Quick answer from a licensed plumber: For a standard tank with the anode port on top, buy the Corro-Protec 40–89 gallon powered anode rod: a titanium rod that plugs into a regular outlet, is only 12 inches tall, and that Corro-Protec says stops rotten egg smell within 24 hours. For most Bradford White heaters, or a factory anode that will not come out, buy the Corro-Protec hot water outlet model.
Our pick for most tanks: the Corro-Protec Powered Anode Rod, 40–89 gallon. Check the Corro-Protec 40–89 gallon model on Amazon
A powered anode rod is a titanium rod that protects a water heater tank with a small electric current instead of dissolving the way a magnesium or aluminum anode does. People buy one for two reasons: hot water that smells like rotten eggs, and not wanting to replace a sacrificial anode every few years. Corro-Protec makes the one to buy, and the only real decision is which model fits your tank.
Powered Anode Rods Compared
| Model | Installs in | Tank size | Thread | Best for |
|---|---|---|---|---|
| Corro-Protec 40–89 gallon | Dedicated anode port on top | 40–89 gallons | 3/4-inch NPT | Most tanks, per Corro-Protec |
| Corro-Protec hot water outlet | Hot water outlet, with a wye fitting | 10–120 gallons | 3/4-inch NPT | Bradford White, or a stuck anode |
Figures come from Corro-Protec’s product page and installation guide and from each Amazon listing. Each linked model was listed in stock on Amazon when we checked on September 28, 2026, shipped by Amazon and sold by Corro-Protec.
Corro-Protec Powered Anode Rod, 40–89 Gallon (Dedicated Anode Port)
Titanium with mixed metal oxide · 3/4-inch NPT · 12 inches tall · plugs into a regular 110 V outlet on a 12-foot cord · 24 V output · green indicator light · power supply to UL 1310 and CSA C22.2 No. 223; WQA-certified to NSF/ANSI/CAN 372 (lead-free) · 5-year warranty, 20 years if registered within 90 days
A powered anode replaces the magnesium or aluminum rod that slowly dissolves to protect a tank. Instead of wearing away, it runs a small current from a plug-in power supply through a titanium rod, which Corro-Protec says does not degrade. It threads into the same 3/4-inch NPT anode port on top of the heater, and a ground wire goes on one of the tank cover screws. Corro-Protec says the 40–89 gallon model is the right choice in almost every case, because most tanks with a dedicated anode port hold 50 to 60 gallons.
The rod is only 12 inches tall, so Corro-Protec says about a foot of clearance above the heater is enough, and the old rod can be cut into pieces as it comes out. The cord is 12 feet, so you need an outlet within reach; if you do not have one, Corro-Protec says to have an electrician add it. Once it is in, the upkeep is a yearly look at the green light on the power supply. Corro-Protec puts average use at about 10 kWh a year, roughly what a 60-watt bulb left on for a week uses (our arithmetic), and it says the rod works with well water, city water and softened water.
- Titanium rod that Corro-Protec says does not wear away like magnesium or aluminum
- Only 12 inches tall; about a foot of clearance to install (Corro-Protec)
- Power supply safety-listed to UL 1310 and CSA C22.2 No. 223; rod certified lead-free to NSF/ANSI/CAN 372
- Green light shows it is working; about 10 kWh a year, per the maker
- Needs a regular outlet within 12 feet and must stay plugged in
- Not for most Bradford White tanks, which put the anode in the hot outlet
- The 20-year warranty needs registration within 90 days, and coverage drops after year 5
- A stuck factory anode can make removal the hardest part of the job
Verdict: The one to buy for a standard 40 to 89 gallon tank with an anode port on top, especially if the hot water smells like rotten eggs or you are tired of replacing sacrificial rods.
Corro-Protec Powered Anode Rod, Hot Water Outlet (Bradford White)
Installs in the hot water outlet instead of an anode port · fits standard 3/4-inch NPT · for 10–120 gallon tanks · comes with a wye fitting for the outlet install · same plug-in power supply and warranty terms as the standard model
Most Bradford White heaters build the anode into the hot water outlet rather than giving it its own port, so the standard model has nowhere to go. This version installs in the hot outlet with a wye fitting, which Corro-Protec says comes in the box, so the hot line and the anode share the connection. Corro-Protec lists it for 10 to 120 gallon tanks and says that, despite the name, it fits almost every brand, including Bosch and A. O. Smith; its Amazon listing names Buderus as the exception.
It is also the fix when the factory anode in a normal port will not come out. Corro-Protec says you can install this model in the hot outlet and leave the old anode where it is. If your heater has two anodes, the manual says to replace one and leave the other in place.
- Made for tanks with the anode in the hot outlet, including most Bradford White heaters
- Wye fitting included, per Corro-Protec
- Works around a factory anode that will not come out
- Covers 10 to 120 gallon tanks
- Adds a fitting to the hot water line, so it is a plumbing job, not just an anode swap
- Same outlet, cord and warranty-registration requirements as the standard model
- Not for Buderus tanks, per the Amazon listing
Verdict: The pick for a Bradford White heater, a tank with no anode port on top, or a factory anode that is seized in place.
I send an occasional note when a new guide goes up — repairs worth doing yourself, and the parts that actually last. No spam, no course funnel; written by a licensed Georgia plumber.
Pick the Right Model for Your Tank
Check your water heater’s manual for where the anode sits. Most heaters have a dedicated port under a plastic cap on top of the tank; most Bradford White heaters put it in the hot water outlet. Then match the tank size:
| Your tank | Model |
|---|---|
| Anode port on top, 10–39 gallons | Corro-Protec 10–39 gallon model |
| Anode port on top, 40–89 gallons | Corro-Protec 40–89 gallon model |
| Anode port on top, 90–120 gallons | Corro-Protec 90–120 gallon model |
| Anode in the hot outlet (most Bradford White), or a stuck anode | Corro-Protec hot water outlet model |
Powered vs Magnesium vs Aluminum Anode
| Magnesium | Aluminum | Powered (titanium) | |
|---|---|---|---|
| How it protects | Dissolves slowly so the tank does not | Dissolves slowly so the tank does not | Small current from a plug-in power supply |
| Wears out | Yes; check and replace | Yes; check and replace | No, per the maker; check the green light yearly |
| Needs an outlet | No | No | Yes, within 12 feet |
Magnesium and aluminum rods are sacrificial: they are meant to corrode instead of the tank, so they get used up and need checking. A powered rod does not wear away, but it only works while it is plugged in and the tank is full. For sizing a replacement sacrificial rod, see water heater anode rod size and type, and for low ceilings, flexible vs rigid anode rods.
Before You Buy
- Find the anode. A dedicated port on top means the standard model; an anode in the hot outlet means the hot water outlet model. Your heater’s manual shows which.
- Check for an outlet. The power supply needs a regular outlet within 12 feet of the heater.
- Plan to get the old rod out. Corro-Protec’s guide uses a 1-1/16-inch six-point socket to remove the old rod and a 1-3/16-inch socket to install the new one. Factory rods can be very tight; a breaker bar or impact wrench helps, and the hot outlet model is the fallback if it will not budge. See how to replace a water heater anode rod.
- Read your water heater warranty. Corro-Protec’s warranty covers its anode system, not the heater, so check what your heater’s maker says about replacing the anode before you swap it.
- Know what it will not fix. If cold water smells too, the source is the water supply; see why your water smells like rotten eggs.
How the Install Goes
Corro-Protec’s guide lays it out: turn off the gas or the breaker and the cold supply, drain enough water that the level is below the anode port, remove the old rod, wrap the new rod’s threads with 5 to 6 layers of Teflon tape and tighten it without excessive force, fasten the ground eyelet to a tank cover screw on bare metal, and crimp on the connector. Refill with a hot tap open to purge air, turn the heater back on, and plug in the power supply. The green light should come on after a few seconds. If you are not comfortable draining a tank and breaking loose a factory anode, have a licensed plumber do it.
FAQ
Does a powered anode rod fix rotten egg smell in hot water?
Corro-Protec says its powered anode gets rid of sulfur or rotten egg smell in hot water within 24 hours by neutralizing the sulfur-reducing bacteria behind it. If the cold water smells too, the problem is in the water supply, not the heater, and an anode will not fix it.
Do I need to replace both anodes if my water heater has two?
No. Corro-Protec’s manual says to replace one sacrificial anode with the powered rod and leave the second one in place, including when the goal is stopping the smell. That is why it sells models by tank size.
Can I use a powered anode rod with a water softener?
Yes, per Corro-Protec. Its manual recommends a powered anode when you have a softener, because softened water is generally harder on the tank, and it says the rod adjusts its output to the water automatically.
How much electricity does a powered anode use?
Corro-Protec says it depends on the water, but averages about 10 kWh a year. It runs from a regular 110 V outlet and should stay plugged in.
Is the 20-year warranty real?
It is conditional. Corro-Protec’s base warranty is 5 years. Registering within 90 days of purchase extends it to 20 years for single-family homes, with full coverage for the first 5 years and 5% less each year after that, so 50% at year 15. It covers the anode system, not the water heater.
Why Trust Plumbing Picks
Plumbing Picks is written by a licensed Georgia journeyman plumber. Every size, rating, dimension and spec on this page comes from the manufacturer pages and documents listed below, which we opened and read, or from the Amazon listing we link; nothing here comes from hands-on testing. Each linked product was shipped or sold by Amazon, new and in stock, when we checked on September 28, 2026. Where a link goes to Amazon we may earn a commission at no extra cost to you. Nobody pays to be included here. More on who writes this and how we pick.
Sources
- Corro-Protec: Powered Anode Rod for Dedicated Anode Port, installation, troubleshooting and warranty guide
- Corro-Protec: Powered Anode Rod for Water Heaters (specifications and FAQ)
- Amazon listings for the Corro-Protec 10–39, 40–89 and 90–120 gallon models and the hot water outlet model (linked above)
Bottom Line
A powered anode trades a rod you replace for a rod you plug in. Match it to where your anode sits and how big the tank is: the Corro-Protec 40–89 gallon model for most tanks with a port on top, the hot water outlet model for most Bradford White heaters or a seized anode. Register it within 90 days if you want the extended warranty.
