Type L vs Type M copper pipe

Wall, pressure and where code lets you use M.

As an Amazon Associate I earn from qualifying purchases.

On this page
  1. The picks
  2. Where M is allowed
  3. ICS ¾ in. Type L hard
  4. VENTRAL ½ in. Type L hard
  5. ICS ¾ in. Type L soft coil
  6. Mueller ¾ in. Type M
  7. Mueller 1 in. Type M
  8. Side by side
  9. Wall by size
  10. Pressure ratings
  11. Joint ratings
  12. Flow and speed
  13. Pinholes and wear
  14. Mixing L and M
  15. Tell L from M
  16. How to choose
  17. Questions
  18. How we compare

Quick answer

Type L’s wall is about 40% thicker than Type M’s: 0.045 in. against 0.032 in. at ¾ in. Both far exceed house pressure. Use Type L for most water lines; the IPC and UPC tables allow it, but your local code and water utility decide. For gas, ask your gas utility first. Buy Type M only where your code allows it.

Most jobs: ¾ in. Type L hard

Five lengths of L and M for five jobs

These tubes are listed as specs, not links.

TubeJob it fitsSpec scoreSpecs
ICS ¾ in. Type L hard, 5 ft¾ in. mains inside the house9.3Spec note
VENTRAL ½ in. Type L hard, 5 ft½ in. branch lines to fixtures9.3Spec note
ICS ¾ in. Type L soft, 60 ftA buried ¾ in. service in one piece9.3Spec note
Mueller ¾ in. Type M, 2 ftShort ¾ in. repairs on an M line8.0Spec note
Mueller 1 in. Type M, 10 ft1 in. mains where code allows M8.3Spec note

Where code lets you use Type M

This is the question that decides most L or M choices, and the answer depends on which plumbing code your town uses.

Meter In the house Under the slab Buried in the yard Is Type M allowed here? In the house, above ground Under the slab Buried in the yard IPC 2024 (Georgia) Yes Yes Yes UPC 2021 Yes No: use L or K Yes Lincoln, NE Yes No: use L or K No: use L or K Meter In the house Under the slab Buried in the yard IPC 2024 (Georgia) In the house, above ground Yes Under the slab Yes Buried in the yard Yes UPC 2021 In the house, above ground Yes Under the slab No: L or K Buried in the yard Yes Lincoln, NE In the house, above ground Yes Under the slab No: L or K Buried in the yard No: L or K
Where Type M copper water tube is allowed. Sources: IPC 2024 Tables 605.3 and 605.4, in force in Georgia since Jan 1, 2026; UPC 2021 section 604.3 as adopted in Hawaii; Lincoln, Nebraska Municipal Code 24.12.250. Your local code and water utility may differ.

The International Plumbing Code is the looser one. Its tables for water service and water distribution both list copper tube “Type K, WK, L, WL, M or WM” with no limit on where each goes. Georgia adopted the 2024 IPC on Jan 1, 2026, and its state amendments leave those tables alone.

The Uniform Plumbing Code starts from the other end. UPC 2021 section 604.3 says water tube “shall have a weight of not less than Type L,” then makes an exception for Type M above ground in or on a building, or underground outside of structures.

That exception leaves one gap: under the slab. A line buried beneath a house’s floor is underground but inside the structure, so a UPC town wants Type L or K there. Some cities go further. Lincoln, Nebraska rewrote 604.3 so Type M is only allowed above ground in or on a building, which rules it out in the yard too.

So check two things before you buy M: which code your town adopted, and whether it amended the copper section. Your water utility may also set the type for the line from its meter to your house.

Type L: the tube most water codes accept

Reference

ICS ¾ in. Type L hard, 5 ft

ICS Industries ¾ in. nominal (⅞ in. OD) Type L hard copper tube, 5 ft

Spec reference, not linked · spec score 9.3 (method)

Pros

  • Allowed under every code on this page
  • 0.045 in. wall, 41% more than Type M at ¾ in.
  • Rated 1,002 psi at 100°F, hard
  • Listing names ASTM B88 and C12200 copper
  • 5 ft fits in a car

Cons

  • About 39% heavier per foot than Type M
  • 6% less bore area than Type M at ¾ in.
  • Only 5 ft; a full main needs couplings
¾ in. nominal0.875 in. OD0.785 in. ID0.045 in. wall0.455 lb/ft5 ft straight

This is a 5 ft straight length of ¾ in. nominal Type L copper in the hard, drawn temper, made by ICS Industries. The listing names ASTM B88, the standard for copper water tube, and C12200 copper.

Nominal ¾ in. copper is ⅞ in. outside in every type. CDA’s handbook says the outside size is always ⅛ in. bigger than the name. What changes from L to M is the wall: 0.045 in. for Type L at ¾ in., against 0.032 in. for Type M.

That 0.013 in. is 41% more wall. CDA’s Table 14.3b rates ¾ in. Type L hard at 1,002 psi at 100°F. Type M at the same size is rated 701 psi. Both are many times the 80 psi code allows inside a house.

So why pay for the heavier tube? Because Type L is legal in every spot on the chart above. The UPC sets Type L as its baseline for water tube, and the IPC allows it everywhere. If you aren’t sure which code your town uses, L passes every code on this page.

The extra wall also means more copper to lose before a leak. CDA ties erosion and pitting to water velocity, aggressive water and workmanship, not to tube type. But once wear starts, ¾ in. Type L has 0.045 in. of metal to get through, and Type M has 0.032.

The trade is weight and bore. Type L weighs 0.455 lb per foot at ¾ in., 39% more than M’s 0.328. Its bore is 0.484 sq in. against M’s 0.517. At 5 GPM that works out to 2.7 psi lost per 100 ft in Type L and 2.3 in Type M, from CDA’s Table 14.6.

CDA’s Table 14.1 lists Type L for domestic water service and distribution, and Table 14.3b rates ¾ in. hard Type L at 1,002 psi at 100°F.

Type L hard is the tube to use. Cut it with a tubing cutter and ream every end; Georgia’s code, section 605.13.6, requires cut ends reamed to the full bore.

Reference

VENTRAL ½ in. Type L hard, 5 ft

VENTRAL ½ in. nominal (0.625 in. OD) Type L hard copper pipe, 5 ft

Spec reference, not linked · spec score 9.3 (method)

Pros

  • The size most sinks, toilets and showers run on
  • Rated 1,242 psi at 100°F, hard
  • 0.040 in. wall, 43% more than Type M at ½ in.
  • Listing says made in the USA
  • Listing names Type L, 0.625 in. OD and hard temper

Cons

  • 9% less bore area than ½ in. Type M
  • Only 5 ft per piece
½ in. nominal0.625 in. OD0.545 in. ID0.040 in. wall0.285 lb/ft5 ft straight

This is ½ in. Type L copper in the hard temper, cut to a 60 in. straight length by VENTRAL, a US pipe fabricator. The listing gives the 0.625 in. outside size and model PI-44-083-0550-001.

At ½ in., the gap between L and M is wider than most people think. CDA’s Table 14.2b gives Type L a 0.040 in. wall and a 0.545 in. bore. Table 14.2c gives Type M a 0.028 in. wall and a 0.569 in. bore. That’s 43% more wall in Type L.

Ratings follow the wall. CDA rates ½ in. Type L hard at 1,242 psi at 100°F and Type M hard at 850 psi. In CDA’s burst tests, ½ in. Type L hard averaged 7,765 psi and Type M hard 6,135. A house runs at 80 psi or less.

Where M wins is the bore. Its 0.254 sq in. is 9% more than Type L’s 0.233. At 3 GPM, about one shower, CDA’s friction table works out to 6.2 psi lost per 100 ft in Type L and 5.1 in Type M. On a 15 ft branch, that’s under 1 psi of difference.

Half-inch lines are also where CDA asks for the most care with speed. It says to keep water under 8 ft per second cold and 5 hot, and lower in ½ in. and smaller tube, because burrs and tight turns stir up erosion. At 5 ft per second, ½ in. Type L carries 3.6 GPM and Type M 4.0.

Five feet is a working length for branch lines. CDA’s Table 14.1 lists 20 ft as the standard straight length, which most cars can’t carry. A short branch may take one piece, with the rest kept for the next repair.

CDA’s Table 14.3b rates ½ in. hard Type L at 1,242 psi at 100°F, far above what a house runs at. Type L is the safe default for fixture branches, and it’s what the UPC asks for anywhere it doesn’t grant the Type M exception. Ream the cut ends. CDA names unreamed burrs as one reason to keep water slower in ½ in. and smaller tube.

Reference

ICS ¾ in. Type L soft, 60 ft

ICS Industries ¾ in. nominal (⅞ in. OD) Type L soft copper tube, 60 ft coil

Spec reference, not linked · spec score 9.3 (method)

Pros

  • 60 ft with no buried joints
  • CDA lists no Type M coils, so this is the soft option
  • Rated 582 psi at 100°F, soft
  • Listing names ASTM B88 and NSF/ANSI 61 and 372
  • Bends by hand or with a tube bender

Cons

  • Soft coil carries no blue print; read the stamp
  • About 27 lb to handle
  • Sags between hangers if used indoors
¾ in. nominal0.875 in. OD0.785 in. ID0.045 in. wall0.455 lb/ft60 ft coil

This is a 60 ft coil of ¾ in. nominal Type L copper in the soft, annealed temper, made by ICS Industries. The listing names ASTM B88, a 0.045 in. wall, and NSF/ANSI 61 and 372 for drinking water.

It’s on a Type L vs Type M page because there’s no Type M version of it. CDA’s Table 14.1 lists Type M in 20 ft straight lengths only, with no coils and no soft temper. If you want a buried line with no joints, the choice is Type L or K.

CDA’s own minimum recommendation for buried water services names exactly two options: Type M hard in straight lengths joined with fittings, or Type L soft where coils are handier. This coil is the second one. It skips the couplings a run of 20 ft sticks would need in the trench.

Soft temper lowers the rating. CDA rates ¾ in. Type L soft at 582 psi at 100°F, against 1,002 hard. Code asks 160 psi of buried service pipe under IPC section 605.3, so it clears that more than three times over.

IPC section 603.1 sets ¾ in. as the smallest water service, so this coil covers the minimum. A long run or a big house may need 1 in.; your plumber sizes that from the fixture count and street pressure.

Weight is 0.455 lb per foot, about 27 lb for the coil. Unroll it along the trench instead of pulling loops off the side, or it kinks. Soft tube carries the incised type stamp but no colored print, so face the stamp up as you lay it.

CDA’s Table 14.1 lists Type L soft tube in 60 ft and 100 ft coils, and Table 14.3b rates ¾ in. soft Type L at 582 psi at 100°F.

Type M: lighter, where code allows it

Reference

Mueller ¾ in. Type M, 2 ft

Mueller Streamline MH06002 ¾ in. nominal (⅞ in. OD) Type M copper tube, 2 ft

Spec reference, not linked · spec score 8.0 (method)

Pros

  • Matches an existing Type M main wall for wall
  • Rated 701 psi at 100°F, hard
  • 7% more bore area than ¾ in. Type L
  • 2 ft is a ready-cut repair length
  • UPC matches Mueller part MH06002

Cons

  • Not allowed under a slab in UPC towns
  • 0.032 in. wall, the thinnest of K, L and M
  • Only 2 ft per piece
¾ in. nominal0.875 in. OD0.811 in. ID0.032 in. wall0.328 lb/ft2 ft straight

This is Mueller Streamline’s 2 ft pre-cut length of ¾ in. Type M copper, part MH06002, sold under its B&K line in hardware stores. The Amazon listing’s UPC, 685768328278, matches that part at several hardware retailers.

Type M is the thinnest of the three water tube types. CDA’s Table 14.2c gives it a 0.032 in. wall and a 0.811 in. bore at ¾ in. It’s 0.875 in. outside, the same as L and K, so every ¾ in. sweat, press and push fitting fits it.

Thin isn’t weak at house pressure. CDA rates ¾ in. Type M hard at 701 psi at 100°F, nearly nine times the 80 psi limit in IPC section 604.8. Its tested burst average is 4,715 psi. Braze it and the rating drops to 407 psi, because the heat softens the copper.

Two feet is a repair length. The usual job is a pinhole, a split from a freeze or a bad section near a fitting. Cut out the damage, slip this in with two couplings, and the line keeps the same wall and bore from end to end.

Matching the type is optional on a repair. L and M have the same outside size, the same copper and the same fittings, and code lists both. A Type L patch in an M line is a thicker spot, not a problem. Matching just keeps the run uniform.

Hard Type M carries a red print along its length, per CDA’s Table 14.1, with the type, maker and country also stamped into the copper. If you’re not sure what’s in your wall, check for red print before you buy this length.

CDA’s Table 14.3c rates ¾ in. hard Type M at 701 psi at 100°F. If the line has had more than one pinhole, though, look at the water and the flow speed before patching again; our pinhole leak guide covers the causes.

Reference

Mueller 1 in. Type M, 10 ft

Mueller Streamline MH10010 1 in. nominal (1⅛ in. OD) Type M copper tube, 10 ft

Spec reference, not linked · spec score 8.3 (method)

Pros

  • Rated 580 psi at 100°F, hard
  • Weighs 29% less per foot than 1 in. Type L
  • 10 ft cuts the coupling count on a long main
  • Listing gives a 0.035 in. wall and 580 psi, matching CDA
  • Listing says made in the United States

Cons

  • Not allowed under a slab in UPC towns
  • 10 ft is long to carry home
  • 0.015 in. less wall than 1 in. Type L
1 in. nominal1.125 in. OD1.055 in. ID0.035 in. wall0.465 lb/ft10 ft straight

This is Mueller Industries’ 1 in. Type M copper tube in a 10 ft straight length, part MH10010, listed under its B And K Industries line. The listing says it’s made in the United States.

We checked the listing’s specs against CDA. The listing gives a 0.035 in. wall and a 580 psi maximum. CDA’s Tables 14.2c and 14.3c give 1 in. Type M exactly that: a 0.035 in. wall and 580 psi at 100°F in the hard temper.

One-inch is where Type M saves the most copper. It weighs 0.465 lb per foot against Type L’s 0.655, about 29% less. On a 60 ft main, that’s 28 lb of tube against 39 lb. Less copper is the reason M costs less; the live price is on the button.

The bore difference is small at this size. Type M’s 0.874 sq in. is 6% more than Type L’s 0.825. CDA notes that above about 1¼ in., friction loss is virtually the same among the three types, because the wall becomes a small share of the bore.

Ten feet is half a standard stick. CDA lists Type M in 20 ft straight lengths, so a 10 ft piece is easier to carry and still cuts the number of couplings on a long run compared with short lengths.

Use it where the code allows. Under the IPC, which Georgia uses, 1 in. Type M is fine for distribution and service. Under the UPC it’s fine above ground in the building and buried outside, but not under the slab. Brazed 1 in. Type M is rated 337 psi, still double code’s 160 psi floor for buried service.

CDA’s Table 14.3c rates 1 in. hard Type M at 580 psi at 100°F. Type M main above ground is a sound, lighter choice. Where you aren’t sure of the local rule, the same run in Type L costs more copper but passes everywhere.

The tool pick: cutting and reaming L or M

Sold by Amazon.com. It isn’t scored, since our spec score only covers tube.

Tool pick for cutting and reaming copper

RIDGID 227S reamer + 151 cutter

RIDGID Pipe Reamer and Tubing Cutter Bundle: 227S reamer and 151 tubing cutter

227S reamer (½–2 in.) + 151 cutter (¼–1⅝ in. OD)
See today’s price on Amazon
Check it on Amazon

Pros

  • Cutter covers ¼ to 1⅝ in. OD, every size on this page
  • Reamer works inside and outside, ½ to 2 in.
  • Fold-away reamer and quick-change wheel on the cutter
  • Sold by Amazon.com

Cons

  • Costs more than buying a cutter alone
  • Not scored: our spec score covers tube only
  • Cutter stops at 1⅝ in. OD
151: ¼–1⅝ in. OD227S: ½–2 in.45 reaming edgesHardened steel

Buy it if

You’re cutting new L or M tube and don’t own a tubing cutter or reamer yet.

Skip it if

You already have a cutter with a built-in reamer and only make a few joints.

Whichever type you buy, every joint starts with a square cut and a clean end. A tubing cutter rolls a wheel around the tube instead of sawing it, which leaves a square end without metal chips inside the line. The rolled cut leaves a raised burr on the inside edge, and that burr is what a reamer takes off.

RIDGID’s 151 is a single-wheel tubing cutter rated for ¼ to 1⅝ in. OD tube, so it covers every size on this page, from ½ in. nominal (⅝ in. OD) to 1 in. nominal (1⅛ in. OD) and past it to 1½ in. nominal. RIDGID builds the frame as an I-beam, stores a fold-away reamer in the frame, and lets you swap the cutter wheel without tools.

The 227S reamer handles ½ to 2 in. tube, inside and out. RIDGID lists 45 cutting edges on the inside cone for reaming the bore, an outer section for beveling the outside edge, knurled grips, and inch and metric marks on the body. Both tools are hardened steel, according to the listing.

Why it matters for L and M: Type M’s thinner wall leaves less metal to work with, and a burr left inside the tube narrows the bore at the joint. Type L’s heavier wall takes a little longer to cut but follows the same steps. Cut square, ream the inside, clean the outside, then make the joint the way the fitting maker says.

The cutter’s built-in reamer works for a quick touch-up, but the separate 227S is faster on a run with many joints and also bevels the outside. If you already own a cutter, RIDGID also sells the 227S on its own.

This card has no spec score. Our score checks code acceptance, CDA’s rated pressure and length per piece, which only apply to tube. The facts here come from RIDGID’s listing details.

Type L and Type M side by side

Figures are for ¾ in. nominal, the smallest water service code allows, from CDA’s 2026 handbook. Scroll sideways on a phone.

CheckType LType MAhead
Outside diameter0.875 in.0.875 in.Even
Wall0.045 in.0.032 in.L
Inside diameter0.785 in.0.811 in.M
Bore area0.484 sq in.0.517 sq in.M
Weight per foot0.455 lb0.328 lbM
Rated, hard, 100°F1,002 psi701 psiL
Rated, brazed, 100°F582 psi407 psiL
Tested burst, hard5,900 psi4,715 psiL
Friction loss at 5 GPM, per 100 ft2.7 psi2.3 psiM
Printed color on hard tubeBlueRedEven
Soft coils madeYes, 60 and 100 ftNoL
Allowed under the slab, UPC 2021YesNoL
Allowed under the slab, IPC 2024YesYesEven
Listed by CDA for natural gas and LPYesNoL
Same fittingsYesYesEven

“Ahead” means ahead on that one check, not overall. Wall, ratings and code reach favor Type L; weight, bore and copper cost favor Type M. Burst figures are CDA’s averages from three certified tests per size.

How much thicker Type L is at each size

Same outside size, so the extra wall comes out of the bore. The gap is biggest in the sizes houses use.

Type LType M Wall thickness, inches ½ in. 0.040 0.028 L +43% ¾ in. 0.045 0.032 L +41% 1 in. 0.050 0.035 L +43% 1¼ in. 0.055 0.042 L +31% 1½ in. 0.060 0.049 L +22% 2 in. 0.070 0.058 L +21% Type LType M Wall thickness, inches ½ in. 0.040 0.028 L +43% ¾ in. 0.045 0.032 L +41% 1 in. 0.050 0.035 L +43% 1¼ in. 0.055 0.042 L +31% 1½ in. 0.060 0.049 L +22% 2 in. 0.070 0.058 L +21%
Wall thickness of Type L and Type M copper water tube by nominal size. Source: CDA Copper Tube Handbook (2026), Tables 14.2b and 14.2c. Percentages are our arithmetic.
SizeL wallM wallL boreM boreL weightM weightM saves
½ in.0.040 in.0.028 in.0.545 in.0.569 in.0.285 lb/ft0.204 lb/ft28%
¾ in.0.045 in.0.032 in.0.785 in.0.811 in.0.455 lb/ft0.328 lb/ft28%
1 in.0.050 in.0.035 in.1.025 in.1.055 in.0.655 lb/ft0.465 lb/ft29%
1¼ in.0.055 in.0.042 in.1.265 in.1.291 in.0.884 lb/ft0.682 lb/ft23%
1½ in.0.060 in.0.049 in.1.505 in.1.527 in.1.14 lb/ft0.940 lb/ft18%
2 in.0.070 in.0.058 in.1.985 in.2.009 in.1.75 lb/ft1.46 lb/ft17%

“M saves” is how much less copper Type M uses per foot. In ½ to 1 in., the sizes that run through a house, Type M uses about 28% less copper. Copper is most of what you pay for in tube, which is why M is the cheaper one on the shelf.

From 1¼ in. up, the gap narrows to about a fifth. CDA makes the same point about flow: above about 1¼ in., friction loss is virtually the same among K, L and M.

Pressure ratings for every common size

Rated working pressure at 100°F, from CDA’s Tables 14.3b and 14.3c. Use the brazed column for any hard tube you braze. Scroll sideways on a phone.

SizeL hardM hardL brazedM brazed
½ in.1,242 psi850 psi722 psi494 psi
¾ in.1,002 psi701 psi582 psi407 psi
1 in.850 psi580 psi494 psi337 psi
1¼ in.755 psi582 psi439 psi338 psi
1½ in.702 psi569 psi408 psi331 psi
2 in.625 psi514 psi364 psi299 psi

The lowest number in that table, 299 psi for brazed 2 in. Type M, is still almost four times the 80 psi a house is held to. Code asks 160 psi of buried service pipe and 100 psi at 180°F of hot water lines, under IPC sections 605.3 and 605.4. Every size of both types clears both.

CDA’s note on the brazed column matters for Type M. CDA says Type M isn’t normally available soft, so those figures exist only for hard M that has been brazed or welded, where the heat softens the copper near the joint.

SizeL hard burstM hard burstM as share of L
½ in.7,765 psi6,135 psi79%
¾ in.5,900 psi4,715 psi80%
1 in.5,115 psi3,865 psi76%
1½ in.4,100 psi3,550 psi87%
2 in.3,365 psi2,935 psi87%

Room-temperature burst pressures from CDA Table 14.5. Each figure averages three certified tests of that type and size, and every test lands within 5% of that average. Working pressure ratings sit far below them by design.

At the joints, L and M often rate the same

CDA says “the lower of the ratings (tube, fitting or joint) will govern.” For ⅛ to 1 in. soldered joints at 100°F, here’s how that plays out.

JointRated at 100°F¾ in. Type L line rated¾ in. Type M line rated
95-5 tin-antimony solder1,090 psi1,002 psi (tube)701 psi (tube)
Alloy HB solder1,035 psi1,002 psi (tube)701 psi (tube)
Alloy E solder710 psi710 psi (joint)701 psi (tube)
50-50 tin-lead solder200 psi200 psi (joint)200 psi (joint)
BrazedTube’s annealed rating582 psi407 psi

With Alloy E solder, a ¾ in. Type L line and a Type M line end up rated within 9 psi of each other, because the joint caps the L line. Tin-lead 50-50 caps both at 200 psi, and it has been banned on drinking water lines since 1986 anyway.

Press fittings carry their own ratings from the maker, and they fit both types. Viega’s ProPress guide covers B88 Types K, L and M. If I could stock only one press fitting brand, it would be Viega ProPress; our copper press fittings guide compares them.

What Type M’s bigger bore does for flow

A thinner wall leaves more room inside. That buys a little flow and a little slower water at the same flow.

Type LType M Gallons per minute at 5 ft per second (hot water limit) ½ in. 3.6 4.0 ¾ in. 7.5 8.1 1 in. 12.9 13.6 Type LType M Gallons per minute at 5 ft per second (hot water limit) ½ in. 3.6 4.0 ¾ in. 7.5 8.1 1 in. 12.9 13.6
Most flow before water reaches 5 ft per second, CDA’s limit for hot water up to about 140°F. Our arithmetic: velocity = 0.4085 × GPM ÷ inside diameter squared, with inside diameters from CDA Tables 14.2b and 14.2c.
Size and flowType L loss per 100 ftType M loss per 100 ftType L at 8 ft/sType M at 8 ft/s
½ in. at 3 GPM6.2 psi5.1 psi5.8 GPM6.3 GPM
¾ in. at 5 GPM2.7 psi2.3 psi12.1 GPM12.9 GPM
1 in. at 10 GPM2.7 psi2.3 psi20.6 GPM21.8 GPM

Friction figures come from CDA’s Table 14.6, which uses the Hazen-Williams formula with C = 150; we checked each one against the formula. The 8 ft/s columns show the most flow CDA recommends for cold water in each size.

The flow gain is real but small: 7 to 9% more flow at the same speed in ½ and ¾ in. If a house has weak pressure, Type M won’t fix it. Our low water pressure guide covers the usual causes first.

Does Type M get pinholes sooner?

It’s the worry behind most L or M questions on plumbing forums. Here’s what CDA’s handbook ties copper wear to.

What CDA ties wear toWhat it doesWhat you control
Water speedFast water scours the inside of the tube, worst at fittings and turnsSize lines to stay under 8 ft/s cold and 5 ft/s hot; 2 to 3 ft/s above 140°F
Burrs left at cut endsTurbulence right past the burr starts local wearReam every cut to the full bore; Georgia code 605.13.6 requires it
Many abrupt turnsEach sharp change in direction adds turbulenceUse fewer fittings and long sweeps where you can
Aggressive waterCombines with the above to speed erosion-corrosionHave your water tested if pinholes keep coming back
Corrosive flux residueCDA warns corrosive action from flux residue can continue after the joint is madeUse flux sparingly and don’t count on “self-cleaning” flux

None of those causes is the tube type. CDA’s guidance on erosion-corrosion is about speed, water and workmanship, and it applies to K, L and M alike. A badly reamed Type L line can fail before a well-made Type M line.

Wall does decide how long a leak takes once wear starts. At ¾ in., Type L has 0.045 in. of copper and Type M has 0.032, so L has about 40% more metal to lose. If your water is known to be hard on copper, that margin is worth paying for.

Hot water recirculation lines deserve extra care with either type. CDA notes that constant circulation and high temperatures make velocity matter most in those loops, so size both the supply and return to stay under the limits.

Already chasing leaks? Our pinhole leak guide walks through finding the cause, and the deburring tool guide covers the reamers that stop burrs.

Can you mix Type L and Type M?

Yes. Both are the same copper to the same standard, with the same outside size, joined by the same fittings.

QuestionAnswerWhy
Do L and M fit the same fittings?YesSame OD at every size; CDA: OD is always ⅛ in. over the name
Does code allow both in one system?YesIPC Tables 605.3 and 605.4 list K, L and M together
Is there a galvanic problem joining them?NoBoth are ASTM B88 copper; only the wall differs
Can M patch an L line?Check codeFine where M is allowed; not under a slab in UPC towns
Can L patch an M line?YesL is allowed wherever M is

The one thing that changes when you mix is the rating of the run. The line is only as strong as its weakest piece, so a Type L system with one Type M patch is rated like Type M at that spot. At 80 psi, that’s still a wide margin.

Write it down if you mix. A note taped near the water heater listing which runs are M helps the next person who opens the wall.

How to tell Type L from Type M in your house

Same outside size, so look for the color, then the stamp, then measure.

CheckType LType MWorks on
Printed color along the tubeBlueRedHard tube only
Incised stamp“L”, maker, country“M”, maker, countryHard and soft
Soft coil in the lineCould be LUnlikely; CDA lists no soft MSoft tube
Wall at ¾ in., with calipers0.045 in.0.032 in.A cut end
Bore at ¾ in., with calipers0.785 in.0.811 in.A cut end
Wall at ½ in., with calipers0.040 in.0.028 in.A cut end
Bore at ½ in., with calipers0.545 in.0.569 in.A cut end

CDA’s handbook says K, L and M tube must all be incised with the type, the maker’s name or mark and the country of origin, and hard tube is also printed in its type’s color. Print wears off with age and cleaning, so turn the tube and look for the stamp.

No print or stamp left? Measure a cut end when you open the line. At ½ in., Type L’s wall is 0.012 in. thicker than Type M’s, easy to read on cheap digital calipers. A soft coil is almost surely not Type M; CDA lists Type M in hard straight lengths only.

For cutting and reaming either type, see the tool pick above. Our pipe cutter guide covers cutters.

When to pick each type

You don’t know your local code

Type L. The IPC and UPC water tables allow it, but your town’s amendments and your water utility can still set the type, and gas follows the fuel gas code.

A line under a slab

Type L, or K. The UPC doesn’t allow Type M underground inside a structure.

A new buried service in one piece

Type L soft coil. CDA lists no Type M coils.

Indoor lines in an IPC area

Either. Type M is lighter and uses less copper; Type L has more wall.

Patching an existing M line

Type M to match, or Type L if you’d rather add wall.

Gas, radiant heat or snow melting

Not Type M. CDA lists Type L or ACR for natural gas and LP, and Type L for radiant and snow melting.

QuestionIf yesIf no
Is the tube going under a slab in a UPC town?Type L or KKeep going
Did your town amend 604.3 to limit Type M?Follow the local ruleKeep going
Is it a buried service you want in one piece?Type L soft coilKeep going
Is it a water line inside the house?L or M; L for more wall, M for less copperKeep going
Is it gas, radiant heat or snow melting?Type L, per CDA; for gas, only if your fuel gas code and gas utility allow copperCheck with your plumber

Choosing between copper and plastic first? Our PEX vs copper vs CPVC guide compares them. Deciding between soldering and pressing? See ProPress vs soldering. For the thicker types, our Type K vs Type L guide covers buried service lines.

Questions people ask

Should I use Type L or Type M copper?

Use Type L if you aren’t sure of your local code, for any line under a slab in a UPC town, and for radiant heat.

For gas, the fuel gas code decides: the International Fuel Gas Code allows only Type K or L copper, and bans copper where the gas averages more than 0.3 grains of hydrogen sulfide per 100 cubic feet, so some gas utilities don’t allow copper at all. Check with your gas utility and building department first.

Type M is fine for water lines where your code allows it, mostly above ground indoors. It weighs and costs less because it uses about 28% less copper. CDA’s own recommendations list Type M for water distribution; your code decides where it’s allowed.

What is thicker, Type L or Type M?

Type L. At ¾ in., Type L’s wall is 0.045 in. and Type M’s is 0.032 in., about 41% thicker. CDA’s handbook says Type K walls are thicker than L, and L thicker than M, at every size.

Can you mix Type L and Type M copper?

Yes. They have the same outside size and take the same fittings, and the IPC lists both for water lines. The run is rated by its weakest piece, so an M section in an L line is rated like M at that spot, still far above house pressure.

Is Type M copper OK for house plumbing?

Under the 2024 IPC, which Georgia uses, yes, for water service and distribution. Under the UPC, yes above ground in the house and buried outside, but not under the slab. Some cities limit it further, so check your local code.

Can Type M copper be buried?

It depends on the code. The IPC allows Type M for buried water service if it’s rated 160 psi, which every size is. The UPC allows it buried outside the building but not under the slab, and Lincoln, Nebraska doesn’t allow it underground at all.

What color is Type M copper?

Hard Type M is printed in red, Type L in blue and Type K in green, per CDA’s Table 14.1. The print can wear off, so look for the incised stamp too. Soft coils carry only the stamp, and CDA lists Type M in hard lengths only.

What is the pressure rating of Type M copper?

At 100°F, CDA rates hard Type M at 850 psi at ½ in., 701 psi at ¾ in. and 580 psi at 1 in. If it’s brazed, use the annealed figures: 494, 407 and 337 psi. A house is held to 80 psi.

Is Type M copper OK for a water heater line?

Code asks hot water pipe to be rated at least 100 psi at 180°F under IPC section 605.4. Hard ¾ in. Type M is rated 701 psi up to 250°F, and 332 psi at 200°F when brazed. CDA asks to keep hot water under 5 ft per second.

Can Type M copper be used for gas?

CDA’s Table 14.1 lists natural gas and LP for Types K and L, not M, and its gas recommendation names Type L or ACR tube. Your fuel gas code and gas utility have the final say.

Is Type M copper cheaper than Type L?

Usually, because it uses less copper: about 28% less per foot in ½ to 1 in., by CDA’s weight tables. Check the live prices on the buttons above; we don’t type prices by hand.

How we compared them

Why trust us

Written by Isaac Daniels, a licensed journeyman plumber in Georgia (license #JP507711). Wall, bore, weight, pressure, burst and flow figures come from the Copper Development Association’s 2026 Copper Tube Handbook; code from the 2024 IPC, Georgia’s 2026 amendments and the 2021 UPC; seller and stock from Amazon.

How we compare

  • Only figures CDA, the codes, Viega and the Amazon listings publish, read Oct 21, 2026.
  • The spec score checks code acceptance, CDA’s rated pressure and the length per piece. It doesn’t replace the code check: code, size and temper still decide the right tube.
  • Percentages, velocities and coil weights are our arithmetic from CDA’s tables.
  • Each Type M listing’s UPC was matched to the maker’s part number at hardware retailers; one listing whose brand didn’t match its maker was left out.
  • Links only to listings sold by Amazon.com.

The spec score, check by check

Each tube gets the same three checks, from CDA’s 2026 Copper Tube Handbook, the codes on this page and the listing’s length, averaged to one decimal. Every pick has to reach 7.0.

The score doesn’t pick your tube. Code, size and temper still decide that: an M line repair takes Type M, and a buried service takes the soft coil. A lower score here means less wall, a lower pressure rating or more joints per run.

Check (weight)How it’s scored
Code acceptance (⅓)10 = Type L, allowed under every code on this page; 8 = Type M, which some codes on this page limit (for example, not under a slab in UPC towns)
Rated pressure (⅓)10 = 1,000 psi or more at 100°F (CDA); 9 = 700 to 999 psi; 8 = under 700 psi
Length per piece (⅓)10 = 50 ft or more in one piece; 9 = 10 to 49 ft; 8 = 5 to 9 ft; 7 = under 5 ft
TotalAverage of the checks, to one decimal
PickCode acceptanceRated pressureLength per pieceScore
ICS ¾ in. Type L hard, 5 ft101089.3
VENTRAL ½ in. Type L hard, 5 ft101089.3
ICS ¾ in. Type L soft, 60 ft108109.3
Mueller ¾ in. Type M, 2 ft8978.0
Mueller 1 in. Type M, 10 ft8898.3

Sources

  • International Code Council, International Fuel Gas Code, copper and copper-alloy tubing section (Type K or L of ASTM B88 or B280 only; not where gas averages more than 0.3 grains of hydrogen sulfide per 100 standard cubic feet), as published on up.codes, read Oct 27, 2026.
  • Copper Development Association, The Copper Tube Handbook, Publication A4015-26/24 (2026): Table 14.1 (types, colors, lengths, coils, applications), Tables 14.2b and 14.2c (Type L and M dimensions and weights), Tables 14.3b and 14.3c (rated working pressures), Table 14.4a (soldered and brazed joint ratings), Table 14.5 (burst pressures), Table 14.6 (friction loss), minimum recommendations by application, water velocity limits, erosion-corrosion causes and identification rules. Read Oct 21, 2026.
  • 2024 International Plumbing Code (ICC), Chapter 6, sections 603.1, 604.8, 605.3, 605.4 and 605.13.6 with Tables 605.3 and 605.4; read on codes.iccsafe.org Oct 21, 2026.
  • Georgia DCA, Georgia State Amendments to the International Plumbing Code (2024 Edition), effective Jan 1, 2026, and Georgia State Minimum Standard Codes list. Read Oct 20, 2026.
  • Uniform Plumbing Code 2021, sections 604.3 and 604.4, as adopted in the Hawaii Plumbing Code (UpCodes). Lincoln, Nebraska Municipal Code 24.12.250 (Ord. 21176, Dec 13, 2021). Read Oct 21, 2026.
  • Viega ProPress installation manual IM-PP: tube types allowed for ProPress fittings. Read Oct 21, 2026.
  • Amazon listings for ICS Industries Type L hard and soft, Mueller Streamline MH06002 and MH10010, and RIDGID 227S (seller, condition, stock, brand and model): read on Amazon, Oct 21, 2026, 2:10 PM (VENTRAL ½ in. Type L hard: 2:12 PM), and again Oct 22, 2026, 1:38 AM. UPC 685768328278 matched to MH06002 at Family Hardware, Little Hardware and SIM Supply listings, Oct 21, 2026.

Related guides
