Best Well Pump Pressure Switch (2026)

Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.

Quick answer from a licensed plumber: Match the switch you have: the same cut-in and cut-out (30/50 or 40/60 on most house systems), a contact rating at or above the pump’s horsepower at its voltage, and a 1/4 in. female port. Only the Red Lion 640134, a 30/50 switch with a low-pressure cutoff, is linked here; the Square D and Merrill switches are reference notes. The terminals carry line voltage. Makers say to kill the power first and use a qualified electrician.

Linked pick for a 30/50 well that needs a low-pressure cutoff: the Red Lion 640134 M4 switch. Check the Red Lion 640134 on Amazon

A well pump pressure switch starts the pump when tank pressure falls to its cut-in setting and stops it at the cut-out. This guide compares four switches by what Square D, Merrill and Red Lion publish. It does not cover changing settings; for that, see Well Pressure Switch 30/50 vs 40/60. For the tank and pump around it, see the best well pressure tank and constant pressure well pumps.

Well Pump Pressure Switches Compared

SwitchSettingLow-pressure cutoffRatedCase
Square D FSG2J21CP30/50No1.5 HP at 115 V; 2 HP at 230 VNEMA 1
Merrill MPSHD406040/60No1.5 HP at 115 V; 2 HP at 230 VNEMA 1
Merrill MPSM4406040/60Yes, about 10 psi below cut-in1.5 HP at 115 V; 2 HP at 230 VNEMA 1
Red Lion 64013430/50Yes, on a 10 psi drop1.5 HP, 20 A at 115 V; 3 HP, 17 A at 230 V (listing)Not stated

Ratings are single-phase: Square D and Merrill from their own documents, Red Lion from its Amazon listing. Only the Red Lion is linked; the other three are reference notes.

This one isn’t linked here

Square D Pumptrol FSG2J21CP 30/50 Pressure Switch

Class 9013 Type FSG · 30 psi cut-in, 50 psi cut-out · 15 to 30 psi adjustable differential · 1.5 HP at 115 V, 2 HP at 230 V single-phase · NEMA 1 · 1/4 in. NPSF internal connection · no low-pressure cutoff (that is the M4 form) · per Square D

Square D’s Pumptrol catalog lists the FSG2J21CP as a standard-action switch: contacts open on rising pressure, 2-pole, NEMA 1 case, 30 psig cut-in and 50 psig cut-out. It calls Type FSG the standard water pump switch and says it suits jet, submersible and reciprocating pumps. The catalog rates FSG at 1.5 HP at 115 V and 2 HP at 230 V, single-phase, with an approximate 15 to 30 psig adjustable differential. Square D’s data bulletin also says the FSG line is CSA approved. The “CP” is Square D’s clamshell package.

Square D’s instruction sheet has two nuts: range for the cut-in, differential for the cut-out. Its bulletin says moving the cut-in moves the cut-out by the same amount, and gives 3-1/2 turns of the range nut to go from 30/50 to 40/60. Neither Square D listing is linked here. Brand and model check out as Square D and FSG2J21CP.

  • Square D lists it as its standard water pump switch
  • Catalog gives HP by voltage and a 15 to 30 psig differential
  • Bulletin gives turns to move from 30/50 to 40/60
  • CSA approved, per Square D’s bulletin
  • Not linked here
  • No low-pressure cutoff on this version
  • The listing says IP54; Square D lists NEMA 1 (see the conflicts section)
  • Limited to 1.5 HP at 115 V

Reference (not linked). Square D FSG2J21CP 30/50 switch.

Merrill MPSHD4060 Heavy-Duty Pressure Switch

Heavy-duty build · 40 psi cut-in, 60 psi cut-out · brass connections for up to No. 8 wire · 1.5 HP at 115 V, 2 HP at 230 V · NEMA 1 cover · NSF/ANSI/CAN 61 and 372 per Merrill

Merrill’s spec sheet (March 2025) describes a fiber board bracket, extra-large silver contacts, and heavy brass wire connections with stainless steel set screws that hold up to No. 8 wire. A hex wrench is stored in the base and adjustment instructions are inside the cover. It gives the connection as 1/4 in. female NPT and the two-pole ratings as 1-1/2 HP at 115 V and 2 HP at 230 V single-phase.

Merrill’s compare table says the heavy-duty line is for systems that cycle more often; that is Merrill’s own positioning. A heavier switch does not cure short cycling: Square D’s bulletin traces rapid cycling to the tank (waterlogged, not charged or undersized), and Merrill’s 2015 cut sheet says switches burned up by rapid cycling are not warranted.

Merrill’s MPS spec sheet adds two limits that apply to buyers: factory settings are +/- 8 psi, so field adjustment may be needed, and the pump and system’s maximum operating pressure must be at least 12 psi above the switch’s shut-off setting. It also says one turn of the adjustment screw is 2 psi. This ASIN is the 40/60 only; other settings are separate listings.

  • Merrill states the wire size (No. 8) and the ratings by voltage
  • Adjustment instructions are inside the cover, per Merrill
  • Merrill lists NSF/ANSI/CAN 61 and 372 certification
  • No low-pressure cutoff (Merrill sells that as the MPSHDM4)
  • The 115 V rating is the same 1-1/2 HP as the standard MPS
  • The Amazon bullet says 2 HP at 230 V, usable at 115 V, without a 115 V rating

Reference (not linked). This one isn’t linked here. The details above are for reference only.

Merrill MPSM44060 40/60 Low-Pressure Cut-Off Switch

40 psi cut-in, 60 psi cut-out · low-pressure cut-off about 10 psi below cut-in, per Merrill · manual start/off lever · 1/4 in. female NPT · NEMA 1 (listing title)

Merrill’s cut sheet lists the MPSM4 series as a “Low Water Cut-Off Pressure Switch” that shuts off at approximately 10 psi below cut-in pressure, with an auto-start, manual start or off lever. Merrill’s compare table calls it extra pump protection, and also warns that a low-pressure cut-off may nuisance-trip on some high-flow or low-yield systems.

Two limits. The cut sheet is a 2015 distributor copy and we did not find a current Merrill spec sheet for this model. And its ratings table says 1-1/2 HP at 115 V and 2 HP at 230 V, while the Amazon bullet says 2 HP at 115 V; read the label on the switch before you wire it. For the same protection on a 30/50 system, Merrill sells the MPSM43050; it isn’t linked here.

  • Cuts the pump about 10 psi below cut-in, per Merrill
  • Manual lever for start or off
  • Same 1/4 in. connection as the standard MPS
  • Merrill warns of nuisance trips on high-flow or low-yield systems
  • HP at 115 V differs between Merrill’s cut sheet and the listing
  • Only a 2015 cut sheet found for this model

Reference (not linked). This one isn’t linked here. The details above are for reference only.

Best 30/50 Low-Pressure Cutoff

Red Lion 640134 M4 Low-Pressure Cut-Off Switch

30 psi cut-in, 50 psi cut-out, adjustable · M4 type, shuts the pump off on a 10 psi drop · manual reset lever · 1/4 in. female NPT · 115 V up to 1.5 HP and 20 A, 230 V up to 3 HP and 17 A (listing)

Red Lion’s accessories list carries item 640134 as a 30/50, 1/4 in. NPTF, M4 pressure switch. The Amazon listing (brand Red Lion, model 640134) says it shuts the pump off when pressure drops 10 psi, so the pump does not run dry. To restart, it says to prime the pump and hold the lever down until the pump kicks in. Its stated limits are 115 V pumps up to 1.5 HP and 20 A, or 230 V pumps up to 3 HP and 17 A.

We did not find a Red Lion instruction sheet for this switch, so the ratings and the reset steps come from the listing. The listing says the adjustment instructions are on the label under the cover. It does not state an enclosure rating.

  • Low-pressure cutoff on a 30/50 setting
  • The listing states HP and amp limits for both voltages
  • Red Lion lists the item in its own accessories list
  • No Red Lion instruction sheet found; specs come from the listing
  • No enclosure rating stated
  • Sold preset at 30/50 (adjustable, per the listing)
  • After a low-water trip, a person has to hold the lever to restart

Verdict: The pick for a 30/50 well, or a Red Lion jet pump, that needs a low-pressure cutoff, if you accept ratings taken from the listing.

I send an occasional note when a new guide goes up — repairs worth doing yourself, and the parts that actually last. No spam, no course funnel; written by a licensed Georgia plumber.

Before You Buy: Five Checks

  • Setting. Copy the two numbers on your old switch. The pump has to reach the cut-out: Pentair’s sheet says the cut-off should be at least 5 psi below the pump’s dead-head pressure, and Merrill says the system’s maximum operating pressure should be at least 12 psi above the shut-off setting.
  • Contacts. Match the pump nameplate’s voltage and horsepower to the rating in the table. Square D’s bulletin lists burned contacts as a sign the pump’s electrical rating is too high for the switch, and says to add a contactor or use a switch with heavier contacts. Square D’s FYG type is rated 2 HP at 115 V and 3 HP at 230 V, and Merrill’s MPSXHD line is its larger switch; neither is linked here. Lefoo lists its LF16 at 2 HP at 120 V and 3 HP at 240 V, and it isn’t linked here.
  • Low-pressure cutoff. Square D says its cutoff stays fixed at 10 psi below cut-in, is not adjustable on its own, and does not work if the cut-in is set below 10 psi. Square D says a cutoff that trips again right after a reset means the water source is low; a new switch will not fix that.
  • Port and gauge. All four take a 1/4 in. female connection that screws onto the 1/4 in. male fitting under the old switch. Square D lists its thread as NPSF and Merrill as NPT; those are different thread standards (our note), so follow the new switch maker’s instructions for the fitting and thread sealant, and check the joint for leaks once the system is back under pressure (our advice). A switch has no gauge. Square D’s bulletin says to remove the switch and confirm that the entry to the diaphragm is free of silt and obstructions, and warns that a plugged line keeps the switch from reading tank pressure. With the power off and the pressure released (open a faucet near the tank until the water stops), check the fitting under the old switch the same way before you thread on the new one (our advice). It also says to check the switch against a pressure gauge; see the best well pressure gauges.
  • Enclosure. Square D and Merrill list NEMA 1 covers. Square D’s ambient rating is -22 to 158°F. Keep the switch dry (our advice).

Installing It: What the Makers Say

  • Wiring. Merrill: with power off, follow the wiring diagram under the cover. Square D’s bulletin advises surge protection at the service entrance and at the wellhead control box, and motor overload protection from the installer. Test for voltage again before you touch a terminal any time power may have been restored (our advice).
  • Contacts. Square D says contacts may look pitted; do not sand, file or chemically clean them.
  • Adjusting. Pentair’s sheet says never to set a cut-on below 20 psi or a cut-off above 60. It gives 2-1/2 psi per turn of its nut; Merrill gives 2 psi per turn of its screw. Square D says check the switch several times after adjusting.
  • Pressure limits. Square D’s instruction sheet says not to use the switch above 220 psi. Pentair warns of explosion risk if you run the pump against a closed discharge longer than needed to read the pressure. Amtrol gives 150 psig as the maximum working pressure of its Well-X-Trol tanks and 125 psig as the maximum relief valve setting in its submittal data. Its manual says to install the relief valve at the tank’s connection to the system piping, able to discharge the pump’s capacity, to protect the system if the pressure switch fails to shut the pump off. On another tank, use the relief setting that tank’s maker gives (our advice).

The Tank Precharge Rule

Amtrol, Pentair and Square D agree: set the tank’s air precharge 2 psi below the switch’s cut-in. Amtrol says 2 psig below the pump cut-in setting, so 38 psig for 40/60. Pentair’s chart runs 18, 28 and 38 psi for 20, 30 and 40 cut-ins. Square D’s bulletin (used when a tank maker gives no figure) says to turn off the pump, drain the tank and check the air with a gauge.

Amtrol’s manual carries explosion warnings: do not add air to a tank that is corroded, has lost air or shows shorter pump cycles, and it says only qualified professionals should check, adjust or recharge tank precharge. Changing a switch setting changes this number, so do not change one without the other.

When to Call a Pro

  • You are not sure of the pump’s voltage or horsepower, or it is a 3-wire pump with a control box.
  • The breaker trips, the pump never shuts off, or the contacts look burned.
  • The low-pressure cutoff keeps tripping. That usually points to the well or the pump, not the switch.
  • You are changing the setting, which means changing the tank precharge.
  • Anything at the tank’s air valve or inside the switch cover. Call a licensed plumber or electrician (my advice).

Where the Documents Disagree

  • Square D ranges. Its catalog footnote gives 20 to 65 psig as the cut-in range and 10 to 45 as the cut-out range. Amazon’s Schneider listing for the 9013FSG2J21 calls 20 to 65 psi the cut-out range. The labels look swapped in one of them, so read the label on your switch.
  • Square D enclosure. The FSG2J21CP Amazon listing bullet says IP54. Amazon’s own 9013FSG2J21 listing says NEMA 1 in its bullets but IP54 in its item details. Square D’s catalog says NEMA 1. We use NEMA 1.
  • Merrill MPSM44060. The listing says 2 HP at 115 V; Merrill’s cut sheet says 1-1/2 HP.
  • Merrill heavy-duty rating. Its 2025 sheet says 2 HP at 230 V; a 2015 Merrill sheet lists higher ratings. We used the 2025 sheet.

FAQ

What is the best well pump pressure switch?

The one that matches your old switch: same cut-in and cut-out, a contact rating at or above your pump’s horsepower at its voltage, and a 1/4 in. female port. For a 30/50 well our pick is the Square D Pumptrol FSG2J21CP. For a 40/60 well with a pump at or under 1-1/2 HP on 115 V or 2 HP on 230 V that starts often, the Merrill MPSHD4060.

Do I need a switch with a low-pressure cutoff?

It is optional. Square D and Merrill both say it shuts the pump off about 10 psi below the cut-in to protect against running dry. Square D adds that if it cuts out again after a reset, the water source is low, and you should not reset it again until the well has recharged. Merrill warns it may nuisance-trip on high-flow or low-yield systems.

Can I change a 30/50 switch to 40/60?

The same Square D switch can be adjusted: its bulletin gives 3-1/2 turns of the range nut. But the tank precharge has to move up with it, and Amtrol’s manual says that failing to follow its instructions when the precharge must rise with a new switch setting can cause a rupture or explosion. See our 30/50 vs 40/60 guide and have a pro do it.

Is a well pump controller the same as a pressure switch?

Not always. A pressure switch turns the pump on and off at two pressures. Merrill’s MCSHD control switch adds a run capacitor for 3-wire pumps and replaces the control box parts, per Merrill. A constant-pressure controller is a different system: see our constant pressure well pump guide.

Can I replace a well pump pressure switch myself?

Merrill recommends a licensed electrician for wiring and installation, and Square D says electrical equipment should be serviced only by qualified electrical maintenance personnel. My advice: if you cannot name your pump’s voltage and horsepower and prove the power is off, hire it out.

Why Trust Plumbing Picks

Plumbing Picks is written by a licensed Georgia journeyman plumber. Every size, rating, dimension and spec on this page comes from the manufacturer pages and documents listed below, which we opened and read, or from the Amazon listing we link. Links go to listings sold by Amazon.com. Where a link goes to Amazon we may earn a commission at no extra cost to you. Nobody pays to be included here. More on who writes this and how we pick.

Sources

  • Square D (Schneider Electric): data bulletin 9013DB0701, maintenance and troubleshooting for Class 9013F and 9013G pressure switches (12/2007) (images.thdstatic.com)
  • Square D: Pumptrol instruction sheet 65013-005-39, types FSG, FYG, FSW, FYW (Rev. 01, 08/2010) (pdf.lowes.com)
  • Square D: Pumptrol catalog pages for Class 9013 types FSG, FRG and FYG (copy hosted by a distributor) (assets.unilogcorp.com)
  • Merrill Manufacturing: MPS pressure switch spec sheet (03/2025) (merrillmfg.com)
  • Merrill Manufacturing: MPSHD heavy-duty pressure switch spec sheet (03/2025) (merrillmfg.com)
  • Merrill Manufacturing: pressure switch cut sheet, incl. MPSM44060 (2015, distributor copy) (pimmedia.winsupplyinc.com)
  • Merrill Manufacturing: pressure switch series compare table (merrillmfg.com)
  • Merrill Manufacturing: pressure switches guide (merrillmfg.com)
  • Merrill Manufacturing: MCSHD control switch spec sheet (03/2025) (merrillmfg.com)
  • Pentair: Adjusting Well Pump Pressure Switches, sheet U80-129 (5/10/06) (pentair.com)
  • Wayne: CWS series jet pump instruction manual (waynepumps.com)
  • Goulds Water Technology: jet pumps installation, operation and troubleshooting manual (IM102) (xylem.com)
  • Amtrol: Well-X-Trol installation and operation manual (07/25) (amtrol.com)
  • Lefoo: LF16 water pump pressure switch page (parameters table) (lefoo.com)
  • Red Lion: accessories list, item 640134 (pressure switch 30/50, 1/4 in. NPTF, M4) (redlionproducts.com)
  • Amazon listings for the Red Lion listing linked above and the Square D FSG2J21CP (not linked), including their description text and bullets

Summary

Copy the two pressure numbers and the horsepower and voltage from what you have, then buy a switch that matches. For a 30/50 well that needs a low-pressure cutoff, the Red Lion 640134 is the linked pick. The Square D FSG2J21CP and the two Merrill switches are reference notes, there for their published specs. Kill the power, lock it out, and hire the wiring out if there is any doubt.
