ProPress insertion depth chart
Viega, NIBCO and Apollo numbers side by side.
As an Amazon Associate I earn from qualifying purchases.
On this page
Quick answer
For Viega ProPress, mark ½ in. copper at ¾ in., and ¾ or 1 in. at ⅞ in. Push the tube to the stop; the mark should still show.

Insertion depth chart: Viega, NIBCO and Apollo
Each number is the minimum insertion depth printed in the maker’s own instructions. Use the column for the brand of fitting in your hand.
NIBCO’s Feb. 2026 sheet prints the ½ in. row as “1 1/16″. Its 2017 sheet gives 11/16 in. and 18 mm, so 11/16 is the right number. Apollo labels its fractions as estimates of 0.75, 0.91, 1.03, 1.43 and 1.58 in.
Viega and Apollo match from ½ to 2 in. NIBCO runs a little shorter at ½, 1½ and 2 in., and its 2½ to 4 in. depths are up to ¼ in. less than Viega’s. A ¼ in. gap is enough to put a mark in the wrong place, so read the brand off the fitting or its bag before you mark.
The depth is a minimum. With a stop inside the fitting, the tube goes in until it hits the stop, and the mark tells you it got there. Without a stop, as on a repair coupling, NIBCO says to insert no less than the chart depth and mark the new depth if you need to.
What the depth mark tells you
The sealing element sits in the bead of the fitting. If the tube stops short of the bead, the jaw squeezes the fitting over an empty spot and the joint can leak. Viega says improper insertion depth may result in an improper seal, and Apollo lists a tube that wasn’t fully inserted as one of its failure causes.
You can’t see the stop from outside, so the mark is your only proof. Check it twice: once after you push the tube in, and again with the jaw on the fitting. Viega’s step 7b says to check the depth by the mark with the jaw in place.
Use the Viega column. ½ to 2 in. fittings take hard copper up to 2 in. or soft copper up to 1¼ in.; 2½ to 4 in. take hard copper only.
Use the NIBCO column. NIBCO lists K, L and M hard tube, plus ½, ¾ and 1 in. annealed (soft) tube sized with a plug and sizing ring.
Use the Apollo column. Its June 2026 manual covers ½ to 1¼ in. soft and ½ to 4 in. hard K, L and M tube.
Insert at least the chart depth on each side, and mark both tubes so you can see the coupling didn’t slide.
Minimum distance between press fittings
Zero means two fittings can butt up against each other. Viega’s chart lists no minimum for ½ to 1 in. ProPress fittings. NIBCO’s sheet goes further and needs no gap up to 2 in.
The gap exists to stop the tube distorting between two presses, and Viega warns that skipping it may give an improper seal. When a run mixes brands, use the bigger number. On a 2 in. Viega joint next to a 2 in. NIBCO joint, that’s ¾ in.
Spacing isn’t the same as jaw clearance. NIBCO also prints minimum clearances so the jaw fits between the fitting and a wall, so check that sheet if you’re pressing tight to framing.
How to mark and press a joint, step by step
These steps follow Viega’s product instructions, with NIBCO’s and Apollo’s extra checks where they add one.
- 1Cut the tube square
Use a tubing cutter or a fine-tooth saw. Viega says don’t deform the tube. Apollo says never cut part way and snap it, and no grease, oil-cooled saws or torches.
- 2Deburr inside and out
Viega wants the burr off the inside and outside, prepped to the insertion depth with a prep tool or fine-grit sandpaper.
- 3Clean the end
NIBCO calls for a maroon Scotch-Brite pad or 180-grit or finer sand cloth, rubbed around the tube, not along it. Stamped print lines can’t sit under a seal.
- 4Check the seal
Look for the sealing element and any grip or separator ring, clean and undamaged. No oil or lubricant. NIBCO allows water only.
- 5Mark the depth
Measure the chart depth from the tube end and mark it all the way around with a permanent marker.
- 6Push the fitting on with a twist
Turn it slightly as it goes on, until the tube end hits the stop. Viega recommends the mark still shows when you’re done.
- 7Set the jaw square
Open the jaw and place it at a right angle on the bead. Check the mark again before you pull the trigger.
- 8Press and release
Hold the trigger until the jaws fully close. Viega says the jaws release on their own after a full press.
- 9Check the joint
NIBCO says to confirm the fitting stayed where it was. Then leak test before you raise the pressure.
Tube that’s hard to push on may have a burr or be out of round, NIBCO warns. Pull it, fix the end and try again. Don’t force it.
Tools for cutting, deburring and marking
Four tools cover the prep steps. Each was new, in stock and sold by Amazon.com on the day of the update. Prices come from Amazon with the time they were read.


RIDGID 152 tubing cutter

RIDGID 227S reamer

Klein Tools 50046 cutter
Product prices and availability are accurate as of the date/time indicated and are subject to change. Any price and availability information displayed on Amazon.com at the time of purchase will apply to the purchase of this product.
| Tool | Key specs | Pick it if | Skip it if |
|---|---|---|---|
| Sharpie Industrial, 12 pack | Fine point, Black, 12 markers, Permanent ink, Rated to 500°F, Sold by Amazon.com | You press copper and want a marker that won’t rub off while you set the jaw and test the line. | You already carry a permanent marker that leaves a clear line on copper. The brand doesn’t matter to the joint. |
| RIDGID 152 tubing cutter | Model 152, Catalog 31642, ¼ to 2⅝ in., Quick-acting slide, Fold-away reamer, X-CEL knob | You cut ½ to 2½ in. nominal copper for press fittings and want one cutter that covers every size in that range. | Most of your cuts are inside walls or between joists. A small cutter like the Klein 50046 fits where this one won’t. |
| RIDGID 227S reamer | Model 227S, Catalog 29993, ⅜ to 1½ in. nominal copper, 45 cutting edges, Hardened steel, Inch and metric bar | You prep ⅜ to 1½ in. nominal copper and want one tool that cleans the inside and bevels the outside. | You need to deburr 2 in. nominal copper, which is beyond the 227S’s listed OD range. |
| Klein Tools 50046 cutter | Model 50046, ⅛ to 1⅜ in. OD, Copper and aluminum, Constant swing, Compact body, Sold by Amazon.com | You cut ½ to 1 in. copper close to walls, joists or other pipes, where a full-size cutter can’t turn. | Your cuts are in open space or over 1 in. nominal. The RIDGID 152 covers more sizes. |
Why the marker needs a fine point
A thin line sits at one depth. A fat line can cover ⅛ in. of tube, and on a ½ in. fitting that’s a big share of a ¾ in. depth. Draw the line all the way around the tube, so you can see it from any side once the fitting is on.
Viega recommends that the mark still show on the finished joint. That’s your record. An inspector or the next plumber can look at it and see the tube went in far enough, long after the pressure test is done.
Cut light, then ream both edges
Light pressure and more turns gives the squarest cut. Tighten the cutter knob a little each turn, not a lot. A crushed end is exactly what Viega and NIBCO warn about, and it shows up as a fitting that won’t slide on.
Then put the end in the 227S cone and turn it a few times. It cuts the inside burr and puts a light bevel on the outside edge, so a sharp edge can’t catch or cut the seal as the tube slides in.
Insertion depth table with metric sizes
| Tube size | Viega ProPress | NIBCO Press | Apollo Press |
|---|---|---|---|
| ½ in. | ¾ in. (19 mm) | 11/16 in. (18 mm) | ¾ in. |
| ¾ in. | ⅞ in. (23 mm) | ⅞ in. (22 mm) | ⅞ in. |
| 1 in. | ⅞ in. (23 mm) | ⅞ in. (22 mm) | ⅞ in. |
| 1¼ in. | 1 in. (26 mm) | 1 in. (25 mm) | 1 in. |
| 1½ in. | 1 7/16 in. (37 mm) | 1⅜ in. (35 mm) | 1 7/16 in. |
| 2 in. | 1 9/16 in. (40 mm) | 1½ in. (38 mm) | 1 9/16 in. |
| 2½ in. | 1 11/16 in. (43 mm) | 1½ in. | 1⅞ in. |
| 3 in. | 1 15/16 in. (50 mm) | 1⅝ in. | 2⅛ in. |
| 4 in. | 2⅜ in. (60 mm) | 2⅛ in. | 2½ in. |
Viega prints millimeters next to every size, and NIBCO prints them for ½ to 2 in. If your tape is metric, those are the numbers to use. Apollo’s small-size fractions are estimates of its decimal dimensions. For 2½, 3 and 4 in. tube, Apollo lists 1⅞, 2⅛ and 2½ in.; use Apollo’s column for those fittings.
Fitting spacing table by maker
| Tube size | Viega ProPress | NIBCO Press | Apollo Press |
|---|---|---|---|
| ½, ¾ and 1 in. | 0 | 0 | 0 |
| 1¼ in. | 7/16 in. (10 mm) | 0 | ½ in. |
| 1½ in. | ⅝ in. (15 mm) | 0 | ⅝ in. |
| 2 in. | ¾ in. (20 mm) | 0 | ¾ in. |
| 2½, 3 and 4 in. | ⅝ in. (15 mm) | ⅜ in. (10 mm) | ⅝ in. |
How far to stay from solder and brazed joints
Heat can soften the copper a press joint relies on, and it can cook the seal in a joint that’s already pressed. Apollo prints the most detail.
| Tube size | Press near solder | Press near braze | Solder near press | Braze near press |
|---|---|---|---|---|
| ½ in. | ¼ in. | 1 in. | 1½ in. | 4½ in. |
| ¾ in. | ¼ in. | 1½ in. | 2¼ in. | 6¾ in. |
| 1 in. | 7/16 in. | 2 in. | 3 in. | 9 in. |
| 1¼ in. | 7/16 in. | 2½ in. | 3¾ in. | 11¼ in. |
| 1½ in. | ⅝ in. | 3 in. | 4½ in. | 13½ in. |
| 2 in. | ¾ in. | 4 in. | 6 in. | 18 in. |
| 2½ in. | ¼ in. | 5 in. | 7½ in. | 22½ in. |
| 3 in. | ¼ in. | 6 in. | 9 in. | 27 in. |
| 4 in. | ¼ in. | 8 in. | 12 in. | 36 in. |
Source: Apollo Press IOM, June 15, 2026. Apollo says to remove leftover solder and flux before pressing near an old joint, and to use a wet rag, heat-sink paste or a prefabricated assembly when you solder or braze near a press joint.
NIBCO is simpler and stricter on brazing. It says not to press within 12 in. of a brazed joint, because brazing heat can anneal the tube and leave it too soft to crimp. NIBCO allows pressing right next to a soldered joint, because it says normal soldering heat isn’t enough to anneal the tube.
Going the other way, NIBCO says don’t solder or braze within 12 in. of a finished NIBCO press joint. If you can’t avoid it, solder first and press second, or wrap the press joint in a cold, wet cloth.
Viega’s ProPress installation manual (IM-PP 724607) prints its own distances, and from ¾ to 4 in. they match the Apollo table above row for row. It says to keep 3 tube diameters when soldering and 9 tube diameters when brazing near a finished ProPress joint, and at least 2 tube diameters when pressing near an old brazed joint.
Its soldering table starts at ¾ in., so for ½ in. follow the Apollo row.
Leak testing after you press
| Maker | First test: find unpressed joints | After it passes |
|---|---|---|
| Viega ProPress | Water 15 to 85 psi, or air ½ to 45 psi with leak-detect solution (Smart Connect) | Up to 200 psi air or 600 psi water |
| NIBCO Press | Air 15 psi max, or water 50 psi max; raise it slowly | Up to 200 psi if code or the job calls for it |
| Apollo Press | No more than 25 psi air, nitrogen or water; watch for a drop | To spec, never over 600 psi water or 200 psi air |
The low-pressure test is the unpressed-fitting check you can’t skip. An unpressed fitting leaks on purpose at low pressure so you find it before the wall closes. Viega calls this Smart Connect, and NIBCO and Apollo publish their own low-pressure steps.
It isn’t a depth check. A fitting pressed on tube that wasn’t pushed in far enough can still be pressed, so it won’t show up here. Viega’s manual says to check insertion depth by the mark on the tube, so look at every mark before and after you press.
Viega is clear that Smart Connect doesn’t replace the pressure test your local code calls for. Do both. NIBCO warns that testing with air can be dangerous at high pressure, so stay inside each maker’s air limit.
When a joint is wrong: what the makers say to do
Relieve system pressure before re-pressing or cutting out a fitting. Then follow the fitting maker’s repair instructions.
| What happened | What to do | Source |
|---|---|---|
| Tube not fully inserted | Cut it out; new tube and new fitting | Apollo, NIBCO |
| Jaw wasn’t square to the fitting | Replace the joint | Apollo |
| Joint rotated after pressing | Re-press with the jaw at 90°, in the same spot | Apollo |
| Press cycle was cut short | Re-press with the jaws in the same location | NIBCO |
| Fitting was never pressed | Press it; the leak test finds these | Apollo, Viega |
| Pressed over a scratch, dent or missing seal | Replace the joint | Apollo |
Notice the pattern. A missed press can be pressed. A short insertion can’t be fixed by pressing again, because the seal was squeezed onto the wrong part of the tube. That’s why the mark matters more than any other step.
Which tool for which step
| Step | Tool | Why |
|---|---|---|
| Cut, open space, ½ to 2½ in. nominal | RIDGID 152 | One cutter covers every size through 2½ in. nominal |
| Cut, tight spot, ½ to 1 in. | Klein 50046 | Turns where a big cutter can’t |
| Deburr inside and outside, ⅜ to 1½ in. nominal copper | RIDGID 227S | Use a larger tool for 2 in. nominal copper |
| Clean the press area | Maroon pad or 180-grit cloth | NIBCO’s named prep |
| Mark the depth | Sharpie Industrial | Permanent, thin line |
| Press the joint | Tool and jaws for the brand | Viega: don’t mix makers on 2½ to 4 in. rings |
The press tool is the big buy. For ½ and ¾ in. ProPress only, RIDGID’s RP 115 mini press kit comes with ½ to ¾ in. ProPress jaws, a battery and a charger (RIDGID RP 115 kit on Amazon). For more sizes, see our press tool guide and RIDGID ProPress jaw guide.
Is there a ProPress depth gauge?
| Gauge type | Made for | Use it on copper press? |
|---|---|---|
| Maker’s chart plus a marker | Viega, NIBCO and Apollo press fittings | Yes; all three makers call for it |
| NIBCO insertion depth tool | NIBCO Press fittings | Yes, on NIBCO; named in NIBCO’s 2026 steps |
| Push-fit depth and deburr gauge | SharkBite-style push fittings | No; push-fit depths differ |
| Refrigerant press depth gauge | HVAC press fittings such as RLS | No; different fittings and sizes |
Search Amazon for a ProPress depth gauge and you’ll mostly get push-fit gauges. Those are cut for push fittings. SharkBite’s ½ in. depth is 1 in., but ProPress is ¾ in., so a push-fit gauge puts your mark in the wrong place. I didn’t find a genuine Viega or NIBCO copper press gauge on Amazon on Oct 19.
A tape and the chart above do the job. Hook the tape on the tube end, mark at the chart depth and draw the line around the tube. If I could stock only one press brand, it’d be Viega ProPress, so that’s the column I’d tape inside the truck door.
Which copper tube each system takes
| Maker | Hard tube | Soft (annealed) tube | Notes |
|---|---|---|---|
| Viega ProPress | ½ to 4 in. | ½ to 1¼ in. (½ to 2 in. fittings) | No stamped print lines under a ProPress valve |
| NIBCO Press | K, L and M, ½ to 4 in. | ½, ¾ and 1 in. | Size soft tube with a plug and sizing ring; no maker stamps in the joint |
| Apollo Press | K, L and M, ½ to 4 in. | ½ to 1¼ in. | No deep scratches, dents, tape, paint or stamped marks |
All three want the press area clean and smooth, because the seal rides on the outside of the tube. If the printed line on the tube runs through the area you just marked, rotate the cut or clean it off before you press. Apollo lists a joint pressed over a scratch or dent as a failure, so don’t try to save a damaged end.
When to call a licensed plumber
Marking depth and spacing is routine work for anyone set up to press.
Viega says its products are for licensed, trained installers, and installation by non-professionals may void Viega’s warranty.
Heat distances are easy to get wrong next to a braze, and a joint that fails inside a wall means opening drywall.
Questions people ask
What is the insertion depth for ½ inch ProPress?
¾ in. (19 mm), per Viega’s ProPress product instructions. Apollo Press also uses ¾ in. NIBCO Press is 11/16 in. (18 mm).
What is the insertion depth for ¾ inch ProPress?
⅞ in. (23 mm), the same as 1 in. ProPress. Apollo is ⅞ in. too, and NIBCO lists ⅞ in. (22 mm).
Is there a ProPress depth gauge?
Viega’s instructions call for marking the depth from its chart. NIBCO’s 2026 steps name a NIBCO insertion depth tool for its own fittings. Push-fit depth gauges are made for push fittings and give the wrong depth for press.
How close can ProPress fittings be?
½, ¾ and 1 in. ProPress fittings can touch. Viega’s minimum is 7/16 in. at 1¼ in., ⅝ in. at 1½ in., ¾ in. at 2 in. and ⅝ in. at 2½ to 4 in.
How close can you ProPress 2 inch fittings?
¾ in. (20 mm) apart for Viega ProPress, and ¾ in. for Apollo. NIBCO needs no minimum at 2 in.
What is the minimum distance between ProPress and a solder joint?
Apollo says ¾ in. for 2 in., ¼ in. for ½ and ¾ in., after removing old solder and flux. NIBCO lets you press right next to a soldered joint. Viega’s ProPress manual lists the same pressing distances from ½ to 4 in., and 3 tube diameters to solder near a finished ProPress joint.
How much pressure can a ProPress fitting hold?
NIBCO rates its Press System at 200 psi from -20°F to 250°F. Apollo lists 300 psi for potable water from 0 to 250°F. Viega’s ProPress manual lists a 300 psi maximum operating pressure, surges included, and its application chart lists potable water at 300 psi with the standard EPDM seal. The 600 psi figure is only the water test ceiling after the Smart Connect test, not a working rating.
Can ProPress be buried underground?
Apollo says its press fittings are approved underground where state and local codes allow, protected from corrosive soil and puncture. NIBCO says its system can go underground per local plumbing codes. Check your local code first.
Should the depth mark show after pressing?
Viega recommends that the depth mark still be visible on the finished joint. NIBCO and Apollo say to check the mark before you press.
Can you re-press a ProPress fitting?
Relieve system pressure before re-pressing or cutting out a fitting. For an incomplete press or rotated joint, follow that maker’s jaw-position instructions. If the tube wasn’t fully inserted, Apollo and NIBCO say to cut it out and use a new fitting.
Can I use lubricant on a press fitting?
No oil or grease. Viega says no oils or lubricants, and NIBCO allows only water on the seal.
