Quick answer

Match your control before counting flashes: one flash can mean normal operation or a low flame signal. Use the code lookup below. Smell gas? Leave without operating switches or using a phone inside, then call your gas supplier.

Klein Tools ET05 digital pocket thermometer
Optional ET05: record water temperature$15.56 at AmazonPrice as of Nov 22, 2026, 9:30 AM EST
Check it on Amazon

Match the control before the code

A. O. Smith uses different controls across its water heaters. The light’s color and the brand on the tank don’t identify the correct chart. Match the installed control and the manual supplied for your model and series. If the label and this reference differ, follow the label.

Read the labels before the light Heater model + series + fuel Installed control model + matching manual Chart A Thermopile control Manual 100276479 Table 5, pp. 34–35 Chart B Powered flue damper Manual 100366636 Table 6, p. 21 No match? Use your exact model manual. A similar knob or tank badge is not enough. Read the labels first Heater model, series, fuel Installed control model Matching model manual Chart A Thermopile control Manual 100276479 Table 5, pp. 34–35 Chart B Powered flue damper Manual 100366636 Table 6, p. 21 No match? Use your manual. The tank badge is not enough.
Identification guide, not a wiring diagram. Chart A follows manual 100276479; chart B follows manual 100366636. Appearance alone does not establish compatibility.
Chart A: thermopile control

A standing pilot heats the thermopile that powers this control. Use chart A only when your heater documentation matches A. O. Smith manual 100276479, Table 5, pages 34–35.

Chart B: powered flue damper

Use chart B when the installed powered-damper system and its documentation match manual 100366636, Table 6, page 21. Its bright/dim heartbeat is a normal heating signal.

A different system

A blower-equipped power vent, tankless display, electric thermostat or hybrid screen needs its own model manual. Neither chart below establishes its fault meanings. Stop here if you cannot match the control.

Read the heater model, series, fuel and serial number from its rating plate. Then record the control’s model from a label you can see without dismantling anything. A control changed during an earlier repair makes that second label useful. A familiar-looking knob is not enough to choose between these charts.

Keep the outer and burner doors in place for this first check. Photograph only safely accessible labels. Don’t loosen a gas fitting, pull a wire or move a hot vent to find a number. If a label is unreadable, a qualified technician can identify the installed system before interpreting the flashes.

Stop for these warning signs

Gas odor

Leave the building. Do not light an appliance, operate an electrical switch or use a phone inside. Call the gas supplier from outside; if you cannot reach it, call the fire department. Do not stay to count flashes or try a handheld detector.

Carbon monoxide alarm

Move everyone outside to fresh air immediately. Call 911 or the fire department from outside. Stay outside until emergency responders allow you to return. Do not look for the source or count flashes. If a faulty appliance caused the alarm, keep it off until trained personnel service it.

Overheating or gas that will not stop

Manual 100276479 directs shutting the manual gas supply valve if overheating occurs or gas fails to shut off. Do that only if you can safely identify and reach it. Keep the heater out of use and call qualified service.

Floodwater or a vapor incident

Do not restart a flooded heater or one with submerged gas controls, burner or pilot. Manual 100366636 requires whole-heater replacement in those conditions. Suspected flammable-vapor ignition also needs qualified inspection, not a reset.

Soot or damaged venting

Stop using a heater with soot or a visibly damaged or disconnected vent. Leave vent adjustment and airflow testing to qualified service. Keep combustion-air openings clear; never cover them to change a flash pattern.

Find your flash pattern

Read a whole repeated sequence, including its pauses. Chart A and chart B refer to the two manuals above, not to every A. O. Smith heater. Open the matching pattern for its meaning and the next safe step, or use the side-by-side code table.

No light or a solid light

Chart A: no light can mean an unlit pilot or a thermopile still warming. A solid light follows a recently extinguished pilot while the thermopile cools. Chart B: these two states are not assigned a fault meaning in Table 6; consult its operating instructions.

Record whether someone recently turned the knob OFF. On chart A, use only the heater label’s lighting procedure and waiting period. A dark LED alone does not prove the control needs replacement. Persistent failure needs a technician. Source: 100276479, Table 5, page 34.

One flash, a short idle flash or a heartbeat

Chart A: one flash every three seconds is normal. Chart B: one flash with a three-second pause means low flame signal, although the control continues operating. Its normal idle pattern is a short flash every four seconds; alternating bright/dim means a call for heat.

Watch the timing rather than reporting simply “one blink.” A normal status signal reports control state, not safe outlet temperature or a complete inspection of the heater. Record cold-water symptoms separately. Sources: 100276479 page 34; 100366636 page 21.

Two flashes

Chart A: the lit pilot is not producing the required thermopile output. A weak pilot, loose wiring or a defective thermopile can cause it. Chart B: the damper end switch has failed closed. Those are different diagnostic paths.

On chart A, the manual directs the control knob to OFF. Do not disconnect leads or adjust the pilot. On chart B, leave damper movement, switch testing and wiring to qualified service. Give the technician the exact model and pattern. Sources: Table 5 page 34; Table 6 page 21.

Three flashes

Chart A: three flashes are not listed in Table 5. Chart B: the damper end switch failed open, or the thermal cutout, abbreviated TCO, has locked out. The code identifies alternatives rather than naming a single failed part.

Do not force the damper open or bridge a switch. Record the code and arrange qualified service. If your standing-pilot control shows three flashes, check its own label instead of borrowing this damper meaning. Source: 100366636, Table 6, page 21.

Four flashes

Chart A: the control detected water that was too hot; its burner and pilot shut down. Chart B: the energy cutoff, abbreviated ECO, is in limit lockout. Treat either matched four-flash condition as a safety fault.

Stop use and call qualified service. For overheating, follow the maker’s manual gas-shutoff direction if safely accessible. Do not relight repeatedly to confirm the code. Chart A specifies control replacement after confirmed recurrence. Sources: 100276479 pages 24 and 34; 100366636 page 21.

Five flashes

Chart A: the temperature-sensing thermistor is defective; this manual specifies gas-control replacement. Chart B: flame is detected out of sequence. Five flashes on the powered system do not carry the thermistor meaning from chart A.

For chart A, the manual calls for control OFF and main gas OFF before qualified replacement work. For chart B, stop attempting restarts and call service. A flash count cannot establish the replacement control’s fuel or compatibility. Sources: 100276479 page 35; 100366636 page 21.

Six followed by one, two, three or four

Chart A: none of these compound codes is listed in Table 5. Chart B: 6-1 is retry-limit lockout after failed trial for ignition; 6-2 is recycle-limit lockout with flame loss and end-switch failure; 6-3 is recycle-limit lockout with flame loss; 6-4 is out-of-sequence flame lockout.

Keep both groups in your notes: “six, then two” is not simply eight flashes. These are soft-lockout descriptions, not permission to reset repeatedly. Qualified service must investigate the underlying ignition, flame or switch condition. Source: 100366636, Table 6, page 21.

Seven flashes

Chart A: gas-control failure. Chart B: flammable-vapor-sensor lockout, abbreviated FVS. Seven flashes therefore cannot tell you to buy a gas control until the exact system and its diagnosis are established.

Chart A directs control OFF and main gas OFF before qualified control replacement. For chart B, do not bypass the vapor sensor or relight around gasoline, solvents or other flammable vapors. Suspected vapor ignition requires inspection. Sources: 100276479 pages 34–35; 100366636 page 21.

Eight flashes without a second group

Chart A: this can occur after the knob is turned OFF but the thermopile keeps producing power. It can also indicate a pilot valve stuck open. Chart B: a plain eight-flash meaning is not listed; check for a second group.

Chart A requires main gas OFF and control replacement if the pilot still burns after one minute with the knob OFF. Do not open the burner compartment to investigate; arrange qualified service. Residual light alone is different from persistent flame. Source: 100276479, Table 5, page 35.

Eight followed by one, two, three or four

Chart B only: 8-1 identifies an FVS fault; 8-2 a temperature-sensor fault; 8-3 an electronic fault; 8-4 a gas-control/thermostat fault. None is listed as a compound code in chart A’s Table 5.

Record the second group and request qualified diagnosis. An FVS fault differs from the seven-flash FVS lockout, and an electronic fault does not identify a safe owner repair. Do not erase the evidence with repeated power cycling. Source: 100366636, Table 6, page 21.

“Not listed” means the cited table does not supply that meaning. It does not mean your heater is safe or that its control cannot display another pattern. Match the model-specific manual before using a chart.

Record the pattern without taking anything apart

  1. 1
    Start with the safety check

    If there is gas odor, a CO alarm, soot, flood damage or overheating, follow the stop instructions above. Do not remain beside the heater to make a video or measure anything.

  2. 2
    Read the accessible labels

    Copy the heater model, series, serial number and fuel, plus the installed control model. Keep electrical covers and gas components closed. Use the manual number to choose chart A, chart B or neither.

  3. 3
    Watch the entire repeated sequence

    Note the flash count, the gap between groups and the longer pause before repetition. Include bright/dim behavior. A phone recording can preserve the timing only when the area is safe.

  4. 4
    Write down the operating state

    Record whether the knob was recently turned OFF, whether a pilot is visible through the existing viewport, and whether hot water has changed. Do not remove a door or touch hot surfaces to gather these observations.

  5. 5
    Pass the notes to qualified service

    Use the worksheet below. Ask the technician to confirm manual applicability before part testing. Leave gas pressure, flame adjustment, damper switches and electrical connections to qualified service.

Two flashes on chart A narrow the investigation to thermopile output and its possible causes. They do not prove a new thermopile will solve it. A loose connection and weak pilot appear in the same maker row. Recording a visible pilot and the timing helps service begin with the right checks.

A normal light with cold water is a different complaint from a locked-out control. Note whether all hot taps are affected or only one fixture. Manual 100263112 lists a faulty mixing valve, demand beyond capacity and plumbing problems among possible causes of insufficient hot water. Let a technician separate them before changing the temperature setting.

Useful owner observations

Accessible labels, complete flash sequence, visible pilot through the viewport, recent OFF action and the fixture symptoms. None requires opening the gas or electrical system.

Qualified measurements

Thermopile output, flame sensing, gas pressure, damper end switches and vent performance. The manual’s service instructions and required isolation steps apply; the LED is only the starting evidence.

Optional tools for separate symptoms

You don’t need to buy anything to read a flash code. The ET05 records water temperature, the RWD21 is a local leak alarm, and the CO710 warns of carbon monoxide. None replaces the heater’s safety controls or a qualified diagnosis.

Klein Tools ET05 digital pocket thermometer
For outlet-temperature records

Klein Tools ET05

$15.56 at Amazon
Check it on Amazon
Price as of Nov 22, 2026, 9:30 AM EST
Resideo RWD21 reusable water leak alarm
For a local water-leak warning

Resideo RWD21

$10.99 at Amazon
Check it on Amazon
Price as of Nov 22, 2026, 9:30 AM EST
First Alert CO710 carbon monoxide alarm with digital display
For a carbon monoxide warning

First Alert CO710

$44.49 at Amazon
Check it on Amazon
Price as of Nov 22, 2026, 9:30 AM EST
ToolKey specsPick it ifSkip it if
Klein Tools ET05−40 to 482°F probe range; above 160°F briefly only, Plastic body/sheath: 160°F (71°C) maximum, 3 in. probe, Two LR44 batteries, 0.1°F/°C resolutionYou need a contact thermometer for an outlet-temperature record and can make the observation without scald exposure.You only need to count flashes, or the water is unexpectedly hot and needs immediate service.
Resideo RWD21RWD21 family, Reusable spot detector, Requires 9V battery, sold separately, No Wi-Fi, No automatic shutoffYou want a local water warning, have the required 9V battery (sold separately), and will follow the placement and test instructions.You need remote notifications, automatic shutoff or an explanation for a blinking gas control.
First Alert CO710CO710, electrochemical CO sensor, sealed 10-year battery, 85 dB at 10 ft, CO and temperature display, UL 2034The room with a gas water heater, or a nearby sleeping area, has no working CO alarm.You need a wall-mounted or hardwired alarm; First Alert designs the CO710 to sit on a flat surface.

Klein ET05 for an outlet-temperature record

Each tool answers a different question, so none of them is scored against the others.

Klein Tools ET05 digital pocket thermometer
Klein Tools ET05. Product photo: Amazon.

The Klein Tools ET05 makes sense when your complaint includes changing outlet temperature as well as a light pattern. It measures by contact, so it can supply an actual temperature record instead of a guess based on the control knob. The reading belongs beside your service notes; it does not identify a failed thermistor.

Klein specifies a three-inch steel probe with a −40 to 482°F measurement range. The plastic body and sheath are rated only to 160°F (71°C); only the steel probe tolerates higher temperatures, briefly. Keep the body and sheath below that limit. The display reads Fahrenheit or Celsius; hold keeps a reading visible away from the measurement point.

Use the thermometer only as its instructions allow. Klein warns that the probe is not insulated, requires approved eye protection and other necessary PPE, and directs power off before measurement near energized conductive parts. An outlet-water observation does not call for opening the heater’s electrical compartment or reaching beside its gas burner.

Where it does well

  • Direct-contact readings in Fahrenheit or Celsius
  • Three-inch stainless steel probe
  • Hold function keeps a reading visible

What to watch

  • Uninsulated probe; keep clear of energized equipment
  • Temperature does not diagnose a control fault

Hot water needs its own caution. A. O. Smith’s manual warns that even 120°F water can scald. Keep hands away from hot flow and the heated probe. If water is unexpectedly hot, stop the observation, follow the heater’s safe shutoff instructions and call qualified service. Don’t keep running hot water just to improve your notes.

The ET05 uses two LR44 batteries. Keep those batteries away from children and follow Klein’s battery warnings. The product page gives room-temperature accuracy of ±2.7°F; the instructions specify ±1.8°F from −3 to 302°F. Neither figure means the thermometer is accurate to the display’s 0.1-degree increment.

My call: choose the ET05 for a separate temperature complaint when you actually need a contact thermometer. Use the code lookup without a purchase when the light pattern is your only question. A thermometer cannot clear a four-flash overheat lockout or make an unsafe heater ready to restart.

Resideo RWD21 for a local leak warning

Resideo RWD21 reusable water leak alarm
Resideo RWD21. Product photo: Amazon.

The Resideo RWD21 addresses a different problem from a status light: water escaping near the heater. It is a reusable spot detector for a reader who also found a puddle. It requires a 9V battery, sold separately. It cannot detect gas or determine whether the tank, piping or another fitting is leaking.

Resideo’s RWD21/A specifications explicitly say no automatic shutoff, no Wi-Fi and no push notification. That makes its limits easy to understand. A person must notice and respond to the local warning. If nobody will hear it where the heater sits, this model does not meet your need for an alert while you are away.

Use the alarm’s own placement and test instructions. Keep access to the heater’s gas shutoff, ventilation openings and existing safety labels clear. Do not reach through water to touch a plug or powered appliance. If a leak is near electrical equipment, keep away and have qualified service isolate the hazard before anyone moves the alarm.

Where it does well

  • Reusable water-leak alarm
  • No Wi-Fi connection needed

What to watch

  • No automatic water shutoff
  • No phone push notification
  • Pack quantity needs a listing check

A sounding water alarm does not identify the leak’s source. The heater jacket, nearby pipes and drain arrangement still need inspection. Our leaking-water-heater guide covers that separate symptom. A flash code may coexist with a leak, but this alarm’s response cannot show that a gas control has recovered or that a burner is safe.

The maker’s RWD21/A page has a six-count heading. The checked Amazon title says RWD21 and does not establish the pack quantity. We keep the listing’s exact name and do not promise six alarms. Confirm the quantity shown on Amazon before ordering; a maker’s shipping configuration is not proof of this offer’s contents.

My call: consider the RWD21 when you want a local warning for water and accept that it will not stop the flow. Skip it as a response to a no-light, thermopile or vapor-sensor fault. For those symptoms, model identification and the matching maker instructions are the useful next step.

First Alert CO710 for a CO warning

First Alert CO710 carbon monoxide alarm with digital display
First Alert CO710 carbon monoxide alarm. Product photo: Amazon.

A gas water heater burns fuel and vents its exhaust, so a carbon monoxide alarm belongs near it whatever the status light shows. First Alert’s CO710 uses an electrochemical CO sensor and sounds an 85 dB alarm, measured at 10 feet, when it detects elevated levels. It’s listed to UL 2034, the standard for household CO alarms.

Its power is a sealed 10-year lithium battery. First Alert says there’s no battery to change during the alarm’s life, and an end-of-life warning tells you when to replace the whole unit. The warranty is 10 years, limited. One button tests the alarm and silences it.

The CO710 is built to sit on a shelf or table, not to mount on a wall. Its backlit display can show the room temperature, the current CO level in parts per million and the recent peak. First Alert notes the peak reading can help emergency or hospital staff after a CO incident.

Where it does well

  • Electrochemical sensor, 85 dB alarm
  • Sealed 10-year battery, no battery swaps
  • Shows current and peak CO in ppm
  • Listed to UL 2034; 10-year limited warranty

What to watch

  • Sits on a flat surface; no wall mount
  • Battery isn’t replaceable; replace the unit at end of life
  • Can’t tell you which appliance made the CO
  • One alarm covers one area, not the whole house

If it sounds, the stop box near the top of this page applies: get everyone outside, call 911 or the fire department from there, and don’t go back in until responders say so. Don’t stay to count flashes or look for the source. A faulty appliance stays off until trained personnel have serviced it.

First Alert recommends CO alarms on every floor of the home and in each sleeping room, so one CO710 near the heater is a start, not a whole-house plan. The offer showed new and in stock from Amazon.com on Oct 22, 2026.

Which observation each tool supports

ToolPhotoUseful forLimitBuy
Klein Tools ET05Klein Tools ET05 digital pocket thermometerOutlet-temperature record; 3 in. probeNot a gas-control diagnosisCheck it on Amazon
Resideo RWD21Resideo RWD21 reusable water leak alarmSeparate local water warningNo remote alert or shutoffCheck it on Amazon
First Alert CO710First Alert CO710 carbon monoxide alarm with digital displayCarbon monoxide warning; peak CO readingNot a diagnosis of the heaterCheck it on Amazon

Code meanings side by side

Use this table only after matching the manual. Chart A is Table 5 in 100276479, pages 34–35; chart B is Table 6 in 100366636, page 21. Service directions are conservative owner guidance, not additional manufacturer fault codes.

Observed patternChart A: thermopileChart B: powered damperOwner boundary
No lightPilot unlit or thermopile warmingNot listed in Table 6Record state; exact lighting label only.
Solid lightPilot recently out; thermopile coolingNot listed in Table 6Respect label wait; report persistent symptoms.
One flash, three-second interval/pauseNormal, one every three secondsLow flame signal; continues operatingConfirm control before calling it normal.
Short flash every four secondsNot listed in Table 5Idle; no call for heat or faultNo correction for this matched idle signal.
Alternating bright/dimNot listed in Table 5Call for heat; no faultRecord as a heating state.
Two flashesInsufficient thermopile outputEnd switch failed closedChart A control OFF; service checks either system.
Three flashesNot listed in Table 5End switch failed open or TCO lockoutQualified service; no switch bypass.
Four flashesOvertemperature detectedECO limit lockoutStop use; follow safe gas isolation; call service.
Five flashesDefective thermistorFlame out of sequenceQualified service; chart A control and main gas OFF.
6-1Not listed in Table 5Soft lockout; retry limit; failed ignition trialRecord both groups; qualified diagnosis.
6-2Not listed in Table 5Soft lockout; recycle limit; flame lost; end switch failsRecord both groups; no forced damper movement.
6-3Not listed in Table 5Soft lockout; recycle limit; flame lostRecord both groups; no repeated resets.
6-4Not listed in Table 5Soft lockout; flame out of sequenceQualified service investigates flame sequence.
Seven flashesGas-control failureFVS lockoutChart A control/main gas OFF; no vapor-sensor bypass.
Eight flashes, no second groupThermopile power after OFF; possible stuck pilot valveNot listed as a plain eight-flash codePilot still on after one minute at OFF: safe main gas isolation and service.
8-1Not listed in Table 5FVS fault detectedQualified sensor/circuit diagnosis.
8-2Not listed in Table 5Temperature-sensor fault detectedQualified service; no guessed replacement fit.
8-3Not listed in Table 5Electronic fault detectedQualified service; leave electrical covers closed.
8-4Not listed in Table 5Gas-control/thermostat fault detectedQualified control diagnosis; no owner valve replacement.

Where product details need care

DetailListing or maker pageInstruction or other maker detailWhat we use
ET05 identityAmazon title names ET05; no numeric accuracy claimProduct page: room-temperature accuracy ±2.7°F; instructions: ±1.8°F from −3 to 302°FRange and probe length agree. Keep accuracy contexts separate; use the instructions supplied with your unit.
ET05 resolutionDisplay reads in 0.1°F/°C incrementsResolution is different from accuracyDo not describe it as accurate to 0.1°F.
RWD21 quantityAmazon title: Resideo RWD21 Reusable Water Leak Alarm,WhiteResideo RWD21/A header: White Reusable Water Leak Alarm (6 ct)Pack quantity unconfirmed; no six-pack promise.
RWD21 battery lifeMaker specification displays “2” without a unitNo usable duration establishedNo battery-life claim.

If the pilot is lit but the light stays off

A pilot flame and a working control are separate observations. On the thermopile system in A. O. Smith’s Status Light Does Not Blink bulletin, the flame must heat the thermopile enough to power the control. The bulletin allows up to 90 seconds before the normal blink begins. That time is specific to its documented system.

The same bulletin lists other possible causes besides a failed control: a pilot that is not lit, a thermopile still warming, a tripped thermal switch, wiring problems or a defective thermopile. Its instructions supplement the heater’s own label. They do not authorize you to reset a safety switch on an unidentified model.

What you observeWhat it establishesSafe next step
No visible pilot through the existing viewportThe control may not have a heat source for the thermopileUse only your exact lighting label if safe; otherwise call service.
Pilot visible, LED remains dark after the label’s warm-up intervalControl power or pilot/thermopile heating needs investigationStop repeated attempts and report both observations to service.
Solid light after OFF on chart AThermopile cooling can explain the lightRespect the label’s wait; do not interpret it as a universal fault.
Pilot remains burning with knob OFFPossible stuck-open pilot valve on chart AManual gas isolation if safely accessible and qualified service; do not restart.

The bulletin’s service test calls for a DC range capable of reading 750 millivolts. It uses 350 millivolts as a diagnostic threshold after warm-up. Those are service-test figures, not permission to put probes on an unknown control. Connection state and the subsequent checks matter, so one displayed number cannot settle the entire diagnosis.

A reading below the bulletin’s threshold points toward the pilot/thermopile path; a reading at or above it still requires the bulletin’s further reconnect-and-check step. Let a qualified technician follow that procedure with the specified isolation and lighting precautions. A non-contact AC tester does not substitute for the DC measurement described there.

Thermopile service figures come from Status Light Does Not Blink, Rev2A, page 6. Follow the heater’s model-specific instructions for all lighting, gas isolation and electrical work. No meter purchase is needed to report a dark light.

Why a universal reset is the wrong next step

The word lockout tells you that the control has stopped normal operation; it does not explain why the condition happened. Table 6 distinguishes a flame-out-of-sequence lockout from an end-switch failure and a vapor-sensor lockout. A repeated restart can remove the pattern you need to report without resolving the underlying problem.

For a permitted pilot-lighting attempt, use the instructions physically attached to your heater. The documented chart A procedure includes OFF and a ten-minute waiting period between attempts. Never shorten the label’s wait, relight around flammable vapors or use a tool to force a stiff control knob. Stop and call service if the directions do not match your system.

Never bridge a safety device

Do not jumper a thermal switch, vapor sensor, end switch or limit to make a burner run. Leave sensor and wiring tests to qualified service. A change in the light after bypassing protection would not make the appliance safe.

A successful restart still needs context

Write down the original pattern and what happened before it. If the fault returns, stop repeated attempts and arrange diagnosis. A brief return to a normal light does not establish that a vent, flame or temperature problem is corrected.

Check the model and serial for recalls

A normal flash pattern cannot rule out a recalled burner screen or flame arrestor. Check the data plate even if the light looks normal. These two CPSC notices identify specific groups, rather than every heater with the A. O. Smith name.

CPSC noticeScreening detailsRequired response
19-029, Nov 8, 2018Certain 30-, 40- and 50-gallon Ultra-Low NOx gas heaters; serial prefixes 1115 through 1631; manufactured Apr 8, 2011 through Aug 1, 2016Stop using affected units and contact the maker for recall screening and repair. Prefix alone is not the entire eligibility check.
19-030, Nov 8, 201830-gallon natural-gas G6-UT3030NV; serial prefixes 1805 through 1809Stop using affected units and contact A. O. Smith for the recall repair.

CPSC notice 19-029 concerns torn burner screens and a fire hazard when an affected heater sits directly on combustible flooring. Notice 19-030 concerns a flame arrestor that may not work properly. Neither hazard has to announce itself as a particular flash code. Copy the complete model and serial before asking about recall eligibility.

For 19-030, CPSC’s short product-name field drops the final V, but its detailed description gives G6-UT3030NV. Use the detailed model and serial criteria when asking the maker to check the unit. Do not dismiss a possible match because one letter differs in a shortened heading. Keep a potentially affected heater out of use until that check is complete.

What to tell the technician

Use this as a note template. Record only what you can safely observe; an empty field is better than opening a cover or repeating an unsafe lighting attempt to fill it in.

FieldWrite downWhy it helps
Heater identityFull model, series, serial and fuelSelects the correct manual and recall check.
Installed controlBrand/model from an accessible labelConfirms the actual control rather than the tank badge alone.
Manual matchDocument number and revision if knownPrevents mixing chart A with chart B.
Complete signalGroups, pauses, bright/dim changes and any safe recordingSeparates one-flash timing and compound patterns.
Operating stateRecent OFF action; visible pilot; cold or unusually hot waterDistinguishes cooling states from persistent symptoms.
Safety observationsGas odor, alarm, soot, leak, flood or solvent exposureTells service when normal troubleshooting should stop.
Attempts already madeWhat was done and when; whether fault returnedPreserves the history without another reset.

For example, a useful note says that the label matches manual 100366636 and the light repeats six flashes followed by two. It also says whether hot water stopped and whether anyone has already cycled the control. That is more specific than “eight blinks on an A. O. Smith” and avoids combining two different diagnostic rows.

Keep the serial number in your private service record. If you post a photo publicly to ask about a pattern, crop account paperwork, addresses and other personal details from the frame. A technician can ask for the full serial directly for a recall or parts check; the page does not need you to submit it here.

Questions about A. O. Smith blinking lights

Is one flash on an A. O. Smith water heater normal?

On the thermopile control documented in manual 100276479, one flash every three seconds is normal. On the powered-damper control in 100366636, one flash with a three-second pause means low flame signal. Match the installed control and manual before using either interpretation.

What do four flashes mean?

In chart A, the control detected overheating. In chart B, it means ECO limit lockout. Stop use and arrange qualified service. Follow the maker’s safe gas-shutoff direction for overheating; do not repeatedly relight or bypass the limit to clear the light.

Does seven flashes mean I need a new gas valve?

Chart A identifies control failure and specifies control replacement by qualified service. Chart B identifies a flammable-vapor-sensor lockout. Seven flashes alone cannot select a replacement valve. The heater model, series, fuel and installed control must be checked first.

Why is the status light solid after I turn the heater off?

Manual 100276479 describes a solid light while the thermopile cools after the pilot is extinguished. Respect the lighting label’s wait before any permitted relight. Persistent flame with the knob OFF is a different and unsafe condition that needs gas isolation and qualified service.

What if the pilot is on but there is no blinking light?

On the documented thermopile system, warm-up can take up to 90 seconds. Continued darkness can involve weak pilot heating, a thermopile problem or wiring. Follow the exact heater label and stop repeated attempts if it does not recover. Leave component measurements and burner access to qualified service.

Are 6-2 and eight flashes the same code?

No. The powered-damper table lists 6-2 as a compound recycle-limit code associated with flame loss and end-switch failure. Chart A’s plain eight flashes concern continued thermopile power after OFF or a pilot valve stuck open. Record groups and pauses rather than adding the flashes together.

Can I use this chart for a tankless or electric heater?

Use the manual for that exact tankless, electric or hybrid model. These charts cover only the two cited gas-control systems. A brand name shared with a different heater does not establish matching fault codes.

Should I buy a gas leak detector before calling for help?

No purchase is needed to count a light. If you smell gas, leave without operating switches or using a phone inside and call the gas supplier from outside. A handheld reading is not a reason to remain in the building or restart the heater.

Can a normal light rule out a recall?

No. The CPSC notices above concern particular heater models and serial groups. They describe burner-screen and flame-arrestor hazards, not a normal-light clearance test. Check model and serial eligibility separately and follow the stop-use direction for affected units.

Will the thermometer or water alarm fix the code?

Neither tool clears a fault. The ET05 documents a separate temperature symptom; the RWD21 provides a separate local water warning. A code lookup, matching manual and qualified diagnosis determine what happens next at the heater.

Why trust this reference

Who is responsible

Isaac Daniels, a licensed journeyman plumber in Georgia, owns PlumbingPicks and is responsible for this page. We read A. O. Smith manuals 100276479 and 100366636 for the two control tables. Their document numbers and page locations are listed below so you can check each chart against your heater’s manual.

How we choose

We choose optional tools for a defined observation, using maker specifications and same-day Amazon offer records. The three offers were new and in stock from Amazon.com on Oct 22, 2026, 6:38 AM EDT. None is a repair for a fault code, and tools with different jobs get no score.

We omit gas controls and pilot assemblies because a flash count cannot establish exact replacement compatibility. Recall screening is separate from fault diagnosis. The code meanings come from the listed manuals; installation labels and model-specific instructions remain the authority for your heater.

CheckRule used here
Control applicabilityRequire the installed control and exact heater manual to match before interpreting a code.
Source choiceMaker manuals for diagnostic meanings; CPSC for recall eligibility; maker specifications for tool limits.
Owner/service boundaryOwner observes accessible labels and patterns; qualified service opens, measures, adjusts or replaces components.
Offer fitExact branded model, New condition and in-stock offer; no generic gas-valve recommendation.
ScoringNo numerical score: the thermometer, water alarm and CO alarm do different jobs.

Sources

  • A. O. Smith, Residential Gas Water Heaters instruction manual 100276479 / 2000538798, Table 5, pages 34–35; gas-shutoff and vent warnings, pages 24 and 27. assets.aosmith.com; read Oct 20, 2026.
  • A. O. Smith, Residential Gas FVIR Use & Care Guide 100366636 / 2000622612 Rev A2, February 2023. Table 6 page 21; lighting-label and flood warnings page 17. Read Oct 20, 2026.
  • A. O. Smith, Residential Atmospheric Gas guide 100263112, January 2015, pages 1, 4, 24–25. Emergency, scald, vent and insufficient-hot-water guidance. assets.aosmith.com; read Oct 20, 2026.
  • A. O. Smith University, Status Light Does Not Blink, Rev2A, pages 1–2 and 6. Thermopile warm-up, waiting periods and service-test context. university.hotwater.com; read Oct 20, 2026.
  • Klein Tools, ET05 product specifications and ET05 instructions 1331361 Rev 05/25 A, English page 1. Probe range, body/sheath temperature limit, batteries, resolution, accuracy and PPE warnings. kleintools.com and data.kleintools.com; read Oct 20, 2026.
  • Resideo, RWD21/A product specifications. Reusable; no automatic shutoff, Wi-Fi or push notification; six-count maker heading. customer.resideo.com; read Oct 20, 2026.
  • Resideo, RWD21 Water Leak Alarm, document 08567769790EFS. Reusable spot detector; required 9V battery sold separately. customer.resideo.com; read Oct 20, 2026.
  • First Alert, CO710 Carbon Monoxide Alarm with 10-Year Battery and Digital Temperature Display: description and specifications (electrochemical sensor, 85 dB at 10 ft, UL 2034, 10-year limited warranty). firstalert.com; read Oct 22, 2026.
  • U.S. Consumer Product Safety Commission, Carbon Monoxide Questions and Answers, “What should you do when the CO alarm sounds?” Immediate evacuation, emergency call and reentry clearance. cpsc.gov; read Oct 20, 2026.
  • U.S. Consumer Product Safety Commission, recall notices 19-029 and 19-030, November 8, 2018. Heater model/serial eligibility and stop-use remedies. cpsc.gov; checked Oct 20, 2026. Recall title searches for First Alert and CO710 on saferproducts.gov, Oct 22, 2026, found none for the CO710.
  • Amazon, Oct 22, 2026, 6:38 AM EDT: the Klein Tools ET05, the Resideo RWD21 and the First Alert CO710; seller Amazon.com, new, in stock. Images read Oct 20 and 22, 2026.
