For the widest fit, pick the Delta Saylor 3535 (4 to 16-inch spacing). For a thick counter, the Delta Arvo 35840LF. For a tall spout with its valve in the box, the Moen Gibson TV6142.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares five widespread bathroom faucets using Delta’s and Moen’s own spec sheets.
Widespread bathroom faucets compared (maker spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Spacing range | Max. deck | Valve | Drain |
|---|---|---|---|---|
| Delta Saylor 3535-MPU-DST | 4 to 16 in. | 2-1/4 in. | Built in | Metal push pop-up |
| Delta Woodhurst 3532LF-MPU | 4-1/2 to 16 in. | 1-3/16 in. | Built in | Metal pop-up |
| Delta Arvo 35840LF-SP | 6 to 16 in. | 2-3/8 in. | Built in | Plastic push pop-up |
| Moen Genta LX TV6708BL | Drawn at 10 in. | Not on trim sheet | Included (9000 series) | See listing |
| Moen Gibson TV6142BL | Drawn at 8 in. | 1-1/2 in. | Included (9000 series) | Metal pop-up |
A widespread faucet has three separate pieces, a spout and two handles, mounted in three holes. The spacing is measured from the center of the left hole to the center of the right one; 8 inches is the common size, but many widespreads adjust across a range because the pieces connect with flexible tubes under the counter. A centerset, by contrast, puts all three on one base with holes 4 inches apart; a widespread will not fit that layout unless its range starts at 4 inches, as the Delta Saylor’s does.
Delta Saylor 3535-MPU-DST: widest spacing range
Choose the Saylor 3535 if your holes might be anywhere from 4 to 16 inches apart. Delta’s spec sheet (media.deltafaucet.com) lists 4 to 16-inch centers, the widest range here, so it can even fit a 4-inch three-hole sink. It lists diamond-coated ceramic cartridges, quarter-turn handle stops, 3/8-inch PEX supply tubes, a metal push pop-up drain with overflow, a 2-1/4-inch maximum deck and a 1.2 gpm flow.
On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model 3535-MPU-DST, chrome. Our Delta Saylor guide covers the matching shower trim.
Check Delta Saylor 3535-MPU-DST widespread bathroom faucet on Amazon →
Delta Woodhurst 3532LF-MPU: metal pop-up, optional low-flow aerators
Choose the Woodhurst 3532LF for a standard 8-inch sink and the option of lower flow. Delta’s spec sheet (media.deltafaucet.com) lists 4-1/2 to 16-inch centers, solid brass end valves, interchangeable stems, quarter-turn stops, 1/2-inch NPSM adapters and a metal pop-up drain. It flows 1.2 gpm, and Delta lists optional aerators for 1.0 or 0.5 gpm.
Its 1-3/16-inch maximum deck is the thinnest here, though Delta’s RP10612 kit adds 1 inch. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 3532LF-MPU, chrome.
Check Delta Woodhurst 3532LF-MPU widespread bathroom faucet on Amazon →
Delta Arvo 35840LF-SP: thickest deck allowance
Choose the Arvo 35840LF for a thick stone counter. Delta’s spec sheet (media.deltafaucet.com) lists 6 to 16-inch centers, a solid brass cast spout, quarter-turn stops, interchangeable stems, 1/2-inch NPSM adapters, a plastic push pop-up drain and a 1.2 gpm flow, with a 2-3/8-inch maximum deck, the most of the five.
Holes are 1-3/16 to 1-1/2 inches, and Delta recommends 2-1/2 inches of backsplash clearance. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model 35840LF-SP, SpotShield brushed nickel.
Check Delta Arvo 35840LF-SP widespread bathroom faucet on Amazon →
Moen Genta LX TV6708BL: valve in the box
Choose the Genta LX TV6708 for a modern square look with the valve included. The “TV” listing pairs Moen’s T6708 trim with its valve; Moen’s T6708 sheet (maker page: assets.moen.com/shared/docs/product-specifications/t6708sp.pdf) lists the 9000 and 69000 valves, lever handles that turn 90 degrees to full on, M-Pact compatibility, a 1.2 gpm flow and WaterSense certification.
The drawing, set at 10-inch centers, shows a 5-1/2-inch spout height, 4-5/16 inches from deck to outlet and a 4-3/4-inch reach. On October 15, 2026, the standard new offer sold by Amazon.com showed a delivery date and an add-to-cart button with model TV6708BL, matte black.
Check Moen Genta LX TV6708BL widespread bathroom faucet with valve on Amazon →
Moen Gibson TV6142BL: tall spout, metal drain
Choose the Gibson TV6142 for more room under the spout. The TV listing pairs Moen’s T6142 trim with its valve; Moen’s T6142 sheet (maker page: assets.moen.com/shared/docs/product-specifications/t6142sp.pdf) lists the 9000 and 69000 valves, 1/2-inch IPS connections, a metal pop-up drain, the 1234 cartridge, lever handles that turn 90 degrees and a 1.2 gpm flow.
The drawing, set at 8-inch centers, shows an 8-5/16-inch spout height with 6 inches from the deck to the outlet, the taller of the two Moen drawings, a 5-inch reach and a 1-1/2-inch maximum deck. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model TV6142BL, matte black.
Check Moen Gibson TV6142BL widespread bathroom faucet with valve on Amazon →
How to measure for a widespread faucet
Spacing. Measure from the center of the far-left hole to the center of the far-right hole. Eight inches is common. The three Delta faucets list ranges that include 8 inches; the Moen drawings are shown at 8 and 10 inches, and these Moen trim sheets do not print a spacing range, so confirm yours with Moen before ordering.
Hole size. The Delta sheets list holes from about 1-1/16 to 1-1/2 inches; the Moen sheets list 1-1/8 inches minimum for the spout and 1-1/4 inches for the valves.
Deck thickness. Measure the counter or sink deck at the holes. Thin decks suit any of these; thick stone may rule out the 1-3/16-inch Woodhurst without its extension kit.
Backsplash. Delta recommends 2-1/2 inches of clearance behind its widespreads so the handles and drain rod work.
Valve included or built in?
Delta builds the valves into these widespread faucets, so one box has everything. Moen’s “TV” listings pair separate trim and valve parts, which Moen sells together; the trim sheets name the 9000 and 69000 valves. Both approaches end with a complete faucet. Both Moen trim sheets carry the M-Pact mark and name the same 9000 and 69000 valves. The cartridges differ too: Delta lists its diamond-coated ceramic or rotating-cylinder designs per model, and Moen lists the 1234 for the Gibson.
Check these before you order
- Spacing. Confirm your center-to-center distance falls in the range.
- Deck. 1-3/16 to 2-3/8 inches maximum, depending on model.
- Spout room. 4-5/16 to 6 inches from deck to outlet on the Moen drawings.
- Drain. Metal on most; plastic push pop-up on the Arvo.
- Finish. Match handles and drain finish to the rest of the room.
- Flow. All 1.2 gpm.
Which widespread bathroom faucet should you buy?
For the widest fit range, the Delta Saylor 3535. For a standard sink and optional lower flow, the Delta Woodhurst 3532LF. For a thick counter, the Delta Arvo 35840LF. For a square modern look with the valve in the box, the Moen Genta LX TV6708. For a tall spout with 6 inches under it, the Moen Gibson TV6142. For one-hole sinks, see our single-hole bathroom faucet guide, and for all styles, our bathroom faucet guide.
Frequently asked questions
What is a widespread bathroom faucet?
A three-piece faucet, a spout and two handles, set in three separate holes, usually 8 inches from the left hole to the right.
Will these fit an 8-inch sink?
The three Delta ranges include 8 inches, and the Moen Gibson drawing is shown at 8 inches; the Delta Saylor covers 4 to 16 inches.
What is the difference between widespread and centerset?
A centerset puts the spout and handles on one base with holes 4 inches apart; a widespread uses separate pieces.
Do widespread faucets include the drain?
All five here list a drain; check the listing for the Genta LX.
What flow rate are these widespread faucets?
All five list 1.2 gpm.
How we chose
This document-based guide makes no hands-on testing claim. We read Delta’s spec sheets for the Saylor 3535, Woodhurst 3532LF and Arvo 35840LF and Moen’s T6708 and T6142 trim sheets. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Delta 3535-MPU-DST spec sheet (media.deltafaucet.com): 4-16 in.
- Delta 3532LF spec sheet (media.deltafaucet.com): 4-1/2 to 16 in.
- Delta 35840LF spec sheet (media.deltafaucet.com): 6-16 in., 2-3/8 deck.
- Moen T6708 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/t6708sp.pdf): Genta LX trim.
- Moen T6142 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/t6142sp.pdf): Gibson trim.
