Dishwasher Supply Line and Elbow Size: What Fits the Inlet?

I match dishwasher supply line and elbow size to the inlet first. The Eastman 41150 covers both common elbows; Whirlpool W10685193 is the genuine hose-thread option.

As an Amazon Associate I earn from qualifying purchases. How this site earns

Updated November 15, 2026 · Connection guidance and parts availability.

Black built-in dishwasher beneath a white kitchen counter, with the door closed
Dishwasher room scene from the Whirlpool fitting’s Amazon listing.

The short answer

I use a 3/8-inch compression-ended supply line for the common setup here, then match the elbow to the appliance inlet: MIP for the specified female pipe thread, or a washer-sealed female hose swivel for a 3/4-inch male hose thread. [1] [2]

New line and either elbow
Eastman 41150 kit has both common elbow types.
Genuine Whirlpool fitting
W10685193 for the matching hose-thread inlet.
Separate aftermarket elbow
Shark Industrial for a confirmed hose-thread connection.
Check the inlet before buying

Picks by need

I choose the kit when the line also needs replacing, and an elbow alone only when the existing line remains suitable under the appliance instructions.

Eastman 41150 dishwasher installation kit
Product photo from the Amazon listing.

Replacing the line and matching either inlet

Eastman 41150 dishwasher installation kit

I would choose this kit when I need a new connector and both common elbow styles in one package. The straight power cord is included, but the dishwasher’s electrical instructions decide whether that cord is appropriate.

Buy it if
The model calls for a conventional compression-ended hose and one of these elbows.
Skip it if
The appliance requires a proprietary inlet hose or a different electrical connection.
The tradeoff
The extra cord and fittings are unnecessary if I only need a replacement elbow.

6-foot stainless-braided line; 3/8-inch compression ends; MIP and female-hose elbows; straight cord. [3]

$24.97 at Amazon

Check price on Amazon
Whirlpool W10685193 inlet fitting
Product photo from the Amazon listing.

Genuine Whirlpool hose-thread fitting

Whirlpool W10685193 inlet fitting

I would choose the genuine fitting when the dishwasher’s parts list calls for W10685193. I check the model lookup instead of relying only on an old replacement-number list.

Buy it if
The Whirlpool instructions specify this washer-sealed hose swivel.
Skip it if
The valve has a small female pipe-thread inlet.
The tradeoff
It is an elbow only; I still need a suitable supply line.

3/4 × 3/8-inch brass swivel elbow; genuine Whirlpool W10685193. [9]

$13.97 at Amazon

Check price on Amazon
Shark Industrial dishwasher swivel elbow
Product photo from the Amazon listing.

Separate aftermarket hose-thread elbow

Shark Industrial dishwasher swivel elbow

I would compare this standalone fitting when a sound, compatible line is already present and the appliance allows an aftermarket connector. I check the washer and the mating male inlet before assembly.

Buy it if
The actual connections match the compression line and male hose-thread inlet.
Skip it if
The appliance calls for its own proprietary hose or a genuine model-specific fitting.
The tradeoff
It is sold by Blackhawk Premium Supplies, rather than Amazon or the appliance maker.

3/8-inch compression × 3/4-inch female hose thread; separate brass swivel fitting. [9]

$5.95 at Amazon

Check price on Amazon

Product prices and availability are accurate as of the date/time indicated and are subject to change.

The sizes, once and for all

I separate dishwasher supply line and elbow size into the stop outlet, the connector ends, and the inlet thread. The common braided connector has 3/8-inch compression nuts at both ends. The elbow adapts that line to the dishwasher valve; I check the model’s installation sheet before ordering. [1] [2]

Connection spec sheet
Connection Size to match Part and source
Sink stop outlet Commonly 3/8-inch OD compression. Check the installed valve. [2] The connector’s compression nut. [2]
Supply line 3/8-inch compression at both ends. BrassCraft offers 48, 60 and 72-inch versions; Eastman’s kit is 6 feet; Bosch’s kit hose is 59 inches. [2] [3] [4] BrassCraft B1-DW6 family, Eastman 41150, Bosch 11045438. [2] [3] [4]
Female pipe-thread inlet Confirm a 3/8-inch female pipe-thread inlet in the appliance manual. [2] [5] 3/8-inch MIP × 3/8-inch compression elbow. BrassCraft’s B1-DW6 family includes this type. GE names WX28X332 as its dishwasher connector elbow. [2] [5]
Male hose-thread inlet 3/4-inch male hose thread on the appliance, with a flat washer-sealing connection. [1] [11] 3/4-inch female hose swivel × 3/8-inch compression elbow. Whirlpool W10685193 is the genuine fitting named in Whirlpool installation literature. [1] [11]

Whirlpool’s W10278636RC kit pairs a braided hose with both elbow styles. Bosch’s 11045438 kit includes a braided hose and a hose-thread elbow. Those examples show why I read the connection description, rather than buying by the dishwasher brand alone. [4] [7]

Which elbow, MIP or garden hose?

Small female pipe-thread port

If the inlet is female pipe thread, the male end of the MIP elbow goes into the valve. The compression end accepts the supply-line nut. BrassCraft groups these connectors as compression × compression with MIP elbow, and also offers a FIP × compression version. I match the stop end as carefully as the appliance end. [2] [8]

I use only the thread sealant and tightening method allowed by the appliance and fitting instructions. Pipe thread is a different joint from either a compression seat or a washer-sealed hose swivel. [10]

Large male hose-thread port

The female swivel elbow screws over the dishwasher’s male hose thread and seals against its rubber washer. Whirlpool identifies its genuine W10685193 as a 3/4 × 3/8-inch elbow fitting. Its listing cross-references W10574777, 3288910, PS9493732, W10273460, W10273460BU, W10574777BU, W10754429 and W10829954. [9]

I check for the washer before assembly and start the nut by hand. A larger wrench does not correct mismatched threads. If the nut will not turn freely, I stop and check the thread type. [6]

The Eastman 41150 kit retains the live guide’s both-elbows option. The Whirlpool fitting remains the genuine hose-thread option. The Shark Industrial fitting remains the separate aftermarket option; its listing’s phrase “female garden hose thread connection” is inconsistent with a female swivel mating to a male appliance inlet. I identify the appliance’s actual thread before selecting that part. [3] [9]

Find the matching connection

I start with the valve and the manual, then choose the line. This checker matches the two common inlet styles to the parts below; it does not replace the model’s installation instructions or an in-person check.

Identify the inlet first

Leave power and water off while identifying connections. If a thread or valve is unclear, check the model’s manual before buying.

The line itself

Whirlpool permits copper tubing with a compression fitting or a flexible braided supply line, and advises against plain plastic tubing. That warning does not mean every approved braided hose must be metal inside. The Eastman line has a reinforced PVC core beneath its stainless braid. BrassCraft’s B1-DW6 is a braided-polymer connector with PVC tubing inside. I use the complete connector rated for the appliance, rather than loose tubing chosen by appearance. [1] [2] [3]

BrassCraft lists its connector for potable-water distribution in accessible locations. Its 48, 60 and 72-inch choices let me match the run instead of stretching a short hose. I measure from the stop to the inlet along the intended route, with enough slack to position the machine without kinking or trapping the line. A 60-inch line is a size option, not a guarantee that every adjacent-sink installation will fit. [2]

I check the hose route with the dishwasher out and again as it slides back. The hose, drain and electrical connection must remain clear of sharp edges and moving parts. Whirlpool specifically warns against pinching the water line, drain hose or cord between the dishwasher and cabinet. [6]

Hooking it up

  1. Isolate power and water

    I turn off the dishwasher circuit before moving the appliance or opening its access panel. I unplug a cord-connected appliance after isolating power, then close the dedicated hot-water stop and confirm the water is off. A hardwired disconnect belongs with a qualified electrician. [1] [6]

  2. Identify the inlet and seal

    I compare the valve connection with the model’s manual. The hose swivel needs its seated rubber washer. The MIP elbow needs the pipe-thread sealing method specified for that joint. I keep tape away from the compression seat. [10] [6]

  3. Connect without forcing the threads

    I start threaded connections by hand and follow the model’s tightening instructions. Whirlpool warns against overtightening its inlet coupling. I do not use one model’s turn count as a rule for every valve or hose. [6]

  4. Open the valve and check for leaks

    I reopen the water slowly with the joints accessible, then inspect each connection before restoring power. I check again during the appliance’s instructed test cycle and after positioning the dishwasher. If a joint seeps, I isolate the supply and correct it before use. [1]

  5. Confirm the hot-water requirements

    Whirlpool calls for a dedicated hot-water shutoff and describes 120°F water as ideal. Its stated supply range is 20 to 120 psi. I use the specific model’s manual if its requirements differ. [1]

A missing dishwasher stop needs a properly selected valve or branch connection on the hot supply. I match that work to the existing pipe and local requirements. I do not improvise a saddle-valve connection. If the stop will not close, or a pipe or fitting is cracked, I stop and call a licensed plumber.

If the dishwasher will not fill, I first check whether the stop is open and the hose is kinked. Debris can obstruct a newly connected inlet, but I follow the model’s service instructions before disturbing an inlet screen. I do not pry a screen from the valve or work on the inlet with power connected. [1]

Plumber’s fit check

  1. Check the stop outlet

    The supply nut must match the valve’s actual connection. A compression nut cannot make an arbitrary pipe-thread outlet compatible.

  2. Check the appliance port

    Look for male hose thread, female pipe thread, or a factory hose assembly. Compare that connection with the model’s instructions.

  3. Check the sealing surface

    The swivel washer must be present, flat and undamaged. A compression connection seals at its seat, rather than at tape on the nut.

  4. Check the route

    Leave working slack, keep the line out from under the feet, and inspect the joints after the machine returns to its opening.

Seal check before tightening
Joint What seals it My check
Hose swivel Rubber washer against the inlet face. [6] Seat the washer; start by hand.
Compression The connector’s designed compression seal. [6] No tape on the compression fitting.
MIP pipe thread The specified pipe-thread joint. [2] Follow the fitting and appliance instructions for compatible sealant. [10]

FAQ

What size is a dishwasher water supply line?

For the common setup described here, the braided connector has 3/8-inch compression ends. BrassCraft lists 48, 60 and 72-inch choices; Eastman’s 41150 kit is 6 feet. I still match the installed stop and the appliance manual before ordering. [2] [3]

What elbow do I need for a dishwasher?

A confirmed female pipe-thread inlet takes the matching MIP elbow. A 3/4-inch male hose-thread inlet takes the female hose swivel with a washer. Both styles have a 3/8-inch compression connection for the common supply line. [1] [2]

Can I use the old dishwasher supply line on a new machine?

I follow the replacement instructions supplied with the new dishwasher. Whirlpool recommends a new water line when replacing the appliance and replacing a flexible braided inlet hose after 5 years. A thread adapter alone does not make a worn hose suitable for reuse. [6]

Does a dishwasher need its own shut-off valve?

Whirlpool calls for a dedicated shut-off valve on the hot-water supply. I want that valve accessible so the dishwasher can be isolated without disturbing another connection. [1]

Should the dishwasher be on hot or cold water?

The Whirlpool guidance cited here specifies hot water, ideally 120°F. I check the exact model’s instructions before connecting a different appliance. [1]

Does the hose-thread elbow need tape?

The washer seals the hose-thread swivel. Whirlpool’s instructions require that washer to be seated and prohibit tape on the compression fitting. I reserve pipe-thread sealant for a pipe-thread joint whose instructions call for it. [2] [6]

When to call a plumber

I call a licensed plumber when the stop will not isolate the water, the inlet valve is cracked, a connection is corroded, or the new line cannot be routed without strain. A missing dedicated stop or an unfamiliar pipe connection also needs proper assessment. I use a qualified electrician for hardwired work or any uncertain electrical connection.

Why trust Plumbing Picks

How I chose

I’m Isaac Daniels, a licensed journeyman plumber in Georgia. I choose the connector by its mating threads, the hose route and the appliance instructions. For this guide I compared three products: the Eastman kit, the genuine Whirlpool elbow and the Shark Industrial elbow. I matched their exact Amazon listings against the maker manuals and spec sheets below.

BrassCraft’s connector family, Bosch’s kit and GE’s elbow remain information references for identifying connections. They are not additional shopping picks here. I keep the product choices tied to the three existing Amazon listings, rather than silently substituting a different part.

I check seller, new condition and availability alongside model identity. A listing’s certification badges do not establish a model’s certification, so I make no independent certification claim for these fittings. The recall screen on November 15, 2026 found no matching connector recall in the CPSC dataset searched; that is not certification of a product’s safety.

Amazon links can earn a commission at no extra cost to you. Nobody pays to be included. Read about Isaac and how I pick .

Sources

  1. Whirlpool Product Help, Dishwasher Water Supply Connection
  2. BrassCraft B1-DW6 connector family and available lengths
  3. Eastman 41150 dishwasher installation kit, maker details
  4. Bosch 11045438 / SMZ3IN1UC junction box and supply hose kit
  5. GE WX28X332 dishwasher connector elbow, identification reference
  6. Whirlpool W11774893A installation instructions, water supply and inlet connection
  7. Whirlpool W10278636RC kit description
  8. BrassCraft dishwasher braided-polymer connector end types
  9. Exact Amazon product listings for the retained picks
  10. BrassCraft dishwasher connector installation instructions
  11. Whirlpool W10685193 maker specifications

Bottom line

I buy the connector by both end connections and the route it must follow. For a conventional compression-ended line, the dishwasher inlet decides which elbow belongs on it. I isolate power and water first, protect the washer or compression seat, and inspect every joint for leaks before leaving the machine in service.
