What well pressure tank size do you need?

Size chart and drawdown calculator for pressure-switch systems.

As an Amazon Associate I earn from qualifying purchases.

On this page
  1. Sizing examples
  2. Amtrol WX-250
  3. Amtrol WX-202
  4. Amtrol WX-302
  5. Compare the examples
  6. Drawdown calculator
  7. Required drawdown chart
  8. Check printed selections
  9. How drawdown works
  10. Find the right inputs
  11. Why switch settings matter
  12. Precharge and safety
  13. Other system types
  14. Fit and document conflicts
  15. Questions
  16. How we choose
  17. Related guides

Quick answer

Drawdown needed = pump GPM × minutes of runtime. At 10 GPM for one minute at 40/60, the WX-250 gives 11.8 gallons. Two minutes at 50/70 needs the WX-302 (20.3).

Reference tanks for three documented sizing needs

Your pump’s delivery, the runtime it needs and your switch setting decide the tank, not a score. All three are references (not linked), shown for comparison only.

TankKey specsPick it ifSkip it if
Amtrol WX-250 for 10 gallons at 40/6044 gal nominal, 11.8 gal at 40/60, 22 × 36 in., 1-1/4 in. NPTFYour confirmed requirement is 10 gallons at 40/60.Your required drawdown exceeds 11.8 gallons at 40/60.
Amtrol WX-202 for 5 gallons at 40/6020 gal nominal, 5.4 gal at 40/60, 15 × 32 in., 1 in. NPTFYou need 5 gallons at 40/60 and the installer confirms this model.You need 5 gallons at 50/70 or 10 gallons at 40/60.
Amtrol WX-302 for 20 gallons at 50/7086 gal nominal, 20.3 gal at 50/70, 26 × 47 in., 1-1/4 in. NPTFYour confirmed requirement is 20 gallons at 50/70, or up to 23.0 at 40/60.You need more than 20.3 gallons at 50/70, or the space can’t take a 26-inch-wide tank.

Warranty note: Amtrol doesn’t back Well-X-Trol tanks sold online, Amazon included: no warranty, no registration, no returns and no tech support, per its warranty sheet. Count that in before you order a tank this size online.

Reference (not linked): the Amtrol WX-250, shown for comparison only

Each tank matches one documented requirement, so none is scored. Match the drawdown at your switch setting.

The WX-250 fits a documented 10 GPM pump needing one minute at 40/60. That combination requires 10 gallons of drawdown. Amtrol publishes 11.8 gallons for this setting, so the tank clears the arithmetic target by 1.8 gallons. Confirm the runtime requirement with your pump or motor instructions before choosing it.

The 44 gallon label describes total tank volume. It does not promise 44 gallons between starts. At 40/60, use the published 11.8 gallons for sizing.

With a constant 10 GPM delivery and no water being used, that corresponds to about 70.8 seconds of refill time. This is a calculation, not an observed cycle.

Where it does well

  • 11.8 gal drawdown at 40/60
  • Meets the 10 gal example requirement

What to watch

  • Does not meet a 20 gal requirement
  • 22 in. diameter needs space
  • No Amtrol warranty or support if bought online

The same tank publishes 13.6 gallons at 30/50 and 10.4 at 50/70. Those figures explain why a switch change belongs in the sizing calculation. A 10 GPM pump with a two minute requirement needs 20 gallons. None of these three pressure settings gives this WX-250 enough drawdown for that target.

Check the space before you order a 44 gallon stand tank. Amtrol lists the WX-250 at 22 inches in diameter and 36 inches high, with a 1-1/4 inch female NPT connection. Those are tank dimensions, not a complete allowance for piping or access to the air valve. Have the installer check the entire assembly.

Check the delivered model label against the intended tank and have a licensed professional handle pressure and electrical work.

Choose this size because its drawdown meets your requirement at the actual pressure setting. Moving from a WX-202 to this WX-250 raises published 40/60 drawdown from 5.4 to 11.8 gallons. It still does not change the well yield or make an undersupplying pump deliver more water.

Reference (not linked): the Amtrol WX-202, shown for comparison only

The WX-202 is a useful fit for a confirmed 5 GPM pump requiring one minute at 40/60. The target is 5 gallons. Amtrol rates this model at 5.4 gallons of drawdown there. It meets the calculated target without treating its 20 gallon shell as 20 gallons of usable water.

That 5.4 gallon rating gives an estimated 64.8 second refill at a steady 5 GPM with no household demand. Keep both assumptions with the number. A running fixture changes the water available to refill the tank, and a pump that changes delivery through the pressure band will not produce this exact calculated time.

At 30/50, the WX-202 publishes 6.2 gallons. At 50/70, it publishes 4.7 gallons. For a strict 5 gallon requirement, the higher setting falls short. Do not buy the 20 gallon model for a 50/70 installation just because it worked for a neighbor whose pressure switch was set to 40/60.

Where it does well

  • 5.4 gal drawdown at 40/60
  • 15 in. diameter stand model

What to watch

  • 4.7 gal at 50/70 misses a 5 gal target
  • Not enough for 10 GPM and one minute
  • No Amtrol warranty or support if bought online

It also falls short for a 10 GPM pump needing one minute. That requirement is 10 gallons, while this tank provides 5.4 at 40/60. The estimated refill is only 32.4 seconds under the stated assumptions. A smaller footprint is helpful only after the required drawdown is met.

Amtrol lists a 15 inch diameter and 32 inch height for the standard stand model, with a 1 inch female NPT connection. The standard stand model is the one described here. Check the received label; other configurations need their own dimensions and installation instructions.

Keep this as the small requirement example, rather than a default tank for every household. The licensed installer still needs to confirm support, relief protection and precharge before the system is put into service.

Reference (not linked): the Amtrol WX-302, shown for comparison only

Use the WX-302 example when a confirmed 10 GPM pump needs two minutes at 50/70. The required drawdown is 20 gallons. Amtrol lists 20.3 gallons for this tank at that setting. It clears the arithmetic requirement by only 0.3 gallon, so verify the actual operating conditions with your installer.

The 86 gallon nominal capacity is not the water you draw between starts. Published drawdown is 26.6 gallons at 30/50, 23.0 at 40/60 and 20.3 at 50/70. At a steady 10 GPM with no simultaneous use, those values correspond to refill estimates of 159.6, 138.0 and 121.8 seconds.

The 50/70 result is close to two minutes because this is a scenario match, not a promise of spare capacity. Amtrol cautions that system conditions can affect drawdown. If your pump delivers more than 10 GPM in the relevant pressure band, the available runtime changes. Recalculate with the confirmed delivery rather than rounding the pump down.

Where it does well

  • 20.3 gal drawdown at 50/70; 23.0 at 40/60
  • Meets the 20 gal two-minute example at 50/70
  • 1-1/4 in. female NPT connection

What to watch

  • Clears 20 gal at 50/70 by only 0.3 gal
  • 26 × 47 in. stand tank needs floor space and a doorway
  • No Amtrol warranty or support if bought online

Check the 26 inch diameter and 47 inch height before selecting the larger stand tank. The published connection is 1-1/4 inch female NPT. A doorway, tank tee and access for future inspection all need attention. A tank that passes the drawdown calculation can still be wrong for the available installation space.

Two minutes is the requirement in this example. It is not a universal rule for every pump. Amtrol groups its printed conventional sizing chart by horsepower and one or two minutes, while the installed pump and motor instructions must settle your requirement. For variable speed control, use the controller maker’s tank instructions instead.

Compare usable drawdown at your switch setting

Use the pressure column your installer confirms. These three tanks are examples, not the complete Well-X-Trol range.

TankSizing useDrawdown, galFit and limitListing
Amtrol WX-202 Well Pressure Tank5 GPM × 1 min at 40/6030/50: 6.2
40/60: 5.4
50/70: 4.7
15 in. diameter; misses 5 gal at 50/70Reference (not linked)
Amtrol WX-250 Well-X-Trol Stand Well Water Tank10 GPM × 1 min at 40/6030/50: 13.6
40/60: 11.8
50/70: 10.4
Meets 10 gal; misses 20 galReference (not linked)
Amtrol WX-302 Well Pressure Tank10 GPM × 2 min at 50/7030/50: 26.6
40/60: 23.0
50/70: 20.3
Meets 20 gal; needs 26 in. diameter spaceReference (not linked)

Calculate the drawdown your pump needs

For an ordinary fixed-speed, pressure-switch system, enter confirmed pump delivery and required runtime. The result uses gallons per minute and minutes, not horsepower as a substitute for flow.

Ordinary fixed-speed switch systems only. Enter confirmed pump data. Input limits of 0.1–1,000 GPM and 0.1–60 minutes are calculator limits, not design recommendations.

10 gallons required. WX-250 is the smallest of the three illustrated tanks that meets this target at 40/60.

WX-250: 11.8 gallons rated drawdown. Estimated refill: 70.8 seconds at constant 10 GPM with no simultaneous water use.

Required gallons = GPM × minutes. Estimated refill seconds = rated drawdown ÷ GPM × 60. Other models may also fit. The calculator checks arithmetic against Amtrol’s published ratings; a licensed professional must confirm the system.

The required drawdown is pump delivery multiplied by required runtime. A 10 GPM delivery and a two minute requirement gives 20 gallons. Match that number to the maker’s published drawdown at the actual switch setting. Do not compare it to total tank volume.

The refill estimate divides a tank’s drawdown by pump delivery, then multiplies by 60 for seconds. It assumes constant delivery and no simultaneous water use. It is a sizing check, not a measured cycle or a guarantee that a tank will operate exactly as the calculation predicts.

Well pressure tank size chart by pump flow

This chart gives required usable gallons. After choosing your row, compare that requirement to a tank’s published drawdown at your switch setting. None of these entries is nominal tank capacity.

Pump deliveryOne minute requiredTwo minutes required
5 GPM5 gal10 gal
7 GPM7 gal14 gal
10 GPM10 gal20 gal
12 GPM12 gal24 gal
15 GPM15 gal30 gal
20 GPM20 gal40 gal
25 GPM25 gal50 gal
30 GPM30 gal60 gal

For a 12 GPM pump with a two minute requirement, start at 24 gallons. The WX-302’s 23.0 gallons at 40/60 falls short by 1 gallon. Its larger 86 gallon label does not change that result. Have the installer choose a tank or properly designed tank arrangement with enough documented capacity.

For a 7 GPM pump with a one minute requirement, start at 7 gallons. The WX-202’s 5.4 gallons at 40/60 is too little, while the WX-250’s 11.8 meets the arithmetic target. Another model between these examples may also work; this chart does not claim that only three tanks can fit.

Does a printed selection meet the exact runtime?

Amtrol’s ESP chart uses approximate pump discharge. These rows audit the source chart; they are not product recommendations. Compare the published drawdown with the required gallons, and have any shortfall checked.

Pump and targetSwitchRequiredPrinted ESP entryRated drawdownRefill estimate
10 GPM × 1 min30/5010 galWX-2039.9 gal59.4 sec; below 60
10 GPM × 1 min40/6010 galWX-25011.8 gal70.8 sec
10 GPM × 1 min50/7010 galWX-25010.4 gal62.4 sec
10 GPM × 2 min40/6020 galWX-25521.7 gal130.2 sec
10 GPM × 2 min50/7020 galWX-30220.3 gal121.8 sec
30 GPM × 2 min30/5060 galOne WX-35036.8 gal73.6 sec; clarify with Amtrol

The 30 GPM, two minute, 30/50 entry still lists a single WX-350 in Amtrol’s March 2026 chart. Its 36.8 gallon drawdown does not supply the calculated 60 gallon requirement. Do not treat that entry as a verified two minute design. Ask Amtrol and your installer to resolve it.

What happens between pump starts

One 40/60 cycle Pump stops: 60 PSIAir cushion compressedWater ready for use You use waterAir expandsPressure falls Pump restarts: 40 PSI Usable water between these points = drawdown. WX-250 rating: 11.8 gallons at 40/60.
Conceptual ordinary switch cycle at 40/60. The water quantities come from the model’s drawdown rating, not the drawing’s proportions.

At the upper switch pressure, the pump stops. As you use water, the compressed air in the tank pushes water into the plumbing. At the lower switch pressure, the pump starts.

The gallons delivered across that pressure band are drawdown. For a WX-250 at 40/60, Amtrol publishes 11.8 gallons.

The tank is not a 44 gallon emergency supply merely because WX-250 has 44 gallons of total volume. Its operating air cushion occupies space. If backup water storage is your goal, tell the well professional that you need a storage design rather than assuming the cycling tank supplies its full shell volume.

Find pump delivery and required runtime first

  1. 1
    Find the pump record

    Use the exact pump and motor identification, installer records and performance information. A 10 GPM name alone may not establish delivery through your operating pressure band. Ask a well professional to confirm the input when records are missing.

  2. 2
    Confirm the runtime requirement

    Read the pump or motor instructions. Amtrol’s conventional ESP chart groups pumps up to 3/4 HP with one minute and larger pumps with two minutes. Those chart headings do not establish every installed motor’s requirement.

  3. 3
    Confirm the actual pressure band

    Record the operating cut-in and cut-out from a working system gauge. Do not open a live pressure-switch cover or turn its adjustments to investigate a sizing question. Electrical and pressure work belongs to a qualified professional.

  4. 4
    Multiply and compare

    Multiply confirmed GPM by required minutes. Compare the resulting gallons to published drawdown at that switch setting, then check physical fit and installation requirements.

InputWhat it answersWhat it cannot replace
Pump delivery, GPMHow much the pump supplies for the calculationThe well’s sustainable yield
Well yieldWhether the source can sustain pumpingRequired tank drawdown
Household demandWhat the system must supply during useThe pump or motor runtime instruction
Required minutesHow long the pump should run in the sizing caseA horsepower-only flow estimate

A well that produces water slowly is a separate design problem. A larger pressure tank can store more water across its pressure band, but it cannot increase the source’s replenishment rate. Give the well professional the well yield and peak demand as well as the pump data.

Likewise, do not turn a maximum-starts-per-hour instruction into runtime by simply dividing 60 by that number. Wessels warns that this shortcut can oversize the tank. If motor documentation specifies cycle limits instead of a runtime, have the system designer apply the appropriate sizing method.

The same tank gives less drawdown at higher settings

30/50 PSI13.6 gal40/60 PSI11.8 gal50/70 PSI10.4 gal30/50 PSI13.6 gal40/60 PSI11.8 gal50/70 PSI10.4 gal
Amtrol MC7025 03/26, page 1. Drawdown varies with operating conditions. This is one tank at three settings, not three tank sizes.

A switch setting is part of tank sizing. For the WX-202, moving from 40/60 to 50/70 changes published drawdown from 5.4 to 4.7 gallons. That crosses the line for a strict 5 gallon target. Raising pressure without recalculating can leave a previously adequate example below its runtime requirement.

Keep pressure selection separate from installation adjustments. Our 30/50 versus 40/60 pressure-switch guide explains the choice. If a change is planned, have the installer check pump capability, component ratings and the tank maker’s precharge procedure before making it.

Precharge is a professional setup check

Do not add air to a suspect tank

Amtrol warns against repressurizing a tank with lost air, visible corrosion or reduced cycle time. Shut off pump power and have a licensed professional inspect it; do not assume rapid cycling only needs more air.

A factory charge is not a universal setting

Amtrol lists a 38 PSIG factory charge and specifies 2 PSIG below cut-in for conventional setup. The professional must follow the exact tank instructions with power off and water pressure released.

Confirmed Amtrol cut-inCalculated initial prechargeService condition
30 PSI28 PSIGLicensed professional; power off, tank empty
40 PSI38 PSIGLicensed professional; power off, tank empty
50 PSI48 PSIGLicensed professional; power off, tank empty

These precharge numbers apply to the cited Amtrol conventional instructions. They are not instructions for every brand or a reason to recharge an aging tank. Amtrol restricts checking and adjusting precharge to licensed professionals and warns that damaged or corroded tanks can rupture.

A pressure gauge reading on a filled water system is not an empty-tank air-charge measurement. Before tank work, Amtrol requires electrical power off and water pressure released. Keep covers closed and call the well professional if you cannot identify the disconnect, the equipment is damaged or water is near electrical parts.

Know when this sizing method does not apply

Your systemUse this calculation?Next step
Fixed-speed pump with ordinary switchYes, with confirmed inputsMatch required gallons to maker drawdown
Variable-speed or constant-pressure controllerNot as its tank selection ruleUse controller maker’s size and precharge instructions
Older air-over-water tankNot as a direct replacement ruleHave the air-control arrangement identified
Low-yield well or separate storageNot as a storage designHave source yield and demand evaluated

Amtrol says a VFD maker’s tank recommendation takes precedence over its fallback chart. It also directs precharge according to the drive maker. A constant-pressure system may therefore use a different tank arrangement from these conventional examples. Identify the controller before applying a one or two minute rule.

An older air-over-water installation also needs its existing air controls identified before conversion to a captive-air tank. The sizing arithmetic does not approve a control change. Have the well professional confirm the equipment and replacement design rather than choosing by the old tank’s outside size.

Check space, model identity and operating limits

CheckWhat to confirm before purchase
Physical routeTank diameter, height, doorway and room for tee and inspection
Exact modelStand versus underground or alternate-base suffix; delivered label
Pressure protectionRelief valve and every component’s permitted working pressure
Leak protectionA drained drip pan where leakage could cause property damage
LocationNo freezing or direct sunlight; follow the manual’s temperature limits

For model identification and physical dimensions beyond these examples, see the well pressure tank model-number reference. That lookup is separate from the GPM-to-runtime selection here. Do the drawdown calculation first, then make sure the actual model fits the installation.

The installation manual requires a licensed professional and calls for a relief valve. A tank’s 150 PSIG maximum working pressure is not a recommended household switch setting. The installer must protect the entire system, including any component rated below the tank.

Documents or listingDifferenceHow to handle it
Amtrol MC10188 08/25 versus installation manual 07/25Brochure lists 200°F maximum operation; manual prohibits a location above 130°FFollow the manual’s stricter location warning; get maker clarification
Amtrol printed ESP versus its own drawdownWX-350 at 30 GPM, two minutes, 30/50 does not reach 60 galDo not use as an accepted two minute design
Selected Amazon titles versus maker sheetsNo numerical contradiction established for the three chosen modelsVerify delivered model and revision; listing title does not certify fit

Questions about well pressure tank sizing

What size pressure tank do I need for a 10 GPM pump?

For one minute, you need 10 gallons of drawdown. For two minutes, you need 20 gallons. At 40/60, the WX-250 publishes 11.8 gallons and the WX-302 publishes 23.0. Confirm which runtime your pump and motor require.

How much drawdown does a 20 gallon pressure tank have?

Amtrol’s WX-202 publishes 6.2 gallons at 30/50, 5.4 at 40/60 and 4.7 at 50/70. Other 20 gallon tanks need their own maker ratings. Nominal capacity alone does not establish drawdown.

Is a 44 gallon tank enough for a 10 GPM pump?

The WX-250 has 11.8 gallons of drawdown at 40/60, enough for the 10 gallon, one minute example. It is below a 20 gallon, two minute requirement. Check the actual tank model and pressure band.

Can I use a bigger well pressure tank?

A tank with more usable drawdown can reduce cycling under the conventional sizing assumptions. It still needs correct physical fit, pressure protection and professional setup. It cannot increase a low-yield well’s replenishment rate.

Does raising the pressure switch change tank sizing?

Yes. The WX-202 publishes 5.4 gallons at 40/60 but 4.7 at 50/70. The same tank can cross below a required drawdown target after a pressure change. Have the installer recalculate and check the setup.

Can I size a tank from horsepower alone?

No. The calculation needs pump delivery in GPM and required runtime. Amtrol’s ESP chart includes horsepower groupings, but horsepower is not a substitute for confirmed delivery at the installed conditions.

Can two pressure tanks provide enough drawdown?

A properly designed matching arrangement can combine usable drawdown. For existing tanks at 40/60, a licensed professional must verify each model’s rating, piping, controls and precharge. Adding shell volumes does not establish combined drawdown.

Does this calculator work for a variable-speed well pump?

It shows arithmetic for an ordinary fixed-speed switch system. It does not select a VFD system’s tank. Amtrol says to use the drive maker’s tank recommendation and precharge instructions first.

Should I add air when my well pump cycles quickly?

Call a licensed professional first. Amtrol warns against adding pressure to tanks with lost air, visible corrosion or reduced cycle time. Power must be off and water pressure released before tank service.

Is a well tank the same as a water heater expansion tank?

No. The cited Well-X-Trol manual addresses potable well systems and pump cycling. Do not substitute a heating-system expansion tank by gallon size. Identify the application and use a tank whose maker approves it.

How we choose and why trust PlumbingPicks

Why trust PlumbingPicks

Isaac Daniels, licensed journeyman plumber in Georgia, is responsible for this page. We read Amtrol’s sizing chart, submittal and installation instructions alongside the Wessels sizing method. The numerical examples distinguish rated drawdown from calculated runtime.

How we choose

We match genuine model listings to maker drawdown at the stated switch setting. Links go to listings sold by Amazon.com. None of the three Amtrol tanks had an offer that met that rule, so all three are references (not linked), shown for comparison only. These are sizing matches, not measured performance rankings. No score is assigned because the required drawdown determines which tank fits.

CheckSelection rule
Required usable waterConfirmed pump GPM × required minutes
Usable capacityPublished model drawdown at the actual switch setting
Estimated refillDrawdown ÷ constant GPM × 60; no simultaneous demand
Offer identityExact branded model, new condition, in-stock reading
Final fitLicensed installer confirms controls, location and safety

Sources

  • Amtrol, Well-X-Trol quick sizing chart MC7025 (03/26), pages 1–2: model drawdown, physical specifications, conventional ESP selections. amtrol.com/wp-content/uploads/2026/03/MC7025-03_26-WXT-card.pdf. Read October 20, 2026.
  • Amtrol, Well-X-Trol brochure MC10188 (08/25), pages 6–7: drawdown, operating-temperature listing and VFD guidance. amtrol.com/wp-content/uploads/2025/08/MC10188-08_25_WXT-brochure.pdf.
  • Amtrol, Residential pre-pressurized well tanks installation and operation instructions 9015-868 / MC10185 (07/25), pages 1–3 and 6: professional installation, pressure/electrical isolation, damaged-tank warnings and precharge. amtrol.com/wp-content/uploads/2025/08/9015-868-MC10185-07_25-WXT-IO-manual.pdf.
  • Amtrol, MC4400 (04/24), printed page 4: stand-model dimensions, NPTF connections and pressure rating. amtrol.com/wp-content/uploads/2024/04/MC4400_04_24_Submittal_Data_Book-4.pdf.
  • Wessels Company, How to size well water and pressure booster tanks: required drawdown equation, constant-flow scope and starts-per-hour warning. westank.com/how-to-size-well-water-and-pressure-booster-tanks/. Read October 20, 2026.
  • Amtrol, Well-X-Trol internet sales policy in the residential well tank warranty MC10253 (07/25), page 3: online purchases are not eligible for Amtrol warranty, registration, returns or technical assistance. Read October 20, 2026.
  • Amazon product listings for the three tanks named on this page, read Oct 27, 2026.
