Buy brass compression couplings, elbows and tees by the tube’s actual outside diameter (OD) at every end, not the nominal pipe size, and keep each fitting’s own nut and sleeve together. BrassCraft’s instructions say these fittings work on copper (not thick-wall Type K), PEX and other plastic tube, never on gas. On PEX, BrassCraft calls for a plastic sleeve with no insert at 3/8-inch OD and smaller, and a brass sleeve plus stainless insert at 1/2-inch OD and larger.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
A familiar fractional size does not establish thread, material or sealing compatibility. Record every connection and the actual service before choosing the fitting.
Name the fitting and every connection
| Part | Purpose | What to verify |
|---|---|---|
| Coupling or union | Joins two tube ends in line | Tube outside diameter at both ends; equal or reducing |
| Elbow | Changes direction | Both connections and room for the complete assembly |
| Tee | Adds a branch | All three sizes and any different thread connection |
| Nut | Retains the specified sleeve in the fitting assembly | Exact body, sleeve and nut compatibility |
Write down each end rather than calling the entire part “3/8-inch brass.” One end may be smaller or use a different connection standard.
One checked elbow example: BrassCraft 65-6X
Choose BrassCraft 65-6X when its exact configuration and application fit. The current maker page (maker page: www.brasscraft.com/product/38-in-o-d-tube-both-ends-7/) identifies a compression union elbow for 3/8-inch outside-diameter tube at both ends.
Skip it for a different tube size, steel tubing, a threaded pipe connection or an application the exact instructions do not cover. A 3/8-inch OD tube connection is not established by a 3/8-inch nominal pipe label.
The Amazon listing shows 65-6X in both the model and manufacturer-part fields. On October 17, 2026, it showed “Currently unavailable” with no offers, so the link below opens an Amazon search instead. Whatever you buy, confirm the delivered fitting, sleeves and nuts, and that it is marked lead-free for drinking water, then apply the actual tube-specific requirements.
Search Amazon for lead-free 3/8-inch OD compression union elbows →
Couplings can be equal-size, reducing or drill-through
For a straight coupling, measure both tube ends and identify whether they are the same size. A reducing union changes size as well as joining the tubes.
BrassCraft’s 62-10-6X example (maker page: www.brasscraft.com/product/58-in-o-d-tube-x-38-in-o-d-tube-2/) is specifically 5/8-inch OD × 3/8-inch OD. Those are two tube dimensions, not a choice of two names for the same connection.
The maker also separately identifies drill-through versions without a tube stop. Do not assume those have the same positioning or assembly requirements as an ordinary stop-equipped union.
When comparing retail packages, check whether you are ordering a complete fitting or a body-only variant. Reusing unidentified nuts and sleeves does not automatically complete a correct assembly.
Read a tee as three separate ends
A tee may have three equal compression connections, reducing connections, or a pipe-thread branch. Record the connection type and size of the run and branch.
For example, BrassCraft’s 64-6X page (maker page: www.brasscraft.com/product/38-in-o-d-tube-all-3-ends-3/) identifies 3/8-inch OD tube at all three ends. It is different from a reducing tee or a tee with a female pipe-thread outlet.
Check clearance for the nuts, the required tools and the tube routing. A fitting that fits the open space before tubing is connected can become inaccessible once the branch is installed.
Do not choose the branch connection from the connected appliance’s marketing description alone. Confirm the actual inlet and tubing requirements for the complete connection.
Tube outside diameter is not a nominal pipe size
Measure the actual tube outside diameter and identify its material and wall specification. Then match the fitting’s documented size and permitted tubing.
A fraction in a plumbing description can refer to a nominal pipe size, actual tube OD or another component dimension. Read what the maker says the number measures.
Do not force a slightly different tube into a familiar fitting or assume metric and inch dimensions are interchangeable. A close-looking fit is not a verified sealing combination.
Record the measurements with the fitting model so a replacement can be checked against the original application. That is more reliable than taking only an old nut to the store.
A replacement nut must match the body and sleeve
Check the exact nut, sleeve and fitting body as one assembly. Matching the tube size alone does not establish that a nut from another fitting has the correct thread and bearing geometry.
Do not mix an old sleeve with a replacement body merely because the nut threads on. Have the maker identify an approved replacement combination or replace the appropriate complete assembly.
Keep loose replacement components labeled by their actual maker and part number. Nuts and sleeves from different fitting systems can be difficult to distinguish after they are mixed in a parts bin.
For a leaking existing joint, identify the damaged or mismatched component before tightening further. Our compression-leak guide covers that related diagnosis.
PEX and other plastics need the specified components
Do not add an arbitrary insert to make any compression fitting suitable for PEX. Match the exact tubing and the maker’s required sleeve and support arrangement.
The currently linked BrassCraft instructions (d2cl5to9q9oami.cloudfront.net) use different sleeve and insert requirements for different PEX tube ODs. They do not establish a universal “all PEX needs the same insert” rule.
Other manufacturers have different fitting families. Parker’s compression-fitting page (maker page: ph.parker.com/us/en/66c-6-6), for example, identifies an acetal sleeve option for thermoplastic tubing. Do not transfer one family’s component choice to another.
Check the current instructions for the actual part and tubing before choosing any plastic application. If the material or required component cannot be confirmed, use another documented connection system.
Follow the exact assembly and service requirements
The BrassCraft instructions prohibit these compression fittings for gas connections and warn against overtightening. They also exclude thick-wall copper such as Type K from the stated application.
Do not use a generic tightening-by-feel rule or a universal number of turns. Follow the actual fitting and tube instructions, including preparation, support, permitted assembly materials and checking.
Compression nut threads should not be treated as proof of a tapered pipe-thread joint. Do not wrap or coat components by habit; identify where that specific connection seals and what its maker permits.
Our thread tape, pipe dope and putty comparison covers separate sealing products. It does not replace the compression fitting’s own requirements.
Check accessibility and application before closing the work
Confirm the fluid, temperature, pressure, tubing and installation location for the exact fitting. A brass body alone is not evidence of approval for every potable-water, industrial or concealed installation.
For a proposed concealed connection, have the applicable requirements and system instructions checked before closing the wall. This guide does not make a universal claim that all compression joints may, or may not, be concealed.
Keep access for the tools and service the installation actually requires. Avoid routing tubes so they must pull sideways on the fitting to reach their destination.
Save the part identifiers and complete the specified leak checks and return-to-service procedure. A correctly named fitting is the start of selection, not proof that the finished connection has been installed correctly.
Frequently asked questions
Is 3/8-inch compression the same as 3/8-inch nominal pipe?
Do not assume so. The featured elbow is specified for actual 3/8-inch tube outside diameter. Identify what each dimension refers to.
Can any compression nut of the same tube size be reused?
No. Confirm the exact nut, sleeve and body combination. Thread engagement alone does not establish a compatible seal.
Does every PEX compression connection need the same insert?
No. Component requirements depend on the exact fitting and tube size. Use the maker’s matching sleeve and support instructions.
Can these BrassCraft compression fittings be used for gas?
The linked BrassCraft compression instructions expressly prohibit gas connections. Do not transfer an unrelated gas-fitting application to them.
How many turns should every compression nut be tightened?
There is no universal turn count in this guide. Follow the exact fitting and tubing instructions and avoid overtightening.
How we chose
This document-based guide makes no hands-on testing claim. We checked current BrassCraft elbow, tee and reducing-union pages and their linked March 2020 compression instructions, plus Parker’s thermoplastic-sleeve distinction. On October 14, 2026, the linked standard new Amazon offer showed stock with matching model and manufacturer-part fields. Unavailable or conflicting retail examples were excluded. No universal torque, concealed-use or system-pressure approval is assigned. Read our selection method and about Plumbing Picks.
