For the widest hole fit and a soap dispenser, pick the Moen Sombra 87701SRS. For a pause feature, the Moen Camerist 7545SRS. For a basic two-spray pull-out, the American Standard Colony Pro 7074100.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares three single-handle pull-out kitchen faucets using Moen and American Standard spec sheets.
Pull-out kitchen faucets compared (maker spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Holes | Hose | Max deck | Cartridge |
|---|---|---|---|---|
| Moen Sombra 87701SRS | 1 to 4 | 59 in. braided | 2-1/2 in. | Moen 1255 |
| Moen Camerist 7545SRS | 1 or 3 | 59 in. braided | 1-1/2 in. | Moen 1255 (current) |
| American Standard Colony Pro 7074100 | 1 or 3 | Nylon | Not listed | 40 mm ceramic disc |
A pull-out faucet has a short or mid-height spout, and the spray head pulls straight out toward you on a hose. A pull-down faucet has a tall, arched spout and the head pulls down into the sink. Because the spout is lower, a pull-out can be a fit under a window or low shelf; our pull-down faucet guide covers the other style, and our low-profile faucet guide covers low-clearance options.
Moen Sombra 87701SRS: fits 1 to 4 holes, soap dispenser
Choose the Sombra for the widest hole-count fit and a soap dispenser in the box. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/87701sp.pdf) lists metal construction, Power Clean spray, a pull-out spray on a 59-inch braided hose, flexible supplies with 3/8-inch compression fittings, a lever handle, 120-degree spout rotation, less than 5 pounds of force to operate, a 1255 Duralast cartridge and a 1.5 gpm flow at 60 psi.
It is designed to install through 1, 2, 3 or 4 holes of 1-1/2 inches, with a 2-1/2-inch maximum deck, and the drawing includes a soap dispenser. The warranty is lifetime against leaks, drips and finish defects to the original homeowner, 10 years multifamily and 5 years commercial. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model 87701SRS, Spot Resist stainless.
Check Moen Sombra 87701SRS pull-out kitchen faucet on Amazon →
Moen Camerist 7545SRS: pause as you cross the counter
Choose the Camerist for a pull-out with a pause feature. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/7545sp.pdf) says the flow pauses as the wand passes over the countertop when you fill a pot outside the sink. The current version (Rev. 10/13) lists metal construction, quick-connect installation, a 59-inch braided hose, 3/8-inch compression supplies, a 1255 Duralast cartridge and a 1.5 gpm flow at 60 psi.
It installs through 1 or 3 holes of 1-1/2 inches with a 1-1/2-inch maximum deck. The same PDF includes an older version (Rev. 8/13) with a 1225 cartridge and 2.2 gpm flow, so check the date code before buying parts for an existing Camerist. The warranty is lifetime against leaks, drips and finish defects to the original consumer purchaser, 5 years commercial. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 7545SRS. More in our Moen kitchen faucet guide.
Check Moen Camerist 7545SRS pull-out kitchen faucet on Amazon →
American Standard Colony Pro 7074100: two sprays, memory position
Choose the Colony Pro for a basic pull-out with a memory-position handle. American Standard’s spec sheet (lixil.cdn.celum.cloud) lists a metal swivel body, handle and deck plate, a pull-out sprayer with two spray functions on a nylon hose, a washerless 40 mm ceramic disc cartridge, and 24-inch braided stainless supply hoses with 3/8-inch compression connections.
It lists memory position valving, so you can turn the faucet on and off at the same temperature without moving the handle, a 1.5 gpm maximum flow, a 9.7-inch height, and a 1-3/8 to 1-1/2-inch mounting hole, with or without the supplied escutcheon plate. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 7074100.002, polished chrome. More in our American Standard kitchen faucet guide.
Check American Standard Colony Pro 7074100 pull-out kitchen faucet on Amazon →
Pull-out or pull-down?
The spout shape is the main difference. All three faucets here have a low, forward-reaching spout and a head that pulls toward you. Moen’s drawings show a 9-9/10-inch overall height for the Sombra and 10-7/8 inches for the Camerist; American Standard lists 9.7 inches for the Colony Pro. Measure from the deck to any shelf or window sill before you choose.
Handle and spray controls
Both Moen sheets list a lever handle that sets temperature across a 100-degree arc, 120-degree spout rotation, less than 5 pounds of force to operate, and stream or spray mode whether the wand is pulled out or docked. Both carry the ADA symbol for the lever handle. American Standard lists two spray functions on the Colony Pro, switching from stream to spray, and says the faucet meets ADA guidelines and ANSI A117.1.
The Camerist adds the pause feature described above; the Sombra lists Moen’s Power Clean spray. If you mostly rinse dishes, compare the spray modes; if you fill large pots, the Camerist’s pause may matter more.
Holes and deck thickness
Count your sink or counter holes. The Sombra lists 1 to 4 holes, so it can cover an old faucet’s layout without a separate plate. The Camerist and Colony Pro list 1 or 3 holes, with a deck plate for the 3-hole layout. Check deck thickness too: Moen lists 2-1/2 inches maximum for the Sombra and 1-1/2 inches for the Camerist; American Standard does not list a maximum on its sheet. If you have a spare hole, a soap dispenser can fill it; see our soap dispenser guide.
Cartridges and repairs
Both Moen faucets list the 1255 Duralast cartridge in their current versions; American Standard lists a 40 mm ceramic disc cartridge. If a single-handle faucet starts to drip or the handle gets stiff, the cartridge is usually the part to replace; see our faucet cartridge guide.
Installing a pull-out faucet
Shut off both supply stops and open the old faucet to release pressure before you start. The Moen Sombra and Camerist list flexible supplies with 3/8-inch compression fittings, and the Colony Pro lists 24-inch braided stainless supply hoses with 3/8-inch compression connections, so check that your shutoff valves have 3/8-inch compression outlets. If they do not, or if the old valves will not close fully, replace them first; see our under-sink shutoff valve guide.
The Camerist sheet lists quick-connect installation for the spray hose. Leave room under the sink for the hose to move freely when the head is pulled out.
Check these before you order
- Holes. 1 to 4 on the Sombra; 1 or 3 on the others.
- Deck. 2-1/2 or 1-1/2 inches maximum on the Moens.
- Height. About 9.7 to 10-7/8 inches.
- Flow. 1.5 gpm on all three.
- Version. The Camerist sheet shows two versions.
- Extras. The Sombra drawing includes a soap dispenser.
Which pull-out kitchen faucet should you buy?
For the widest hole fit and a soap dispenser, the Moen Sombra 87701SRS. For a pause feature when filling pots on the counter, the Moen Camerist 7545SRS. For a basic two-spray pull-out with memory-position handle, the American Standard Colony Pro 7074100. For all styles, see our kitchen faucet guide.
Frequently asked questions
What is a pull-out kitchen faucet?
A faucet with a low spout whose spray head pulls straight out toward you on a hose.
Which pull-out here fits the most hole layouts?
The Moen Sombra, designed for 1, 2, 3 or 4 holes.
What cartridge does the Moen Camerist use?
The current version lists the 1255 Duralast; an older version used the 1225.
What is memory position valving?
American Standard says it lets you turn the faucet on and off at your preferred temperature without readjusting the handle.
How much water do these use?
All three list a 1.5 gpm maximum flow.
How we chose
This document-based guide makes no hands-on testing claim. We read Moen’s sheets for the Sombra 87701 and Camerist 7545 series and American Standard’s sheet for the Colony Pro 7074.100. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Moen 87701 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/87701sp.pdf): Sombra.
- Moen 7545 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/7545sp.pdf): Camerist, two versions.
- American Standard 7074.100 spec sheet (lixil.cdn.celum.cloud): Colony Pro.
