For six settings at 2.5 gpm, pick the Pfister HydroFuse 015-HF01. For a 1.75 gpm fixed head, pick the Universal 015-WS2-UT01. For a handheld, pick the HydroFuse 016-WS2-HF01. For a rain head plus handheld, pick the 020-HFM01 combo.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares four Pfister shower heads using Pfister’s own spec sheets.
Pfister shower heads compared (Pfister spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Type | Flow | Functions | Face / hose |
|---|---|---|---|---|
| HydroFuse 015-HF01GS | Fixed head | 2.5 gpm | 6 | 5-9/16 in. face |
| Universal 015-WS2-UT01K | Fixed head | 1.75 gpm | 5 | 4-13/16 in. face |
| HydroFuse 016-WS2-HF01SDB | Handheld kit | 1.75 gpm | 6, with pause | 60 in. metal hose |
| HydroFuse 020-HFM01GS | Rain head plus handheld | 2.5 gpm | Rain head 1; handheld 6 | 60 in. metal hose, 3-way diverter |
HydroFuse and Universal are Pfister shower head collections. All four sheets list easy-to-clean nozzles and a limited lifetime warranty, and none includes the shower arm or flange, so they thread onto the arm you already have. Pfister’s Spot Defense finish, which Pfister says resists spots and fingerprints, applies to the GS and SDB finishes on the HydroFuse sheets.
Pfister HydroFuse 015-HF01GS: six-function fixed head
Choose the HydroFuse 015-HF01 for a fixed head with six settings where 2.5 gpm is allowed. Pfister’s spec sheet (pfisterstorage.blob.core.windows.net) lists 2.5 gpm, six functions (full spray, full and massage combo, massage, pause, HydroFuse and a HydroFuse and full combo), easy-to-clean nozzles, a 1/2-14 NPSM connection and no arm or flange. The drawing shows a 5-9/16-inch face and a 3-1/16-inch depth. Finishes listed are polished chrome, Spot Defense brushed nickel (GS), Spot Defense matte black (SDB) and Tuscan bronze.
Some states limit shower heads below 2.5 gpm, so check your local rule first. On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model 015HF01GS, Spot Defense brushed nickel.
Check Pfister HydroFuse 015-HF01GS shower head on Amazon →
Pfister Universal 015-WS2-UT01K: 1.75 gpm, five functions
Choose the Universal 015-WS2-UT01 for a WaterSense-certified 1.75 gpm head that fits most arms. Pfister’s spec sheet (pfisterstorage.blob.core.windows.net) lists 1.75 gpm, five functions (full spray, massage, combo, rinse and drench), easy-to-clean nozzles, no arm or flange, a 1/2-14 NPT connection and EPA WaterSense and CEC/CALGreen marks. Pfister lists an optional 941-055 insert to drop it to 1.5 gpm. The drawing shows a 4-13/16-inch face and a 3-7/16-inch depth. Finishes are matte black, polished chrome and brushed nickel.
On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model 015WS2UT01K, brushed nickel.
Check Pfister Universal 015-WS2-UT01K shower head on Amazon →
Pfister HydroFuse 016-WS2-HF01SDB: handheld kit
Choose the HydroFuse 016-WS2-HF01 if you want a handheld on a hose, at 1.75 gpm. Pfister’s spec sheet (pfisterstorage.blob.core.windows.net) lists a handshower kit at 1.75 gpm with a 60-inch metal hose, six functions including pause, a pause button, easy-to-clean nozzles, no arm or flange, and EPA WaterSense and CEC/CALGreen marks. The drawing shows a 4-3/4-inch spray face and a 10-1/2-inch overall handheld length.
Pfister calls it a handshower kit. The drawing shows the 60-inch hose with 1/2-14 NPSM connections at both ends and a separate holder bracket that mounts at the shower arm. As drawn, the handheld takes the place of your fixed head rather than adding to it. If you want both a fixed head and a handheld, the 020-HFM01 combo below is the one with a separate rain head and a diverter.
On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 016WS2HF01SDB, Spot Defense matte black. Our handheld shower head guide compares other brands.
Check Pfister HydroFuse 016-WS2-HF01SDB handheld shower on Amazon →
Pfister HydroFuse 020-HFM01GS: rain head and handheld combo
Choose the HydroFuse 020-HFM01 combo if you want a rain head and a handheld on one arm. Pfister’s spec sheet (pfisterstorage.blob.core.windows.net) lists 2.5 gpm, a single-function raincan showerhead, a six-function handheld with a pause button, a 3-way diverter, MagnePfit magnetic docking for the handheld, a 60-inch metal hose, easy-to-clean nozzles and no arm or flange. The drawing shows a 16-7/8-inch overall height for the assembly, with a 10-1/8-inch handheld and 1/2-14 NPSM connections.
On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model 020HFM01GS, Spot Defense brushed nickel.
Check Pfister HydroFuse 020-HFM01GS shower combo on Amazon →
What the spray settings and features mean
The HydroFuse sheets name six functions: full spray, a full and massage combo, massage, pause, HydroFuse, and a HydroFuse and full combo. HydroFuse is Pfister’s own name for one of the spray patterns; the sheets do not describe it further, so we do not either. Pause stops the spray at the head while the valve stays on.
The handheld kit and the combo also list a separate pause button. The Universal head lists five plainly named settings: full spray, massage, combo, rinse and drench. On the combo, the 3-way diverter selects the rain head, the handheld or both, and MagnePfit is Pfister’s magnetic dock that holds the handheld in place.
Finish codes on the sheets
Pfister ends each model number with a finish code. On these sheets, CC and C are polished chrome, GS is Spot Defense brushed nickel, SDB is Spot Defense matte black, K is brushed nickel, B is matte black, and YY or Y is Tuscan bronze. The Spot Defense finishes are the GS and SDB codes on the HydroFuse sheets. Match the code to your valve trim if you want the same tone, and quote the full model number when you order.
Check these before you order
- Flow limit. The 015-HF01 and 020-HFM01 are 2.5 gpm; the Universal and the 016 handheld are 1.75 gpm. Some states allow 1.8 gpm or less.
- Shower arm. None of the four includes an arm or flange. Check the arm is sound and threads cleanly before you swap heads.
- Combo height. The 020-HFM01 drawing shows a 16-7/8-inch overall height; check head clearance under your shower arm.
- Connection. The HydroFuse sheets list 1/2-14 NPSM and the Universal 1/2-14 NPT; both are the standard shower-arm size.
- Valve. A new head does not fix a shower that will not hold temperature. See our Pfister 0X8 cartridge guide.
Which Pfister shower head should you buy?
Start with your state’s flow rule. Where 2.5 gpm is allowed, the HydroFuse 015-HF01 fixed head or the 020-HFM01 combo give the most settings; the combo adds a handheld on a magnetic dock. Where 1.75 gpm or less is required, the Universal 015-WS2-UT01 or the 016 handheld fit, and the Universal can drop to 1.5 gpm with its insert. To match a full Pfister trim, see our Pfister shower faucet guide. For other brands, see our high-pressure shower head guide.
Frequently asked questions
Do Pfister shower heads include the shower arm?
No. All four sheets say the arm and flange are not included.
What is the flow rate of the Pfister HydroFuse shower head?
2.5 gpm for the 015-HF01 fixed head and the 020-HFM01 combo; 1.75 gpm for the 016-WS2-HF01 handheld.
Can I lower the flow on the Pfister Universal head?
Yes. Pfister lists a 941-055 insert for 1.5 gpm.
How long is the HydroFuse handheld hose?
60 inches, metal, per Pfister.
Does the HydroFuse combo have magnetic docking?
Yes. Pfister lists MagnePfit magnetic docking.
How we chose
This document-based guide makes no hands-on testing claim. We read and rendered Pfister’s spec sheets for the HydroFuse 015-HF01, Universal 015-WS2-UT01, HydroFuse 016-WS2-HF01 and HydroFuse 020-HFM01. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Pfister HydroFuse 015-HF01 spec sheet (pfisterstorage.blob.core.windows.net): 6 functions, 2.5 gpm, 5-9/16 face.
- Pfister Universal 015-WS2-UT01 spec sheet (pfisterstorage.blob.core.windows.net): 5 functions, 1.75 gpm, 941-055 insert.
- Pfister HydroFuse 016-WS2-HF01 spec sheet (pfisterstorage.blob.core.windows.net): handheld, 60 in. hose, 1.75 gpm.
- Pfister HydroFuse 020-HFM01 spec sheet (pfisterstorage.blob.core.windows.net): combo, MagnePfit, 3-way diverter.
