For a tiled shower floor, pick the Kohler Clearflo K-9136 (square) or K-9135 (round). For a prefabricated shower base, pick the K-9132. For a curbless or wall-to-wall shower, pick the K-80646 linear channel with a K-80647 grate. Match the drain to your floor and pipe size first.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares Kohler shower drains using Kohler’s own spec sheets and drawings.
Kohler shower drains compared (Kohler spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Drain | For | Pipe / size | Material |
|---|---|---|---|
| Clearflo K-9136 (square) | Tiled shower floor | 2 or 3 in. PVC; 4-9/16 in. square grate | Brass and PVC |
| Clearflo K-9135 (round) | Tiled shower floor | 2 or 3 in. PVC; round grate | Brass and PVC |
| K-9132 | Acrylic, fiberglass, cast iron or Vikrell shower base | 2 in. metal or plastic; 4-3/8 in. strainer | Solid brass |
| K-80646 channel + K-80647 grate | Tiled floor, linear along a wall | Channel 36 to 60 in.; up to 15 gpm | Stainless channel, aluminum grate |
The right Kohler shower drain depends on the floor. A prefabricated shower base, the one-piece pan many showers sit on, takes a drain like the K-9132 that seals through the base. A tiled shower floor takes a tile-in drain like the Clearflo, set in the floor with the tile around it. A linear drain runs along one wall and lets the floor slope one way.
Kohler Clearflo K-9136: square tile-in drain
Choose the Clearflo K-9136 for a tiled shower floor with a square grate. Kohler’s spec sheet (resources.kohler.com) lists a removable square grid plate, a reversible collar that adjusts for different tile thicknesses, 2-inch and 3-inch PVC connections, brass and PVC construction, through-the-floor tile-in installation and the drain body included.
The drawing shows a 4-9/16-inch square top on a 6-1/2-inch round flange, and a grate height above the flange adjustable from 1-3/8 to 2-7/16 inches with the collar threads down, or 2-1/8 to 3-1/4 inches with the collar flipped. That adjustment is what lets the grate finish flush with the tile.
On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with part K-9136-CP, polished chrome.
Check Kohler Clearflo K-9136-CP square shower drain on Amazon →
Kohler Clearflo K-9135: round tile-in drain
Choose the Clearflo K-9135 for the same tile-in drain with a round grate. Kohler’s spec sheet (resources.kohler.com) lists a removable round grid plate, the same reversible collar for different tile thicknesses, 2-inch and 3-inch PVC connections, brass and PVC construction, through-the-floor tile-in installation and the drain included.
Choose between the square and round Clearflo by the look you want with your tile; the sheets list the same connections and features.
On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 9135-BL, matte black.
Check Kohler Clearflo K-9135-BL round shower drain on Amazon →
Kohler K-9132: drain for a shower base
Choose the K-9132 to replace or install the drain in a prefabricated shower base. Kohler’s spec sheet (resources.kohler.com) lists a round, perforated strainer drain for acrylic, fiberglass, cast iron or Vikrell shower bases, solid brass construction, and use with 2-inch metal or plastic pipe, with a 2-inch plastic pipe gasket and bushing included.
The drawing shows a 4-3/8-inch strainer on a 4-1/2-inch body and a 1-1/4-inch maximum dimension between the strainer flange and the clamping nut, which limits how thick a base it can clamp. It marks two points where the seal must meet local codes. This style seals through the base and does not need tile.
On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 9132-CP, polished chrome.
Check Kohler K-9132-CP shower base drain on Amazon →
Kohler K-80646 linear drain channel with K-80647 grate
Choose the Kohler linear system for a curbless or wall-to-wall shower where the floor slopes one way. Kohler’s K-80646 spec sheet (resources.kohler.com) lists a stainless steel channel adjustable from 36 to 60 inches long, pitched to the outlet, with flow capacity up to 15 gpm (Kohler notes the rate may vary by installation). The outlet position can be moved to avoid joists or venting, the subfloor brackets set the height from 1-1/2 to 4 inches, and it includes a domed hair strainer and a removable tile guide. The wide flange carries protective film for waterproofing adhesion.
The channel needs a separate 2-1/2-inch grate. Kohler’s K-80647 sheet (resources.kohler.com) lists a 36-inch anodized aluminum grate with a tile-in panel you fill with your own floor tile, field-trimmable, with feet adjustable up to 1 inch.
On October 15, 2026, the standard new offers sold by eFaucets showed limited stock for part 80646-NA (channel) and part 80647-BNK (grate, anodized brushed nickel).
Check Kohler K-80646 linear drain channel on Amazon →
Check Kohler K-80647-BNK 36 in. tile-in grate on Amazon →
Point drain or linear drain?
A point drain like the Clearflo sits near the middle of the floor, and the floor slopes to it from all sides. A linear drain sits along one wall, so the floor slopes in one direction, which suits large-format tile and curbless showers. The linear channel is the bigger job: it has to be set at the right height before the floor goes in, and its outlet and grate are bought separately. Waterproofing details depend on the shower system you use; follow Kohler’s installation instructions and the membrane maker’s.
For linear drains from other brands, see our linear shower drain guide, and for other point drains our shower drain guide.
Before you buy: measure and match
Start with what is under the shower. If there is a one-piece base, measure the hole in the base and the pipe below it; the K-9132 is made for a 2-inch pipe and lists a gasket for plastic pipe. If you are building a tiled floor, decide the pipe size first; the Clearflo connects to either 2-inch or 3-inch PVC. Then think about tile thickness, since the Clearflo’s reversible collar sets how high the grate sits.
For a linear drain, measure the wall the drain will run along. Kohler’s drawing shows the K-80646 channel adjustable from about 37-1/4 to 61-1/4 inches overall, and the grate comes in 36, 48 and 60-inch lengths that can be trimmed. If you are pairing a drain with a new prefabricated pan, our shower pan guide covers bases.
Hair, cleaning and covers
Kohler lists its drain treatment and faucet cleaner as recommended accessories on the Clearflo and K-9132 sheets. The linear channel includes a domed hair strainer, and the Clearflo grid plates lift out for cleaning. To match a strainer or hair catcher to your drain, see our shower drain size guide.
Frequently asked questions
What size pipe does a Kohler shower drain fit?
The Clearflo K-9136 and K-9135 connect to 2- or 3-inch PVC; the K-9132 fits 2-inch metal or plastic pipe.
Which Kohler drain is for a shower base?
The K-9132, which Kohler lists for acrylic, fiberglass, cast iron or Vikrell bases.
Can the Clearflo adjust for tile thickness?
Yes. Kohler lists a reversible collar for different tile thicknesses.
Does the Kohler linear drain include the grate?
No. The K-80646 channel needs a separate 2-1/2-inch grate such as the K-80647.
How much water does the Kohler linear drain handle?
Kohler lists up to 15 gpm, noting the rate may vary by installation.
How we chose
This document-based guide makes no hands-on testing claim. We read and rendered Kohler’s spec sheets for the K-9136, K-9135, K-9132, K-80646 and K-80647. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Kohler Clearflo K-9136 spec sheet (resources.kohler.com): square grate, reversible collar, 2/3 in. PVC, drawing heights.
- Kohler Clearflo K-9135 spec sheet (resources.kohler.com): round grate, same features.
- Kohler K-9132 spec sheet (resources.kohler.com): shower base types, 2 in. pipe, gasket, drawing.
- Kohler K-80646 linear channel spec sheet (resources.kohler.com): 36-60 in., 15 gpm, adjustable outlet, brackets, strainer.
- Kohler K-80647 grate spec sheet (resources.kohler.com): tile-in panel, aluminum, trimmable, requires K-80646.
