For one hole, pick the Delta Arvo 15840LF-SP; for 4-inch centers, the 25840LF-SP; for a widespread, the 35840LF-SP. For a tub and shower on a MultiChoice valve, the 144840-SP-I trim.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares five Delta Arvo products using Delta’s own spec sheets.
Delta Arvo compared (Delta spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Type | Holes | Max. deck | Valve |
|---|---|---|---|---|
| 15840LF-SP | Single-handle | 1 or 3 (plate included) | 2-1/8 in. | Built in |
| 25840LF-SP | Two-handle centerset | 2 or 3, 4-in. centers | 1-5/8 in. | Built in |
| 35840LF-SP | Two-handle widespread | 3, 6 to 16-in. centers | 2-3/8 in. | Built in |
| 144840-SP-I | Tub and shower trim | Wall | n/a | Needs MultiChoice R10000 |
| 142840-SP-I | Shower trim | Wall | n/a | Needs MultiChoice R10000 |
Arvo is a Delta bath collection with bathroom faucets and 14 Series shower trim. All links here are SpotShield brushed nickel (the -SP suffix), so the finish matches across the room. Each Delta sheet lists a lifetime limited warranty on parts and finish for homeowners; commercial buyers get 10 years in multifamily housing and 5 years for other commercial use.
Delta Arvo 15840LF-SP: single-handle
Choose the 15840LF for a one-hole sink, or three holes using the included plate. Delta’s spec sheet (media.deltafaucet.com) lists a solid metal body, a 1.2 gpm maximum flow, a replaceable cartridge with ceramic plates, braided flexible supply hoses with 3/8-inch compression fittings, and a plastic push pop-up drain with overflow and a plated flange.
The sheet lists a hole size of 1-1/8 to 1-1/2 inches, a maximum deck thickness of 2-1/8 inches and a recommended 2-1/2 inches of clearance to the backsplash. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model 15840LF-SP.
Check Delta Arvo 15840LF-SP single-handle bathroom faucet on Amazon →
Delta Arvo 25840LF-SP: two-handle centerset
Choose the 25840LF for a sink with holes on 4-inch centers. Delta’s spec sheet (media.deltafaucet.com) lists a two-handle centerset on 4-inch centers that mounts in two or three holes, a 1.2 gpm maximum flow, quarter-turn handle stops, interchangeable hot and cold stems, all operating parts replaceable from the top, 1/2-inch NPSM threaded shanks and a spring-loaded pop-up drain.
The maximum deck is 1-5/8 inches; Delta says the RP76691 kit extends that by 1 inch. Holes are 1-1/8 to 1-1/2 inches, and Delta recommends 2-1/2 inches of backsplash clearance. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model 25840LF-SP.
Check Delta Arvo 25840LF-SP centerset bathroom faucet on Amazon →
Delta Arvo 35840LF-SP: two-handle widespread
Choose the 35840LF for a three-hole sink with handles spread apart. Delta’s spec sheet (media.deltafaucet.com) lists a two-handle widespread for centers from 6 to 16 inches, a solid brass spout, quarter-turn handle stops, interchangeable stems, parts replaceable from the top, 1/2-inch NPSM adapters, a plastic push pop-up drain and a 1.2 gpm maximum flow.
The sheet lists holes of 1-3/16 to 1-1/2 inches, a 2-3/8-inch maximum deck and the same 2-1/2-inch backsplash recommendation. That range covers the common 8-inch widespread spacing. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model 35840LF-SP.
Check Delta Arvo 35840LF-SP widespread bathroom faucet on Amazon →
Delta Arvo 144840-SP-I: tub and shower trim with In2ition
Choose the 144840-SP-I for a tub and shower on a Delta MultiChoice valve. Delta’s spec sheet (media.deltafaucet.com) covers the 142840-I shower-only and 144840-I tub/shower trim. It lists Monitor 14 Series pressure-balanced trim for the MultiChoice universal rough valve body (R10000 series), which is not included, a 1.75 gpm maximum flow at 80 psi, a 120-degree handle and a field-adjustable limit on how far the handle turns into hot.
The In2ition shower has a hand shower that docks into the showerhead, with four settings: full body spray, full spray with massage, massaging spray and pause; Delta notes pause is not a positive shut-off. The tub version uses the RP101696 pull-up diverter spout. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model 144840-SP-I.
Check Delta Arvo 144840-SP-I tub and shower trim on Amazon →
Delta Arvo 142840-SP-I: shower-only trim
Choose the 142840-SP-I for a stall shower without a tub spout. The same Delta sheet (media.deltafaucet.com) covers it with the same Monitor 14 Series valve trim, In2ition two-in-one shower, 1.75 gpm flow, 120-degree handle and MultiChoice R10000 valve requirement, without the tub spout. Delta lists back-to-back installation capability and says all parts are replaceable from the front of the valve.
On October 15, 2026, the standard new offer sold by Amazon.com showed a delivery date and an add-to-cart button with model 142840-SP-I. For which Delta trims fit which valve, see our Delta MultiChoice trim guide.
Check Delta Arvo 142840-SP-I shower trim on Amazon →
Bathroom faucet choice by sink holes
Count your sink holes and measure from the center of the left hole to the center of the right one. One hole: the 15840LF. Three holes 4 inches apart: the 25840LF, or the 15840LF with its plate. Three holes 6 to 16 inches apart: the 35840LF. All three list 1.2 gpm, so the choice is about fit and style, not flow.
Measure the deck thickness too. Delta lists 2-1/8 inches for the single-handle, 1-5/8 inches for the centerset (with a kit to add 1 inch) and 2-3/8 inches for the widespread.
Shower trim details from the Delta sheet
One handle, temperature only. Delta says temperature is controlled with the handle only; the Monitor 14 Series is a single-control valve, so the handle sets temperature and there is no separate volume control.
Rough-in. The drawing notes that the face of the plaster guard on the MultiChoice valve should be flush with the finished wall. If you are replacing only trim on an existing R10000 valve, that is already set.
Body. Delta lists a solid brass fabricated valve body for the trim set, and says it maintains a balanced pressure of hot and cold water even when a valve is turned on or off elsewhere in the house.
Drains for the sink faucets. The single-handle and widespread sheets list a plastic push pop-up drain, and the centerset lists a spring-loaded pop-up with drain plug. If you prefer a metal drain, plan to buy one separately.
Check these before you order
- Hole spacing. 1 hole, 4-inch centers or 6 to 16-inch centers.
- Deck. Check the maximum thickness for your model.
- Backsplash. Delta recommends 2-1/2 inches of clearance.
- Shower valve. The trims need a Delta MultiChoice R10000 valve.
- Pause. The In2ition pause setting is not a positive shut-off.
- Finish. -SP is SpotShield brushed nickel on all five links.
Which Delta Arvo should you buy?
For one hole, the 15840LF-SP. For 4-inch centers, the 25840LF-SP. For a widespread, the 35840LF-SP. For a tub and shower on a MultiChoice valve, the 144840-SP-I; for a stall shower, the 142840-SP-I. For other Delta options, see our Delta bathroom faucet guide and Delta shower head guide.
Frequently asked questions
Does Delta Arvo shower trim include the valve?
No. Delta lists it for the MultiChoice universal rough valve body, R10000 series.
What flow rate are Delta Arvo bathroom faucets?
1.2 gpm maximum at 60 psi, per the sheets.
Does the Delta Arvo single-handle faucet fit a three-hole sink?
Yes. Delta lists one or three hole mounting with the escutcheon included.
What hole spacing does the Delta Arvo widespread fit?
6 to 16-inch centers.
Is the In2ition pause setting a shut-off?
No. Delta says pause is a non-positive shut-off.
How we chose
This document-based guide makes no hands-on testing claim. We read Delta’s spec sheets for the Arvo 15840LF, 25840LF, 35840LF and 142840-I/144840-I trim. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Delta 15840LF spec sheet (media.deltafaucet.com): single-handle.
- Delta 25840LF spec sheet (media.deltafaucet.com): centerset.
- Delta 35840LF spec sheet (media.deltafaucet.com): widespread.
- Delta 142840-I/144840-I spec sheet (media.deltafaucet.com): 14 Series In2ition trim.
