How to replace a water heater anode rod

When to pull the rod, how to swap it, and when to leave it alone. This water heater anode rod replacement guide follows the steps A.O. Smith, Rheem and Bradford White print in their own manuals.

As an Amazon Associate I earn from qualifying purchases. Disclosure.

Rheem SP11309T magnesium anode rod with hex head
Rheem SP11309T magnesium anode rod. Product photo from Amazon.

Quick answer

Check the rod yearly and swap it once 6 inches of steel core shows. Turn off power or gas and the cold supply, break the hex loose with a 1-1/16 in. socket, and refill before power goes back on.

Rod for a hex port on top: Rheem SP11309T

Check the Rheem SP11309T on AmazonFind the rod on your tank

Should you pull the rod now?

Answer four questions. The helper uses the makers’ check intervals and flags the one case where I’d stop and think first.

Check it now.

Rheem says to pull the rod every year, and yours is past that. Follow the hex-head steps and compare it with the replace-now rules.

Tank age is on the rating plate, often coded into the serial number. A leak from the tank itself is past anything a rod can fix.

The common case is a tank that’s a few years old and a rod nobody has ever touched. That’s the case the helper slows down on. A rod left in for a decade can be fused to the tank threads, and the force it takes to break it free lands on an old fitting.

Forum threads on this are full of plumbers saying to let an old tank ride. I agree when the tank is past ten years and the rod has never moved. On a younger tank, the yearly check is quick and the rod is the part that keeps the steel from rusting.

How often each maker says to check the rod

Every maker sets its own interval, and all of them shorten it for softened water.

A.O. Smith, first check6 monthsA.O. Smith, after that12 monthsRheem12 monthsEastman listing, check24 monthsEastman, replace rod48–60 monthsA.O. Smith, first check6 monthsA.O. Smith, after that12 monthsRheem12 monthsEastman listing, check24 monthsEastman, replace rod48–60 months
Shorter bar means a sooner check. Tank makers: A.O. Smith manual 100341465 and Rheem AP21980. Rod maker: Eastman’s product page and its Amazon listing.
MakerWhen to lookOn softened water
A.O. SmithDrain, flush and inspect after the first 6 months, then at least once a yearA softener wears the rod faster
RheemPull the rod every year for a lookCheck more often
Bradford WhiteInspect periodically, as its hybrid manual saysMore often with softened or phosphate-treated water
Eastman (rod maker)Inspect periodically; replace every 4 to 5 yearsNot stated

My call: put the check on the calendar with the flush. A.O. Smith pairs them, and you have the tank drained part-way anyway. The water heater flush guide covers the drain side.

When the rod needs replacing

Pull it, wipe it and look at both ends. The makers give clear lines.

What you seeWhose ruleWhat to do
More than 6 in. of bare steel core wire at either endRheemReplace it
Rod worn to half its new width, about 3/8 in. left on a 3/4 in. rodBradford WhiteReplace it
Any steel core showingBradford WhiteReplace it
Rod mostly a bare wireAll makersReplace it now; the tank is on its own
Thick, even rod with light pittingRheem’s 6-inch rule not metPut it back with fresh tape and check next year
Rod gone fast on softened waterBradford WhiteAsk about an aluminum rod, and test the water

A.O. Smith doesn’t give a length. It says to replace a rod that’s badly worn, and it treats rods as wear parts that aren’t covered by the tank warranty. If you’re between rules, go with the stricter one. A new rod costs less than the heat a rusty tank loses.

Which metal and size to buy is its own question. The anode rod size and type guide covers threads, lengths and magnesium versus aluminum.

The rod, the socket and the bar

One rod for your tank’s port, a 6-point socket and a long bar. In my 7 years of experience, these are the products I’d install.

Rheem SP11309T magnesium anode rod with hex head
Product photo from Amazon.

Rheem SP11309T rod

Best for a hex port on top

Key specs
Magnesium, 0.750 in. × 39-3/8 in., 1-1/16 in. hex, 3/4 in. NPT, Rheem part
Pick it if
Your rod has a hex head in its own port on top.
Skip it if
You don’t have about 40 in. of headroom. Use a flexible rod.
Check the Rheem SP11309T on Amazon
Eastman 60286 flexible magnesium anode rod with stainless nipple
Product photo from Amazon.

Eastman 60286 rod

Best for an anode on the hot outlet

Key specs
Magnesium, 42 in., 4 links of 5/8 in., 3/4 × 3 in. stainless nipple
Pick it if
The anode hangs from the hot outlet nipple, as on many Bradford White tanks.
Skip it if
Your tank has a separate hex port. This one replaces the outlet nipple.
Check the Eastman 60286 on Amazon
TEKTON SHD22027 1-1/16 inch 6-point socket
Product photo from Amazon.

TEKTON SHD22027 socket

Best for the 1-1/16 in. hex

Key specs
1/2 in. drive, 1-1/16 in., 6-point, shallow
Pick it if
You’re turning a hex-head rod.
Skip it if
Your anode is on the outlet nipple. That job takes a pipe wrench.
Check the TEKTON socket on Amazon
TEKTON SBH00224 24 inch breaker bar
Product photo from Amazon.

TEKTON SBH00224 bar

Best for a factory-tight rod

Key specs
1/2 in. drive, 24 in., 230° pivoting head, 2.91 lb, TEKTON warranty with no time limit
Pick it if
The rod is factory tight or has sat for years.
Skip it if
You own an impact wrench and a safe way to brace the tank.
Check the TEKTON bar on Amazon

Add thread seal tape or pipe joint compound (A.O. Smith accepts either), a garden hose for the drain and a rag. A.O. Smith’s steps also call for an extension on the socket and a keyhole saw for the foam over some rods.

Why a 6-point socket: TEKTON’s 6-point pushes on the flats of the hex, not the corners. A 12-point on a rusty, factory-tight hex is how heads round off.

Want a rod that never wears out? A powered anode is a different design. The Corro-Protec powered rod on Amazon fits a dedicated hex port, needs an outlet within its 12-foot cord, and takes both a 1-1/16 and a 1-3/16 in. socket to install. The powered anode rod guide compares them.

Where the rod is on your tank

What you see on topRod typeGo to
A hex head in its own port, or a plastic cap marked “Anode”Hex-head rodHex-head steps
No anode port, and a short nipple on the hot outletOutlet (combo) anodeHot-outlet steps
Two hex ports and no labelsCheck the manualThe diagram names the anode
A powered anode with a cordPowered rodIts maker’s steps; no wear check

A.O. Smith hides its rod under a black plastic cover marked “Anode,” with foam insulation over the hex. Bradford White’s 47150A service manual puts the anode in the hot outlet nipple on its TTW gas models. Rheem’s gas manual diagram shows a magnesium anode.

Shut the heater down safely

Power or gas off first, then the water. Each maker starts its anode steps this way.

StepElectric heaterGas heater
Energy offBreaker off. A.O. Smith says turn off power first.Gas control to OFF. Bradford White also says unplug models with a cord.
Cool the waterRun hot water at a tap until it runs cool.Same. Hot water scalds.
Water offClose the cold supply valve.Close the cold supply valve.
Relieve pressureOpen a hot faucet in the house.Open a hot faucet in the house.

Leave that hot faucet open while you work. It lets air in so the tank drains and stops pressure building back up while the rod is out.

Rheem warns that a heater left unused for 2 weeks or more can build hydrogen gas. Before you use it, open the kitchen hot faucet for several minutes, with no flame or spark nearby. Rheem also says to minimize rotten-egg odor by chlorinating the supply.

Drain just enough water

  1. 1

    Hook up a hose

    Thread a garden hose onto the drain valve at the bottom and run it to a floor drain or outside.

  2. 2

    Open the drain

    Let a few gallons out with the hot faucet open. Bradford White drains below the outlet nipple for its outlet anode.

  3. 3

    Close it when you’re low enough

    For a hex rod on top, a few gallons keeps water from rising out of the port. My call, not a maker number.

  4. 4

    Flush while you’re here

    If you’re due a flush, drain the whole tank now. A.O. Smith pairs the two jobs.

An old drain valve can drip once it has been opened. Have a brass cap or a hose cap ready if yours won’t seal again.

Remove and replace a hex-head rod

These follow A.O. Smith’s electric manual 100341465 and Rheem’s AP21980.

  1. 1

    Uncover the hex

    Pry off the plastic cover marked “Anode.” If foam covers the hex, A.O. Smith says to cut it away with a keyhole saw.

  2. 2

    Fit the socket

    Put the 1-1/16 in. socket on with an extension and the breaker bar. Seat it all the way down on the flats.

  3. 3

    Break it loose

    Pull counterclockwise in one steady move. Have a helper hold the tank so it doesn’t twist the pipes.

  4. 4

    Lift it out

    Pull the rod straight up. A rigid rod needs about its own length of headroom.

  5. 5

    Check it

    Wipe it and compare it with the replace-now rules. If it’s still good, it goes back in.

  6. 6

    Seal the new threads

    Wrap thread seal tape or put pipe joint compound on the new rod’s threads, as A.O. Smith says.

  7. 7

    Thread it by hand

    Start it by hand so it can’t cross-thread, then tighten it with the bar.

  8. 8

    Close up

    Put the cover back. A.O. Smith says the foam you cut out doesn’t need replacing.

Not enough headroom for a rigid rod? A segmented rod bends as it goes in. Most rigid rods have to be bent as they come out, which can take two people. The flexible versus rigid rod guide covers that choice.

Never leave the tank running without a rod. Rheem says doing that greatly shortens tank life and voids its warranty.

Watch Rheem swap a rod

Rheem’s own service channel walks through a rod swap. The video gives the same rule as this page: check the rod every year and replace it once 6 inches of core wire shows.

Picked because Rheem makes the rod in my kit and links this video from the SP11309T part page.

Video: “How to Replace a Water Heater Anode Rod,” Rheem Water Heating on YouTube (2021). The player loads from YouTube only after you press the button. Watch it on YouTube

Replace an anode on the hot outlet

From Bradford White’s service manual 47150A for its TTW gas models. Bradford White writes these steps for qualified service providers.

  1. 1

    Drain below the outlet

    With gas off, cold supply off and the hot faucet open, drain the tank below the outlet nipple.

  2. 2

    Disconnect the hot line

    Take the hot water connection off the outlet nipple.

  3. 3

    Turn out the nipple

    Bradford White says to unscrew the outlet nipple and its anode with a pipe wrench without damaging the threads.

  4. 4

    Check it

    Replace it if the anode has worn to half its width, about 3/8 in., or any steel core shows.

  5. 5

    Seal and thread in

    Seal the new nipple’s threads, start it by hand and tighten it with the wrench.

  6. 6

    Reconnect

    Put the hot line back on. Check the dielectric fitting or connector while it’s off.

The Eastman 60286 in the kit is built for this: a flexible magnesium rod on a 3/4 × 3 in. stainless nipple. Eastman also makes a 5 in. nipple version, the 60287, so match the length of the one you take out.

The connection on top of the nipple matters too. Dielectric union or brass nipple explains what goes between steel and copper.

When the rod won’t budge

A factory rod is tight, and an old one can be fused in. Work up in force and stop at the first sign the tank is moving.

ProblemWhat to tryStop if
Won’t break loose with the barA helper holds the tank, then a slow, hard pullThe tank turns or the pipes on top bend
Still won’t moveAn impact wrench on the same 6-point socket, a burst or two at a timeThe tank shakes on its base or the port moves
Hex starts to round offStop and switch to a 6-point socket if you weren’t using oneThe corners are gone
Rod snaps below the hexNothing at homeRight away. Call a licensed plumber
No room above to pull itA flexible rod for the new one; bend or cut the old one as it comesYou’d have to move the heater

My call: an impact wrench hammers in small hits, so it breaks a seized thread with less twist on the tank than a long bar does. That’s why so many people in forum threads finished the job with one.

If the tank twists, stop. Copper lines on top can crack at the fittings, and the cure for that is a new water heater, not a new rod.

Refill before the power goes back on

This is the step that burns out elements. A.O. Smith is specific about it.

  1. 1

    Close the drain

    Close the drain valve and take the hose off.

  2. 2

    Open the cold supply

    Leave the hot faucet open so the air can push out.

  3. 3

    Run hot water for 3 minutes

    A.O. Smith says to run the hot water full for at least 3 minutes before you turn power back on. Firing an electric tank that isn’t full can burn out the upper element.

  4. 4

    Check for leaks

    Look at the rod or nipple threads while the tank is at full pressure, before the insulation cover goes back on.

  5. 5

    Restore power or gas

    Breaker on, or light the gas the way the label on your heater says.

  6. 6

    Give it time

    A.O. Smith says a full tank can take 2 hours to heat.

A small weep at the threads usually means the tape or compound didn’t seal. Shut down, drain a little, and redo the seal. Don’t keep tightening a leak.

Smells, air and leaks after the swap

A new rod can change what comes out of the tap. Here’s what Bradford White and Rheem say it means.

What you noticeLikely causeWhat the maker says to do
Rotten-egg smell in hot waterBacteria in the water reacting with the rodChlorinate the system (Rheem; Bradford White Service Bulletin 109)
Air or sputtering at hot tapsA magnesium rod reacting with the waterTest the water; Bradford White suggests aluminum
Discolored hot waterWater chemistry or a worn rodTest the water and check the anode material
Water at the rod or nippleThread seal didn’t takeDrain a little and reseal

Taking the rod out to stop a smell isn’t the answer. Rheem and Bradford White both say an anode must stay in the tank. The rotten-egg water smell guide goes through the fixes.

What changing the rod does to your warranty

MakerWhat it says
A.O. SmithAnode rods wear out by design and aren’t covered under warranty
RheemRunning without an anode greatly shortens tank life and voids the warranty
Bradford WhiteRemoving an anode other than for inspection or replacement voids the warranty

None of the three bans a homeowner from swapping a rod. What they don’t allow is leaving it out. Keep the receipt for the new rod with the heater’s paperwork.

When to call a licensed plumber

The tank moves when you pull

Stop before the lines on top crack.

The rod snaps off inside

Getting the rest out without damaging the port needs the right tools.

The tank leaks from the body

The steel has failed. No rod fixes it; see replacing a water heater.

Gas you can smell

Leave the house and call your gas company from outside.

If you’d rather hand the job off, the plumbing cost estimator gives a range for your area. If the tank is old enough that it isn’t worth the visit, what a new heater costs helps you compare.

Questions people ask

How often should I replace my water heater anode rod?

Check it every year, as Rheem says, and replace it when 6 inches of core wire shows. A.O. Smith says to look after the first 6 months, then at least yearly. Eastman says to replace its rods every 4 to 5 years. Check sooner on softened water.

Can I replace an anode rod myself?

Yes, with a 1-1/16 inch socket, a long breaker bar and a helper to hold the tank. Stop if the tank turns or the rod snaps. Bradford White writes its outlet-anode steps for qualified service providers.

What are the signs of a bad anode rod?

You can’t tell for sure without pulling it. A rotten-egg smell, air at hot taps or discolored hot water point to the rod or the water. Rheem’s line is bare core wire: more than 6 inches at either end means replace it.

Do I have to drain the whole tank to change the rod?

No. Turn off the power or gas and the cold supply, open a hot faucet, and drain a few gallons. For an anode on the hot outlet, Bradford White drains below the outlet nipple.

What happens if I never replace the anode rod?

Once the rod is used up, the water starts on the steel tank. Rheem says running without an anode greatly shortens tank life, and a tank that rusts through can’t be repaired.

Is it worth replacing the anode rod on an old water heater?

In my view, often not on a tank past 10 years whose rod has never been out. The rod may be seized and the tank may already be rusting. On a younger tank, a yearly check is worth it.

Does changing the anode rod void the warranty?

No. A.O. Smith treats rods as wear parts that aren’t covered. Rheem and Bradford White void the warranty only when a tank runs without an anode.

How I put this together

Why trust me

I’m Isaac Daniels, a licensed journeyman plumber in Georgia. In my 7 years of experience, these are the products I’d install. The steps and limits come from A.O. Smith, Rheem, Bradford White and Eastman documents read on Oct 22, 2026. I re-checked the A.O. Smith and Rheem rules on November 11, 2026.

How I pick

  • Maker-branded rods and name-brand tools, matched to the job by the maker’s specs.
  • New and in stock on Amazon on Oct 22, 2026, and again on November 11, 2026. No “replacement for” rods.
  • No scores: a rod, a socket and a bar do different jobs, so they’re listed as a kit.
  • Prices come from Amazon, shown with the time they were read.

Sources

  1. A.O. Smith, residential electric water heater manual 100341465 (March 2021), anode rod inspection and replacement (re-read Nov 11, 2026).
  2. Rheem, residential electric water heater manual AP21980 Rev. 02, anode rod, hydrogen gas and odor sections; gas manual AP21831.
  3. Bradford White, service manual 47150A (TTW gas models), anode inspection and replacement; service manual 47985 (D series).
  4. Bradford White, “Water Heater Anode Rods,” For The Pro (May 19, 2020, updated July 19, 2024).
  5. Bradford White, hybrid heat pump water heater installation and operation manual 238-55123-00.
  6. Eastman, Flexible Magnesium Anode Rod product page, SKUs 60286 and 60287 (eastmanplumbing.com, read Oct 22, 2026).
  7. Rheem, SP11309T part page (parts.rheem.com, read Oct 22, 2026; part record re-read Nov 11, 2026).
  8. TEKTON, SBH00224 product page and warranty page (tekton.com, read Oct 22, 2026 and Nov 11, 2026).
  9. Corro-Protec CP-R and TEKTON SHD22027 details, read from Amazon’s product listings on Oct 22, 2026 and Nov 11, 2026.
  10. U.S. CPSC recall database, searched for anode, water heater, breaker bar and socket on Oct 22, 2026, and for anode, Rheem, Eastman, TEKTON and Corro-Protec on Nov 11, 2026. No anode rod or kit recall found.
  11. Rheem Water Heating, “How to Replace a Water Heater Anode Rod” video and description (youtube.com, read Nov 11, 2026).
  12. Rheem, residential electric water heater maintenance section: magnesium anode, annual inspection, 6 in. core-wire rule, softener note (read Nov 11, 2026).
