Best solder and flux for copper pipe

Lead-free solder, B813 flux, clean copper.

As an Amazon Associate I earn from qualifying purchases.

On this page
  1. My picks
  2. Flux
  3. Solder
  4. Cleaning
  5. The rules
  6. Side-by-side
  7. Wire per joint
  8. Flux types
  9. Temperatures
  10. Solder or braze
  11. Lead-free rules
  12. What to buy
  13. How to solder
  14. How much to buy
  15. FAQ
  16. How I pick

Quick answer

LA-CO 22194 flux and a sized fitting brush, used with any lead-free solder marked ASTM B32. Never 50/50 on water lines.

LA-CO 22194 water-soluble copper flux paste with brush in cap
Top flux: LA-CO 22194$8.69 at AmazonPrice as of Nov 22, 2026, 9:30 AM EST
Check it on Amazon

My picks

LA-CO 22194 water-soluble copper flux paste
Best flux for drinking-water lines

LA-CO 22194 flux paste, 4 oz, brush in cap

$8.69 at Amazon
Check it on Amazon
Price as of Nov 22, 2026, 9:30 AM EST
ToolKey specsPick it ifSkip it if
LA-CO 22194 flux paste, 4 oz, brush in capASTM B813 (22194), NSF 61 (22194), Water-soluble, Lead-freeYou’re soldering copper water lines and want a flux that meets the standards the handbook names.You’re brazing or soldering stainless. Those need their own fluxes.
Oatey 22017 95/5 lead-free solder, 1 lb95/5: 450–464°F, Safe-Flo: 415–455°F, Lead-free, Solid wireYou’re sweating copper water lines and want the common lead-free alloy.You’re joining dissimilar or high-temperature lines. Some need brazing; the handbook covers when.
Fitting brushes and emery cloth½ and ¾ in. brushes, 120 grit, 1½ in. rollYou’re soldering ½ and ¾ inch copper, the house sizes.You already have a 4-in-1 brush you like. Keep it.

Flux: LA-CO and Oatey

The Copper Tube Handbook says flux keeps cleaned copper from oxidizing again, helps the solder wet the surface and lifts leftover oxide. Brush a thin, even coat of a B813 flux on the tube and fitting right after cleaning, never with your fingers. Too much leaves residue that can corrode the pipe.

That’s why I like LA-CO’s 22194. LA-CO says it meets ASTM B813 and NSF/ANSI 61, has no zinc chloride, and is non-acid, lead-free and water-soluble, so LA-CO says it won’t leave residue in the piping. Still apply it sparingly, wipe residue off the outside of the joint and flush the system as the instructions say. It’s sold as an all-weather paste, and the brush is built into the cap.

Oatey’s H-20 95 (30140) is a tinning flux: a paste with solder powder in it. Oatey lists ASTM B813, NSF 14 and NSF 61, says it won’t turn copper green and calls it good for large-diameter copper. It works on most metals, but not aluminum or stainless steel.

What it does wellWhat to watch
LA-CO 22194 meets ASTM B813 and NSF/ANSI 61, per LA-COOatey’s tinning flux isn’t made for stainless or aluminum
Oatey 30140 lists ASTM B813 plus NSF 14 and 61The 1 lb LA-CO 22107 listing names a military spec; check the label for B813
No zinc chloride in either LA-CO paste

LA-CO’s 1 lb 22107 Regular is the bulk choice for a busy van; it’s a reference, shown for comparison only. LA-CO says it has no zinc chloride and works with lead-free and common soft solders on copper, brass, galvanized iron and more.

Its Amazon listing gives Mil-F-4995 type II. LA-CO’s own page for its Regular Flux Paste family says the paste meets ASTM B813 and lists a 1 lb size, but doesn’t name SKU 22107, so check the B813 mark on the label.

Be wary of any flux sold as a way to skip cleaning. The handbook says some ‘self-cleaning’ fluxes carry a risk: a strong, corrosive flux can remove some oxide, but you can’t be sure the joint was cleaned evenly, and the residue may keep working after you’re done.

Plan on about 2 ounces of flux per pound of solder, the handbook’s usual rate, so the 4 ounce LA-CO jar covers roughly 2 pounds of wire. When the joint cools, wipe off leftover flux with a wet rag and flush the line, as the handbook directs.

Solder: 95/5 or silver-bearing

95/5 tin-antimony is the workhorse. Oatey’s 22017 is lead-free, meets the Safe Drinking Water Act, and is sold for drinking water, refrigeration and cooling lines, especially where temperature swings and vibration are frequent. Oatey lists a 450 to 464°F melting range.

AIM’s Dura-Pure 95/5 (model 5114) is the same alloy in ⅛ inch wire. AIM lists the 450 to 464°F range, a 10,080 psi ultimate tensile strength, ASTM B32 compliance for potable water joints, and NSF and UPC certification. AIM calls it ideal for brass and copper plumbing joints, and it’s sold by AIM’s own Amazon store.

Oatey’s Safe-Flo 29025 is a silver-bearing blend of copper, bismuth, tin and silver. Oatey lists a 415 to 455°F melting range, so it goes liquid sooner than 95/5. It meets the Safe Drinking Water Act, it’s made for copper plumbing and potable lines, and it can’t be used on aluminum.

What it does wellWhat to watch
95/5 is 95% tin, 5% antimony and lead-free, per Oatey and AIMAll three are references, shown for comparison only
Oatey says 22017 and Safe-Flo meet the Safe Drinking Water Act95/5 melts hotter (450–464°F, per AIM), so it takes more heat
Safe-Flo melts lower: 415–455°F, per Oatey
AIM’s 95/5 lists ASTM B32, NSF and UPC

Wire size changes how much you feed. Oatey’s 22017 is 0.117 inch, AIM’s is 0.125 and Safe-Flo 29025 is listed at 0.084 inch, so a joint takes about twice the length of Safe-Flo as of ⅛ inch wire. The wire-per-joint table below works it out by size.

The handbook adds two limits. For service above 250°F, or where the highest joint strength is needed, it calls for brazing instead of solder. For higher pressures than 50-50 tin-lead suits, it names 95/5 and the lead-free alloys E and HB. It also says to weigh the stress thermal expansion puts on joints, though a short run or an expansion loop makes that small.

Whichever you buy, it must be solid wire for plumbing. A 95/5 rosin-core wire is for electrical work, and every solder here needs a separate flux. Check the model number on the spool when it arrives.

Cleaning: brushes and emery cloth

Most bad solder joints are dirty joints. The handbook says to lightly clean the tube end a little past the fitting depth with sand cloth or nylon pads, and the fitting cups with cloth, pads or a properly sized fitting brush.

It also warns that copper is soft. The gap the solder fills is about 0.004 inch, and the handbook says capillary flow works best between 0.004 and 0.006. Sand off too much and the fit gets loose, which is harder to fill on bigger fittings. Clean until bright, then stop.

Don’t touch cleaned copper with bare hands or oily gloves; the handbook says skin oils and grease spoil the joint. Flux right away, too, because an oxide film can form again quickly on fresh copper.

Get the cut right first. The handbook says a tube cut too short won’t reach the bottom of the cup, a tube cut too long strains the system, and every cut must be square so the tube seats properly. A disc-type tube cutter is one of the tools it lists.

What it does wellWhat to watch
Sized brushes clean the inside of fitting cupsOne brush per size
120-grit cloth cleans the tube endDon’t overdo it: too much sanding loosens the fit, per the handbook

Ream before you clean. The handbook lists reaming right after cutting, with a half-round file, a pocket knife or a deburring tool, to take off the burr the cutter leaves. Then clean, flux and assemble, in that order.

The EZ-FLO roll is waterproof 120-grit aluminum oxide cloth, 1½ inches wide and 5 yards long. EZ-FLO says it’s made for metal and warns against using it on delicate surfaces.

Eastman’s ½ inch brush (45245) has high-impact steel bristles and a contoured plastic handle, and Eastman says it’s for cleaning the inside of fittings before soldering. For ¾ inch, the 45261 has the same steel bristles on a loop wire handle. Buy one brush for each size you sweat most.

Chemical cleaners are allowed too, the handbook says, as long as you rinse the tube and fittings thoroughly by the cleaner maker’s directions.

The two rules for water lines

Get these right and the brand matters a lot less.

No more than 0.2% lead

Federal law caps solder and flux for drinking water at 0.2% lead (EPA, Safe Drinking Water Act). That rules out 50/50 tin-lead on any water line.

Solder listed in ASTM B32

The Copper Tube Handbook says solders in Section 1 of ASTM B32’s Table 1, like 95/5 tin-antimony, can join copper in potable water systems.

Flux to ASTM B813

The handbook calls for a flux meeting ASTM B813’s general requirements, brushed on thin and even.

Rosin-core solder

Oatey sells a 95/5 rosin-core wire for electrical work. Wrong product for a water line; buy solid wire.

What each product is for

ProductTypeStandard on the labelLead-freeSold by
LA-CO 22194Paste flux, brush in capASTM B813, NSF 61YesAmazon.com
Oatey 30140 H-20 95Tinning flux with solder powderASTM B813, NSF 14 and 61YesReference (not linked)
LA-CO 22107Paste flux, 1 lbMil-F-4995 type II on the listing; B813 on LA-CO’s family pageYesReference (not linked)
Oatey 2201795/5 wire solderSafe Drinking Water ActYesReference (not linked)
Oatey Safe-Flo 29025Silver-bearing wire solderSafe Drinking Water ActYesReference (not linked)
AIM Dura-Pure 95/595/5 wire solderASTM B32, NSF, UPCYesAIM store

How much wire one joint takes

The handbook’s fill length for ⅛ inch wire at the ideal 0.004 inch gap, converted to the other wire sizes on this page.

Tube sizeFitting cup depth⅛ in. wire (AIM)0.117 in. wire (Oatey 22017)0.084 in. wire (Safe-Flo 29025)
½ in.0.500 in.0.32 in.0.37 in.0.71 in.
¾ in.0.750 in.0.67 in.0.77 in.1.49 in.
1 in.0.910 in.1.05 in.1.20 in.2.32 in.
1¼ in.0.970 in.1.37 in.1.56 in.3.02 in.
1½ in.1.090 in.1.81 in.2.07 in.4.02 in.
2 in.1.340 in.2.92 in.3.33 in.6.46 in.

Source: Copper Tube Handbook Table 14.10, 0.004 in. clearance column. The thinner-wire columns are our math: length scales with the wire’s cross-section. The handbook says actual use depends on workmanship, so feed until small drops show behind the point you’re feeding: the handbook’s sign the joint is full.

Which kind of flux is which

Three kinds show up on the plumbing aisle. The label tells you which one you’re holding.

Flux typeWhat it isOn this pageWhat the handbook or maker says
Water-soluble pastePaste that rinses out with waterLA-CO 22194ASTM B813, NSF 61, no zinc chloride (LA-CO)
Tinning fluxPaste with solder powder mixed inOatey 30140 H-20 95ASTM B813, NSF 14 and 61; good on large copper (Oatey)
General soldering pastePaste for many metalsLA-CO 22107Mil-F-4995 type II on the listing; LA-CO says the Regular family meets B813
“Self-cleaning” corrosive fluxStrong flux meant to replace cleaningNoneA risk: cleaning may be uneven and residue may keep corroding (handbook)

The temperatures that matter

Solder, flame and service temperature all have limits. Here they are in one place.

WhatTemperatureSource
Most soldering workAbout 350–600°FCopper Tube Handbook
Safe-Flo 29025 melts415–455°FOatey listing
95/5 (Oatey 22017, AIM 5114) melts450–464°FOatey and AIM listings
Upper limit for anything called solder840°F liquidusAWS definition, quoted in the handbook
Continuous service where you braze insteadAbove 250°FCopper Tube Handbook

Watch the flame, not just the solder. The handbook says overheating burns the flux, and burnt flux stops the solder from entering the joint.

Silver-bearing solder isn’t brazing

CheckSoldering (this page)Brazing
Filler melts at415–464°F for the solders here (Oatey, AIM)1100–1500°F (handbook Table 14.12)
Filler names95/5 tin-antimony; Safe-Flo tin, copper, bismuth and silverBCuP (phosphorus) and BAg (high silver) series
Most used in plumbing95/5 and other ASTM B32 lead-free alloysBCuP-2 to BCuP-5, BAg-1, BAg-5 and BAg-7
When the handbook calls for itWater lines in normal serviceService above 250°F, or where the highest joint strength is needed
Heat sourceTorch on the tube, then the fittingMuch hotter flame, with its own flux for BAg alloys

The handbook asks people to stop calling brazing filler “hard solder” or “silver solder”, because the terms get confused. Safe-Flo has silver in it, but it’s still a soft solder that melts below 455°F, so it goes on with the same torch and flux as 95/5.

Brazing rod melts at 1100°F or more and joins the tube in a different way. The handbook says BCuP alloys cost less and suit general piping, while BAg alloys are for joining unlike metals. If your job needs brazing, none of the solders on this page will do it; our ProPress vs brazing guide covers that choice.

What lead-free means for solder and flux

Federal rules set the numbers, and the EPA spells them out.

RuleWhat the EPA says
Solder and fluxNo more than 0.2% lead
Pipes, fittings and fixturesNo more than a 0.25% weighted average of lead across wetted surfaces
Where it appliesInstalling or repairing public water systems and any plumbing that provides water for people to drink
Since whenJune 1986 for solder and flux; the pipe limit was lowered by the Reduction of Lead in Drinking Water Act (2011)
Selling itProducts that aren’t lead-free can’t be sold for this use, except for manufacturing or industrial purposes
CertificationSince September 1, 2023, makers and importers must certify lead-free products

Every solder and flux on this page is sold as lead-free by its maker, Oatey names the Safe Drinking Water Act on its solder, and LA-CO lists NSF/ANSI 61 for potable water. That’s the first thing to read on any spool or jar you pick up.

The EPA exempts products used only for nonpotable service. The handbook notes some local codes still allow 50-50 tin-lead on certain HVAC and drain work, so if you also work on those, keep that solder apart from your water-line stock.

What to buy for your job

Built from the picks above and the handbook’s rule of about 2 ounces of flux per pound of solder.

JobFluxSolderCleaning
A few repairs, ½ and ¾ in.LA-CO 22194, 4 ozOatey 22017 or AIM 95/5, 1 lbEastman ½ and ¾ in. brushes, EZ-FLO cloth
Copper 1 in. and upOatey 30140 tinning flux95/5 wireA brush sized to each fitting, cloth
Lots of joints on a vanLA-CO 22107, 1 lb (check B813 with your inspector)95/5 by the poundA brush for every size you stock
You want a lower melting pointLA-CO 22194Oatey Safe-Flo 29025, 1 lbSame brushes and cloth

Brushes are sized by fitting, so a ½ in. brush won’t clean a ¾ in. cup properly. If you sweat both sizes, buy both.

How to sweat a copper joint

The order from the Copper Tube Handbook. The diagram shows how to feed solder into a horizontal joint.

abcdTorch heat at the base aStart slightly off-center at the bottom. bAcross the bottom, up one side to the top. cBack to the start, overlapping a little. dUp the other side, overlapping again. Small drops behind the solder = that part is full. abcdTorch heat at the base aStart slightly off-center at the bottom. bAcross the bottom, up one side to the top. cBack to the start, overlapping a little. dUp the other side, overlapping again. Small drops behind the solder = that part is full.
From the handbook’s Figure 7.18. The solder that sets at the bottom first acts as a dam, so the sides and top fill without running out.
  1. 1
    Cut, ream and clean

    Square cut, ream the burr, then clean tube and cup until bright. See our deburring tool picks.

  2. 2
    Flux thin and even

    Brush flux on the tube and inside the fitting right after cleaning. Not with fingers.

  3. 3
    Assemble

    Seat the tube against the bottom of the cup with a slight twist, wipe off extra flux, and support it so the gap stays even. Finish the joint the same day.

  4. 4
    Heat tube, then fitting

    Start with the flame on the tube, then move to the fitting cup and sweep between them. Don’t preheat the top of a horizontal joint or aim into the cup; burnt flux stops the solder.

  5. 5
    Feed the solder

    With the torch at the base of the cup, touch solder to the joint. If it doesn’t melt, take it away and keep heating. Then follow the a-b-c-d order above.

  6. 6
    Cool, wipe, test

    Let it cool on its own; water shock-cooling can stress the joint. Wipe off flux with a wet rag, flush the system and test.

Soldering next to a valve? The handbook says to follow the valve maker’s instructions, leave a solder-cup valve partly open before you heat it, and put the heat mainly on the tube. A heat-sink paste can protect seats and seals nearby. Our guide to soldering a ball valve open or closed lists what each maker says.

How much flux for your solder

½ lb solder≈1 oz flux1 lb solder≈2 oz flux2 lb solder≈4 oz flux½ lb solder≈1 oz flux1 lb solder≈2 oz flux2 lb solder≈4 oz flux
The Copper Tube Handbook: “The flux requirement is usually 2 ounces per pound of solder.” A 4 oz jar covers about 2 lb of wire.

Questions people ask

What solder do plumbers use on copper water pipe?

Lead-free solid wire, usually 95/5 tin-antimony or a silver-bearing blend. The Copper Tube Handbook says solders in ASTM B32’s Section 1 can be used on potable water copper.

Can you use 50/50 solder on water pipes?

Not on drinking water. Solder over 0.2% lead has been banned for potable water since the 1986 Safe Drinking Water Act amendments. The handbook notes some places still allow 50/50 on certain HVAC and drain work.

Is 95/5 solder lead-free?

Yes. It’s 95% tin and 5% antimony. Oatey says its 22017 95/5 meets the Safe Drinking Water Act. AIM’s 95/5 lists ASTM B32, NSF and UPC.

Can you use too much flux?

Yes. The handbook warns excess flux leaves residue that can corrode the tube, and in extreme cases perforate it. Brush on a thin, even coat and wipe the joint after.

Why won’t my solder flow into the fitting?

Usually dirty copper, burnt flux or wrong heat. The handbook says not to overheat or aim the flame into the cup, because burnt flux stops the solder entering.

Is 60/40 or 63/37 solder better for copper pipe?

Neither, for water lines. Those are tin-lead solders, and solder over 0.2% lead is banned for drinking water. Use a lead-free plumbing solder like 95/5.

Can you use rosin-core solder on copper pipe?

No. Rosin-core wire is for electrical work; Oatey labels its 95/5 rosin-core for electrical use. For plumbing use solid wire with a separate plumbing flux.

Should I solder or use press fittings?

If you own a torch and do the odd repair, solder is cheap. For no-flame jobs or lots of joints, press fittings are faster. See ProPress vs soldering.

What is tinning flux?

A flux paste with powdered solder mixed in. Oatey’s H-20 95 is one: Oatey says it’s water-flushable, lead-free, meets ASTM B813 and is good on large-diameter copper. You still feed wire solder to fill the joint.

Is water-soluble flux better for drinking water lines?

It’s easier to flush out. LA-CO says its water-soluble 22194 won’t leave residue in water piping, and it meets ASTM B813 and NSF/ANSI 61. Whatever you use, the handbook says to wipe the joint and flush the system when you’re done.

How much solder does one joint take?

About a third of an inch of ⅛ inch wire fills a ½ inch joint at the ideal 0.004 inch gap, per the Copper Tube Handbook, and about two thirds of an inch for ¾ inch. Thinner wire takes more length; see the wire-per-joint table.

What does ‘self-cleaning’ flux mean?

It’s a strong, corrosive flux sold as a way to skip cleaning. The handbook calls these a risk: you can’t be sure the copper was cleaned evenly, and the residue may keep corroding after the joint is done. Clean the copper anyway.

What melting point does plumbing solder have?

Oatey and AIM list 450 to 464°F for 95/5. Oatey lists 415 to 455°F for its silver-bearing Safe-Flo. The handbook says most soldering happens between about 350 and 600°F.

Can you solder a vertical copper joint?

Yes. The handbook says to make a similar series of overlapping passes, starting wherever is convenient. Capillary action pulls molten solder into the gap whether it flows up, down or sideways.

How do you know a solder joint is full?

The handbook says small drops may appear behind the point where you’re feeding solder. That means the joint is full to that point and will take no more.

Is lead-free solder required by law?

For drinking water, yes. The EPA limits solder and flux to 0.2% lead in any plumbing that provides water for people to drink, and has since June 1986.

Does flux go on the pipe or inside the fitting?

Both. The handbook says to brush a thin, even coat on the tube end and inside the fitting cup as soon as possible after cleaning, then twist the tube in slightly so the flux spreads evenly and wipe the extra off the outside.

How I picked these

Links go to listings sold by Amazon.com.

Why trust me

I’m Isaac Daniels, a licensed journeyman plumber in Georgia (license #JP507711). The rules here come from the Copper Development Association’s Copper Tube Handbook and the EPA, named below.

How I pick

  • Lead-free and meant for drinking water, per the maker.
  • A named standard on the label (ASTM B813, ASTM B32, NSF) counts for more.
  • Listings whose title and model match the maker’s product, new and in stock. A listing can’t prove a seller is authorized.
  • Prices read from Amazon with the time shown, never typed in.
  • Flux, solder and cleaning tools are listed as one kit with no shared score, because each does a different job in the joint and one formula wouldn’t be fair to all three.
  • The Oatey, Safe-Flo, AIM and LA-CO 22107 products are references, shown for comparison only.

Sources

  • Copper Development Association, Copper Tube Handbook, publication A4015-26/24, section 6 (solders, fluxes), section 7 (soldered joints, solder-cup valves), section 8 (brazed joints: 1100–1500°F filler, BCuP and BAg series, avoid “silver solder”) and Table 14.10 (solder requirements): ASTM B32 Section 1 solders; over 0.2% lead banned for potable water by the 1986 SDWA amendment; 95/5 and alloys E and HB for higher pressures; brazing above 250°F; ASTM B813 flux and its three functions; ‘self-cleaning’ flux risk; thin even coat, not with fingers; excess flux can corrode; 0.004 in. gap and 0.004–0.006 in. best range; soldering at about 350–600°F and the AWS 840°F definition; about 2 oz flux per lb of solder; cool naturally. Read Oct 18, 2026.
  • U.S. EPA, “Use of Lead Free Pipes, Fittings, Fixtures, Solder, and Flux for Drinking Water” (epa.gov): solder and flux no more than 0.2% lead.
  • LA-CO 22194 and 22107, Oatey 30140, 22017 and 29025, AIM Dura-Pure 95/5 (5114), Eastman 45245 and 45247, EZ-FLO 45205: maker text on each Amazon listing, read Oct 18, 2026.
