Spot a failed tube, find its length and swap it safely. Rule out a mixing valve first, then match the water heater dip tube to your heater’s parts list before you order.
As an Amazon Associate I earn from qualifying purchases. Disclosure.
A. O. Smith 100108609 dip tube. Product photo from Amazon.
Quick answer
A cracked or short dip tube lets cold water into the top of the tank, so hot water runs out early. Match your heater’s parts list: A. O. Smith 100108609 for a 52-inch PEX tube, or Camco 11162 for a 48-inch tube on a threaded nipple.
A hot water dip tube carries incoming cold water to the bottom of the tank. When it cracks or breaks off short, cold water enters near the top and dilutes the hot water you draw.
How a whole tube and a broken tube move cold water. Drawing based on the dip tube definition in A. O. Smith’s FY1999 Form 10-K and Bradford White’s note that an out-of-spec tube dilutes hot water with cold.
Hot water runs out early
Bradford White lists an out-of-spec dip tube diluting hot water with cold among the causes of not enough hot water, along with thermostat setting, very cold inlet water, demand, heater size and gas valve calibration.
White plastic bits in aerators
Plumbing & Mechanical reported tiny floating white particles and less hot water as symptoms of the 1990s dip tube failures.
Trouble began right after a new install
A. O. Smith says reversed connections or a melted dip tube usually show up soon after installation. Soldering copper while it’s attached can melt the tube.
Weak flow on the hot side only
A. O. Smith’s manual names melted heat traps or a melted dip tube as primary causes when only the hot side has low pressure.
Gas smell or water near wiring or a burner
Stop here. If you smell gas, don’t light anything, touch switches or use a phone inside; leave and call the gas supplier from a neighbor’s phone. Water near wiring or a burner: keep the heater off and call a licensed plumber.
Parts and supplies for a dip tube swap
Two tubes for two common designs, plus the nipples and thread sealant the inlet work touches. Check every part number against your heater’s parts list first.
Product photo from Amazon.
A. O. Smith 100108609 PEX dip tube
For a 52-inch PEX tube
Key specs
Part 100108609, PEX, 52 in. long, Gasket included, Brand: A. O. Smith
Pick it if
Your heater’s parts list or the A. O. Smith parts lookup for your model and serial calls for 100108609.
Skip it if
Your heater uses a tube fixed to its inlet nipple, a diffuser tube, or a length other than 52 inches.
Tube lengths come from the listing titles and Amazon detail tables read on October 20, 2026, and checked again on November 10, 2026.
Dip tube lengths by maker part number
Gallons don’t tell you the length. These are genuine maker part numbers and the lengths their Amazon listings state, read on October 20, 2026 and again on November 10, 2026.
Lengths as stated in each genuine listing’s title, Amazon read October 20, 2026 and again on November 10, 2026. Most of these listings were low stock or unavailable, so they appear here as reference sizes only.
Maker and part
Diameter or thread
Listed length
Notes in the listing
Stock at my Nov 10 check
Rheem SP11248R
3/4 in. diameter
54-3/4 in.
No material stated
Unavailable
Rheem SP11251R
3/4 in. diameter
54-3/4 in. (one says 54)
Polysulfone; anti-siphon hole
Low stock
Rheem AP12933
1/2 in. diameter, 3/4 in. NPT nipple
53 in.
Tube and nipple together
Low stock
A. O. Smith 100273983
.65 (as listed)
52-1/2 in.
Listing code CE5.5X3/4
Low stock
A. O. Smith 100108609
Not stated
52 in.
PEX, with gasket
Low stock
A. O. Smith 100112695
3/4 in. NPT x 4 in.
40-3/4 in.
PEX, heat trap
Low stock
A. O. Smith 100217958
3/4 x 3 in.
42 in.
Diffuser
Low stock
A. O. Smith 100217961
3/4 x 3 in.
40 in.
Diffuser
Low stock
A. O. Smith 100110992
Not stated
38-1/4 in.
PEX, listed for 75 gallon
Low stock
A. O. Smith 100217962
3/4 x 3 in.
32 in.
Diffuser
Low stock
A. O. Smith 100109784
1 in. NPT
31.44 in.
Polypropylene, diffuser
Low stock
Bradford White (no part number in title)
3 in. nipple
43-1/2 in.
Nipple and tube together
Low stock
Camco 11162
3/4 x 2-1/2 in. nipple
48 in.
Threaded
In stock
GE WS08X23164 / 23222 / 23232
Not stated
24 / 22 / 20 in.
23222 listed for gas heaters
Low stock / In stock / In stock
Look at the A. O. Smith rows. A tube listed for a 75-gallon heater is 38-1/4 inches, shorter than several other A. O. Smith tubes at 40 to 52-1/2 inches. Tank height, inlet location and the maker’s design set the length, so the gallon number on the label can’t pick the part.
Diameter and the top fitting vary too. Rheem lists both 3/4-inch and 1/2-inch tubes, A. O. Smith lists a 1-inch NPT tube, and some tubes come fixed to a 2-1/2, 3 or 4-inch nipple. Those details decide whether the tube even seats in your heater’s inlet.
Find the right length for your heater
Use the heater’s identity first and the old tube second. A photo of a similar tube on a store page is the weakest evidence.
Method
What you need
How reliable
Watch out for
Heater maker’s parts list
Model and serial from the rating plate
Best
Model suffixes change parts; copy every character
Measure the old tube
The tube out of the tank, in one piece
Good
A broken or melted tube reads short
Read the old part number
A label or molding on the nipple or tube
Good if readable
Older numbers may be superseded
Match a store photo
A listing image
Weak
Same look, different length or fitting
The rating plate is the label on the side of the jacket with the model and serial number. Bradford White’s service procedure works from the inlet nipple and dip tube as one assembly, while A. O. Smith’s manual describes pulling the tube after removing the cold inlet connection. That design difference is why the parts list beats a tape measure.
If the old tube comes out whole, measure from the bottom of the nipple or the seating collar to the tip. Note any holes. Bradford White places an anti-siphon hole about 6 inches from the bottom of the nipple and hydro-jets near the bottom of the tube, and a replacement should keep both.
Rule out a mixing valve or crossover first
A failed shower cartridge or mixing valve can make every hot tap lukewarm while the tube is fine. Both makers point you there first.
A. O. Smith’s troubleshooting starts with a faulty thermostatic mixing valve in a faucet or shower control, and tells you to check the temperature at several faucets.
Bradford White says that when a mixing valve is installed and the hot water is too cool, check the mixing valve first. A cross-connection lets cold water push into the hot piping through a failed valve.
1
Check several taps
Run hot at a tub, a kitchen sink and a bathroom sink. If only one fixture is lukewarm, that fixture’s cartridge or mixing valve is the suspect, not the tank.
2
Close the cold inlet valve at the heater
Make sure it actually shuts off; an old gate valve that still passes water will fool this test. This valve feeds the tank. With it closed, the tank can’t be refilled, so hot taps in the house have no supply except what cold water leaks across from somewhere else.
3
Open one hot tap and watch it
Flow should slow and fade as the tank loses pressure. Keep a hand away from the stream; the water can be scalding.
4
Read the result
If the hot tap keeps running steadily, cold water is crossing into the hot side through a fixture. Close fixture stops one at a time until the flow stops; the last one closed is the likely culprit. Many single-handle shower valves have no stops, so if the flow never stops, have a plumber check those valves.
5
Reopen the cold inlet
Open the heater’s cold inlet valve fully before you leave. A. O. Smith lists a partly closed supply valve as a cause of low hot-water pressure.
If the hot tap fades out and every fixture checks fine, move on to the tube. A crossover and a broken tube give the same lukewarm water, and this test is the quickest way to tell them apart.
Replace the dip tube with the maker steps
These steps follow Bradford White’s service procedures for its gas and electric heaters, written for qualified service providers. Your heater’s own manual controls if it differs.
1
Shut off the energy
Gas: turn the gas control knob to OFF. Electric: turn the power OFF at the breaker and confirm it’s off. Bradford White warns that heater parts and stored water may be hot during this work.
2
Shut off the cold supply and vent
Turn off the cold water supply to the heater. Connect a hose to the drain valve and run it to an open drain. Open a nearby hot faucet so the tank can drain.
3
Drain below the inlet
Open the drain valve and let the tank drain to a point below the inlet connection nipple. You don’t need a full drain for the tube; you need the water level under the opening.
4
Disconnect and remove
Disconnect the inlet nipple from the house piping. With a suitable wrench, remove the inlet nipple or dip tube from the heater without damaging the threads.
5
Inspect the old tube
It should be free of cracks and blockage. Hydro-jets near the bottom and the anti-siphon hole about 6 inches below the nipple should be free of any blockage. Cracks, deformation or extra holes aren’t field repairable; replace it.
6
Reinstall with pipe dope
Put the new tube in, use pipe dope on the nipple’s threads, and reconnect the house piping. Close the drain valve and remove the hose.
7
Refill before restarting
Turn the cold supply back on and refill the tank, with a hot faucet open to purge air. Electric: be sure the tank is full of water before power goes back on. Gas: relight using the lighting instruction label.
Don’t solder copper while it’s attached to the heater. A. O. Smith says it can melt the dip tube and heat traps; solder the pipe to an adapter first, then thread the adapter on.
If the nipple comes off without the tube, the tube is still sitting in the tank opening. Twist a large flat screwdriver or a tapered wooden dowel into it and pull straight up.
If the old tube breaks apart, flush the tank before you refill so the pieces don’t end up in the drain valve and faucet aerators. The flushing guide linked below covers the setup.
Plan for the nipple to fight you. Tank fittings that have been in place for years can be tight, and a stripped tank thread is a far bigger repair than a dip tube. If the nipple won’t turn with steady force, stop and call a licensed plumber before the threads in the tank are damaged.
After the refill, run hot water at one tap for a few minutes and check the inlet for drips. Bradford White’s procedure ends with refilling and restarting. Then give the heater a full recovery and test the shower again; a fixed tube should bring back the hot water you had before.
Check the heat traps while the inlet is open
The inlet you open for the tube also holds a heat trap on many heaters. Melted traps cause their own hot-water complaints.
What you find
What the maker papers say
What to do
Hot side has weak flow only
A. O. Smith: melted heat traps or a melted dip tube restrict hot water flow
Replace the heat traps or the tube
Pipes were soldered on the heater
A. O. Smith: soldering while attached can melt traps and the tube
Inspect both; solder to an adapter next time
Inlet nipple and tube are one piece
Bradford White removes the inlet nipple and dip tube together
Replace the assembly; don’t split it
Heat-trap nipples look like a pair
Eastman 60098 listing: blue for cold inlet, red for hot outlet
Keep each nipple on its marked side
Plastic bits in faucet screens
Plumbing & Mechanical: floating white particles reported with failed tubes
Inspect the tube and any plastic trap insert
Plastic in an aerator doesn’t prove the dip tube is the source. Heat-trap inserts are plastic too, and hard white flakes that crumble like chalk are more likely mineral scale. Pull the inlet parts and look at them together, so you replace the part that actually broke down.
For scale, flushing the tank is the related job. My guide to flushing a water heater covers draining sediment, and the same drain hose setup works for the partial drain this repair needs.
Where the listings and the makers disagree
Item
What the listing says
What I found
My call
Camco 11162 pack size
Title: “(25Pk)”
Detail table: Unit Count 1 Count
Treated as one tube; confirm on the order page
Rheem SP11251R length
One listing: 54-3/4 in.; another: 54 in.
Same part number, two lengths
Confirm against Rheem’s parts list
“RHEEM Dip Tube”
No part number or size
Manufacturer field: CAI - RHEEM
Left off: can’t be matched to a heater
“Flared” dip tube set
Copper, 5.4-inch length in the bullets
No part number; length unlike any dip tube above
Left off
“Upgraded replacement… compatible with” tubes
Use Rheem, A. O. Smith or Bradford White part numbers
Not made by those brands
Left off as look-alikes
Brand names in a title don’t make a part genuine. I list only parts whose Amazon detail table names the same brand as the title.
The 1990s dip tube failures, briefly
A batch of 1990s tubes failed early, and A. O. Smith described the case in its own annual report.
Fact
Source
Tubes made, designed or sold by Perfection Corporation, August 1993 to October 1996
A. O. Smith Form 10-K, fiscal 1999
Class action against Rheem, A. O. Smith, Bradford White, American Water Heater, Lochinvar and State
A. O. Smith Form 10-K, fiscal 1999
Settlement covered reimbursement and repair or replacement of the subject tubes
A. O. Smith Form 10-K, fiscal 1999
A national lawsuit said some plastic tubes made by Apcom Inc. and Perfection Corp. between 1993 and 1997 wore out early
Plumbing & Mechanical, April 11, 2000
Reported symptoms: less hot water and tiny floating white particles
Plumbing & Mechanical, April 11, 2000
A heater from that era with these symptoms gets the same inspection as any other. CPSC’s recall database returned no dip tube recall in my November 10 search, and the recalls it lists for A. O. Smith and Rheem cover whole heaters, not replacement tubes.
When to call a licensed plumber
Bradford White writes its service procedure for qualified providers. These are the points where I would stop.
Reasonable to do yourself
The cold inlet valve works, the drain valve opens and closes, the inlet nipple turns with a wrench, and you can shut the gas control or breaker off.
Nipple won’t turn or threads look damaged
Stop before forcing it. A damaged tank thread can’t be fixed by a new tube, and more force can twist the fitting or the tank connection.
Drip at the inlet after refilling
Shut the cold supply, drain below the inlet again and re-dope the threads. If it still weeps, have a plumber check the tank thread.
Gas smell, scorching or water on wiring
Leave the heater off. If you smell gas, don’t touch switches or use a phone inside; leave and call the gas supplier from a neighbor’s phone. Water on wiring needs the breaker off and a qualified electrician or plumber.
Short answers to common dip tube questions, from the maker manuals above.
How do I know if the dip tube in my water heater is bad?
Hot water that runs out much sooner than it used to, with a heater that still recovers, is the main sign. Small white plastic bits in aerators were also reported with the 1990s failures. Rule out a mixing valve and the thermostat or elements first, then pull the inlet and look at the tube.
What is a dip tube in a water heater?
It is the plastic tube that carries incoming cold water from the inlet at the top down to the bottom area of the tank. That way the cold supply doesn’t mix into the hot water at the top of the tank, where the hot outlet draws from.
How do you fix a broken dip tube?
Shut off gas or power and the cold supply, drain the tank below the inlet, remove the inlet nipple or connection, and pull the old tube. Install the replacement your heater’s parts list names, dope the nipple threads, refill fully and restart.
How much does a plumber charge to replace a dip tube?
Rates vary by area and by how stuck the fittings are, so I don’t quote a figure here. Doing it yourself costs the part plus thread sealant; the current part prices are in the picks above. My water heater repair cost guide covers what drives a service bill.
Are water heater dip tubes universal?
No. A hot water heater dip tube is sized to its tank. Genuine maker tubes I found range from 20 to 54-3/4 inches, with 1/2-inch to 3/4-inch tube diameters, 3/4-inch or 1-inch NPT tops, and some fixed to a nipple while others sit on a gasket. Match the heater’s model and serial to its parts list.
Do I have to drain the whole hot water tank?
No. Bradford White’s procedure drains the tank only to a point below the inlet connection nipple. Turn off the energy source first, and refill the tank completely before restoring power or relighting.
Can a dip tube melt?
Yes. A. O. Smith says soldering copper pipe while it is attached to the heater can melt the dip tube and the heat traps. Solder to an adapter first, then thread the adapter onto the heater.
Why does my new heater give lukewarm water?
A. O. Smith says reversed hot and cold connections or a melted dip tube usually show up soon after a new installation. Check that the house hot line connects to the heater’s hot outlet.
Is the anti-siphon hole a defect?
No. Bradford White places an anti-siphon hole about 6 inches from the bottom of the inlet nipple and says it should be free of any blockage. Unintended holes elsewhere are damage and mean the tube needs replacing.
How I pick and why trust me
Why trust me
I’m Isaac Daniels, a licensed journeyman plumber in Georgia. In my 7 years of experience, these are the products I’d install. The symptoms, inspection points and steps on this page come from Bradford White’s service manuals and A. O. Smith’s heater manual, with each step tied to its source.
How I pick
I checked Amazon’s live listings on October 20, 2026 and kept only genuine branded parts sold New and fully in stock. I re-checked the four linked parts on November 10, 2026, and all four were still sold New and in stock. Low-stock and look-alike listings stayed off the buy list. The four parts do different jobs, so they’re listed as a kit with a fit table instead of ranked; fit to your heater matters more than any number.
I checked CPSC’s recall database by brand and found no recall for these parts, last on November 10, 2026. Lengths come from the listings and are flagged where two listings disagree.
