Quick answer

MIP is the male thread and FIP is the female one. Both are normally NPT, the tapered US pipe thread, so a ½ in. MIP screws into a ½ in. FIP. Code puts the tape or dope on the male thread only; my pick is RectorSeal T Plus 2.

RectorSeal T Plus 2 pipe thread sealant, quarter pint can with brush top
Best for sealing MIP threads on water and gas$8.78 at AmazonPrice as of Nov 22, 2026, 9:30 AM EST
Check it on Amazon

Two sealants and two tools that name a thread

Specs come from RectorSeal and Mitutoyo, not the listings.

RectorSeal T Plus 2 pipe thread sealant, quarter pint can with brush top
Best for sealing MIP threads on water and gas

RectorSeal T Plus 2

$8.78 at Amazon
Check it on Amazon
Price as of Nov 22, 2026, 9:30 AM EST
Roll of RectorSeal white PTFE thread sealing tape, half inch wide
Best for quick water joints and toolbox carry

RectorSeal PTFE tape 35942

$2.98 at Amazon
Check it on Amazon
Price as of Nov 22, 2026, 9:30 AM EST
Reference (not linked)

Mitutoyo 188-151 pitch gage

Shown for comparison only.

Reference (not linked)

Mitutoyo 505-742J dial caliper

Shown for comparison only.

PickKey specsPick it ifSkip it if
RectorSeal T Plus 2¼ pint (118 mL), brush top, PTFE plus synthetic fibers, Water hot to 203°F, 10,000 psi liquids, 2,000 psi gases, 2-year shelf lifeYou seal a mix of water, gas and plastic threads and want one can that covers them, with a brush that puts it only on the male thread.You only do a few water joints a year and want something that lives in a pocket. The RectorSeal 35942 tape is cleaner.
RectorSeal PTFE tape 35942½ in. wide, 260 in. long (about 21½ ft), Pure PTFE, White, −100 to 550°F (35949 page), UPC 021449359429You’re making a handful of water joints, like a hose bibb adapter or a shower arm, and want a clean, fast seal you can carry anywhere.The joint is on a gas line. RectorSeal’s page for this tape names no gas listing; use T Plus 2, which has one.
Mitutoyo 188-151 pitch gage (reference)51 leaves, Inch: 4 to 42 TPI (188-111), Metric: 0.4 to 7 mm (188-122), 11½ TPI leaf, 27 TPI leaf, 60° thread formYou face unknown threads often, on old pipe or on parts made to other standards, and want to know the threads per inch for sure.You only need to tell ½ from ¾ in. on a US fitting. The caliper alone settles that.
Mitutoyo 505-742J dial caliper (reference)0 to 6 in., ±0.001 in. accuracy, 0.001 in. graduation, 0.1 in. per dial turn, 175 g, Fitted plastic caseYou need to tell a ½ from a ¾ in. thread, or NPT from a straight thread, without guessing from the box.You already know the size and only need to seal it. A can of T Plus 2 is all the joint needs.

What a ½ in. MIP or FIP really measures

The size on the label is a name, not a measurement. Here’s what each one measures across the threads.

Male thread (MIP), measured across the threads Female thread (FIP), measured inside ⅛ in. NPT 27 threads per inch 0.401 0.336 ¼ in. NPT 18 threads per inch 0.533 0.436 ⅜ in. NPT 18 threads per inch 0.668 0.571 ½ in. NPT 14 threads per inch 0.832 0.705 ¾ in. NPT 14 threads per inch 1.043 0.914 1 in. NPT 11.5 threads per inch 1.305 1.148 1¼ in. NPT 11.5 threads per inch 1.649 1.491 1½ in. NPT 11.5 threads per inch 1.888 1.730 2 in. NPT 11.5 threads per inch 2.362 Inches, crest to crest. Swagelok says real parts can measure a little off these numbers because of manufacturing tolerances, so match the threads per inch too. Male thread (MIP), measured across the threads Female thread (FIP), measured inside ⅛ in. NPT · 27 threads per inch 0.401 0.336 ¼ in. NPT · 18 threads per inch 0.533 0.436 ⅜ in. NPT · 18 threads per inch 0.668 0.571 ½ in. NPT · 14 threads per inch 0.832 0.705 ¾ in. NPT · 14 threads per inch 1.043 0.914 1 in. NPT · 11.5 threads per inch 1.305 1.148 1¼ in. NPT · 11.5 threads per inch 1.649 1.491 1½ in. NPT · 11.5 threads per inch 1.888 1.730 2 in. NPT · 11.5 threads per inch 2.362 Inches, crest to crest. Swagelok says real parts can measure a little off these numbers because of manufacturing tolerances, so match the threads per inch too.
Source: Swagelok Thread and End Connection Identification Guide (MS-13-77), NPT tapered thread tables.

A ½ in. MIP fitting measures about 0.83 in. across its threads, and a ¾ in. one about 1.04 in. The name is the nominal pipe size, which Petersen notes is neither the pipe’s inside nor its outside diameter.

The female side runs smaller. Swagelok lists a ½ in. FIP at about 0.705 in. inside the threads, because the male thread has to fit inside it.

The thread count changes in steps, not with every size. ⅛ in. has 27 threads per inch; ¼ and ⅜ in. have 18; ½ and ¾ in. have 14; 1 in. through 2 in. all have 11½. So two numbers, the diameter and the threads per inch, are enough to name almost any pipe thread in a house.

That’s why the two tool picks are a caliper and a pitch gauge.

Why a MIP into a FIP seals

NPT seals on its own threads. Some straight threads look the same and seal somewhere else.

NPT: tapered, seals on the threads seals along these threads MIP (male) FIP (female) Taper 1°47′, thread angle 60°. It wedges tighter as it turns in, and the seal is in the threads, so it needs tape or pipe dope. NPSM: straight, seals at a seat seals at this cone Male end Nut Same threads per inch as NPT, but no taper. The threads only hold the nut; a cone-shaped seat makes the seal. NPT: tapered, seals on the threads seals along these threads MIP (male) FIP (female) Taper 1°47′, thread angle 60°. It wedges tighter as it turns in, and the seal is in the threads, so it needs tape or pipe dope. NPSM: straight, seals at a seat seals at this cone Male end Nut Same threads per inch as NPT, but no taper. The threads only hold the nut; a cone-shaped seat makes the seal.
Drawn from the Swagelok guide’s NPT and NPSM pages. The taper is drawn larger than life so you can see it.

NPT threads taper 1°47′ along their length, per Swagelok, with a 60° thread angle. As a MIP turns into a FIP, the threads wedge tighter, and the seal forms right there on the thread flanks.

Swagelok is blunt about the next part: tapered pipe threads always need a sealant to seal and to cut the risk of galling. That’s the job of tape or pipe dope.

NPSM, the straight cousin, has the same threads per inch as NPT and no taper. Swagelok’s drawing shows its seal at a 30° cone seat, with the threads only holding the nut. Tape on those threads doesn’t fix a bad seat.

So the first question with any leak is which kind of thread you have.

RectorSeal T Plus 2 for the MIP side

Two of these seal a thread and two name it, so none of them is scored against the others.

RectorSeal T Plus 2 pipe thread sealant, quarter pint can with brush top
RectorSeal T Plus 2 pipe thread sealant with PTFE, 23631, ¼ pint. Product photo: Amazon.

T Plus 2 is RectorSeal’s non-hardening pipe dope: PTFE and synthetic fibers in a resin base with mineral fillers. Item 23631 is the ¼ pint brush-top can, 118 mL.

The data sheet covers the jobs a house throws at you. Water hot or cold, with hot water listed to 203°F. Natural gas and propane in the vapor state. RectorSeal rates it to 10,000 psi on liquids and 2,000 psi on gases.

The gas listing is narrower than those numbers. Under ANSI LC 7-2009, RectorSeal lists it for natural gas and LP vapor up to 1¼ in. pipe, at a working pressure up to 125 psi, from −40 to 125°F. On bigger gas pipe, use a sealant listed for that size.

Where it does well

  • Water hot or cold, plus natural gas and propane vapor
  • NSF/ANSI/CAN 61 certified
  • Non-hardening; pressurize right away
  • Metal and plastic pipe, incl. CPVC

What to watch

  • Not for oxygen lines
  • Gas listing stops at 1¼ in. pipe
  • Gas working pressure 125 psi max
  • Messier than tape
  • Stir before each use

It’s certified to NSF/ANSI/CAN 61 for drinking water and is lead free with no other metals, per the sheet. It’s also certified to IAPMO PS-36 for PE, PVC, CPVC and ABS, and it carries the FBC System Compatible mark for FlowGuard Gold CPVC.

The brush top matters for code. The 2024 IPC puts compound on the male threads only, and the brush makes that easy: wipe the MIP clean, stir the can, brush the threads and assemble. RectorSeal says the line can go into service right away.

One line on the sheet disagrees with the code. RectorSeal says to coat male threads only up to 1¼ in. and both threads on larger pipe. The IPC sections for copper and steel say male threads only. On an inspected job, I’d follow the code.

Two limits. RectorSeal says not to use it on oxygen lines. And it’s a paste, so stir it before each use, as the sheet says. Since it’s non-setting, RectorSeal says it won’t dry out in the can, with a two-year shelf life.

My call: if you keep one sealant for threaded water and gas joints, this is it, and the brush keeps it on the MIP side where the code wants it.

RectorSeal 35942 tape for water joints

Roll of RectorSeal white PTFE thread sealing tape, half inch wide
RectorSeal PTFE tape 35942, ½ in. × 260 in.. Product photo: Amazon.

Item 35942 is RectorSeal’s ½ in. wide PTFE tape on a 260 in. roll, about 21½ ft. RectorSeal lists it as pure PTFE for metal and plastic threaded pipe joints.

RectorSeal’s page says the tape resists most liquids and gases, and calls it non-toxic, completely inert and non-flammable. The same tape in 1 in. width, item 35949, lists a range of −100 to 550°F. That’s far more heat than any water line will see.

Tape is the other half of the code line. The 2024 IPC says pipe-joint compound or tape goes on the male threads only, so this wraps the MIP, never the inside of the FIP. Wrap the outside of the male thread, where the code puts it.

Where it does well

  • Pure PTFE, per RectorSeal
  • Metal and plastic threads
  • Inert and non-flammable, per RectorSeal
  • Nothing to stir

What to watch

  • No gas listing on RectorSeal’s page
  • No NSF mark on RectorSeal’s page
  • No temperature on the 35942 page
  • Only ½ in. wide
  • Sold in cases on RectorSeal’s site

Tape and dope share the same rule. RectorSeal’s tape page says only that it seals threaded pipe joints against internal pressure; it gives no wrap count, so the joint itself is your test. Pressure test it the way your local code asks.

The ½ in. width matches the ½ and ¾ in. threads on the size table below. RectorSeal also sells the same tape 1 in. wide, item 35949, on a 520 in. roll.

There’s a gap on paper for gas. RectorSeal’s page for 35942 doesn’t list gas approval or an NSF mark, so I keep this tape on water. For gas, the can of T Plus 2 has the ANSI LC 7 listing printed on its data sheet.

On its own site, RectorSeal lists 35942 by the case of 12, under UPC 021449359429.

My call: for a few water joints, it’s the quick, clean choice. Keep a roll in the truck and the dope on the shelf for gas.

Mitutoyo 188-151 to count threads per inch

Mitutoyo 188-151 screw pitch gage set with fold-out steel leaves
Mitutoyo 188-151 screw pitch gage set, 4 to 42 TPI and 0.4 to 7 mm. Product photo: Amazon.

The 188-151 is Mitutoyo’s inch and metric pitch gage set: 51 steel leaves. Mitutoyo’s catalog says it’s the 188-111 unified set plus the 188-122 metric set, with the pitch stamped on each leaf.

The inch half is what matters for pipe. Mitutoyo lists 30 leaves from 4 to 42 TPI, including 8, 11½, 14, 18 and 27. Those are the NPT pitches from ⅛ in. to 2 in., and 8 TPI is the 2½ in. size in Petersen’s NPT table.

The inch leaves are for unified screw threads, which Swagelok lists with a 60° flank angle. NPT uses the same 60° angle, so the right leaf sits flat in the thread with no light showing.

Where it does well

  • Has 27, 18, 14, 11½ and 8 TPI leaves
  • Inch and metric in one set
  • Pitch stamped on each leaf
  • Unified leaves share NPT’s 60° angle
  • Listed in Mitutoyo’s own catalog

What to watch

  • Can’t tell taper from straight
  • No 19 TPI leaf for BSPT
  • 51 leaves take time to sort
  • Overkill for one fitting

Here’s how I’d use it: hold the leaf along the thread, parallel to the pipe, and look for daylight. If 14 sits flat, it’s ½ or ¾ in. If 11½ sits flat, it’s 1 in. or bigger. Then the caliper picks the size from the chart above.

What it can’t tell you is taper. NPT and NPSM share the same threads per inch, so the leaf fits both. Swagelok’s fix is the caliper: measure the first, fourth and last full threads, and if they change, the thread is tapered.

The set also has a blind spot for British threads. BSPT uses 28 TPI on ⅛ in. and 19 TPI on ¼ and ⅜ in., per Swagelok, and the 188-111 has 28 but no 19. Mitutoyo’s Whitworth set, the 188-102, has both 19 and 28 TPI leaves.

The 51 leaves are the main hassle. The set is two gauges, though, and the inch one alone has 30 leaves, so pipe work never needs the metric half.

Mitutoyo 505-742J to measure a thread

Mitutoyo 505-742J six inch dial caliper
Mitutoyo 505-742J dial caliper, 0 to 6 in.. Product photo: Amazon.

The 505-742J is Mitutoyo’s 6 in. inch dial caliper. Mitutoyo lists it with a 0 to 6 in. range, ±0.001 in. accuracy, 0.001 in. graduations and 0.1 in. per turn of the dial.

A caliper is the first tool in Swagelok’s thread procedure. Measure across the crests: on a tapered thread, the fourth or fifth full thread. Then match the number to the chart above. A male thread near 0.83 in. is ½ in. NPT; near 1.04 in. is ¾ in.

The 6 in. range reaches past every house size. Swagelok lists 2 in. NPT at 2.362 in. on the male side, well inside the jaws.

Where it does well

  • Reads to 0.001 in.
  • 6 in. range covers 2 in. NPT
  • Outside, inside, depth and step jaws
  • Mechanical dial
  • Lock screw holds the reading

What to watch

  • Inch only, no mm on the dial
  • Dial takes a minute to learn
  • Can’t count threads per inch
  • More tool than a tape measure

It reads the female side too. Mitutoyo says the 505 series measures outside, inside, depth and steps, so the small inside jaws go into a FIP fitting. A ½ in. FIP comes in near 0.705 in., per Swagelok.

The caliper also answers the taper question the pitch gauge can’t. Measure the first, fourth and last full threads. Swagelok says a male thread that grows toward the fitting is tapered; if all three match, it’s straight, like NPSM.

It’s mechanical, so there’s no battery to die in the truck. Mitutoyo calls out a lock screw to hold the reading, and the 505 series’ 2015 update brought an improved finish on the sliding surfaces and an easier-to-read dial font. It ships in a fitted plastic case.

Keep tolerance in mind. Swagelok notes real parts can read a little off its table because of manufacturing tolerances. Pair the diameter with the threads per inch before you order a fitting.

The four picks compared

From RectorSeal’s and Mitutoyo’s own pages and sheets. Scroll sideways on a phone.

PickWhat it doesWorks onKey limitMaker documentSold byBuy
RectorSeal T Plus 2Seals male threadsWater, gas vapor, metal and plasticGas listing to 1¼ in. pipeT Plus 2 data sheetAmazon.comCheck it on Amazon
RectorSeal PTFE tape 35942Seals male threadsMetal and plastic threadsNo gas listing shownrectorseal.com product pageAmazon.comCheck it on Amazon
Mitutoyo 188-151Reads threads per inch4 to 42 TPI, 0.4 to 7 mmNo taper readingMitutoyo series 188 catalog—Reference (not linked)
Mitutoyo 505-742JReads diameter and taper0 to 6 in.No thread countMitutoyo 505 series page—Reference (not linked)

The sealants and the tools solve different problems. If you know the size, you only need a sealant. If you don’t, the caliper and the gauge tell you what to buy before you order a fitting.

What MIP, FIP, MPT and the rest stand for

Most of these are the same NPT thread with a different name. A few are not.

LabelStands forSideThreadMates with
MIPMale iron pipeMaleNPT, taperedFIP, FPT, FNPT
MPT, MIPTMale (iron) pipe threadMaleNPT, taperedFIP, FPT, FNPT
MNPT, NPT(M)Male pipe thread (NPT)MaleNPT, taperedFIP, FPT, FNPT
FIPFemale iron pipeFemaleNPT, taperedMIP, MPT, MNPT
FPT, FIPTFemale (iron) pipe threadFemaleNPT, taperedMIP, MPT, MNPT
FNPT, NPT(F)Female pipe thread (NPT)FemaleNPT, taperedMIP, MPT, MNPT
NPTFNational pipe thread, fuel (Dryseal)EitherTapered, made to seal without sealantNPTF; check the maker
NPSMNational pipe straight, mechanicalEitherStraight, same TPI as NPTNPSM; seals at a seat
BSPTBritish standard pipe, taperedEitherTapered, 55° threadBSPT; not NPT

The first six rows are one thread. The Red Seal plumber acronym list gives FIP as female iron pipe and MIP as male iron pipe; Spears’ catalog writes FPT and MPT as female and male iron pipe thread; Petersen’s chart lists every one of them as interchangeable with NPT.

So a box marked ¾ in. MIP and a valve marked ¾ in. FNPT go together.

The last three rows are the trouble. NPSM has the same threads per inch as NPT but no taper. BSPT has a taper but a 55° thread, and Swagelok warns its ½ and ¾ in. sizes look nearly the same as NPT. NPTF is a fuel thread Petersen describes as made to seal without sealant.

If a fitting says any of those, read its maker’s sheet before you mix it with NPT.

Size, threads per inch and hand-tight turns

Pipe outside diameter and hand-tight engagement from Petersen’s NPT size table. Thread sizes from Swagelok.

SizeThreads per inchPipe ODMale thread measuresFemale thread measuresHand-tight engagement
⅛ in.270.405 in.0.401 in.0.336 in.4.36 turns
¼ in.180.540 in.0.533 in.0.436 in.4.10 turns
⅜ in.180.675 in.0.668 in.0.571 in.4.32 turns
½ in.140.840 in.0.832 in.0.705 in.4.48 turns
¾ in.141.050 in.1.043 in.0.914 in.4.75 turns
1 in.11½1.315 in.1.305 in.1.148 in.4.60 turns
1¼ in.11½1.660 in.1.649 in.1.491 in.4.83 turns
1½ in.11½1.900 in.1.888 in.1.730 in.4.83 turns
2 in.11½2.375 in.2.362 in.Not used here5.01 turns

Hand-tight engagement is how far a MIP should turn into a FIP by hand before the wrench, about 4½ turns on ½ in. Petersen’s table puts the effective thread at about 7½ turns on ½ in., so a metal joint takes a few more turns with a wrench. Plastic threaded fittings are different: follow the fitting maker’s limit, which is often hand-tight plus one or two turns, because extra wrench turns can split a female plastic fitting.

Swagelok adds that no standard sets a torque or turn count once sealant is on. If a fitting spins in far past those numbers by hand, check the size and the thread type.

The two outside diameter columns differ a little: Petersen’s 0.840 in. is the pipe; Swagelok’s 0.832 in. is what a caliper reads on a cut thread. Either way, nothing near 0.84 in. is ¾ in. pipe.

Our pipe threading oil guide covers cutting new threads on steel.

What the plumbing code says about pipe threads

Read on codes.iccsafe.org, Oct 21, 2026. Georgia adopted the 2024 IPC on Jan 1, 2026, and its state amendments leave these sections as written.

CodeSectionPipeWhat it says
2024 IPC605.12.4Copper pipeThreads to ASME B1.20.1. Pipe-joint compound or tape on the male threads only.
2024 IPC605.17.1Galvanized steelThreads to ASME B1.20.1. Pipe-joint compound or tape on the male threads only.
2024 IPC605.14.3CPVCASME B1.20.1; Schedule 80 to be threaded; plastic-pipe dies; pressure rating cut 50 percent; lubricant or tape on male threads only.
2024 IPC605.21.4PVCSame rules as CPVC, including the 50 percent pressure cut for threaded pipe.
2024 IRCP2906.14Any threaded pipeAmerican National Taper Pipe Thread. Deburr the ends and remove chips. Compound only on male threads.

Two rules stand in every row. The thread is NPT, the ASME B1.20.1 or American National Taper Pipe Thread. And sealant goes on the male thread, never inside the female fitting.

The plastic rows add a real limit. Threaded PVC and CPVC pipe loses half its pressure rating, and it has to be Schedule 80 to be threaded at all.

Your local code wins. Some states and cities adopt the UPC or amend the IPC. On a permitted job, ask your inspector which code and sealant they accept.

How to name a thread you’re holding

Swagelok’s five-step method, cut down to the four steps a house needs.

StepDo thisToolWhat it tells you
1. Taper or straightMeasure the first, fourth and last full threadsCaliperMale grows toward the fitting: tapered (NPT or BSPT). All the same: straight (NPSM).
2. DiameterMeasure across the crests on the fourth or fifth threadCaliperNear 0.83 in. male is ½ in.; near 1.04 in. is ¾ in.
3. Threads per inchTry leaves until one sits flat with no lightPitch gauge14 TPI for ½ and ¾ in.; 11½ for 1 to 2 in.
4. Match the tableMale or female, taper, diameter, pitchThe tables on this pageThe thread’s name and size

Swagelok notes that even experienced workers sometimes have trouble naming threads, so don’t skip step 3. The diameter tells you the size; the pitch tells you which standard. On ½ and ¾ in., where NPT and BSPT both run 14 threads per inch, Swagelok says only an optical comparator can tell them apart for sure.

In a US house, expect NPT: the IRC calls for American National Taper Pipe Thread.

Threads that look like NPT but aren’t

From the Swagelok guide’s tapered and straight thread tables.

SizeNPTNPSM (straight)BSPT (ISO 7/1)
⅛ in.27 TPI, 60°27 TPI, 60°28 TPI, 55°
¼ in.18 TPI, 60°18 TPI, 60°19 TPI, 55°
⅜ in.18 TPI, 60°18 TPI, 60°19 TPI, 55°
½ in.14 TPI, 60°14 TPI, 60°14 TPI, 55°
¾ in.14 TPI, 60°14 TPI, 60°14 TPI, 55°
1 in.11½ TPI, 60°11½ TPI, 60°11 TPI, 55°
Where it sealsOn the threadsAt a 30° cone seatOn the threads

NPSM matches NPT thread for thread, so a pitch gauge can’t tell them apart. The caliper can: a straight thread measures the same along its length. Swagelok shows NPSM on a nut that seals against a cone seat, and Petersen says straight threads seal with a gasket or O-ring.

BSPT gives itself away with its 55° thread and, on most sizes, a different count.

Faucet and toilet supply connections are their own topic. Our faucet supply line guide and toilet supply line size guide cover them, and our tub spout guide covers threaded spouts.

Tape or dope on a MIP thread

The code allows either on the male thread. The papers behind each pick decide where it goes.

Water, ½ or ¾ in.

Either one. The code allows tape or compound, and RectorSeal lists both for metal and plastic threads.

Natural gas or propane

T Plus 2, listed under ANSI LC 7 up to 1¼ in. pipe. RectorSeal’s tape page shows no gas listing.

PVC or CPVC threads

Either. T Plus 2 is certified to IAPMO PS-36 and FBC System Compatible; RectorSeal says the tape works on plastic threads.

Oxygen lines

Not T Plus 2; RectorSeal says not recommended for oxygen.

Inside the FIP

Never. Both codes say male threads only.

NPSM or a seat seal

Neither fixes a bad seat. Check the cone, gasket or O-ring instead.

Some joints get both tape and dope. Neither RectorSeal sheet I read covers that combination, so I won’t claim it helps or hurts. Our tape vs pipe dope vs putty guide goes deeper on the choice.

Where the sources disagree

Four places the references don’t match, and what to go by.

TopicOne source saysThe other saysGo by
NPSRed Seal: nominal pipe sizePetersen: also national pipe straightRead the context; NPSM is the straight thread
IPSSpears: iron pipe sizePetersen: iron pipe straightAsk the maker what they mean
Dope on big threadsRectorSeal: both threads above 1¼ in.IPC 605.12.4 and 605.17.1: male onlyThe code
½ in. thread ODPetersen: 0.840 in. pipe ODSwagelok: 0.832 in. measured male threadBoth; tolerance

The NPS row explains a lot of search results. People type “nps vs npt” meaning straight thread, and get pages about nominal pipe size. If a part says NPSM, it’s the straight mechanical thread; if a chart says NPS beside a pipe size, it usually means the nominal size.

The same goes for IPS on faucet parts: ask what the maker means.

Which pick do you need?

QuestionIf yesIf no
Do you know the size and thread type?Just a sealant: T Plus 2 or the tapeCaliper first
Is it a gas line?T Plus 2Either sealant
Is it under 1¼ in. and water?Tape or T Plus 2T Plus 2, male thread only
Are threads per inch unclear, or made to another standard?Add the pitch gaugeCaliper alone
Does the diameter stay the same along the thread?Straight thread; look for a seatTapered; seal the threads

For most people reading this, the answer is simple: the fitting says ½ in. MIP, the valve says ½ in. FIP, they go together, and the tape or dope goes on the male side. Keep the caliper for the day a fitting doesn’t fit.

Our brass vs poly PEX fittings guide and dielectric union guide show where threaded adapters meet PEX and copper.

Questions people ask

Can FIP and MIP be used together?

Yes. A MIP is the male thread and a FIP is the female thread of the same NPT standard, so a ½ in. MIP screws into a ½ in. FIP. Seal the male thread with tape or pipe dope.

Are FIP and MIP the same?

No. They’re the same thread standard, NPT, but opposite sides of the joint. MIP is the male, outside thread; FIP is the female, inside thread.

Is NPT the same as FIP and MIP?

NPT is the thread itself, the tapered US pipe thread in ASME B1.20.1. FIP and MIP say which side you have. Petersen’s chart lists FIP, MIP, FPT, MPT, FNPT and MNPT as interchangeable with NPT.

Does FIP need teflon tape?

Not inside it. The 2024 IPC and IRC put tape or compound on the male threads only, so the tape goes on the MIP part that screws into the FIP.

What does 1 inch FIP mean?

A female NPT thread for 1 in. nominal pipe. It has 11½ threads per inch and measures about 1.148 in. inside the threads, per Swagelok. The pipe that fits it measures 1.315 in. outside.

Why does ½ inch MIP measure more than ½ inch?

The size is a nominal name, not a measurement. A ½ in. male pipe thread measures about 0.83 to 0.84 in. across, per Swagelok and Petersen.

What’s the difference between MPT and MIP?

Nothing that matters at the store. Spears writes MPT as male iron pipe thread, and the Red Seal list writes MIP as male iron pipe. Both mean a male NPT thread.

What is the difference between NPS and NPT?

NPS often means nominal pipe size, the size name. Petersen also uses NPS for national pipe straight, a straight thread. NPT is tapered and seals on the threads; NPSM is straight and seals at a seat.

Can I mix NPT and BSPT?

They’re different standards. BSPT has a 55° thread and, on most sizes, a different thread count. Swagelok says ½ and ¾ in. are so close only an optical comparator can tell them apart, so use matching threads.

Is NPTF the same as NPT?

Not quite. Petersen describes NPTF as the Dryseal fuel thread, made to seal without sealant. Check the maker’s sheet before you mix NPTF and NPT parts.

How tight should an NPT fitting be?

Swagelok says no standard sets a torque or number of turns. Petersen’s NPT size table lists about 4½ turns hand-tight on ½ in., and about 7½ turns of effective thread in all.

Can you thread PVC pipe?

Only Schedule 80 or heavier, per the 2024 IPC, with dies made for plastic pipe. The code cuts the pressure rating of threaded PVC and CPVC pipe by 50 percent.

How I picked them

How I picked

I picked the two sealants and two measuring tools a homeowner or plumber needs to seal or name an NPT thread.

Specs come from RectorSeal’s and Mitutoyo’s own sheets and pages. Thread sizes come from the Swagelok identification guide, and code text from codes.iccsafe.org. Two seal a thread and two name it, so the job decides and none is scored.

Why trust me

I’m Isaac Daniels, a licensed journeyman plumber in Georgia (license #JP507711). Every number on this page comes from a named maker document, standard table or code section listed below, and nothing is copied from Amazon reviews.

Sources

  • Swagelok, Thread and End Connection Identification Guide, MS-13-77
  • Petersen Products, Pipe Threading Standards (acronyms and NPT size table)
  • 2024 International Plumbing Code, sections 605.10.3, 605.12.4, 605.14.3, 605.17.1, 605.21.4 (codes.iccsafe.org)
  • Georgia DCA, Georgia State Amendments to the International Plumbing Code (2024 Edition), revised Jan 1, 2026
  • 2024 International Residential Code, section P2906.14 (codes.iccsafe.org)
  • Red Seal Program, plumber acronyms list
  • Spears Manufacturing, Appendix A: Basic Abbreviations Used in this Catalog
  • RectorSeal, T Plus 2 product data sheet
  • RectorSeal, PTFE Tape 1/2 x 260 (35942) and 1 x 520 (35949) product pages
  • Mitutoyo, Radius Gages Series 186 and Thread Pitch Gages Series 188 catalog page
  • Mitutoyo, Dial Caliper (505 series) product page and 2015 new product announcement

Related guides
