A pipe freezing kit makes an ice plug inside a full, still water line. After the installer verifies a stable plug using the exact manual, it can allow a repair without draining the whole system. This guide helps choose equipment; it does not replace the operating procedure. RIDGID’s domestic SuperFreeze SF-2500 (catalog 68967) is the 115-volt unit sold for U.S. outlets. Owning one makes sense if you regularly work on metal lines where an ordinary shutdown or draining the system is impractical, while still having an emergency isolation plan. For a one-off job, a valve that will close, a rental or a plumber is usually the better route. The specifications and limits below come from RIDGID’s SF-2300/SF-2500 operator’s manual (document 999-998-750.10, Rev. D), which is the manual linked from RIDGID’s current SF-2500 page.

The short answer

Consider owning the SF-2500 (68967) if you often service copper tube from 1/2 to 2-1/2 inch CTS, or steel pipe from 1/2 to 1 inch, in buildings where shutting down or draining the system is impractical, and you have a grounded 115 V outlet nearby.
Do not buy it for PEX, CPVC, PVC or any plastic pipe. Do not buy it for water that keeps moving, partly drained lines, systems with additives you can’t identify, or steel pipe larger than 1 inch.
Rent or call a plumber if this is a single repair. That includes the common case where the only reason to freeze is one main valve that won’t fully close.

What a pipe freezer actually does

RIDGID describes the SuperFreeze as a self-contained refrigeration unit that circulates refrigerant (R-507) to two aluminum freeze heads on hoses. You clamp the heads to the pipe, and they freeze a plug in the water inside. When the work is done, you switch the unit off and the plug melts, which returns the system to service. RIDGID notes that the units use neither CO₂ nor nitrogen and do not release refrigerant.

RIDGID cautions that several conditions affect whether an ice plug can form; suitable pipe size alone does not guarantee success. Treat it as a tool with prerequisites, not a guarantee.

Five conditions that must all be true

Go through these before you buy or rent. If any one fails, a freezer is the wrong tool.

The water is still. RIDGID says moving water prevents the unit from forming a plug. Flow has to be stopped first, by closing a valve, turning off a circulating pump or other means. A freezer is not a substitute for stopping a line that is actively running.
The pipe is metal and full. RIDGID says the unit works only on metallic piping and excludes plastic pipe and tube. A plug cannot be frozen in a partly filled pipe.
The fluid is water you understand. Additives can change the freezing temperature and prevent reliable plug formation.
Water and air are cool enough. They must be below 110°F for sizes up to 1 inch, 90°F for 1-1/4 and 1-1/2 inch, and 80°F for 2 inch and larger. Otherwise you have to cool them first.
There is room and a backup plan. You need access for at least one freeze head (both, ideally, for a single plug). The plug must be more than 1 foot from elbows, end caps, closed valves or other plugs. You also need a known way to shut the system off in an emergency.

Size limits for the U.S. 115 V model (68967)

Match the voltage and pipe material before comparing the size range. The manual lists different capacities for each SF-2500 version, and the 2-inch steel figure belongs to the 230 V model, not the U.S. unit.

Copper tube: 1/2 to 2-1/2 inch CTS.
Steel pipe: 1/2 to 1 inch only. The domestic unit’s freeze-head cavities are sized for copper tube. Per RIDGID’s footnote, they can be used on steel sizes only by following the manual’s instructions.
Electrical: 115 V, single phase, 60 Hz. Use a properly grounded outlet. Check the unit nameplate and supplied manual for the circuit and cord requirements.
Reach: 8.5 ft hoses, 17 ft hose span.

Some sizes need adapter bushings (RIDGID’s capacity chart for the 68967):

3/4 inch CTS copper or 1/2 inch steel: bushing Cat. #69712
1-1/4 inch CTS copper or 1 inch steel: bushing Cat. #70652
2 inch CTS copper: bushing Cat. #69717
1/2, 1, 1-1/2 and 2-1/2 inch CTS copper and 3/4 inch steel: a freeze-head cavity directly, no bushing listed

Check the box contents before you rely on those sizes. The manual’s “Standard Equipment” list names only two Velcro straps with D-rings, a Quick Grip clamp, freeze gel, a water spray bottle and the operator’s manual. It lists the bushings as accessories. RIDGID’s current 68967 product page lists the bushing sets in its ordering information. Confirm what the seller’s listing says ships in the carton. If the 69712, 70652 or 69717 bushings aren’t listed, plan to buy them before a job at those sizes.

How long a freeze takes

A fast-sounding freeze time is a best case, not a schedule. RIDGID’s freeze-time chart for the SF-2500 assumes copper tube, freeze gel, two freeze heads, and water at the same temperature as the air. Under those conditions it lists about 6 minutes for 1/2 inch copper at 70°F. That grows to about 19 minutes for 1-1/2 inch and about 40 minutes for 2-1/2 inch at 70°F, rather than a universal six-minute turnaround. Some chart rows show hotter conditions than the setup section permits; a chart time does not override the size-dependent temperature limits above. RIDGID adds that steel pipe takes longer, and that less favorable conditions can take more than twice the chart time.

The clock also keeps running after the plug forms. The manual says to confirm there is no flow before opening the system. It then says to wait at least five more minutes, or at least 15 minutes when the water is between 90°F and 100°F. RIDGID also requires the unit to stay running and attended throughout the repair; its no-flow test and waiting procedure apply before opening the line. Budget for that time when you decide whether owning the tool saves you anything.

If you will solder or braze near the plug

Heat can thaw an ice plug while the pipe is open. For steel pipe, RIDGID’s spacing rule is at least 1 foot from the heat per inch of diameter. For all other materials, including copper, it is at least 3 feet per inch. For a 1-inch copper tube that means at least 3 feet from the heat (our arithmetic). The manual separately requires clearance from obstructions and circulating hot-water mains; an installer must confirm all applicable spacing. A press fitting avoids flame, but the plug and flow checks still apply. See can you press a wet line for what press fittings tolerate.

Owning it: what comes with the decision

Size and weight. The manual lists the 115 V SF-2500 at 69 lb and 24-1/2 × 11 × 14-1/2 inches. RIDGID’s current page lists 55 lb and 22-7/8 × 11 × 14-1/2 inches. Those differ from the manual; we cannot establish which describes the unit that will ship. Confirm the actual unit with the seller before planning transport or storage.
Storage. RIDGID says not to store the unit in a vehicle, because vibration and shock can damage it. Keep it upright and level when running.
Service. The unit contains refrigerant. Repairs must go through a RIDGID Independent Authorized Service Center, not your own workbench.
Warranty. The manual’s back cover gives RIDGID’s Full Lifetime Warranty against defects in material and workmanship. It excludes misuse, abuse and normal wear.

When renting or another route is the better buy

You have one job. One freeze rarely justifies owning a tool that carries all of the storage, service and setup demands above. A rental, or a plumber who already owns a freezer, is the proportionate choice. Ask for the operator’s manual and the bushings for your size.
The real problem is a bad shutoff. If the main or a branch valve won’t hold, replacing or repairing that valve is often the lasting fix. A freezer only works around it for one job. Start with our shut-off valve guide for fixture stops.
The line is plastic. No freezer in this guide applies. Isolate and drain it instead.
The water won’t stop moving. Find out why first. A freezer cannot plug a moving line, and the manual says so.

If you decide to buy

Buy the exact domestic kit: RIDGID 68967, Model SF-2500 SuperFreeze, 115 V. Do not substitute the 230 V export (68962) or European (68832) versions on a U.S. 120 V circuit. Before checkout, confirm three things on the seller’s listing:

The catalog number reads 68967.
Which bushings and accessories ship in the box.
The weight and dimensions shown.

Check the RIDGID 68967 SF-2500 kit on Amazon

If the freeze is for a copper repair you will finish with press fittings, the tool decision is covered in our ProPress tool guide. Fittings are covered in copper press fittings.

FAQ

Can a pipe freezer freeze PEX or PVC?

No. RIDGID’s manual says the SuperFreeze works only on metallic piping and warns not to use it on plastic pipe or tube.

Will it work if water is still running through the pipe?

No. The manual says the unit will not work on flowing water. Flow must be stopped first, by closing a valve, turning off a circulating pump or other means.

What steel pipe size can the U.S. SF-2500 handle?

The 115 V domestic SF-2500 (68967) is rated for 1/2 to 1 inch steel pipe. The 1/2 to 2 inch steel rating in the same manual belongs to the 230 V model.

How long does it take to freeze a pipe?

RIDGID’s chart lists about 6 minutes for 1/2 inch copper at 70°F under ideal conditions, and about 40 minutes for 2-1/2 inch copper at 70°F. Steel and less ideal conditions take longer, and RIDGID calls the chart a general guide only.

Can I turn the freezer off once the plug forms?

No. RIDGID says to keep the unit running for the whole repair so the plug does not melt while the system is open. Shut it off only after the system is closed.

Sources and how this guide was checked

#ad Buying for a shop? Amazon Business (opens in a new tab) accounts are free to create, with business-only prices and bulk quantity discounts.

RIDGID SF-2500 current model page: domestic catalog number, voltage and pipe-material ranges; current ordering information.
RIDGID SF-2300/SF-2500 operator manual, 999-998-750.10, Rev. D: printed pages 3–10 and back cover. Printed December 2013; it is still the document linked by RIDGID’s model page when checked October 7, 2026. We have not inferred a newer revision.

Specifications come from maker documents, not hands-on testing. The exact Amazon listing was checked separately for catalog 68967; package contents and the conflicting transport dimensions still need confirmation before purchase. No maker or seller pays to be included. See how we pick and our affiliate disclosure.
