Air Separators

For a residential hot-water heating loop, the Caleffi 551005A is a 3/4-inch NPT brass air separator rated 150 psi and 32–250°F; it is the body only, so add an automatic vent such as the Caleffi 502015A on top. The Spirotherm VJR100TM is a 1-inch separator for a larger loop. Size it to the pipe and flow of the system, and keep radiator bleeders for individual emitters.

Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.

This guide concerns closed hydronic heating and cooling circuits. Match the actual application before treating any boiler-area fitting as a suitable replacement.

Choose the function before the brand

The two separators below have different connection sizes. They are fit-based examples, not a measured performance ranking. The small automatic vent serves another role and should not be substituted for the whole separator assembly.

Caleffi 551005A: a three-quarter-inch threaded example

Choose the 551005A when the hydronic design calls for this exact horizontal-pipe DISCAL body with 3/4-inch female NPT connections. The current North American maker table (caleffi.com) identifies the size, brass body and separate model options.

Skip it when the job requires another connection, vertical-line arrangement or a different approved fluid application. Do not assume a neighboring 551 part number has the same ends.

The standard new Amazon offer checked for this guide showed stock from Voomi Supply, with model and part number 551005A. It is one identified retail example, not a claim that every DISCAL variant is interchangeable.

Also distinguish body-only selection from a version supplied with a service check. Decide what the actual system needs before treating an accessory shown in a family illustration as included.

Check Caleffi 551005A air separator on Amazon →

Spirotherm VJR100TM: a one-inch threaded example

Choose the VJR100TM for a compatible one-inch threaded hydronic circuit where its documented orientation and flow requirements suit the design.

The maker’s currently linked VJR submittal (spirotherm.com) maps the 100TM suffix to the one-inch NPT version. The retail title was shortened to VJR-100, but its model and part fields both identified VJR100TM.

The checked standard new offer showed stock from Homestead Supply & More. This check establishes the listed identity and availability; it does not prove a particular system will operate correctly with that size.

Skip it when the installation needs sweat, press or another orientation-specific product. VJR, VJS and VJP are separate connection families. Standard and high-temperature variants also need their own exact specifications rather than a blended family rating.

Check Spirotherm VJR100TM air eliminator on Amazon →

Caleffi 502015A: an automatic vent rather than an inline separator

Choose the 502015A only for a compatible location calling for its 1/8-inch male NPT automatic vent. It releases collected air; it is not the same component as either inline separator above.

The current maker page (caleffi.com) lists a 150-psi maximum operating pressure and a separate 40-psi maximum air-discharge pressure. Reading only the larger number can lead to the wrong selection.

The standard new Amazon offer checked here showed stock from SYDCO-USA INC., with both model and part number 502015A.

Skip it if its actual discharge limit, fluid compatibility, temperature range, connection or approved mounting arrangement does not fit the system. Do not assume that the service-check accessory supplied with another MINICAL model is automatically included with this one.

Check Caleffi 502015A automatic air vent on Amazon →

Microbubble separator versus conventional air scoop

A microbubble separator uses an internal collecting medium to help small bubbles combine and separate from the circulating fluid. A conventional scoop uses its chamber and baffle arrangement to collect free air.

Both descriptions still leave important selection work: flow, pressure loss, available space and the actual piping arrangement. A product name alone does not establish that the system meets those requirements.

The Taco Air Scoop submittal (tacocomfort.com) shows a straight-run requirement in its system drawing. The Spirovent Junior instructions have different straight-run guidance. Keep those instructions with their own products.

Do not copy an air-scoop dimension into every microbubble installation, or assume a microbubble model’s instructions cancel the requirements for a conventional scoop. Neither comparison supports an invented percentage improvement or a promise that every noise problem will disappear.

Placement must follow the actual hydronic design

The Spirovent Junior instructions (spirotherm.com) place the unit where the fluid temperature is highest and pressure lowest, illustrating the relationship to the heat source and circulator suction.

That is more useful than the loose instruction “put it somewhere on the supply.” The expansion-tank connection and pump arrangement must be understood together.

For standard Juniors, the maker requires an upright body in a straight horizontal run. Its current instructions do not impose a fixed number of pipe diameters before and after the unit.

The selected Caleffi belongs to a horizontal-pipe family too. A rotating-collar or vertical-line version is a distinct selection, not permission to turn any separator sideways.

Use the exact manufacturer drawing and system plan to confirm the installation. These examples do not provide a complete boiler repiping design.

A radiator bleeder is a local component

A bleeder valve at a radiator addresses air collected at that emitter. It is not a substitute for understanding central air removal and the rest of the circuit.

Identify the existing radiator’s connection and specified vent mechanism. A manually opened bleeder, float-operated vent and hygroscopic vent do not all work in the same way.

The North American Caleffi HYGROCAL 508013A (caleffi.com) is an example of an automatic/manual hygroscopic product. It is described here to distinguish mechanisms, not as a checked Amazon purchase recommendation.

Do not transfer a European fitting’s thread specification to that North American part, or choose an unfamiliar radiator valve merely because it looks similar. Obtain the exact emitter and vent instructions before replacement.

Read pressure, temperature and fluid limits separately

Make a selection record with the maximum system conditions, venting conditions, fluid and additives. Those are separate entries, not one generic “boiler rated” label.

The Caleffi DISCAL instructions (caleffi.com) identify closed hydronic service and explicitly exclude plumbing applications because this product does not meet the stated low-lead plumbing standards. Do not treat a domestic hot-water line as an interchangeable application.

Likewise, do not borrow a whole family’s highest temperature rating for a model supplied with another accessory. The exact assembly determines the applicable limit.

Our valve-marking guide explains why a pressure marking needs context. It does not approve another component or expand the separator’s allowed service.

Leave room for the vent and its service requirements

Check overhead and side clearance before ordering. Account for the actual vent body, adjacent equipment, access and the instructions for any optional tank connection.

The Spirovent instructions address keeping the vent outlet available for air discharge during operation. Do not invent a universal cap or discharge-pipe arrangement for every vent based on one product’s instructions.

Hot, pressurized system fluid is a service hazard. Follow the exact isolation, depressurizing and cooling requirements before servicing any component; this buying guide is not a live-system vent-removal procedure.

Keep device names distinct as well. A hydronic air vent is not a pressure-relief valve, a boiler drain or a water-heater expansion tank. Our boiler-drain terminology guide covers that separate drain-valve role.

Before buying: record the whole selection

Write down the exact model, connection size and thread or joining system. Add piping orientation, required flow, pressure loss, fluid limits and service access to that record.

Confirm whether any check valve, insulation shell, tank connector or other accessory is included. A product-family picture is not a packing list.

Check the current package and exact instructions against the system plan. A one-inch separator does not automatically suit every one-inch circuit, and a small automatic vent does not fix an unidentified cause of recurring air.

The useful choice is the one that matches the design and can be maintained correctly. If those requirements are unresolved, settle them before ordering rather than choosing by brand reputation alone.

Frequently asked questions

Is an automatic air vent the same as an air separator?

No. A vent releases collected air; an inline separator also provides a means of separating air from circulating fluid.

Can the selected Spirovent Junior be mounted sideways?

Its standard Junior instructions require an upright body in horizontal piping. Choose the correct orientation-specific product rather than rotating it arbitrarily.

Does 150 psi mean the 502015A vents air at 150 psi?

No. Its current maker page separately lists a 40-psi maximum air-discharge pressure.

Will a radiator bleeder replace central air removal?

It serves a local emitter role. The complete circuit still needs the appropriate air-removal design.

Is the DISCAL 551005A intended for domestic drinking-water piping?

The cited DISCAL instructions specify closed hydronic use and exclude plumbing applications because of the stated low-lead standards limitation.

How we chose

This comparison is based on maker documents, not hands-on testing. We checked current North American Caleffi pages, DISCAL instructions, the currently linked Spirovent Junior IOM dated 2023 and VJR submittal dated 2007, and a Taco air-scoop reference. Spirotherm diagrams and the exact model table were visually checked. Standard new stock offers and model/part fields were checked on October 14, 2026. Product examples are selected by role and fit; no measured performance ranking or complete system design is claimed. Read our selection method and about Plumbing Picks.

Primary sources

• Caleffi current 551005A table (caleffi.com): exact connection and separate model options.
• DISCAL instructions, 2020 (caleffi.com): closed hydronic restriction and mounting requirements; text checked.
• Spirotherm current residential family (spirotherm.com): separate NPT, sweat, press and temperature variants.
• Current linked Junior instructions, 2023 (spirotherm.com): orientation, placement and vent/service requirements; diagram visually checked.
• Current linked VJR submittal, 2007 (spirotherm.com): exact 100TM model mapping and dimensions diagram visually checked.
• Caleffi current 502015A page (caleffi.com): separate operating-pressure and air-discharge limits.
• Caleffi current North American HYGROCAL (caleffi.com): local automatic/manual mechanism, information only.
• Taco Air Scoop submittal, effective 2007 (tacocomfort.com): scoop-specific layout requirement; not universal separator guidance.
