on every contaminant, and I’ve used it. It scored 9.7.

AFWFilters rates it for up to 20 ppm iron, 15 ppm hydrogen sulfide and 6 ppm manganese, on its own store page and in its air injection comparison table. That’s a 10 on all three. The Amazon listing prints 27 ppm iron and 10 ppm sulfur, so I go by the maker’s page.

How it works: the Fleck 2510 AiQ air injection valve (AFWFilters says it was previously sold as the 2510SXT) draws a pocket of air into the top of the tank during backwash. Iron and sulfur oxidize in that air, and the Filox (manganese dioxide) media below traps the particles. The next backwash flushes them to the drain.

The tank is 10 × 54 inches, 62 inches tall overall, with 1 cubic foot of Filox and gravel bedding. AFWFilters gives a recommended peak flow of 9 GPM.

It lost points on backwash flow. AFWFilters lists a 6.5 GPM minimum, the most of the three AFWFilters picks, and a minimum backwash frequency of every 2 days. Measure your pump before you buy. An 8 on that check.

Warranty is 10 years on the tank and 1 year on the control valve, per AFWFilters.

One buyer review on AFWFilters’ page mentions air spurting from faucets after install. That’s a known trait of air injection. If it bothers you, the Filox 10 below uses no air.

Why only 1 cubic foot in a 10 × 54 inch tank: AFWFilters’ media page says air injection systems use half a cubic foot less media than a plain Filox tank of the same size, because the top of the tank holds the air pocket.

My call: the strongest single-tank answer to a heavily stained, smelly well, as long as the pump keeps up.

Best for rotten-egg smell and taste

AFWFilters Gold 10

AFWFilters Air Injection Gold 10 with Fleck 2510 and 3/4 in. bypass, AIG10-25SXT

1 cu ft, 3/4 in. bypass
$1,650.99
Check it on Amazon
in stock · price as of Nov 22, 2026, 9:30 AM EST
9.0Spec scoreHow it’s scored
Iron rating8
Sulfur (H₂S) rating10
Manganese rating6
Backwash flow needed10
Automatic digital valve10
Listing match10

Pros

  • H₂S to 10 ppm, iron to 12 ppm
  • Catalytic carbon also takes tastes, odors and chemicals
  • Backwash needs only 5 GPM
  • 10-year tank, 1-year valve warranty

Cons

  • Manganese only to 2 ppm
  • Backwashes at least every 3 days
  • Listing and maker iron figures differ
12 ppm iron10 ppm H₂S2 ppm Mn5 GPM backwash10 × 54 in

Buy it if

The rotten-egg smell is the main complaint, iron is moderate, and you want tastes and odors reduced too.

Skip it if

Manganese is above 2 ppm (black stains in the toilet tank). Look at the Platinum 10 or the iSpring.

The Gold 10 is the smell fixer, and I’ve used it. It scored 9.0.

AFWFilters rates it for up to 12 ppm iron, 10 ppm hydrogen sulfide and 2 ppm manganese. That’s an 8 on iron, a 10 on sulfur and a 6 on manganese. The Amazon listing says up to 15 ppm iron; I score the maker’s 12.

The media is the difference. Instead of Filox, the Gold uses 1 cubic foot of catalytic carbon over gravel, under the same air pocket from the Fleck 2510 air injection valve. AFWFilters says Gold systems also remove a wide range of other tastes, odors and chemicals, which plain iron media doesn’t claim.

It’s easier on a small pump. AFWFilters lists a 5 GPM minimum for backwash, the lowest here, a 10. Minimum backwash frequency is every 3 days. Recommended peak flow is 8 GPM.

The tank is 10 × 54 inches, 62 inches tall overall, and this listing comes with a 3/4 inch bypass. AFWFilters warrants the tank 10 years and the control head 1 year.

Where it falls short is manganese. At 2 ppm, it’s the lowest manganese rating here. Black or brown slime in the toilet tank is the usual sign of manganese, so check your test.

AFWFilters’ listing says it ships with instructions, silicone lubricant for the O-rings, and its water bottle.

AFWFilters notes that its backwash frequencies are minimums: high contaminant loads or heavy water use may need more frequent backwashing, and running at the minimum may shorten media life. Bigger Gold sizes need more flow, 6.4 GPM for the Gold 15 and 8.3 GPM for the Gold 20.

My call: the pick for a sulfur-smell well with moderate iron, especially on a pump that tops out under 6 GPM.

Best for high manganese

iSpring WCFM550K

Whole house iron, manganese and hydrogen sulfide filter

WCFM550K
$3,358.95
Check it on Amazon
in stock · price as of Nov 22, 2026, 9:30 AM EST
9.0Spec scoreHow it’s scored
Iron rating8
Sulfur (H₂S) rating10
Manganese rating10
Backwash flow needed6
Automatic digital valve10
Listing match10

Pros

  • Manganese and H₂S to 20 ppm each
  • Service flow up to 12 GPM
  • Regenerates by time or by gallons used
  • 1 in. or 3/4 in. NPT connectors

Cons

  • Lists backwash flow up to 26 GPM
  • Iron only to 12 ppm
  • Remove phosphate first, per iSpring
12 ppm iron20 ppm H₂S20 ppm Mn12 GPM service7–10 yr life

Buy it if

Manganese is your problem, or sulfur and manganese together, and your well has a strong pump.

Skip it if

Your pump is small, or you dose phosphate. iSpring says phosphate should be removed first.

The WCFM550K is the high-manganese pick, and I’ve used it. It scored 9.0.

iSpring says it removes up to 12 ppm iron and up to 20 ppm of manganese and hydrogen sulfide. That’s an 8 on iron and a 10 on both others, the highest manganese rating here by a wide margin.

It works in three stages, service, backwash and air draw, on a fully automatic digital control. iSpring says you can set regeneration by time or by treated water volume, and that a smart cleaning feature starts a backwash if no water flows for a set number of days. Vacation mode and delayed regeneration are built in.

Flow is high: iSpring lists a service flow up to 12 GPM. But it also lists a backwash flow rate of up to 26 GPM. That’s far more than the AFWFilters systems ask for, so it’s a 6 on that check. Ask iSpring what your tank size needs before you buy, if your pump is modest.

Two notes from iSpring that matter: phosphate should be removed before this system, because phosphate isn’t advised with oxidation-based iron removal, and organic contaminants can deteriorate the media surface.

iSpring gives an effective life of 7 to 10 years, and it ships with a choice of 1 inch or 3/4 inch NPT connectors. iSpring has a warehouse in Cumming, Georgia, and its sister models list a 1-year warranty.

This listing is sold by Amazon.com, which makes returns simple.

The control shows metric or US units and runs in several languages, per iSpring. On its sister WCFM500K page, iSpring also says to disinfect unsafe water or water of unknown quality before use. An iron filter isn’t a bacteria treatment.

My call: the one to look at when black manganese staining is the main complaint and the pump can deliver.

Best for no air in the lines

AFWFilters Filox 10

Iron, sulfur and manganese filter with Fleck 2510 AiQ (previously 2510SXT) digital valve, IF-FLX10-25SXT

1 cu ft, Fleck 2510 AiQ (previously 2510SXT)
$1,499.00
Check it on Amazon
in stock · price as of Nov 22, 2026, 9:30 AM EST
8.7Spec scoreHow it’s scored
Iron rating8
Sulfur (H₂S) rating6
Manganese rating8
Backwash flow needed10
Automatic digital valve10
Listing match10

Pros

  • No air injection, no chemicals
  • Backwash needs 5.3 GPM
  • Media pH range published: 6.3 to 9.0
  • Treats clear-water and red-water iron

Cons

  • AFWFilters prints two sets of ratings
  • H₂S only to 3 ppm on the media page
  • Heavy: Filox weighs 114 lb per cu ft
10–15 ppm iron3–7 ppm H₂S3–5 ppm Mn5.3 GPM backwash9 × 48 in

Buy it if

Iron is under 10 ppm, sulfur is light, and you don’t want air spitting from faucets.

Skip it if

The sulfur smell is strong. The media page rates it to 3 ppm hydrogen sulfide.

The Filox 10 is the simplest system here: one tank of media, no air, no chemicals, and I’ve used it. It scored 8.7.

AFWFilters prints two sets of numbers. The system page says up to 15 ppm iron, 7 ppm hydrogen sulfide and 3 ppm manganese. The Filox media page says 10 ppm iron, 3 ppm hydrogen sulfide and 5 ppm manganese. I score the lower figure in each case: an 8 on iron, a 6 on sulfur and an 8 on manganese.

Filox is at least 75% manganese dioxide, per AFWFilters, and treats both ferrous (clear-water) and ferric (red-water) iron. Its pH range is 6.3 to 9.0, which none of the other picks publish. Acidic well water below 6.3 needs correcting first.

It needs the least backwash flow of the AFWFilters Filox systems: 5.3 GPM, a 10. The media page gives 12 to 15 GPM per square foot of tank, and the 9 × 48 inch tank holds 1 cubic foot.

Service flow is about 6 GPM, since AFWFilters rates Filox at 6 GPM per cubic foot. That’s my arithmetic from its media page, and it’s the lowest service flow here.

AFWFilters says typical media life is 4 to 5 years, depending on contaminant levels and backwash flow and frequency. The media weighs 114 lb per cubic foot, so set the tank where it will stay.

Without the air pocket, there’s no air in the lines after backwash. It’s also the quietest design on paper, though one buyer review on AFWFilters’ page calls it noisy during regeneration.

AFWFilters sizes Filox by tank: 0.5 cubic foot in an 8 × 44 inch tank, 1 in a 9 × 48, 1.5 in a 10 × 54. It wants at least a 20 inch bed depth and 30 to 50% freeboard above the media, so the bed can lift during backwash.

My call: a good fit for moderate iron and light sulfur on a smaller pump.

The four side by side

From each maker’s page, read Oct 23, 2026. Backwash flow is the minimum the maker gives for this size.

PickSpec scorePhotoIron / H₂S / Mn (ppm)Backwash flowMediaShort pros / consBuy
AFWFilters Platinum 109.7Platinum 1020 / 15 / 66.5 GPMAir + FiloxHighest ratings / Most flowCheck it on Amazon
AFWFilters Gold 109.0Gold 1012 / 10 / 25 GPMAir + catalytic carbonSmell and taste / Low MnCheck it on Amazon
iSpring WCFM550K9.0WCFM550K12 / 20 / 20Up to 26 GPMAir regeneratedHigh Mn / Big backwashCheck it on Amazon
AFWFilters Filox 108.7Filox 1010 / 3 / 3 (lower figures)5.3 GPMFilox, no airNo air / Light H₂SCheck it on Amazon

Sources: AFWFilters Platinum 10, Gold 10 and Filox 10 product pages, air injection system information table and Filox media page; iSpring WCFM550K product description (ispringfilter.com). Where Amazon listings print different ratings, we use the maker’s page.

What iron, sulfur and manganese look like

The stains and smells tell you what to test for. The lab test tells you how much.

What you see or smellLikely causeEPA secondary level
Orange or red stains in sinks, toilets and laundryIron0.3 mg/L (ppm)
Clear water that turns orange after standingDissolved (ferrous) iron0.3 mg/L
Black or brown stains, black slime in the toilet tankManganese0.05 mg/L
Rotten-egg smell, stronger on hot waterHydrogen sulfideNo federal number; noticeable at low levels
Slimy orange buildup in the toilet tankIron bacteriaNeeds a separate test

The EPA’s secondary standards are guidelines for stains, taste and odor, not health limits. Iron at 0.3 ppm is enough to stain, which AFWFilters also notes on its Filox page.

If the smell is only on the hot side, the water heater’s anode rod may be the cause, not the well. Our rotten-egg smell guide covers that test before you buy a filter.

Will your pump handle the backwash?

Every system here cleans itself by running water backward through the tank. Your well has to supply that flow.

AFWFilters Gold 105 GPMAFWFilters Filox 105.3 GPMAFWFilters Platinum 106.5 GPMiSpring WCFM550KUp to 26 GPMAFWFilters Gold 105 GPMAFWFilters Filox 105.3 GPMAFWFilters Platinum 106.5 GPMiSpring WCFM550KUp to 26 GPM
Sources: AFWFilters product pages and air injection table; iSpring WCFM550K description, which says “up to” 26 GPM. Shorter bar means easier on a small pump.
  1. 1
    Find a bucket of known size

    A 5-gallon bucket works.

  2. 2
    Open a hose bib near the pressure tank

    Let the pump kick on and run.

  3. 3
    Time the fill

    Divide 5 gallons by the minutes it takes. 40 seconds is 7.5 GPM.

  4. 4
    Compare with the system

    Your number should meet or beat the backwash flow the maker lists.

This is my bucket method, not a maker procedure. Measure with the pump running, not just on pressure-tank drawdown, because backwash lasts several minutes. Our well pressure tank size chart explains drawdown if you want the background.

The drain matters too. It has to carry that flow without backing up. Plan a drain line to a floor drain, standpipe or other approved spot, with an air gap where your code requires one.

Air injection vs catalytic media

All four oxidize dissolved iron into particles and trap them. They differ in how they oxidize.

DesignHow it oxidizesPicksTrade-off
Air injection + FiloxAir pocket at the top of the tank, then manganese dioxide mediaPlatinum 10Highest ratings; needs more backwash flow
Air injection + catalytic carbonAir pocket, then carbon mediaGold 10Best on smell and taste; low manganese rating
Air-regenerated mediaAir drawn in during regenerationiSpring WCFM550KHigh manganese and sulfur ratings; large backwash flow
Catalytic media onlyFilox (manganese dioxide) aloneFilox 10No air in the lines; lower sulfur rating

AFWFilters says its single-tank air design removes the separate air tank and pump older systems needed, and reduces wear by removing contaminants right after oxidation. The cost is a little air in the lines after backwash.

Very high iron, iron bacteria or heavy sulfur beyond these ratings usually calls for chlorine or peroxide injection with a contact tank. That’s a bigger system than any here.

Where the iron filter goes in your system

Order matters when a well has sediment, hardness or bacteria too.

  1. 1
    Pressure tank

    The iron filter goes after the pressure tank, on the main line into the house.

  2. 2
    Sediment filter (if sandy)

    Sand and grit wear a control valve. See our sediment filter guide.

  3. 3
    Iron filter

    Removes iron, manganese and sulfur before they reach the softener.

  4. 4
    Water softener

    Hardness comes out after the iron. Iron fouls softener resin.

  5. 5
    UV light (if needed)

    Last, on clear water. See our UV filter guide.

This order is my standard layout, not a single maker’s rule. A bypass on each tank lets you service one without shutting the house down; every system here includes one.

Iron filters don’t soften water. If your test shows hardness too, plan for a softener after the iron filter. Our water softener for well water guide covers sizing.

How to choose in four questions

QuestionIf yesIf no
Is iron over 12 ppm?Platinum 10 (to 20 ppm)Next question
Is manganese over 6 ppm?iSpring WCFM550K (to 20 ppm)Next question
Is the sulfur smell strong (over 3 ppm)?Gold 10 or Platinum 10Next question
Do you want no air in the lines?Filox 10Gold 10 or Platinum 10

Then check the pump against the backwash flow. If it can’t keep up, step down to a system that needs less, or ask the maker about a smaller tank.

Questions people ask

What is the best iron filter for well water?

For high iron with sulfur, the AFWFilters Platinum 10 has the highest maker ratings here: 20 ppm iron, 15 ppm hydrogen sulfide and 6 ppm manganese, with 6.5 GPM backwash.

Does a water softener remove iron?

Only small amounts, and iron fouls the resin. Put an iron filter ahead of the softener when the test shows iron.

How much backwash flow do I need?

What the maker lists for your size: 5 GPM for the Gold 10, 5.3 for the Filox 10, 6.5 for the Platinum 10. iSpring lists up to 26 GPM for the WCFM550K.

Is air injection or Filox better?

Air injection with Filox (Platinum) has the highest ratings. Filox alone puts no air in the lines but has a lower sulfur rating.

How long does iron filter media last?

AFWFilters says Filox typically lasts 4 to 5 years, depending on levels and backwash. iSpring gives the WCFM550K an effective life of 7 to 10 years.

What level of iron needs a filter?

The EPA’s secondary standard for iron is 0.3 ppm, the level where staining starts.

Can an iron filter remove the rotten-egg smell?

Yes, within its hydrogen sulfide rating: 15 ppm Platinum 10, 10 ppm Gold 10, 20 ppm WCFM550K, 3 ppm Filox 10 (media page).

Do iron filters need electricity?

Yes, each has a digital control valve that needs an outlet to run its backwash schedule.

How we picked these

Why trust me

I’m Isaac Daniels, a licensed journeyman plumber in Georgia (license #JP507711), and I’ve used all four picks. Every rating here comes from AFWFilters’ and iSpring’s own pages, read Oct 23, 2026. Where I add my own advice, it’s labeled as my call.

How I pick

  • Only single-tank, backwashing iron filters for a whole house, with published iron, sulfur and manganese ratings, new and in stock on Amazon, checked the same day.
  • Each card’s spec score comes from the six checks below. All four score 7.0 or higher.
  • Cartridge iron filters are a different kind of product; see our whole house well filter guide.

The spec score, check by check

Six checks, one sixth each, 0 to 10, averaged to one decimal. The score reads makers’ published ratings; it isn’t our own water test, and buyers’ opinions play no part in it.

Check (weight)How it’s scored
Iron rating (1/6)15 ppm or more 10; 10 to 14 ppm 8; under 10 ppm 6
Sulfur (H₂S) rating (1/6)10 ppm or more 10; 5 to 9 ppm 8; 3 to 4 ppm 6; none 0
Manganese rating (1/6)5 ppm or more 10; 3 to 4 ppm 8; 2 ppm 6
Backwash flow needed (1/6)5.5 GPM or less 10; 5.6 to 8 GPM 8; more than 8 GPM 6
Automatic digital valve (1/6)10 when backwash runs automatically on a digital control
Listing match (1/6)10 when the Amazon product’s model matches the maker’s
TotalAverage of the checks, to one decimal. Where a maker prints two figures, the lower one is scored
SystemIronH₂SMnBackwashValveListingScore
Platinum 1010 (20)10 (15)10 (6)8 (6.5)10109.7
Gold 108 (12)10 (10)6 (2)10 (5)10109.0
iSpring WCFM550K8 (12)10 (20)10 (20)6 (26)10109.0
Filox 108 (10)6 (3)8 (3)10 (5.3)10108.7

Sources

  • AFWFilters, Air Injection Platinum 10 System product page, and Air Injection System Information comparison table (store.afwfilters.com): read Oct 23, 2026.
  • AFWFilters, Air Injection Gold 10 System product page (store.afwfilters.com): read Oct 23, 2026.
  • AFWFilters, 1 cu ft Digital Filox 10 System product page (the control valve is named Fleck 2510 AiQ, previously 2510SXT), and Filox (MangOx) media page with operating conditions (store.afwfilters.com): product page read Oct 23, 2026, valve name read again Nov 2, 2026.
  • iSpring, WCFM550K, WCFM500K and WCFM400K product descriptions (ispringfilter.com): read Oct 23, 2026.
  • US EPA, Secondary Drinking Water Standards guidance for nuisance chemicals, and private well testing guidance (epa.gov).
  • Amazon product data for the AFWFilters Platinum 10, the AFWFilters Gold 10, the iSpring WCFM550K and the AFWFilters Filox 10, read on Amazon on Oct 23, 2026.
  • Search volume from Semrush, Oct 22, 2026.

Related guides
