For a 4-inch centerset sink, pick the Moen Banbury WS84913. For a widespread sink and a taller spout, pick the WS84924. For one hole, pick the 84945. Add the 23045 showerhead to match the shower.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares four Moen Banbury pieces using Moen’s own spec sheets.
Moen Banbury faucets compared (Moen spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Fits | Reach / spout height | Max deck | Drain on sheet |
|---|---|---|---|---|
| WS84913 centerset | 3 holes, 4 in. centers | 4-3/4 in. / 7 in. | 1-3/16 in. | Pop-up waste |
| WS84924 widespread | 3 holes, 8 to 16 in. centers | 4.9 in. / 8.5 in. | 1-1/4 in. (kit to 3 in.) | Non-metal pop-up |
| 84945 single-handle | 1 hole, or 3 with plate | 5 in. / 5 in. | 1-1/2 in. | Non-metal push-down |
| 23045 showerhead | 1/2 in. IPS shower arm | 4 in. face | n/a | n/a |
Banbury is a Moen collection with lever-handle bathroom faucets, shower trim and a matching showerhead. Each sink faucet sheet lists ADA-compliant lever handles and WaterSense certification. The warranties differ by sheet, as noted under each model, so read the one for the model you buy.
Moen Banbury WS84913SRN: 4-inch centerset
Choose the Banbury WS84913 for a three-hole sink with 4-inch centers. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/ws84913sp.pdf) lists a two-handle 4-inch centerset with a pop-up waste, lever handles that turn 90 degrees to full on, a rotating spout and a 1224 cartridge design. It installs through three 1-inch minimum holes. Moen notes the 1/2-inch IPS connections are for flexible hoses only, not rigid or semi-rigid risers with coupling nuts. The sheet lists a lifetime limited warranty against leaks, drips and finish defects to the original homeowner, with 10 years for multifamily and 5 years for commercial use.
The drawing shows a 4-3/4-inch reach, a 7-inch spout height, 4-1/8 inches from deck to aerator, a 9-1/4-inch overall width and a deck range of 5/16 to 1-3/16 inches, with 2-1/2 inches recommended to the back splash for the lift rod. On October 15, 2026, the standard new offer sold by Mid Atlantic Merchants showed In Stock with model WS84913SRN, Spot Resist Brushed Nickel.
Check Moen Banbury WS84913SRN centerset faucet on Amazon →
Moen Banbury WS84924: widespread, high arc
Choose the Banbury WS84924 for a widespread sink and a taller spout. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/ws84924sp.pdf) lists Duralock quick connect installation, 1/2-inch IPS connections, a non-metal pop-up waste, lever handles and a 1234 cartridge design. The spout and valves install through 1-1/8-inch minimum holes on 8- to 16-inch centers. The drawing shows a 4.9-inch reach, an 8.5-inch spout height, 4.84 inches from deck to aerator and a 1-1/4-inch maximum deck; Moen lists service kit 115001 for decks from 1-3/8 to 3 inches. The sheet lists a lifetime limited warranty to the original consumer and 5 years for commercial use.
On October 15, 2026, the standard new offer sold by MPAD USA showed limited stock with model WS84924, chrome.
Check Moen Banbury WS84924 widespread faucet on Amazon →
Moen Banbury 84945BL: single handle
Choose the Banbury 84945 for one lever on a single-hole sink. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/84945sp.pdf) lists flexible supply lines with 3/8-inch compression fittings, a non-metal push-down waste, an optional three-hole deck plate, a lever with a 100-degree arc and ceramic disc technology. It installs through a 1-1/8-inch minimum hole, and the supply lines are drawn 28 inches long. The drawing shows a 5-inch reach, a 5-inch spout height, 3-3/16 inches from deck to outlet, an 8-inch overall height, a 5-7/8-inch deck plate and a 1-1/2-inch maximum deck.
The only warranty line on this sheet is a 10-year limited warranty for multifamily installations; check Moen’s site for the home-use terms. On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model 84945BL, matte black.
Check Moen Banbury 84945BL single-handle faucet on Amazon →
Moen Banbury 23045: 5-function showerhead
Choose the Banbury 23045 to match the shower to Banbury faucets without changing the valve. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/23045sp.pdf) lists a fixed-mount showerhead with five functions selected by turning the outer ring and a 1/2-inch IPS connection. The drawing shows a 4-inch face. Moen lists 1.75 gpm at 80 psi for heads made after March 1, 2018, and 2.0 gpm for heads made before then. The warranty is lifetime limited against material or manufacturing defects to the original homeowner, 10 years multifamily and 5 years commercial.
On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model 23045, chrome. For other Moen heads, see our Moen shower head guide.
Check Moen Banbury 23045 showerhead on Amazon →
Finish suffixes and connections
Moen marks the finish with letters after the model number, and the Amazon listings we checked use the same codes: SRN for Spot Resist Brushed Nickel, BL for matte black, BRB for Mediterranean Bronze, and no suffix for chrome. Matching the suffix across the sink faucet and the showerhead keeps the metal tone the same, and it is the code to quote when you order a replacement handle later.
The connections differ by model too. The WS84913 uses 1/2-inch IPS inlets meant for flexible hoses, the WS84924 uses 1/2-inch IPS connections with Duralock quick connects between the valves and spout, and the 84945 comes with flexible supply lines ending in 3/8-inch compression fittings. The 23045 showerhead threads onto a standard 1/2-inch IPS shower arm.
Check the shutoff valves under your sink and the arm in your shower before install day, so you only need one trip for parts.
Check these before you order
- Hole pattern. 4-inch centers take the WS84913; 8 to 16 inches take the WS84924; one hole takes the 84945.
- Supply lines. The WS84913 sheet says its 1/2-inch IPS connections are for flexible hoses only. Plan flexible supplies if you have rigid risers today.
- Deck thickness. The WS84913 allows 5/16 to 1-3/16 inches; the WS84924 allows 1-1/4 inches, or up to 3 inches with kit 115001.
- Drain. The WS84913 uses a pop-up with a lift rod and needs 2-1/2 inches behind it; the 84945 uses a push-down drain with no lift rod.
- Showerhead flow. Look for the 1.75 gpm marking if your state limits shower flow.
Which Banbury piece should you buy?
Pick the sink faucet by your hole pattern, then add the showerhead to tie the shower in. The WS84913 is the choice for a 4-inch sink; the WS84924 gives a taller 8.5-inch spout for a widespread sink; the 84945 is the simple one-hole option with a push-down drain. Banbury shower trim exists too, but the trim kits we found on Amazon were sold as used or had a non-Moen UPC, so we left them out. For other Moen bathroom faucets, see our Moen bathroom faucet guide, our Moen Eva guide and our Moen Brantford guide.
Frequently asked questions
What cartridge does the Moen Banbury centerset use?
The WS84913 sheet lists a 1224 cartridge design.
What is the flow rate of Moen Banbury faucets?
1.2 gpm at 60 psi on the three sink faucet sheets.
Does the Banbury single-handle faucet include a deck plate?
Yes, an optional three-hole deck plate, per Moen.
What hole spacing does the Banbury widespread fit?
8 to 16 inches center to center.
What is the flow rate of the Banbury showerhead?
1.75 gpm at 80 psi for heads made after March 1, 2018; 2.0 gpm before.
How we chose
This document-based guide makes no hands-on testing claim. We read and rendered Moen’s spec sheets for the Banbury WS84913, WS84924, 84945 and 23045. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Moen Banbury WS84913 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/ws84913sp.pdf): centerset, 1224, flexible hoses only.
- Moen Banbury WS84924 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/ws84924sp.pdf): widespread, kit 115001.
- Moen Banbury 84945 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/84945sp.pdf): single handle, push-down, warranty line.
- Moen Banbury 23045 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/23045sp.pdf): 5-function head, flow by date.
