Press fitting O-rings and seal ratings

I match press fitting O-rings to the fitting size, seal material and approved service before choosing a replacement.

As an Amazon Associate I earn from qualifying purchases. How this site earns

Updated November 15, 2026

Viega 2989 EPDM sealing element for 1/2-inch ProPress fittings
Viega 2989 EPDM seal. Product photo from Amazon.
On this page
  1. The parts
  2. Viega 2989 EPDM
  3. Viega 17778 FKM
  4. Viega 17823 FKM
  5. Compare parts
  6. Listing checks
  7. Seal ratings
  8. Job approval check
  9. Identify the seal
  10. Water and steam
  11. Gas and other media
  12. Model and size reference
  13. Before or after pressing?
  14. Installation checks
  15. Selection worksheet
  16. Seal questions

The short answer

EPDM is the factory-default ProPress seal and the only one Viega’s manual permits for drinking water: Viega 2989 on 1/2-inch fittings. For approved FKM service, use 17778 (3/4-inch) or 17823 (2-inch), before pressing. A seal swap never approves gas service. [1] [2] [3] [5] [9] [10]

Viega ProPress model 2989 shiny-black EPDM sealing element for 1/2-inch fittings
For 1/2-inch drinking-water fittings: Viega 2989 EPDM$16.02 at AmazonPrice as of Nov 22, 2026, 9:30 AM EST · low stock then
Check it on Amazon

Replacement seals for unpressed fittings

Each seal fits one ProPress size and one kind of service, so your line decides, not a score. Only the EPDM ring is permitted for drinking water, and none of them repairs a joint that’s already pressed.13

SealKey specsPick it ifSkip it if
Viega 2989 EPDM seal for 1/2-inch ProPressModel 2989, Part 78242, 1/2-inch fitting size, EPDM, Shiny black, Seal range: 0 to 250°F [1] [9] [10]A 1/2-inch Viega ProPress fitting on a drinking-water or standard heating line lost or nicked its ring before pressing. [1]The specification calls for FKM, the fitting is another size, or the joint has already been pressed.
Viega 17778 FKM seal for 3/4-inch ProPressModel 2986, Part 17778, 3/4-inch fitting size, FKM, Dull black, Seal range: 14 to 284°F [1] [5]The approved application specifies FKM for an unpressed 3/4-inch Viega ProPress CTS fitting, and the listing’s pack quantity suits the job. [1]The line carries drinking water, the fitting is a different size, or the joint has already been pressed.
Viega 17823 FKM seal for 2-inch ProPressModel 2986, Part 17823, 2-inch fitting size, FKM, Dull black, Seal range: 14 to 284°F [1] [5]The application chart and specification permit FKM in an unpressed 2-inch Viega ProPress CTS fitting, with package identity confirmed. [1]The fitting is 2-1/2-inch XL, the line carries drinking water, or you need to repair a permanent pressed connection. [1]
123457910

Viega 2989 EPDM for 1/2-inch water lines

Fitting size and the approved service decide which ring goes in, so none of the three is scored.

Viega ProPress model 2989 shiny-black EPDM sealing element for 1/2-inch fittings
Viega 2989 EPDM seal for 1/2-inch ProPress. Product photo: Amazon.

Model 2989 is Viega’s EPDM sealing element, the shiny-black ring ProPress copper fittings ship with. The listing names Viega, model 2989, EPDM and the 1/2-inch size. Viega’s catalog maps that size to part 78242; the title doesn’t print the part number, so match it on the package. [1] [3] [9] [10]

EPDM is the ring to keep on a drinking-water line. Viega’s ProPress manual permits only EPDM for potable installations, so a domestic hot or cold fitting that loses its ring before pressing gets this element back, not FKM.13

Viega’s seals sheet gives EPDM a 0 to 250°F material range. That covers domestic hot water and most hydronic heating. Viega suggests considering FKM when heating media run at 200°F or above continuously; that advice is for closed heating loops, never the drinking-water side. [1] [2] [3]

Where it does well

  • The only seal Viega’s manual permits for drinking water
  • The factory-default ProPress seal, shiny black
  • Listing names Viega model 2989, EPDM and 1/2 inch

What to watch

  • Listing omits part 78242 and the pack count
  • Material range tops out at 250°F, below FKM’s 284°F
  • New stock from ZenSupplyInc at my current check

Half-inch sits inside Viega’s small-fitting procedure for 1/2 through 2-inch fittings. Lift the old ring out with a blunt object, never a sharp metal pick, and seat the new one fully in the bead. Check the metal seat for scratches and debris while the ring is out. [1] [4]

The listing does not state a pack count. ZenSupplyInc had new stock at my November 15 check. If you need rings for several fittings, confirm the quantity on the order page before you count on it. [1]

My call: if a 1/2-inch ProPress fitting on a water line has a missing or nicked ring before pressing, this is the replacement. A pressed joint can’t be fixed by swapping rings, and no seal swap approves gas service. [1] [2] [4]

Viega 17778 FKM for 3/4-inch fittings

Viega ProPress model 2986 part 17778 FKM sealing element for 3/4-inch fittings
Viega 17778 FKM seal for 3/4-inch ProPress. Product photo: Amazon.

Viega identifies part 17778 as the dull-black FKM element for a 3/4-inch ProPress CTS fitting under model 2986. That is the fitting size, rather than a measured loose-ring diameter. The model names the material family; the article number separates this size from the other rings in that family. [1] [3] [5]

The Amazon title names 17778 and a three-pack. Viega’s model 2986 article table lists a catalog quantity of five for that same part. Treat the maker’s table as the size and material reference, but do not assume the Amazon package contains five. Check the listing quantity and package label before planning how many replacements you need. [1] [4] [5] [9]

The FKM material range is 14 to 284°F. Its separate 356°F thermal-spike allowance lasts 24 hours or less. Neither figure overrides a lower limit in the application chart. For ProPress copper low-pressure steam, for example, FKM is specified at no more than 15 psig and 250°F, with adequate condensate drainage. [1] [2] [3]

Where it does well

  • Maker maps part 17778 to 3/4-inch ProPress CTS fittings
  • FKM option for documented nonpotable applications
  • Published continuous and short-duration temperature limits

What to watch

  • Not permitted for drinking water under the ProPress manual
  • Amazon title says three-pack; maker catalog quantity is five
  • Does not repair an already pressed joint

For a closed heating loop, document the fluid as well as its normal temperature. Viega recommends considering FKM when heating media run continuously at 200°F or above. That advice does not apply the same way to domestic hot-water recirculation: drinking water remains subject to the ProPress manual’s EPDM-only rule. [1] [2] [3]

Before pressing a 3/4-inch fitting, use the small-fitting replacement procedure. Viega calls for a suitable blunt object during removal and an undamaged replacement seated fully in the bead. Inspect the metal seat as well as the ring. A new sealing element cannot make a damaged fitting acceptable. [1] [4]

My call: choose 17778 when the specification calls for FKM in a 3/4-inch ProPress fitting. Resolve the three-versus-five quantity difference before relying on the package for several connections. If the service, size or fitting condition is unclear, have the plumber or Viega settle that question before assembly. [1] [3] [5] [9]

Viega 17823 FKM for 2-inch fittings

Viega ProPress model 2986 part 17823 FKM sealing element for 2-inch fittings
Viega 17823 FKM seal for 2-inch ProPress. Product photo: Amazon.

The 2-inch FKM element is part 17823 in Viega’s model 2986 catalog. The Amazon title identifies Viega ProPress, FKM, the 2-inch size and dull-black appearance, but omits the article number. Match the delivered package to the maker’s row before installation. The title alone does not provide every identifier. [1] [3] [5] [9]

Two inches is the upper end of the small-fitting procedure in Viega’s Changing Sealing Elements instructions. The 2-1/2 through 4-inch procedure is separate and involves separator and grip rings. A 2-inch 2986 element is therefore not an alternative to a 2-1/2-inch XL FKM element, even though both materials are FKM. [1] [3] [4] [5]

The material range remains 14 to 284°F at this size. A larger ring does not increase the application rating. On ProPress copper low-pressure steam, retain the 15-psig and 250°F limits and the condensate-drainage condition. Have a mechanical professional confirm steam isolation and safe depressurization before any installed piping is opened. [1] [2]

Where it does well

  • Maker maps part 17823 to 2-inch ProPress CTS fittings
  • Covered by the 1/2 through 2-inch replacement procedure
  • Dull-black FKM identity documented in model 2986

What to watch

  • Not permitted for drinking water under the ProPress manual
  • Listing title omits the maker part number and pack quantity
  • Not interchangeable with a 2-1/2-inch XL element

Compressed air needs an oil check before material selection. Viega’s chart distinguishes concentrations at or below 25 mg/m³ from those above that boundary. FKM appears in the higher-oil ProPress copper row, but the fluid identity and chart conditions still matter. An unknown compressor lubricant cannot be approved from the ring’s dull-black color. [1] [2] [3]

For an unpressed 2-inch fitting, remove the old element with a suitable blunt object and seat the correct undamaged replacement fully in the bead. Avoid metallic pointed or sharp objects. Inspect the fitting for damage or debris before the tube enters; a replacement ring is no cure for a scratched metal seat. [1]

My call: use the 2-inch choice only for a documented FKM application in that exact ProPress size. The listing does not state a pack count, so do not infer five from Viega’s catalog quantity or three from the smaller listing. Keep drinking-water and already-pressed repairs outside this replacement choice. [1] [3] [4] [9]

Compare the three seals

Part and photoUseKey specsFit and limitsBuy
Viega ProPress model 2989 shiny-black EPDM sealing element for 1/2-inch fittingsViega 2989 / 78242Drinking water or standard service before pressing1/2 inch; 0 to 250°F [1]Only seal permitted for drinking water
Title omits part number and pack count
Check it on Amazon
Viega ProPress model 2986 part 17778 FKM sealing element for 3/4-inch fittingsViega 2986 / 17778Approved FKM service before pressing3/4 inch; 14 to 284°F [1] [5]Exact maker size mapping
Three-pack title; catalog quantity five
Check it on Amazon
Viega ProPress model 2986 part 17823 FKM sealing element for 2-inch fittingsViega 2986 / 17823Approved FKM service before pressing2 inches; 14 to 284°F [1] [2]Within small-fitting procedure
Not for drinking water or XL fittings
Check it on Amazon
135910

EPDM is the factory-default ProPress seal and remains the only permitted material for drinking water in the manual. Its shiny-black appearance and 0 to 250°F material range are reference facts. FKM cannot replace that drinking-water approval. Sources: ProPress manual §§2.2.1 and 2.4.5; Seals and Gaskets TD-PP 0522. [1] [3]

Where the listing and maker details differ

PartAmazon listingViega catalogWhat to check
78242, 1/2-inch EPDMTitle states Viega model 2989, EPDM, shiny black and 1/2 inch; no part number or pack count [1] [9]Model 2989; 1/2 inch; shiny black; part 78242 [1] [9] [10]Confirm part 78242 and the pack count on the package. [10]
17778, 3/4-inch FKMTitle states three-packQuantity column: five; 3/4 inch; dull black; part 17778 [1] [5]Use the maker size/material mapping. Do not describe this Amazon offer as a five-pack. Confirm its three-pack quantity.
17823, 2-inch FKMTitle states 2 inches and dull black; no part number or pack count [1]Quantity column: five; 2 inches; dull black; part 17823 [1] [5]Confirm package part 17823. Catalog quantity five does not establish this listing’s pack count. [5]
135910

Source: Viega U.S. catalog, “Viega ProPress sealing element – Model 2986,” Articles, parts 17778 and 17823, and model 2989, part 78242, accessed October 20, 2026. The catalog quantity and an individual seller’s package description can differ. [1] [5] [7] [9] [10]

What each press fitting seal is rated for

These ranges describe Viega’s U.S. sealing elements. EPDM, FKM and HNBR from another maker need that maker’s own data. A matching compound abbreviation does not establish an identical fitting approval.13

Viega sealSeal appearanceMaterial operating rangeAdditional boundary
EPDMShiny black0 to 250°F [1]Only permitted material for the manual’s drinking-water installations
FKMDull black14 to 284°F [1]Thermal spike to 356°F for 24 hours or less; application limits still govern [1] [2]
HNBRYellow−40 to 180°F [1]Model 0687 cannot provide LC-4 gas approval; not for drinking water [1] [6]
1236
Viega seal material limits EPDM0 to 250°F FKM14 to 284°F HNBR−40 to 180°F Bars share a −40 to 284°F scale. Check the application limits separately.
Viega seal material ranges from TD-PP 0522. Application limits can be lower. FKM’s separate 356°F spike allowance lasts 24 hours or less.

The temperature number answers one question: whether the sealing material is within its stated temperature range. The application chart answers a different question: whether the named assembly is permitted for the fluid and operating conditions. Read both before you choose the ring.12

Use the more restrictive applicable boundary. For example, FKM’s 284°F material ceiling does not change the ProPress copper steam row’s 250°F ceiling. The same logic applies at the cold end: an EPDM material rating down to 0°F does not protect water-filled tubing from freezing. [1] [2] [3]

Continuous temperature

Use the system’s normal operating condition when you compare the application and seal limits. A sustained heating load is different from a brief temperature excursion.1

Thermal spike

Viega limits the FKM spike allowance to 24 hours or less. That allowance cannot be used to overwrite a lower limit in the service row. [1] [3]

Unknown operating conditions

Have the designer or Viega check unlisted fluids or conditions outside the published chart. Do not commission a system on a material-temperature figure alone.1

Can this seal approve this job?

Start with the medium and named fitting system. Check its seal requirement and any condition that rules out the installation. The numbers apply only to the stated system and application.1

JobSystemSealService limitsStop ifSource
Drinking waterU.S. ProPress copperEPDMOnly EPDM permitted by the manualFKM or HNBR substitutionManual §2.2.1 [1]
Continuous hot hydronicsProPress copper, approved heating mediumEPDM or FKM per specificationConsider FKM when media run continuously at 200°F or above [1]Treating heating advice as potable-water permissionApplication chart 0926, note 8 [1] [2]
Residential steamProPress copperEPDM or FKM5 psig; maximum 227°F; adequate condensate drainage [1] [2]Using the seal ceiling as the steam ratingChart 0926, steam row and note 5 [1] [2]
Low-pressure steamProPress copperFKM15 psig; maximum 250°F; adequate condensate drainage [1] [2]EPDM substitution or inadequate drainageChart 0926, steam row and note 5 [1] [2]
Natural gas or propane conversionProPress with replacement model 0687 [6]HNBRNot permitted where ANSI/CSA LC-4 approval is required [1]Installing a yellow replacement to claim gas approvalModel 0687 catalog note [6]
Natural gas or propaneMegaPressGHNBR125 psig; −40 to 180°F in listed fuel rows [1] [2]Transferring MegaPressG approval to copper ProPressChart 0926, fuel rows and note 10 [1] [2]
Oil-bearing compressed airProPress copperDepends on oil concentrationChart distinguishes ≤25 and >25 mg/m³; 200 psig; maximum 140°F [1] [2]Unknown carryover oil or incompatible lubricantChart 0926, compressed-air rows [2]
Refrigerant or unlisted chemicalExact purpose-approved system requiredAs specified for that systemA generic seal change provides no documented approvalUsing FKM’s chemical resistance as refrigerant approvalManual §2.3 and project-specific maker approval [1]
12346

Read the named-system column before the seal column. MegaPressG and copper ProPress are separate product systems. Seeing HNBR beside a fuel-gas rating for MegaPressG does not transfer that approval to a ProPress fitting that has been altered with a replacement ring.1234

For compressed air, the concentration of carried oil changes the ProPress copper seal choices in the chart. EPDM is checked in the lower-oil row, but not above 25 mg/m³. FKM and HNBR appear in the higher-oil row. Identify the compressor lubricant as well as its carryover concentration before specifying a seal. [1] [2] [3]

Application source: Viega Commonly Approved Applications, AP-PP-MP-PF 0926. Its footnotes are part of the rating. Systems outside the listed parameters require Viega Technical Services approval. [1] [2]

Ring color, fitting dots and package labels

A green dot on a Viega metal fitting and a black seal inside it can be correct at the same time. The dot is an external identifier; the ring is a separate component. Reading one color as if it described the other is an easy way to misidentify an unused fitting.17

Viega’s sealing-element explainer associates green dots with EPDM, white with FKM and yellow with HNBR on its metal fittings. The actual sealing elements are shiny black, dull black and yellow respectively. Confirm the product line and package rather than choosing a loose replacement by dot color.13479

Where you lookViega identifierWhat to check next
Seal inside the beadShiny black EPDM; dull black FKM; yellow HNBRExact replacement model and fitting size
Dot on a metal fittingGreen EPDM; white FKM; yellow HNBR in Viega’s explainerNamed system and approved service
Bag or packagePart number and size; maker’s identificationMatch the replacement to the fitting specification
A different maker’s ringColor convention may differUse that maker’s document, not the Viega color key
1349

Eurotubi offers green FPM/FKM seals, and its source also lists red FPM/FKM for industrial applications. Viega identifies FKM with dull black seals. These colors belong to particular products and applications; they are not a universal code for every press fitting.138

A listing for a press ring may also describe a tool accessory rather than an elastomer seal. The steel rings used around large fittings during pressing are not replacement sealing elements. Search with the maker’s seal model, fitting size and material to avoid ordering a jaw or actuator accessory by mistake.149

Water and steam need separate checks

On a domestic hot-water recirculation line, the water remains potable. Apply the ProPress manual’s EPDM-only rule for drinking water. A closed heating loop has its own working fluid and specification. Do not let the shared phrase “hot water” merge those two applications.13

For hydronic and chilled-water applications, the chart gives a glycol concentration boundary of 50% or less for ethylene or propylene glycol. The actual mixture and additives still matter. If the system uses an unfamiliar inhibited fluid, have the designer obtain maker confirmation rather than approve it from the glycol percentage alone. [1]

Condition to documentWater or hydronic exampleWhy it changes the decision
Fluid identityPotable water versus closed-loop heating fluidThe drinking-water manual permits only EPDM
MixtureEthylene or propylene glycol at no more than 50% [1]An unknown mixture cannot be matched to the chart row
Duty cycleHeating media continuously at or above 200°F [1]Viega recommends considering FKM for that heating condition
Steam pressure and temperature5 psig / 227°F versus 15 psig / 250°F [1] [2]The higher steam row requires FKM for ProPress copper
Condensate handlingAdequate drainage on approved steam entriesA temperature-compatible seal does not solve poor drainage
123

The ProPress copper water rows distinguish a 300-psig system operating rating from a 600-psi water test pressure. A test number is not a continuous service rating. It is also not an instruction to apply that pressure to an existing house system with other components attached. [1]

A mechanical professional should check every component before a steam conversion or repair. The residential and low-pressure steam entries have different limits, and both require condensate drainage. Keep steam isolation, cooldown and safe depressurization with that professional; a replacement-seal purchase is not a steam-work procedure.124

For an installed water or heating repair, have the plumber isolate the supply, let hot components cool and safely relieve trapped pressure before opening piping. Follow the connected equipment maker’s shutdown instructions. Do not open steam equipment or a hot pressurized fitting to inspect its ring.

Fuel gas, refrigerant and chemicals

ProPress HNBR is not a gas conversion

Viega model 0687 explicitly prohibits use in ProPress systems requiring ANSI/CSA LC-4 approval for natural gas or propane. A yellow seal cannot supply the missing system approval. [1] [2] [6]

Refrigerant needs its own fitting approval

Do not specify a copper water fitting for refrigerant because FKM resists some chemicals. Have an HVAC professional identify a fitting system approved for the exact refrigerant and conditions.13

Oil type affects seal selection

The application chart notes that HNBR is not recommended for silicone-based oils. “Oil resistant” is not approval for every lubricant or process fluid.123

For a gas project, give the qualified gas professional the actual fitting model and its listing requirements. A general elastomer description is insufficient. The ProPress replacement restriction remains relevant even if an online seller describes yellow HNBR as a material used in gas equipment.12349

An unlisted chemical mixture needs an application review. Viega’s chart says uses outside its listed applications or parameters must be approved by Technical Services. Supply the chemical name, concentration and operating conditions. A general FKM description cannot settle the compatibility of a particular process stream.123

If you smell fuel gas or suspect a gas leak, leave the area and contact the gas utility or emergency services from a safe location. Do not investigate it by loosening a fitting, operating a press tool or adding a different seal.12

Find the exact model and fitting size

These are maker catalog identifiers for Viega ProPress CTS sealing elements. A model names the family; the part number identifies its size. Catalog quantities are not a statement of what an Amazon package contains.19

Material and familyFitting sizeMaker part numberCatalog reference
EPDM 29891/2 inch [1]78242 [10]Shiny black; standard-size assembly
FKM 29861/2 inch [1]17768 [5]Dull black; standard-size assembly
FKM 29863/4 inch [1]17778 [5]Dull black; standard-size assembly
FKM 29861 inch [1]17788 [5]Dull black; standard-size assembly
FKM 29862 inches [1]17823 [5]Dull black; standard-size assembly
HNBR 06871/2 inch [1]21023 [6]Yellow; LC-4 restriction applies [1]
EPDM 2989XL2-1/2 inches [1]78268 [11]Shiny black; XL assembly
135610

Viega lists the 1/2-inch EPDM part under model 2989 and the 1/2-inch FKM part under model 2986. Those model numbers are not tubing sizes. The complete part number distinguishes a specific size from the broader material and model family. [1] [3] [5] [9] [10]

The larger 2-1/2 through 4-inch ProPress construction includes separator and grip rings. Its replacement procedure is separate from the 1/2 through 2-inch procedure. Do not stretch a smaller replacement or choose a generic ring because it appears close to the groove diameter. [1]

The model 0687 catalog’s LC-4 restriction concerns system approval, regardless of the seal’s yellow color. XL models belong to a different fitting assembly from the smaller 2989 and 2986 families. A shared material name does not establish interchangeability between those assemblies. [1] [5] [6] [9] [10]

When a sealing element can be changed

Before pressing

An undamaged, unpressed fitting can receive the specified Viega replacement seal using the maker’s procedure. Confirm the replacement material is approved for the intended application.14

Damaged fitting or bead

The installation manual says to replace damaged components and not repair them. A new ring cannot establish that a scratched or deformed metal seat is sound.

Already pressed and leaking

Treat the connection as a permanent press joint. Have a plumber diagnose the leak and plan the correct repair. Do not attempt to pull out and exchange the ring in place.

Viega calls the element a static seal: after pressing, it stays in a permanent connection. That distinction explains why a bag of replacement seals is useful during installation, but does not create a routine maintenance interval for completed joints. Do not apply a faucet’s serviceable O-ring procedure to a press fitting.147

The words “changing sealing elements” in the instruction title refer to assembling the correct fitting before pressing. They do not describe opening a completed joint like a union. If removal is needed, my press fitting removal guide covers the separate repair question.1

  1. Confirm the unpressed fitting and service

    Have the licensed installer match the Viega system, size and seal material to the application chart. If an installed line must be opened, first isolate it, allow cooldown and safely relieve pressure under the equipment maker’s instructions.12

  2. For 1/2 through 2-inch fittings, use a blunt object

    The replacement instruction specifies a finger or suitable blunt O-ring pick. Avoid metallic pointed or sharp objects that could damage the seal or bead.14

  3. Seat the undamaged replacement fully

    Install the specified new sealing element into the bead. Check that the entire ring is in the bead before the tube enters the fitting.1

  4. For 2-1/2 through 4-inch fittings, follow the separate procedure

    The grip ring is extremely sharp. Viega calls for gloves or extreme caution. The replacement instruction addresses the separator and grip rings as well as the seal; have the trained installer follow the full sequence.14

The small-fitting instruction is short because its ring can be placed directly in the bead. The XL procedure controls how the sealing element passes the separator and grip rings. These are different assemblies, so the shorter method should never be extended to a larger fitting merely because both use EPDM.134

Viega’s manual requires components to be free of debris and the sealing element to be intact and correctly located. Keep unused fittings clean and dry. If a replacement has been dropped into metal chips, do not insert it and hope the press cycle will compensate for contamination.14

Protect the seal when the tube goes in

Check before pressingMaker’s instructionWhat to avoid
Tube endCut square without deforming the tubeFlame cutters or grease and oil during cutting
Inside and outside edgesDeburr both sides to the proper insertion depthA sharp edge passing through the sealing element
Seal and beadCorrect element, undamaged, fully in the beadA displaced ring or damaged fitting
Insertion markMeasure and mark the required depthGuessing that the tube reached the stop
Press toolingCorrect ProPress jaw or compatible ring and actuatorAssuming every tool that fits the diameter is approved
14

Deburring protects the sealing element as the tube enters. Viega’s manual requires both inside and outside deburring. The manual also warns against pressing over grooves, stamped markings or engravings on the tube surface. A replacement ring cannot make a damaged sealing surface suitable.14

Mark the insertion depth for the exact fitting and size before pressing. My press fitting insertion-depth guide handles those measurements. Watch the mark during assembly so a correct seal is not paired with a tube that has slipped out before the press cycle.1

The seals technical sheet describes a factory-applied H-1 food-grade silicone oil lubricant. That statement does not approve an arbitrary jar of faucet grease, solvent or spray for field use. If lubrication is missing or contamination is suspected, have the installer obtain Viega’s direction for the exact component. [1] [3]

Keep hands and foreign objects clear of the press tool during its cycle, as the ProPress manual warns. Follow the tool maker’s safety and PPE instructions. Metallic piping also needs proper bonding; Viega assigns bonding testing and verification to a qualified electrician.1

What to confirm with the plumber

A useful seal specification identifies the job as well as the part. “Black ProPress O-ring” leaves both material and size unclear. Write down the fitting system and the intended medium before looking at a product photo. That keeps the appearance check from becoming the whole specification.1

Record thisExample of a complete entryWho resolves a missing answer
Fitting identityViega ProPress copper, unpressed, 1/2 inch [1]Licensed plumber
ServicePotable water, rather than simply “hot water”Plumber or system designer
Operating conditionsDocumented normal and maximum temperature and pressureMechanical designer
Replacement2989 EPDM, part 78242, for the documented application [9] [10]Installer with maker catalog
RestrictionsNo gas conversion; no repair of a pressed jointLicensed professional
CommissioningRequired inspections and pressure testing for the whole installationInstaller and local authority
123410

For an unfamiliar heating fluid, add its product name and concentration to that worksheet. For compressed air, add the lubricant identity and oil concentration. Those details let Viega compare the real installation to a chart row instead of offering an answer to a vague description such as “air line.”13

After assembly, Smart Connect helps identify unpressed connections during leak testing. Viega says that check does not replace testing required by local codes and standards. Have the installer carry out the applicable system test; do not use the absence of a visible drip as the only commissioning check.14

Questions about press fitting O-rings

What do the colors on press fittings mean?

In Viega’s metal-fitting explainer, green dots identify EPDM, white dots identify FKM and yellow dots identify HNBR. The actual seals are shiny black EPDM, dull black FKM and yellow HNBR. Read the package and exact fitting identity alongside the colors.1379

Other makers can use different colors. Eurotubi offers green FPM/FKM and also lists red FPM/FKM for industrial applications. The Viega color key cannot identify every loose press seal.138

How long do ProPress sealing elements last?

Viega describes its pressed sealing elements as permanent static seals, rather than routine replacement parts. The actual installation must stay within the approved application and operating conditions. A material-temperature rating does not establish a guaranteed service life for every building.147

If a joint leaks, have the plumber check the fitting and installation. Do not assign a replacement interval from a faucet O-ring or treat a service-life claim as proof that a particular damaged joint is sound.

Can I replace a seal before pressing a fitting?

Yes, where Viega specifies the replacement for that system and application. For 1/2 through 2-inch ProPress fittings, its instructions call for a blunt removal object, followed by an undamaged replacement fully seated in the bead. The larger fitting procedure is separate. [1] [4]

Can I fix a leaking pressed fitting with a new O-ring?

The replacement-seal procedure is for an unpressed fitting. A pressed ProPress joint is a permanent connection. Have a plumber diagnose it and plan the appropriate repair; do not try to extract its seal while leaving the pressed joint assembled.147

Can I swap EPDM for HNBR to use ProPress for gas?

Viega’s model 0687 catalog explicitly prohibits installing its HNBR replacement elements in ProPress systems requiring ANSI/CSA LC-4 approval for natural gas or propane. Have a qualified gas professional select a fitting system with the required approval. Yellow material alone does not provide it. [1] [2] [3] [4] [6]

Can ProPress fittings be used on low-pressure steam?

The Viega application chart lists ProPress copper with FKM for low-pressure steam at 15 psig and a maximum 250°F. Its residential steam entry allows EPDM or FKM at 5 psig and a maximum 227°F. Adequate condensate drainage is required. [1] [2] [3]

Have a mechanical professional confirm the exact steam application and safe isolation. Do not substitute the seal material’s temperature ceiling for the lower service-row limit.12

Does an FKM seal approve a water fitting for refrigerant?

No approval follows from the seal change alone. The fitting system must be approved for the exact refrigerant and operating conditions. Have an HVAC professional confirm the manufacturer’s application documentation before choosing any refrigerant press connection.1

Can burrs or scratches damage the seal?

Viega requires deburring inside and outside the tube and warns against damaged tube surfaces. It also prohibits metallic pointed or sharp objects during seal removal. A correct material cannot compensate for a cut sealing element or a damaged bead.14

Is the substance around a fitting lubricant or a leak?

Viega’s technical sheet describes factory-applied H-1 food-grade silicone oil lubricant. That fact alone cannot identify an unknown substance on an installed joint. Have the installer inspect suspected leakage and carry out the required test; do not assume all moisture is lubricant. [1] [3]

Can heat or oil damage a press fitting seal?

Conditions outside the approved temperature or fluid limits need maker review. Compressed-air seal selection changes with oil concentration, and Viega does not recommend HNBR for silicone-based oils. For work near heat, follow the manual’s joining precautions rather than rely on a material maximum.13

Is a generic O-ring with the same dimensions suitable?

The dimensions alone do not establish material identity or approval. Viega’s replacement instructions call for the applicable sealing element, and its catalog ties model and part numbers to fitting sizes. Use the specified replacement instead of an unmarked ring from a mixed assortment.14

Does a 600-psi water test figure mean 600-psi service?

No. The application chart separates the ProPress copper water operating rating of 300 psig from the 600-psi water test pressure. Have the installer use the required system test and account for all connected equipment; this figure is not a pressure-test instruction for a house. [1] [2]

Why I recommend these seals

I am a licensed journeyman plumber in Georgia. I have installed Viega ProPress, NIBCO Press and ApolloPress copper fittings on real jobs. If I could stock one copper press fitting brand, I would choose Viega ProPress. I match each replacement to the maker’s service restrictions and fitting size.14

How I chose

I read the ProPress manual, application chart, seals technical sheet and replacement instructions. I matched model 2989 part 78242 and model 2986 parts 17778 and 17823 to 1/2-inch, 3/4-inch and 2-inch fittings, then checked the Amazon offers on November 15, 2026. [1] [5] [7] [9] [10]

I give these seals no numerical score because approval is a fit requirement, not a contest. EPDM cannot earn permission for an FKM-only job, and FKM’s higher temperature ceiling cannot override the drinking-water rule.

Linked parts must be genuine Viega, new and in stock. My November 15 check found all three new and in stock: the EPDM ring from ZenSupplyInc, 17778 from KHC Shop and 17823 from Voomi Supply. The 17778 listing’s three-pack differs from the maker’s catalog quantity of five. [1] [5]

The seal limits here come from the named maker documents. My recommendations depend on fitting size and approved service. I checked the current CPSC recall results for Viega; the search returned no matching recalls.

Selection checkRule used
ApplicationMatch the fluid and operating conditions to the named system
Part identityMatch maker model, part number and fitting size
OfferGenuine Viega listing, new and in stock at my November 15, 2026 check [1] [7]
ImageExact Amazon product photo for the listed seal
SafetyRetain service restrictions beside the recommendation
ScoringNone: fitting size and approved service are requirements, not points to average
19

Sources
