The two RLS jaws I link

Two RLS jaws for pressing 3/8 and 3/4 in. line sets on a RIDGID compact tool. The brazing kits and rods below are Reference (not linked). Buy buttons show Amazon’s price and the time it was read. [22] [20]

RIDGID 55118 3/8 inch RLS compact press jaw
Best for pressing 3/8 in. RLS liquid lines

RIDGID 55118 RLS jaw

$173.51 at Amazon
Check RIDGID 55118 on Amazon
Price as of Nov 22, 2026, 9:30 AM EST

Product photo from the Amazon listing.

New offer sold by Amazon.com.

Buy it if: I need this exact RLS tube size and already have a compatible RIDGID compact tool.

Skip it if: I use a different fitting system or a standard-size tool.

The tradeoff: this is one jaw, not a press tool or fitting kit.

RIDGID 55133 3/4 inch RLS compact press jaw
Best for pressing 3/4 in. RLS suction lines

RIDGID 55133 RLS jaw

$245.38 at Amazon
Check RIDGID 55133 on Amazon
Price as of Nov 22, 2026, 9:30 AM EST

Product photo from the Amazon listing.

New offer sold by Amazon.com.

Buy it if: I need this exact RLS tube size and already have a compatible RIDGID compact tool.

Skip it if: I use a different fitting system or a standard-size tool.

The tradeoff: this is one jaw, not a press tool or fitting kit.

ToolKey specsPick it ifSkip it if
RIDGID 55118 RLS compact jawRIDGID 55118 on Amazon
RIDGID 55133 RLS compact jawRIDGID 55133 on Amazon
55118: 3/8 in. jaw; 55133: 3/4 in. jaw. RLS fittings only. Fitting pressure/listing/warranty depend on the RLS system, not the jaw alone. [22] [20]You already run a RIDGID compact press tool and want to press R-410A line sets without a torch. [22] [20]Your fittings are ZoomLock MAX, your lines are over 1-3/8 in., or the job uses a refrigerant RLS hasn’t approved. [22] [20]

Brazing gear I reference

These brazing kits and rods are named in the makers’ documents this page uses. They’re here as reference, from ESAB, Harris and Lucas-Milhaupt specs.

Reference (not linked)

TurboTorch PL-8ADLX-B air-acetylene kit (0386-0835)

PL-8A tip, AR-B regulator, G-4 handle and AH-12 hose, for a B acetylene tank sold separately. ESAB rates it to braze to 1 in. and solder to 2 in. ESAB rates its PL-12A tip for 1 to 2 in. [23]

Reference (not linked)

TurboTorch PL-5ADLX-MC air-acetylene kit (0386-0832)

PL-5A tip, AR-MC regulator, G-4 handle and AH-12 hose, for the smaller MC tank. ESAB rates it to braze to 3/4 in. and solder to 1-1/2 in. [23]

Reference (not linked)

Harris Stay-Silv 15 BCuP-5 brazing alloy, 28 sticks

BCuP-5 class, 4.8 to 5.2% phosphorus, solidus 1190°F and liquidus 1475°F. Harris says the phosphorus forms a low-ductility layer on ferrous metals, so it isn’t for copper to steel. [24]

Reference (not linked)

Lucas-Milhaupt Sil-Fos 15 brazing alloy, part 95177

15% silver, 80% copper and 5% phosphorus; solidus 1190°F, flow 1300°F and liquidus 1475°F. Not for steel or nickel alloys, or joints that will see sulfur compounds. [25]

Which joint for which line

Press and torch each win on some lines. The makers’ ratings settle it line by line, with RLS, Parker ZoomLock MAX, Viega ProPress and a brazed joint side by side.

Information source: RLS current product information

RLS press700 psi, HNBR ZoomLock MAX700 psi, HNBR Viega ProPress300 psi, EPDM Brazed jointBCuP-5 + nitrogen 3/8 in. liquid lineR-410A system ListedR-410A on list ListedR-410A on list Not listedfor refrigerant Standard methodpurge with N2 3/4 or 7/8 in. suctionhard drawn tube Listedhard ACR, L, K Listedhard ACR, L, K Not listedfor refrigerant Standard methodannealed rating Soft coil over 7/8 in.annealed tube IMC limit:7/8 in. OD max IMC limit:7/8 in. OD max Not listedfor refrigerant No such limitin the IMC note 1-5/8 or 2-1/8 in.large lines Made in these32 kN tool only Sizes stopat 1-3/8 in. Not listedfor refrigerant Standard methodbigger torch tip A2L refrigerantR-454B or R-32 On RLS’s listcheck local code On the listextra rules apply Not listedfor refrigerant Open flamefollow site rules CO2 or ammoniaR-744, R-717 Not onRLS's list Not suitable,per Parker Not listedfor refrigerant Engineered jobno copper on NH3 Chilled or hydronicwater and glycol Ethylene glycol,non-potable water Refrigerantside only Built for itchilled, hydronic Allowedsolder is usual Listed or built for it Possible, with a limit Not listed for it Your local code and inspector have the final say. N2: dry nitrogen. NH3: ammonia. Boxes in each row: RLS and ZoomLock (top),ProPress and brazed joint (bottom). 3/8 in. liquid line, R-410A system RLS: ListedR-410A on list ZoomLock: ListedR-410A on list ProPress: Not listedfor refrigerant Braze: Standard methodpurge with N2 3/4 or 7/8 in. suction, hard drawn tube RLS: Listedhard ACR, L, K ZoomLock: Listedhard ACR, L, K ProPress: Not listedfor refrigerant Braze: Standard methodannealed rating Soft coil over 7/8 in., annealed tube RLS: IMC limit:7/8 in. OD max ZoomLock: IMC limit:7/8 in. OD max ProPress: Not listedfor refrigerant Braze: No such limitin the IMC note 1-5/8 or 2-1/8 in., large lines RLS: Made in these32 kN tool only ZoomLock: Sizes stopat 1-3/8 in. ProPress: Not listedfor refrigerant Braze: Standard methodbigger torch tip A2L refrigerant, R-454B or R-32 RLS: On its listcheck local code ZoomLock: On the listextra rules apply ProPress: Not listedfor refrigerant Braze: Open flamefollow site rules CO2 or ammonia, R-744, R-717 RLS: Not onRLS's list ZoomLock: Not suitable,per Parker ProPress: Not listedfor refrigerant Braze: Engineered jobno copper on NH3 Chilled or hydronic, water and glycol RLS: Ethylene glycol,non-potable water ZoomLock: Refrigerantside only ProPress: Built for itchilled, hydronic Braze: Allowedsolder is usual Listed or built for it Possible, with a limit Not listed for it
From the RLS product catalogue, Parker’s ZoomLock MAX Catalog K-3, Viega’s ProPress system data sheet SM-PP 0926 and the CDA Copper Tube Handbook, read Oct 20, 2026.

The ProPress column is the one most people miss. ProPress lists water, hydronic and specified non-medical gas applications; this does not approve it for fuel gas or refrigerant. Viega’s data sheet lists potable water, chilled water, hydronic heat, compressed air and non-medical gases.

Each use carries its own limit. The system maximum is 300 psi with an EPDM seal, while low-pressure steam is capped at 15 psi with an FKM seal swap. Refrigerant isn’t on the list. [26]

Refrigerant press fittings are a separate product. RLS and ZoomLock MAX are both listed by their makers to UL 207 and rated to 700 psi, both use HNBR O-rings, and both hold a vacuum to 200 microns. Each needs its own approved jaws, so a ProPress jaw set doesn’t carry over. [22] [27]

Press jaws and brazing gear side by side

Every figure comes from the makers’ documents. On a phone, each row is shown as a labeled record. Buy buttons show Amazon’s price when the latest check worked.

PickPhotoJobSizeFlameKey limitShort pros / consBuy
RIDGID 55118
RLS jaw
RIDGID 55118 RLS jawPress RLS fittings3/8 in. [22]NoRLS fittings only700 psi system / One size [22]Check RIDGID 55118 on Amazon [20]
RIDGID 55133
RLS jaw
RIDGID 55133 RLS jawPress RLS fittings3/4 in. [22]NoRLS fittings onlyNo purge / One sizeCheck RIDGID 55133 on Amazon [21]
TurboTorch
PL-8ADLX-B
ReferenceBraze and solderBrazes to 1 in. [23]YesB tank, sold separatelySelf-lighting / Air-fuelReference (not linked)
TurboTorch
PL-5ADLX-MC
ReferenceBraze and solderBrazes to 3/4 in. [23]YesMC tank, sold separatelySmall tank / 3/4 in. max [23]Reference (not linked)
Harris Stay-Silv 15
28 sticks
ReferenceFiller rodCopper; size set by the tipYesNot for steelNo flux on copper / No sulfurReference (not linked)
Lucas-Milhaupt Sil-Fos 15
95177, 7 sticks
ReferenceFiller rodCopper; size set by the tipYesNot for iron or nickelSelf-fluxing / Small packReference (not linked)

Green marks a strength and amber marks a trade-off. “Flame” means the job needs a torch, with the hot work rules that come with one.

ProPress, RLS, ZoomLock MAX and brazing by the numbers

Each figure is from the maker’s own document or the Copper Tube Handbook.

Information source: RLS current product information

RatingViega ProPressRLSZoomLock MAXBrazed BCuP-5
Max pressure300 psi [26]700 psi MRP [22]700 psi [27]Annealed tube rating
BurstNot stated2,100 psi min (UL 207) [22]>2,100 psig [27]n/a
Temperature0 to 250°F [26]250°F continuous [22]-40 to 250°F [27]Up to 350°F service, per CDA [28]
SealEPDMHNBR, -40 to 300°F [22]HNBR, -40 to 284°F [27]Metal filler, no seal
Vacuum29.2 in. Hg at 68°F [26]Below 200 microns [22]200 microns [27]No rated figure
Sizes1/2 to 4 in. (hard) [26]1/4 to 2-1/8 in. [22]1/4 to 1-3/8 in. [27]No fitting size list
RefrigerantNot listedNamed compatible refrigerants; also ethylene glycolListed, incl. A2L with extra rules [27]Per the equipment maker; copper not for ammonia
ListingsASME B16.51, ICC-ES IC1002 [26]UL 207 SA#33958, ICC-ES PMG-1296 [22]UL SA7511, ICC-ES PMG-1440 [27]Follow the equipment maker and applicable refrigeration piping code
Fitting warrantyViega limited warranty15-year limited [22]15-year [29]n/a
Flame and purgeNoneNoneNoneTorch and N2 purge [28]

From Viega SM-PP 0926, the RLS catalogue, Parker Catalog K-3 and the CDA Copper Tube Handbook (A4015-26/24), read Oct 20, 2026. ProPress sizes shown are for hard drawn tube; Viega limits soft copper to 1/2 to 1-1/4 in.

RLS fittings700 psiZoomLock MAX fittings700 psiCDA: HVACR press-connect700 psigViega ProPress300 psiCDA: general press-connect200 psigRLS fittings700 psiZoomLock MAX fittings700 psiCDA: HVACR press-connect700 psigViega ProPress300 psiCDA: general press-connect200 psig
From the RLS catalogue, Parker Catalog K-3, Viega SM-PP 0926 and CDA Table 14.4b, read Oct 20, 2026.

The gap is the whole answer. The refrigerant fittings are listed to more than twice ProPress’s rating. The CDA handbook makes the same split in Table 14.4b: press-connect for high-pressure HVACR at 0 to 700 psig, and general press-connect at 0 to 200 psig. [28]

The handbook’s HVACR row covers 1/4 to 1-1/8 in. at -25 to 300°F. RLS and ZoomLock MAX publish their own wider size lists, so read the fitting maker’s document for anything past 1-1/8 in. [28]

Why a ProPress fitting can’t go on a refrigerant line

It’s a fair question, since the fittings look alike and the same tool presses both. Three things in Viega’s own data sheet rule it out.

Information source: Viega ProPress systems pocket guide

  1. 1
    Refrigerant isn’t an approved use

    Viega’s approved list runs from potable water to non-medical gases and vacuum. No refrigerant appears on it, and the application chart doesn’t add one.

  2. 2
    300 psi is the ceiling

    ProPress is rated to 300 psi operating and 600 psi test. Refrigerant press fittings are listed to 700 psi with a 2,100 psi minimum burst. [26] [22] [27]

  3. 3
    The seal is EPDM

    RLS and ZoomLock MAX use HNBR and list the oils they’re approved with: mineral, POE, PVE and PAG for RLS. Viega’s EPDM seal is specified for water and gas service.

ProPress is built for water. On a refrigerant line, the fitting has to carry a refrigerant listing, and ProPress doesn’t.

Viega’s MegaPress is a different case again: it’s for steel pipe, covered in my MegaPress vs ProPress guide. For water lines, my ProPress vs soldering guide compares press with a torch.

Which press tool takes which refrigerant jaw

The good news for plumbers: the RIDGID and Milwaukee tools you may already own can press refrigerant fittings. The catch is that each fitting system needs its own jaws.

Information source: RLS current product information

ToolRLS jawsZoomLock MAX jaws
RIDGID RP 200-B, RP 210-BRIDGID RLS compact jaws, 1/4 to 1-3/8 in. [22]ROTHENBERGER 24 kN jaws, 1/4 to 1-1/8 in. [27]
RIDGID RP 240, RP 241RIDGID RLS compact jaws, 1/4 to 1-3/8 in. [22]ROTHENBERGER 24 kN jaws, 1/4 to 1-1/8 in. [27]
RIDGID RP 330, RP 340RLS-approved jaws, 1/4 to 1-3/8 in. [22]ROTHENBERGER 32 kN jaws, 1/4 to 1-3/8 in. [27]
RIDGID RP 350RLS-approved jaws, 1/4 to 1-3/8 in. [22]ROTHENBERGER 32 kN jaws, 1/4 to 1-3/8 in. [27]
Milwaukee M12 and M18 Force LogicRLS-approved jaws, 1/4 to 1-3/8 in. [22]ROTHENBERGER 24 kN jaws to 1-1/8 in. (M12) or 32 kN to 1-3/8 in. (M18) [27]
Viega ProPress jaws on any toolNoNo

From the RLS tool and jaw compatibility matrix and Parker Catalog K-3’s tool table. Both makers allow only their approved jaws. Parker makes its 1-3/8 in. jaw in 32 kN only. Tool model names follow each maker’s chart. [22] [27]

RLS’s chart lists 1/4 to 1-3/8 in. for every RIDGID and Milwaukee tool it covers. The RLS XL fittings at 1-5/8 and 2-1/8 in. sit on its 32 kN jaw list, and the catalogue’s 32 kN tool and jaws are Klauke’s. If your lines are that big, check RLS’s current chart before you count on your own tool. [22]

My M12 vs M18 press tool guide and press tool guide cover the tools themselves.

Brazing a refrigerant line: filler, heat and nitrogen

Brazing is still the default the handbook names. The CDA says brazing is preferred, and often required, for air-conditioning and refrigeration piping. Here’s what the handbook and the filler makers ask for.

Information source: CDA Copper Tube Handbook

StepWhat the handbook or maker says
FillerBCuP-5 or another BCuP alloy on copper to copper; no flux needed (Harris, Lucas-Milhaupt) [24]
FluxOnly on brass or bronze, and brazing flux, not soldering flux (CDA, Harris)
AssembleTube hard against the fitting stop, supported so it stays aligned (CDA)
PurgeInert gas through the line while brazing; the CDA names ACR systems, and Parker calls a nitrogen purge good practice
TorchOxy-fuel with a neutral flame preferred; air-fuel sometimes used on smaller sizes (CDA)
HeatTube first, about 1 in. from the fitting, then the base of the cup, flame always moving (CDA) [28]
FeedRod where the tube enters the socket, flame off the rod, until a full fillet shows (CDA)

From the CDA Copper Tube Handbook, section 8 (brazed joints) and its HVACR guidance, and the Harris and Lucas-Milhaupt data sheets, read Oct 20, 2026.

TurboTorch tipSilver brazesSoft solders
PL-3A1/8 to 1/2 in. [23]1/4 to 1 in. [23]
PL-5A1/4 to 3/4 in. [23]3/4 to 1-1/2 in. [23]
PL-8A1/2 to 1 in. [23]1 to 2 in. [23]
PL-12A1 to 2 in. [23]2 to 4 in. [23]

From ESAB’s TurboTorch Extreme self-lighting tip chart, read Oct 20, 2026.

The purge is the step press fittings remove. The purge gas pushes oxygen out of the tube while it’s at brazing heat, so oxide doesn’t form inside, per the CDA. Press joints drop the purge, not the nitrogen. Parker says dry oxygen-free nitrogen should still be used for tightness and strength testing.

Brazing heat is also hotter than soldering by a wide margin. The CDA describes solder as a filler with a liquidus no higher than 840°F, used from about 350 to 600°F. Lucas-Milhaupt says its Sil-Fos 15, a BCuP-5 rod, flows freely at 1300°F. That’s why my plumbing torch guide and this page point to different tips. [28] [25]

Mixing press and brazed joints on one system

If one run has both kinds of joint, the heat from brazing can reach a press fitting’s O-ring. Parker publishes how far apart they have to be.

Information source: Parker current ZoomLock MAX FAQ and warranty

1-3/8 in. tube35-1/2 in.1-1/8 in. tube27-1/2 in.7/8 in. tube23-3/4 in.3/4 in. tube19-3/4 in.5/8 in. tube17-3/4 in.1/2 in. tube13-3/4 in.3/8 in. tube12 in.1/4 in. tube10 in.1-3/8 in. tube35-1/2 in.1-1/8 in. tube27-1/2 in.7/8 in. tube23-3/4 in.3/4 in. tube19-3/4 in.5/8 in. tube17-3/4 in.1/2 in. tube13-3/4 in.3/8 in. tube12 in.1/4 in. tube10 in.
Minimum distance to braze near an existing ZoomLock MAX joint, from Parker Catalog K-3, Table 2, read Oct 20, 2026.

Those distances are long because the heat travels down the copper to the O-ring. Parker says if you can’t keep the distance, braze the section first and press after, or wrap the tube in a wet rag or use a heat barrier spray, gel or putty.

The other direction is short. Parker lists 1/2 to 1-3/8 in. as the minimum gap between a new press fitting and an existing brazed joint, depending on size. The joint just has to be clean, with no brazing filler on the tube where the fitting seals. [27]

  1. 1
    Braze first, press second

    Make the brazed stubs and transitions, let them cool, then press the run. Parker lists this order as the first fix when space is tight.

  2. 2
    Keep the torch off the O-ring

    On a 3/8 in. line, Parker’s figure is 12 in. On 1-3/8 in., it’s 35-1/2 in. Wrap or block the heat when you can’t keep that. [27]

  3. 3
    Mark the insertion depth

    Parker says to mark every tube end with the insertion depth from its gauge or chart. RLS’s kits include a depth gauge for the same job.

What the codes allow for press joints on refrigerant lines

Both refrigerant press systems carry ICC-ES reports for the mechanical codes. There’s one size rule worth knowing before you plan a soft copper run.

Information source: CDA Copper Tube Handbook

RuleWhat it saysSource
Annealed tube, IMCNo mechanical joints on soft copper larger than 7/8 in. OD [27]Parker K-3, citing the IMC [27]
Annealed tube, UMCNo mechanical joints on soft copper larger than 3/4 in. nominal [27]Parker K-3, citing the UMC [27]
RLS listingsIMC, IRC and UMC 2006 to 2021; ASHRAE 15; ASME B31.5 [22]RLS catalogue
ZoomLock MAX listingsIMC, IRC and UMC 2006 to 2018 via ICC-ES PMG-1440; ASHRAE 15 [27]Parker K-3 [27]
Brazed drawn tubeUse annealed tube pressure ratingsCDA handbook
Mixed ratingsThe lowest of tube, fitting and joint governsCDA handbook

Your local code and inspector have the final say. Code editions differ by state; check which mechanical code your area uses.

The annealed rule is the one that bites on line sets. Both press systems approve soft ACR, L and K tube.

But Parker’s catalogue notes the IMC bars mechanical joints on annealed tube over 7/8 in. OD, and the UMC over 3/4 in. nominal. Above those sizes, braze the soft copper or use hard drawn tube. [27]

RLS lists soft annealed tube from 1/4 to 1-3/8 in. That’s the fitting’s approval. The code limit still applies on top of it. [22]

A2L refrigerants and flame-free joints

New systems are moving to lower-flammability refrigerants such as R-454B and R-32. That’s where the press pitch gets loudest, so here’s what the documents actually say. [27]

Information source: RLS compatible refrigerants

  1. 1
    ZoomLock MAX

    Parker’s approved list includes R-32, R-454B, R-454A, R-454C and R-1234yf, each marked with a note: A2L, A2 and A3 refrigerants may bring extra standards, local rules and codes. [27]

  2. 2
    RLS

    RLS’s current compatible-refrigerant list, checked November 15, 2026, includes R-32 and R-454B among its A2L refrigerants. RLS says to check local codes and to contact it about blends it doesn’t list. Equipment, code and approved-jaw limits still apply. [30]

  3. 3
    Brazing

    Brazing is open flame. RLS describes pressing as flame-free, avoiding the torch-related hot work and fire-watch requirements; I still check the site rules. On A2L equipment, follow the equipment maker’s service instructions for either method. [22]

Neither press system is approved for CO2 or ammonia in these documents. Parker says ZoomLock MAX isn’t suitable for R-717, R-723, R-764 or R-744, and RLS doesn’t list them. The CDA handbook adds that copper isn’t recommended with ammonia at all. [27] [28]

If you work on a mix of systems, the refrigerant list decides more than the tool does. Check it against the equipment’s nameplate before you pick a fitting.

Where brazing still wins, and where press does

Refrigerant press joints avoid a brazing purge and open flame; site permits and work rules still apply. Brazing keeps a few jobs the press systems can’t take, by their own documents.

Information source: RLS current product information

JobBetter choiceWhy
Line set in an occupied buildingPressNo flame at the joint, per RLS; confirm site permit and fire-watch rules
Soft copper over 7/8 in. ODBrazeIMC bars mechanical joints, per Parker’s note
Lines over 1-3/8 in.Braze or RLS XLZoomLock MAX stops at 1-3/8 in.; RLS XL needs 32 kN jaws [22] [27]
Copper to brass valve bodyBrazeBCuP-5 with flux; press fittings are copper to copper [24]
Refrigerant not on the press listBraze, if allowedPress makers approve refrigerants by name; the equipment maker and code decide the rest
Many joints, tight schedulePressAbout 10 seconds a joint and no purge, per RLS [22]

Cost per joint isn’t in any of these documents, so I do not guess at it here. What the makers do publish is the gear list. Press needs a tool, a jaw per size and the fittings. Brazing needs a torch, a tank, filler, a nitrogen cylinder and regulator, and the time to purge.

For deburring and cutting before either joint, see my copper deburring tool guide and pipe cutter guide. RLS says to prep tube ends the same way you would for brazing.

Find your joining method

Choose the service and check the approvals first.

This finder cannot replace an equipment inspection, a test or an in-person check. I have a qualified refrigeration professional confirm unknown refrigerants, code requirements and tube sizes before work.

How to choose in five questions

QuestionIf yesIf no
Is it a refrigerant line?Go to the next questionWater or glycol: ProPress or solder, see my water guides
Is the refrigerant on the press fitting’s list?Go to the next questionBraze, if the equipment maker and code allow it
Is the tube soft copper over 7/8 in. OD?Braze it, or switch to hard drawnGo to the next question
Is your press tool on RLS’s or Parker’s chart?Add that system’s jaws, in the sizes its chart listsBraze, or buy into one press system
Is the line over 1-3/8 in.?Braze, or check RLS XL and its 32 kN jaws [22]Press with the jaw for that size

Then pick one press system and stay with it. RLS jaws don’t press ZoomLock MAX fittings, and the reverse is true too. Each maker approves specific tools and jaws for its fittings.

If you braze, size the torch tip to your biggest line, purge with nitrogen while you braze, and use BCuP-5 without flux on copper. My NIBCO Press vs Viega ProPress guide and RIDGID ProPress jaw guide cover the water side. [28] [24]

Questions people ask

Can you use ProPress on refrigerant lines?

No. Viega’s ProPress data sheet lists water, glycol, low-pressure steam (15 psi, with an FKM seal swap), compressed air, non-medical gases and vacuum, and no refrigerant. Its system maximum is 300 psi. For refrigerant, use a press system listed for it, such as RLS or ZoomLock MAX, rated to 700 psi. [26] [22] [27]

Can you press an HVAC line set?

Yes, with refrigerant press fittings and their approved jaws. RLS and ZoomLock MAX are listed by their makers to UL 207 and rated to 700 psi and approved for R-410A. Check the refrigerant list, and note the IMC bars mechanical joints on soft copper over 7/8 in. OD. [27] [22]

What are the downsides of press fittings?

Each system needs its own approved jaws, the refrigerant must be on the maker’s list, and sizes stop at 1-3/8 in. for ZoomLock MAX and 2-1/8 in. for RLS. Brazing near a pressed joint also needs distance or a heat barrier to protect the O-ring. [22] [27]

Can you braze ProPress fittings?

No, a ProPress fitting is joined by pressing, and its EPDM seal is part of the joint. Brazing near any press fitting is a separate question with maker-specific answers. Parker, for its ZoomLock MAX refrigerant fittings, gives minimum distances from 10 in. on 1/4 in. tube to 35-1/2 in. on 1-3/8 in. For ProPress, follow Viega’s instructions. [27] [26]

What brazing rod is used for refrigerant lines?

BCuP-5, a phosphorus-copper rod with about 15 percent silver, such as Harris Stay-Silv 15 or Lucas-Milhaupt Sil-Fos 15. Both makers say it needs no flux on copper. Use flux on brass, and don’t use it on steel. [24] [25]

Why do plumbers solder instead of braze?

They’re different joints for different jobs. The CDA handbook describes soldering at about 350 to 600°F, and says brazing is preferred, and often required, for joints in air-conditioning and refrigeration piping. [28]

Do you need to purge with nitrogen when brazing?

Yes, on refrigerant lines. The CDA handbook lists ACR systems among those that need an inert gas purge during brazing, so oxide doesn’t form inside the tube. Parker calls a nitrogen purge during any brazing good installation practice. Follow your brazing procedure for flow rate.

Is RLS the same as ZoomLock?

No. They’re separate refrigerant press systems with their own jaws. Both are rated to 700 psi with HNBR O-rings. RLS goes to 2-1/8 in. with a 15-year limited warranty; ZoomLock MAX goes to 1-3/8 in. with a 15-year warranty. [22] [27] [29]

Can my RIDGID ProPress tool press RLS fittings?

Often, yes, with RLS jaws. RLS’s chart lists RIDGID’s RP 200, 210, 240, 241, 330, 340, 350 and 351 for 1/4 to 1-3/8 in. Your ProPress jaws can’t be used on RLS fittings. [22]

Are press fittings approved for R-454B?

ZoomLock MAX lists R-454B and R-32 with a note that A2L refrigerants may bring extra rules. RLS’s current list, checked November 15, 2026, also includes both, with a note to check local codes. Equipment, code and approved-jaw limits still apply. [27] [30]

How I picked them

Why I choose by application

I am Isaac Daniels, a licensed journeyman plumber in Georgia. I match the joint to its service, tool and fitting instructions. Every rating here comes from the makers’ documents and the Copper Tube Handbook.

How I pick

  • Press picks are jaws for a refrigerant-listed fitting system that fit tools plumbers already own.
  • Brazing picks match the filler the handbook and makers name for copper refrigerant lines, and torch tips sized to the 3/8, 3/4 and 7/8 in. line examples on this page.
  • The two linked RIDGID jaw offers are sold by Amazon.com.
  • Left out: nearly sold-out listings, Viega ProPress fittings (not listed for refrigerant), and “RLS-compatible” jaws that RLS doesn’t approve.
  • The jaws, torch kits and brazing alloys are listed as one kit with no shared rating, because each does a different job. I compare published ratings directly.
  • I checked the CPSC recall records on November 15, 2026 for RIDGID, TurboTorch, Harris, Lucas-Milhaupt, RLS and ZoomLock. No matching recall for these jaw, torch or filler models appeared in that search.

Sources

Related guides
