For a standard sink, pick the Moen Align 6190; for low clearance, the 6191; for a vessel, the 6192. For three holes, the TV6193 with valve. For a tub and shower, the T2193EPBN trim.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares five Moen Align bathroom and shower products using Moen’s own spec sheets.
Moen Align bathroom and shower compared (Moen spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Type | Holes | Height | Outlet | Cartridge |
|---|---|---|---|---|---|
| 6190 | Single-handle | 1 (3 with included plate) | 6-3/8 in. | 3-5/16 in. | 1255 |
| 6191 | Low-profile single-handle | 1 (plate sold separately) | 4-7/8 in. body | 2-5/16 in. | 1255 |
| 6192 | Vessel | 1 | 12-3/32 in. | 9 in. | 1255 |
| TV6193 | Two-handle widespread | 3 | Not used here | Not used here | 1234 |
| T2193EPBN | Tub and shower trim | Wall | n/a | n/a | 1222 |
Align is a Moen collection that runs from bathroom faucets to shower trim and kitchen faucets. The kitchen models are covered elsewhere: the Align 7565 pull-down in our Moen kitchen faucet guide and the Align 5923EW MotionSense in our touchless kitchen faucet guide. This page covers the bathroom and shower pieces. The four bathroom faucets list a 1.2 gpm maximum flow, and every sheet lists Moen’s lifetime limited warranty for the original homeowner or purchaser.
Moen Align 6190: single-handle, standard height
Choose the 6190 for a standard single-hole or three-hole bathroom sink. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/6190sp.pdf) lists metal construction, a lever handle with 100 degrees of travel, a metal pop-up drain, red and blue temperature indicators, an optional 3-hole deck plate in the box, 3/8-inch compression supply lines, the 1255 Duralast cartridge and a 1.2 gpm maximum flow.
The drawing shows a 6-3/8-inch height, 3-5/16 inches from the deck to the outlet, a 5-inch reach, a 6-inch optional escutcheon and a 2-1/2-inch maximum deck. Moen says it installs through one hole at least 1-1/4 inches across. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 6190, chrome.
Check Moen Align 6190 single-handle bathroom faucet on Amazon →
Moen Align 6191: low profile
Choose the 6191 for a shallow sink or under a low mirror or medicine cabinet. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/6191sp.pdf) lists the same 1255 cartridge, lever with 100 degrees of travel, metal pop-up drain and 1.2 gpm flow as the 6190, but a shorter body; the 3-hole deck plate is sold separately.
The drawing shows a 4-7/8-inch body height, 2-5/16 inches from the deck to the outlet and a 4-1/2-inch reach. The low outlet leaves less room for filling a cup or rinsing hands under the spout. On October 15, 2026, the standard new offer sold by MI Deals Beyond Belief showed limited stock with model 6191, chrome.
Check Moen Align 6191 low-profile bathroom faucet on Amazon →
Moen Align 6192: vessel sink
Choose the 6192 for a vessel sink that sits on top of the counter. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/6192sp.pdf) lists a tall single-handle vessel faucet with 24-inch flexible supply lines, the 1255 cartridge, a lever with 100 degrees of travel and a 1.2 gpm flow. It does not list a drain in the box; vessel sinks usually need a separate vessel drain.
The drawing shows a 12-3/32-inch height, 9 inches from the deck to the outlet and a 4-1/2-inch reach. Compare the 9-inch outlet with your vessel bowl height so the water clears the rim. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 6192, chrome.
Check Moen Align 6192 vessel bathroom faucet on Amazon →
Moen Align TV6193: two-handle widespread with valve
Choose the TV6193 for a three-hole sink with handles on each side. The “TV” listing pairs the T6193 trim with its valve; Moen’s T6193 trim sheet (maker page: assets.moen.com/shared/docs/product-specifications/t6193sp.pdf) lists the 9000 and 69000 valves, Duralock quick connect installation, 1/2-inch IPS connections, lever handles that rotate 90 degrees to full on, the 1234 Duralast cartridge and a 1.2 gpm flow.
The sheet says it installs through three holes, the spout through at least 1-1/8 inches and the valves through 1-1/4 inches, and lists a service kit for decks 1-1/2 to 3 inches thick. The T6193 sheet lists a lifetime limited warranty to the original consumer purchaser and 5 years in commercial use. On October 15, 2026, the standard new offer sold by eFaucets showed limited stock with model TV6193, chrome.
Check Moen Align TV6193 widespread bathroom faucet with valve on Amazon →
Moen Align T2193EPBN: tub and shower trim
Choose the T2193EP to update a tub and shower that has a Moen Posi-Temp valve. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/t2193sp.pdf) lists trim that includes the showerhead, arm, flange and diverter spout, red and blue temperature markings, a 270-degree handle arc with off at 6 o’clock and maximum hot at 9, and an adjustable temperature limit stop to control maximum hot water temperature.
Moen says the pressure-balancing mechanism holds temperature to within 3 degrees, EP models are limited to 1.75 gpm at 80 psi and WaterSense certified, and the valve uses the 1222 cartridge. The valve is not included. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model T2193EPBN, brushed nickel.
Check Moen Align T2193EPBN tub and shower trim on Amazon →
Which Align height fits your sink?
The three single-handle faucets share the 1255 cartridge and lever, so the real choice is height. The 6191 is the shortest, with its outlet about 2-1/4 inches above the deck; the 6190 is standard at about 3-1/4 inches; the 6192 puts the outlet 9 inches up for a vessel bowl. For a sink set into the counter, pick between the 6190 and 6191 by how much room you want under the spout and what sits above the faucet. For a vessel, the 6192 is the only one tall enough.
If you have three holes and want two handles, the TV6193 widespread includes its valve. For the shower, the T2193EP needs a Moen Posi-Temp valve in the wall; see our Moen trim compatibility guide if you are unsure, or our Moen shower faucet guide for kits with the valve.
Check these before you order
- Sink type. Undermount or drop-in sinks use the 6190 or 6191; vessel sinks the 6192.
- Holes. One hole for the single-handles; three for the TV6193.
- Deck plate. Included with the 6190, sold separately for the 6191.
- Drain. The 6190 and 6191 include a metal pop-up; the 6192 sheet lists none.
- Shower valve. The T2193EP needs a Moen Posi-Temp valve.
- Sellers. Two offers are third-party; check stock.
Which Moen Align should you buy?
For a standard bathroom sink, the 6190. For low clearance, the 6191. For a vessel sink, the 6192. For a three-hole widespread with the valve, the TV6193. For a tub and shower on a Posi-Temp valve, the T2193EPBN trim. For other Moen bath options, see our Moen bathroom faucet guide.
Frequently asked questions
What cartridge does the Moen Align bathroom faucet use?
The 6190, 6191 and 6192 sheets list the 1255 Duralast cartridge; the T6193 widespread lists the 1234.
Does the Moen Align 6190 come with a deck plate?
Yes. The sheet lists an optional 3-hole deck plate included.
How tall is the Moen Align vessel faucet?
The 6192 drawing shows 12-3/32 inches, with the outlet 9 inches above the deck.
Does Moen Align shower trim include the valve?
No. The T2193EP needs a Moen Posi-Temp valve.
What is the flow rate of Moen Align bathroom faucets?
1.2 gpm maximum, per the sheets.
How we chose
This document-based guide makes no hands-on testing claim. We read Moen’s spec sheets for the Align 6190, 6191, 6192, T6193 and T2193 and rendered the single-handle drawings. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Moen Align 6190 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/6190sp.pdf): single-handle, plate included.
- Moen Align 6191 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/6191sp.pdf): low profile.
- Moen Align 6192 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/6192sp.pdf): vessel.
- Moen Align T6193 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/t6193sp.pdf): widespread trim, 9000 valve.
- Moen Align T2193 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/t2193sp.pdf): Posi-Temp tub/shower trim.
