Air chamber vs water hammer arrestor

Identify the device. Match the connection.

Sioux Chief 660-HB washer hose-thread arrestor
Sioux Chief 660-HB washer hose-thread arrestor. Product photo: Amazon.

The short answer

An air chamber is capped pipe with air touching water. A mechanical arrestor keeps them apart. Choose the 660-HB for washer hose threads, GTR1B for compression stops or Watts LF15M2-B for a ¾-inch pipe tee. An unidentified stub needs inspection before replacement.

Best for washer hose threads → Sioux Chief 660-HB

Best for ⅜-inch compression stops → Sioux Chief 660-GTR1B

Best for a ¾-inch threaded branch line → Watts LF15M2-B

$52.00 Price as of Nov 18, 2026, 1:30 AM EST

Check it on Amazon

As an Amazon Associate I earn from qualifying purchases. Disclosure.

Match the connection first

For new shock protection, choose a correctly sized, listed arrestor. These three cover different connections; none of them identifies a hidden capped pipe.

Air chamberDirect contactAir cushionWater sideSchematic • not to scale
A traditional capped pipe has no separator. Water can occupy the space that held its cushioning air. Concept from Oatey’s banging-pipes explanation; original schematic.

The two devices work differently

Traditional capped-pipe air chamber

Oatey describes a traditional air chamber as capped vertical pipe near an outlet. Air touches water without a piston or diaphragm, so the pipe can waterlog and lose its cushion. Draining may restore air, but cannot identify the device or guarantee a fix. An unmarked homemade stub has no listed capacity or maker-established recharge interval.

Have uncertain or concealed capped pipework inspected before changing it. No new capped-pipe build is recommended here. Have a plumber assess the old stub and the new device’s placement.

For new ASSE 1010 protection, see the Sioux Chief 660-HB for ¾-inch washer hose threads or Sioux Chief 660-GTR1B for ⅜-inch OD compression stops. Both are AA point-of-use models. For a branch that serves several fixtures, the Watts LF15M2-B threads into a ¾-inch pipe tee and is sized B for 12 to 32 fixture units; check the capacity guide and adopted code before choosing.

Piston arrestorSealed pistonAir cushionWater sideSchematic • not to scale
A piston keeps the water and gas cushion apart in the Sioux Chief models below. Other engineered designs use a diaphragm. Original schematic, not a service drawing.

Best for washer hose threads

Sioux Chief 660-HB washer tee

Sioux Chief 660-HB stainless chamber on a washer hose-thread tee
Product photo: Amazon

Sioux Chief 660-HB 660-HB Water Hammer Hose Arrestor, 3/4-Inch (Two Pack) (‎660-HB-2)

$52.00 Price as of Nov 18, 2026, 1:30 AM EST

Check it on Amazon
10Spec scoreHow it’s scored
Working pressure10
Temperature limit10
Retrofit route10
ASSE 1010 listing10

Pros

  • ¾-inch female and male hose-thread tee
  • AA-size ASSE 1010 certification stated by maker
  • Piston separates air and water
  • Two-pack listing covers hot and cold

Cons

  • Washer hose connections only
  • Check clearance in a recessed washer box
  • Does not regulate house pressure
Model 660-HB¾-inch hose threads5-inch overall height250 PSIG maximum250°F maximum304 stainless body

Buy it if

Your washer has compatible hose-thread supplies and the noise coincides with its fill valve closing. Check both supplies and clearance.

Skip it if

The connection is a compression stop, ballcock shank or branch pipe. A similar-looking tee with hose threads will not match it.

The 660-HB is a practical replacement route when the troublesome valve belongs to a washing machine. Its female and male hose-thread connections match that job. It does not replace a capped copper stub at the same joint; it gives you a separate, maker-documented point-of-use installation at compatible washer supplies.

The important difference from an air chamber is inside the stainless body. Sioux Chief specifies a polypropylene piston with two EPDM O-rings. That separator keeps the water apart from the air cushion. Whole-house draining is therefore not the model’s equivalent of replenishing an open-contact capped pipe.

The 660-HB sheet calls for arrestors on both the hot and cold washer inlets. This Amazon record is a two-pack, which fits that arrangement. Verify the listing quantity before ordering, because another offer for a single 660-HB does not become a pair just because the product photograph looks the same.

Check the laundry box before adding the tees. Sioux Chief gives an overall height of 5 inches. Leave room for the existing hoses to connect without forcing the machine against them. A correct thread size does not establish that a recessed box or a tight space behind the washer has enough clearance.

The published limits are 250 PSIG working pressure and 250°F. Those are component maximums, not recommended household settings. A high-pressure supply still needs its own diagnosis. The sheet states AA-size certification to ANSI/ASSE 1010-2004; check that printed edition against the applicable local requirement.

Choose the 660-HB for a confirmed washer hose connection, then follow the exact installation instructions. Close the serving supplies before disconnecting hoses and stop if a valve will not isolate the water. Pipe changes, inaccessible valves or leakage near electrical equipment belong to a qualified plumber before the washer is returned to service.

Best for ⅜-inch compression stops

Sioux Chief 660-GTR1B stop tee

Sioux Chief 660-GTR1B with female and male compression tee connections
Product photo: Amazon

Sioux Chief 660-GTR1B Mini Hammer Rester

$13.99 Price as of Nov 18, 2026, 1:30 AM EST

Check it on Amazon
10Spec scoreHow it’s scored
Working pressure10
Temperature limit10
Retrofit route10
ASSE 1010 listing10

Pros

  • Fits ⅜-inch OD compression connections
  • AA-size piston design
  • 4-inch height and 2-inch trunk width
  • Maker specifies supply-stop installation

Cons

  • Does not fit washer hose threads
  • Read the GTR model suffix carefully
  • An old leaking stop needs repair first
Model 660-GTR1B⅜-inch OD compression4-inch overall height2-inch trunk width250 PSIG maximum250°F maximum

Buy it if

The supply stop and line really use ⅜-inch OD compression, and you have enough room for the tee and chamber.

Skip it if

You are matching the toilet tank inlet instead of the stop outlet. That is the ballcock-connection route, which uses a different model.

The 660-GTR1B addresses a different joint from the washer model. It connects at a supply stop with a matching compression outlet. A toilet can have a compression connection at the wall and a ballcock connection at the tank. Decide which end you are working on before choosing the arrestor.

Sioux Chief’s GTR sheet identifies this version as the ⅜-inch OD model. The neighboring GTR0B and GTRB entries have different connection sizes. Copy the whole model number from the package and compare it with the maker’s item table. The word MiniRester by itself does not settle which threads are present.

The sheet gives a 4-inch overall height and a 2-inch trunk width for the ⅜-inch model. Under a vanity, check those dimensions against the cabinet and the supply-line route. Behind a toilet, check the clearance around the stop rather than assume a part that fits under a sink will clear the tank.

Like the washer model, the GTR uses a polypropylene piston with two EPDM O-rings inside a stainless body. Sioux Chief publishes maximums of 250 PSIG and 250°F for this family. Do not borrow the higher pressure figure from a different GT-family sheet merely because the model names look related.

The GTR sheet lists AA-size certification to ANSI/ASSE 1010-2004 and specifies installation at supply stops, on the applicable hot and cold lines. That is useful evidence for selecting the connection, but it is not a guarantee that every bang under the sink comes from hydraulic shock or that the existing stop is fit to disturb.

Use the GTR1B when the measured connection and the shutoff condition both support a stop-mounted retrofit. Close the serving valve and verify isolation before opening the joint. If the stem leaks, the valve will not shut or the pipe turns when you try to hold the fitting, stop and have a plumber repair the supply first.

Best for a ¾-inch threaded branch line

Watts LF15M2-B ¾-inch threaded arrestor

Watts LF15M2-B copper water hammer arrestor with its PDI label and brass male thread adapter
Product photo: Amazon

Watts LF15M2-B ¾-inch MNPT water hammer arrestor

$77.85 Price as of Nov 18, 2026, 1:30 AM EST

Check it on Amazon
8.3Spec scoreHow it’s scored
Working pressure8
Temperature limit8
Retrofit route7
ASSE 1010 listing10

Pros

  • Threads into a standard ¾-inch pipe tee
  • PDI size B: 12 to 32 fixture units
  • Sealed piston, no access panel needed
  • ASSE 1010 and PDI WH201 listed

Cons

  • The tee has to be cut into the line
  • 150 psi and 180°F, under the Sioux Chief tees
  • Watts calls for a PRV above 60 psi
  • Not rechargeable in the field
Model LF15M2-B¾-inch NPT malePDI size B150 psi working33–180°F0.9 lb

Buy it if

The supply line is open or a plumber is already working on it, and the branch needs a size B arrestor on a ¾-inch tee.

Skip it if

You want a fix with no pipe cut. The 660-HB threads onto washer hoses and the 660-GTR1B onto a supply stop.

The LF15M2-B is Watts’ ¾-inch threaded arrestor, unit size B in the PDI sizing table. Unlike the two Sioux Chief tees, it doesn’t thread onto a washer hose or a supply stop. It goes on a standard pipe tee in the supply line, so it’s the route when the wall is open or the branch is being repiped.

Inside, a polypropylene piston with an EPDM O-ring keeps the water away from a factory air charge of 60 psi, sealed for good. Watts says the piston is the only moving part, and its instructions say the unit isn’t rechargeable in the field. That’s the opposite of a capped air chamber, which you drain to get the air back.

Size it from the fixture units, not the pipe size. Watts’ table puts size B at 12 to 32 fixture units, against 1 to 11 for the ½-inch size A. On a branch up to 20 ft long, Watts places it at the end of the line between the last two fixtures. Past 20 ft, its sheet adds a second unit.

The limits are lower than the Sioux Chief tees: 150 psi working pressure and 33 to 180°F, against 250 PSIG and 250°F. Watts’ installation sheet also says a system over 60 psi shall have a pressure reducing valve upstream of the unit. Check your static pressure first; the pressure section below shows how.

The body is copper and the threaded adapter is lead-free brass. Threaded size B measures 1⅜ by 8 9/16 in. and weighs 0.9 lb, per Watts. It’s listed to ASSE 1010, ANSI A112.26.1M and PDI WH201, and Watts says it can sit in a concealed space with no access panel, at any angle. The warranty is one year from shipment.

Watts asks for one on both the hot and cold lines, as close to the shock source as you can get. If the line is copper and you’d rather sweat it in, Watts makes the same unit as the LF15M2-BS with a solder end.

My call: when the branch is open, this is the threaded arrestor I’d put on it. It was new and in stock at my check on Oct 22, 2026, 2:53 AM EDT, with only a few left from small sellers, so check the seller and quantity before you order.

Air chamber vs arrestor at a glance

The arrestor has the stronger documented route for new protection. The right choice among arrestors still depends on connection, load and placement.

CheckCapped air chamberMechanical arrestorAhead
Air meets waterDirect contactSeparated by piston, diaphragm or another engineered barrierArrestor
WaterloggingCan lose its air spaceSeparator protects the gas cushion from direct contactArrestor
New code-required protectionDo not presume a homemade stub meets ASSE 1010Select a conforming, correctly sized modelListed arrestor
IdentityTrace exposed pipework and purposeRead model and confirm maker sheetLabeled device
ChargingDraining may restore air; no guaranteed intervalDepends on model; LF05 sealed, LF150A rechargeableModel-specific
House pressure controlDoes not set static pressureDoes not replace a PRVEven
Concealed unknown deviceInspection neededInspection neededEven
Retrofit routeSpec scoreConnection and classStrength / limitOffer
Sioux Chief 660-HB washer teeSioux Chief 660-HB10¾-inch hose thread; AABest for washer hose threads. Both supplies / check box clearanceCheck it on Amazon
Sioux Chief 660-GTR1B stop teeSioux Chief 660-GTR1B10⅜-inch OD compression; AABest for compression stops. Supply stop / not the toilet tank threadCheck it on Amazon
Watts LF15M2-B threaded arrestorWatts LF15M2-B8.3¾-inch NPT male on a pipe tee; PDI BBest for a threaded branch line. Size B, 12–32 fixture units / 150 psi, PRV above 60 psiCheck it on Amazon

A cap is an end closure, not an arrestor certification. The 2024 IPC, section 604.9, calls for water-hammer arrestors where quick-closing valves are used and requires conformity to ASSE 1010. Your adopted code and amendments determine the requirement at your property; a model-code excerpt is not a local inspection decision.

An existing chamber also does not tell you whether the house needs a pressure regulator. Shock at the instant a valve closes and excessive static pressure are different checks. Correcting one can leave the other unresolved. Keep your observations tied to the actual valve and operating event.

Identify it, then choose the connection

Read across from visible evidence to a documented model. If you cannot establish the device, use the unknown row instead of guessing from the age of the house.

EvidenceDeviceSeparationConnectionService ruleNext actionSource
Plain capped vertical pipePossible traditional chamberNone if confirmedExisting pipeworkCan waterlogTrace purpose; inspect if uncertainOatey blog
Label 660-HBMiniResterPiston¾-in. hoseUse exact model instructionsCheck both washer supplies660-HB p.1
Label 660-GTR1BMiniResterPiston⅜-in. OD comp.Use exact model instructionsMatch stop and lineGTR p.1
Label 660-TKBMiniResterPistonBallcock teeUse GT instructionsConfirm toilet tank inletGT p.1
Mark 653-BHydraResterPiston¾-in. MIPSize and place by makerHave branch load assessed650 p.1
Label LF150AWatts diaphragm arrestorDiaphragm½-in. NPTRechargeable per IS-150AQualified model-specific serviceIS-150A pp.1–2
Unreadable or hiddenUnknownUnknownUnknownUnknownStop and obtain inspectionEditorial boundary

Start with the part you can actually see. A washer tee marked 660-HB gives you a model to look up. An unmarked copper cylinder gives you less evidence. A capped vertical pipe gives you a construction clue, but not permission to assume its original purpose or remove its cap.

Photograph the label, the full connection and the surrounding pipework before shopping. A close-up of the cylinder alone can hide the joint that matters. For a toilet, include both the stop and tank connection so the plumber can distinguish a compression-outlet retrofit from a ballcock-tee retrofit.

House age does not substitute for those observations. Older houses can have later repairs, and a newer appliance can connect to older pipework. A noise that improves after draining is an operating observation. It is not evidence of a piston, diaphragm, model number or certification inside a wall.

Why an air chamber stops cushioning

An air space works only while there is air available to compress. A plain capped stub has no separator to preserve that arrangement.

Inside the stubWhat changesWhat you can conclude
Air above waterAir can compress during a pressure eventThis describes the principle, not a measured capacity
Water occupies the former air spaceThe original gas cushion is reduced or lostWaterlogging can explain loss of cushioning
Noise improves after a refillAn operating condition changedYou still have not identified the installed device
Noise does not improveThe attempted step did not resolve the symptomInvestigate other causes, sizing and placement

Oatey’s explanation distinguishes the capped-pipe arrangement from a sealed piston device. The practical maintenance question is whether the water and the cushioning air are allowed to share the same space. Do not apply the chamber’s refill idea to every metal fitting sold as an arrestor.

For an actual old air chamber, a plumber may consider draining as part of an assessment. No fixed recharge interval is established for that unknown stub, and this page does not prescribe a whole-house procedure. A water heater, recirculation arrangement or a supply that does not isolate changes what a safe shutdown involves.

If work could drain a water heater, follow that heater’s shutdown and refill instructions. For an electric tank, power must be off before draining, and the tank must be completely filled before power returns. Have a qualified professional handle uncertain heater isolation, hot-water exposure or electrical equipment.

Can a water hammer arrestor be recharged?

Sometimes. The model decides: Watts documents both a sealed piston family and a rechargeable diaphragm model.

DeviceMaker’s constructionRecharge adviceWhat not to do
Traditional chamberAir and water share capped pipeMay regain air through a suitable draining procedurePromise a fixed service interval
Watts LF05Factory-charged sealed pistonMaker says not rechargeableDrill, open or add a charging valve
Watts LF150ADiaphragm with charging valve under capFollow IS-150A for this exact modelTransfer its procedure to LF05 or MiniRester
Unidentified arrestorNot establishedIdentify model before serviceGuess charge pressure from house pressure

The LF05 specification explicitly describes factory-charged, sealed construction. The LF150A instructions show a diaphragm and a charging valve. Both are called water hammer arrestors, so a blanket statement that every arrestor is sealed for life would give the wrong service advice to at least one documented design.

A charging valve does not make the LF150A an interchangeable expansion tank, and the example here is not a purchase recommendation. Its selection table and instructions apply to its own application. A plumber must establish suitability, code acceptance and the exact service procedure before using it as a replacement.

Watts’ LF150A instructions distinguish system flow pressure when describing charging. Do not charge an arrestor to a static gauge reading unless its instructions call for it. Have a plumber confirm the model, operating conditions and maker’s safety instructions before charging.

Hose, compression and pipe threads differ

Nominal size alone does not identify a connection. Start with the joint, then confirm the entire model number.

Where you connectConnection to establishDocumented exampleCommon wrong turn
Washer hose valve¾-inch hose thread660-HBAssuming ¾-inch MIP is the same
Small supply-stop outlet⅜-inch OD compression660-GTR1BReading the size of the pipe in the wall
Toilet fill-valve shankBallcock thread660-TKBOrdering a washer tee for the tank
Threaded branch fitting¾-inch MIP653-BOrdering a sweat or PEX suffix
¾-inch branch pipe tee¾-inch NPT maleWatts LF15M2-BOrdering the solder LF15M2-BS
Sweat branch connectionMaker’s sweat fitting653-BSCalling the plain 653-B a sweat model
F1807 PEX connectionMaker’s crimp connection653-BXTreating X as packaging only

The GTR1B dimension is an outside-diameter compression designation. It does not describe the copper pipe coming through the wall or the tank inlet at the other end of a toilet connector. Match the nut and mating fitting at the actual installation point. Avoid using adapters to rescue an order based on the wrong end.

The 653-B suffix matters during a larger repair. Sioux Chief’s 650-series table lists the B as MIP, BS as male sweat and BX as F1807 PEX. Those letters change the connection. A listing for the 653-BX does not fit a job requiring the threaded 653-B.

A fitting that starts to turn onto another thread has not proved a safe match. Use the maker’s connection method, seals and tightening directions for the selected part. If the existing stop leaks or cannot hold against the connection work, have the stop repaired before installing an arrestor.

Sioux Chief 660-HB arrestor held in a hand, showing its female hose swivel and male hose thread
The 660-HB has a female hose swivel on one side and a male hose thread on the other, so it sits between the washer valve and the hose. Listing photo: Amazon.

Choose capacity separately from thread size

AA is a capacity class in the point-of-use guidance. A ¾-inch thread is a connection. They answer different questions.

ApplicationMaker’s sizing routeWhere to start
Applicable single fixturePoint-of-use AA on hot and coldSioux Chief residential sizing column
Multi-fixture branchTotal fixture units on each hot/cold branchMaker’s commercial sizing column
HydraRester size BPublished range 12–32 fixture units; 7 in³650-series capacity table; ¾-inch connection
Unknown capped stubNo documented listed class establishedInspect and design replacement protection

A washer tee and a branch arrestor can both have a ¾-inch connection while serving different loads. The Sioux Chief sizing guideline separates point-of-use AA arrestors from the A through F branch classes. Choosing whichever cylinder is longer does not replace a fixture-unit calculation.

In a multi-fixture arrangement, the maker sizes each hot and cold branch from the fixture units it serves. The guide places the arrestor at the end of the branch. A single small arrestor beside the incoming main should not be assumed to protect every remote quick-closing valve in the building.

The 653-B is included as an identification example, not a general upgrade from the washer tee. Branch sizing belongs to the plumber who can see the layout and apply the maker’s guidance. My arrestor buying guide covers a broader set of connection choices without changing this page’s focus on identifying the device.

Put it near the valve that closes

Location is part of the maker’s instructions. The rules for a fixture tee and a multi-fixture branch should not be swapped.

Maker guidancePlacementRead it this way
660-HB sheetBoth hot and cold washer supply inletsCheck both sides, not just the loudest hose
GTR sheetOn applicable hot and cold supply stopsUse the matching compression connection
GT sheetWithin 6 feet of culprit valve or faucetThis figure belongs to that family
Watts LF05 sheetAs close as possible to shock sourceAny orientation does not mean any location
Sioux Chief branch guidelineAt end of each sized branchFollow the branch design, not fixture-tee guesswork

Horizontal installation is permitted for some engineered arrestors, but the permission comes from the specific model document. Watts says its LF05 can be vertical, horizontal or angled; Sioux Chief’s 650-series sheet permits any angle. Those statements do not describe a traditional open-contact air chamber.

An arrestor tucked far away because it fits neatly may not follow the maker’s placement rule. First locate the valve that stops the flow. Then establish the connection and a permitted mounting position. If getting close requires opening a wall or changing pipework, have a plumber plan the installation.

Check pressure without confusing it with shock

A component maximum is a survival limit within its specified use. It is not a household pressure target.

Number or eventWhat it meansNext question
Over 80 psi static2024 IPC 604.8 calls for pressure reduction, with a stated exceptionWhich code and amendments apply here?
250 PSIG on HB or GTRThat family’s maximum working pressureIs the house pressure separately controlled?
350 psig on 650 seriesThat family’s maximum, with connection-material qualificationsIs this the exact model and connection?
Bang at fast valve closureConsistent with a water-hammer eventAre placement, capacity and supports correct?
Pressure rises during heater operationThermal-expansion investigation may be neededDoes the closed system have proper expansion control?

Measure static pressure with the water outlets closed; that is a different condition from a pressure reading while a faucet runs. Record the gauge location and whether the heater was operating. Use a gauge suitable for the connection, following its instructions, or have a plumber make the measurement if safe access is uncertain.

The 2024 IPC sets its pressure-reduction threshold at more than 80 psi static and requires reduction to no greater than 80 psi, subject to the section’s exception. An arrestor rated above that figure does not cancel the regulator rule. Confirm the edition and amendments adopted locally before applying that threshold.

A pressure reducing valve controls supply pressure; an arrestor addresses the shock from a sudden flow stop. A closed water-heater system can also need thermal-expansion control under IPC 607.3. Correctly selecting one device does not establish that the other jobs have been handled.

For readings that change overnight, use my overnight pressure investigation. For the gauge itself, see home water-pressure gauges. Keep a record of when the noise occurs so a plumber can compare the pressure behavior with the appliance cycle.

Keep, replace or call a plumber

Confirmed accessible washer connection

Consider the 660-HB when its hose threads and clearance match. Close both supplies before disconnection; stop if either valve fails to isolate.

Confirmed compression stop

Consider the GTR1B for the documented ⅜-inch OD joint. Verify the existing stop and line are sound before adding the tee.

A readable device without a symptom

Read its instructions and inspect accessible connections. An old installation date alone does not establish failure or justify a guessed replacement interval.

A hidden or unmarked stub

Obtain inspection. Do not use the house’s age or a drain-and-refill result to identify what is concealed.

Leak, failed isolation or electrical exposure

Stop the retrofit. Have a plumber secure the water supply; electrical hazards need a qualified electrician before work continues.

Cutting, heater draining or uncertain hot water

Use a qualified professional and the equipment’s shutdown instructions. This comparison is not a soldering, charging or water-heater draining procedure.

What a safe fixture retrofit involves

Oatey’s accessible-fixture guide starts by closing the serving valve. The exact fitting’s instructions govern the connection work.

  1. Confirm the joint

    Identify the valve causing the event, read the arrestor model and compare the connection and space with the maker’s sheet. A washer hose thread and a toilet ballcock thread are different jobs.

  2. Isolate the water

    Close the serving supply before opening the line. Verify isolation and allow hot components to cool. Stop if water keeps flowing, a valve leaks or safe access is uncertain.

  3. Follow the fitting instructions

    Catch residual water in a bucket, protect the surrounding area and use the specified connection method. Do not transfer generic thread-sealant or tightening advice between hose, compression and pipe-thread fittings.

  4. Restore and inspect

    Reconnect as directed, restore the supply and inspect every disturbed joint for leaks. Operate the fixture and note whether the original closure event still produces the bang.

  5. Stop on an unresolved fault

    A leaking joint, turning pipe or noise that persists needs diagnosis. Have a plumber check placement, sizing, pressure and support rather than add another unmatched arrestor.

Record after the workUseful observationAvoid concluding
Exact device and locationModel on each hot/cold connectionAny cylinder is the same type
Leak inspectionWhich joints were disturbed and remained drySilence proves the joints are safe
Repeat the same appliance eventNoise at washer fill closure, toilet refill or another valveA quieter house proves an air chamber was recharged
Pressure conditionGauge location, static or flowing, heater cycleComponent maximum equals allowed house pressure

If the fitting is dry but the original bang remains, compare the same operating event before buying another part. Oatey’s guide names incorrect placement and loose pipes as possible reasons noise persists. A repeated clunk elsewhere in the house is a reason to investigate, not proof the new arrestor is defective.

Check the supply hose route after a washer retrofit as well. A new tee can change the space available behind the machine. Do not return the machine to a position that strains its connections. My washer hose guide covers hose fit; the banging-pipe diagnosis guide addresses competing noise causes.

Read the whole model, not the search result

Model or claimMaker evidenceWhat to choose
653-B versus 653-BS650-series table: B = MIP; BS = sweat653-B for MIP; 653-BS for sweat
Search result: SIOUX 653-BX650-series table: BX = F1807 PEXNot a threaded 653-B replacement
LF05H search returns LF15M2-BES-LF05 names LF05H as washer hose teeNo LF05H purchase link from a different model; the LF15M2-B is linked only as itself, from its own ES-LF15M2 sheet
HB single and two-pack results660-HB sheet describes the individual device; offer determines packUse exact verified two-pack ASIN
All arrestors never need rechargingIS-150A shows a diaphragm and charging valveKeep service advice model-specific
Current standard means current product editionHB and GTR sheets print 1010-2004Retain the printed certification edition

For the 660-HB and GTR1B, compare the complete model and connection with the maker’s sheet before ordering. Use that sheet for dimensions, working limits and placement. A matching brand name alone does not establish that a listing has the hose or compression fitting your job needs.

A 653-BX or LF15M2-B listing is a different model from the 653-B or LF05H. Do not transfer specifications between them. If a manufacturer changes a model, check the new document and the label together before carrying over any dimensions or approvals.

Questions people ask

What are the capped pipes above my water supply?

They may be traditional air chambers if the exposed pipework confirms that purpose. Oatey describes an air chamber as capped vertical pipe near an outlet. A cap alone cannot establish whether a line is an air chamber, an abandoned branch or something else. Have uncertain pipework inspected instead of opening it.

Is an air chamber the same as a water hammer arrestor?

In this comparison, air chamber means a traditional capped pipe with air directly touching water. A mechanical arrestor separates its gas cushion from water with a piston, diaphragm or another engineered barrier. Product language can use the words air chamber for the gas space inside an engineered device, so read the model document.

Will draining the house recharge an air chamber?

It can restore air in a suitable traditional chamber, but it is not guaranteed to resolve the noise or identify the device. Do not start a whole-house drain without accounting for the water heater and the equipment’s shutdown instructions. Have a professional assess an uncertain system.

Why did draining fail to stop the banging?

The device may not be a traditional air chamber, or the noise may involve placement, sizing, pressure or loose pipework. A failed drain-and-refill attempt cannot distinguish those possibilities. Record which valve triggers the noise and have the cause checked before choosing another part.

Can a sealed water hammer arrestor fail?

Yes, a sealed design is not a promise of unlimited service life. Oatey recommends replacement when an arrestor shows damage or leaks. Persistent noise alone does not establish failure; inspect the connection, placement and pipe support as well. No guaranteed lifespan is assigned here.

Can a water hammer arrestor be recharged?

The model decides. Watts says its LF05 family is sealed and not rechargeable, while its LF150A has a diaphragm and charging valve. Follow the exact model’s instructions. Never drill or open a sealed device, or apply LF150A charging advice to an unidentified arrestor.

Can an arrestor be installed horizontally?

Some can. Watts permits LF05 installation vertically, horizontally or at an angle; Sioux Chief permits any angle for the 650 series. Check the exact model and its placement guidance. Any-angle permission does not mean an arrestor can be placed anywhere in the house.

Does a washing machine need arrestors on both supplies?

Sioux Chief’s 660-HB specification calls for arrestors on both the hot and cold washer supply inlets. Its point-of-use sizing guide also identifies the applicable hot and cold lines. Check your actual appliance connections and the adopted local requirement rather than assume the cold line is the only one that matters.

Does a toilet use a different connection from a washer?

Yes. A washer tee such as the 660-HB uses hose threads. The 660-GTR1B fits a ⅜-inch OD compression supply-stop joint, while the 660-TKB is the ballcock-tee version for a compatible toilet tank connection. Choose the end of the toilet supply you intend to work on before ordering.

Why do pipes still bang after installing an arrestor?

Oatey identifies loose pipes and incorrect placement as possible causes. Also check that the model and capacity match the application and that house pressure is properly controlled. An arrestor cannot replace a pressure regulator or thermal-expansion control. Stop on leaks and have unresolved noise diagnosed.

How I choose and check the facts

Why trust this page

Isaac Daniels is PlumbingPicks’ responsible editor and a licensed journeyman plumber in Georgia. In my 7 years of experience, these are the products I’d install. I use the makers’ connection tables and service instructions to distinguish capped pipes from engineered arrestors. The credential does not turn an unidentified device in your home into a confirmed model.

How I pick

I use the Sioux Chief sheets for the HB, GTR, GT and 650 families and the Watts LF05 and LF150A documents. For the Watts LF15M2-B I use its own ES-LF15M2 sheet and IS-15M2 instructions. Amazon records dated October 20 and Oct 22, 2026, 2:53 AM EDT identify the three linked offers. I compare connection fit, construction and published limits.

The three arrestors share one spec score, set out below, built from published ratings and how each one connects. It isn’t a measured shock test, and none of the makers publishes a common one.

These recommendations come from documented construction and connection fit. The diagrams explain the mechanism; they are not measurements, product cutaways or instructions to open a device. A local plumber must resolve uncertain identification and code acceptance.

The spec score, check by check

The three arrestors get the same four checks, read from Sioux Chief’s 660-HB and 660-GT sheets and Watts’ ES-LF15M2 sheet and IS-15M2 instructions, then averaged to one decimal. Every pick has to reach 7.0.

Capacity isn’t in the score. AA and size B answer different loads, and the fixtures on the line pick the size first. A higher score doesn’t mean better shock control; no maker publishes a common shock test.

Check (weight)How it’s scored
Working pressure (¼)10 = 250 psi or more maximum working pressure on the maker’s sheet; 8 = 150 psi
Temperature limit (¼)10 = 250°F or more maximum temperature on the maker’s sheet; 8 = 180°F
Retrofit route (¼)10 = threads onto a connection that’s already there (washer hose or supply stop); 7 = needs a tee cut into the pipe
ASSE 1010 listing (¼)10 = the maker’s sheet states ASSE 1010; 0 = it doesn’t
TotalAverage of the checks, to one decimal
PickWorking pressureTemperature limitRetrofit routeASSE 1010 listingScore
Sioux Chief 660-HB1010101010
Sioux Chief 660-GTR1B1010101010
Watts LF15M2-B887108.3
Decision checkEvidence requiredWhen it stops a recommendation
Device identityReadable model or confirmed exposed constructionUnknown or concealed pipework
ConnectionMaker’s complete model tableOnly nominal diameter matches
Capacity and placementMaker’s application/sizing instructionsBranch load or location unconfirmed
ServiceExact sealed or rechargeable model instructionsGeneric drain or charge advice
OfferGenuine exact model, New, qualified stockDifferent model, scarce or future availability
Spec scorePublished pressure, temperature, certification and connectionSame checks for all three; no measured shock result is claimed

Sources

  1. Sioux Chief, MiniRester 660-HB specification, footer 5-14, p.1: connections, piston, dimensions, limits, certification and both washer supplies. siouxchief.com; read October 20, 2026.
  2. Sioux Chief, MiniRester 660-GTR series specification, footer 5-18, p.1: GTR1B connection, dimensions, construction, working limits and supply-stop placement. siouxchief.com; read October 20, 2026.
  3. Sioux Chief, MiniRester 660-GT series specification, footer 5-14, p.1: 660-TKB ballcock tee and family placement guidance. siouxchief.com; read October 20, 2026.
  4. Sioux Chief, HydraRester 650-series specification, footer 09-26, p.1: capacity, connection suffixes, any-angle installation and connection-material limits. siouxchief.com; read October 20, 2026.
  5. Sioux Chief, Water hammer arresters: Sizing guideline, p.1: point-of-use AA versus hot/cold multi-fixture branch sizing and placement. siouxchief.com; read October 20, 2026.
  6. Watts, ES-LF05 revision 2036, pp.1–2: sealed piston, non-rechargeable construction, orientation, washer models and placement. watts.com; read October 20, 2026.
  7. Watts, IS-150A revision 1510, pp.1–2, EDP 1910323: LF150A diaphragm, charging valve, flow-pressure distinction and NPT connection. watts.com; read October 20, 2026.
  8. Oatey, What causes banging pipes and how to stop them, section How to fix and prevent water hammer: traditional chambers and waterlogging. oatey.ca; read October 20, 2026.
  9. Oatey, How to install hammer arrestors to silence banging pipes, June 4, 2026, steps 1–4 and maintenance FAQs: serving-valve shutoff, reconnection, leak checks and persistent noise. oatey.com; read October 20, 2026.
  10. International Code Council, 2024 International Plumbing Code, sections 604.8, 604.9 and 607.3: static pressure, arrestors and expansion control. codes.iccsafe.org; read October 20, 2026. Adopted local edition and amendments require confirmation.
  11. A. O. Smith, Residential electric water heater use and care guide, 100263105, pp.11 and 21: full-tank requirement before energizing and shutdown before draining. assets.hotwater.com; read October 20, 2026.
  12. Watts, ES-LF15M2 1329, pp.1–2: construction, 60 psi pre-load, 150 psi, 33–180°F, materials, standards, size B fixture units, dimensions and placement rules. watts.com; read October 22, 2026.
  13. Watts, IS-15M2 installation instructions, EDP 2915049: both hot and cold lines, PRV above 60 psi, not field-rechargeable, one-year warranty. watts.com; read October 22, 2026.
  14. Amazon: the Sioux Chief 660-HB washer tee and the Sioux Chief 660-GTR1B stop tee, October 20, 2026, offer checked 11:42 EDT; search checked 11:50 EDT. Those two and the Watts LF15M2-B re-read Oct 22, 2026, 2:53 AM EDT. Product titles, seller, New condition and stock.
