For a home bathroom with hidden plumbing, pick the Kohler Pinoir K-2035-1 with its shroud. For a widespread faucet and a long bowl, pick the ModernLife K-77767-8. For a utility or commercial-style restroom, pick the Greenwich K-2031 or the deeper Soho K-2084.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares four Kohler wall-mount bathroom sinks using Kohler’s own spec sheets.
Kohler wall-mount sinks compared (Kohler spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Sink | Width x projection | Faucet holes | Depth* | Mounting on the sheet |
|---|---|---|---|---|
| Pinoir K-2035-1 | 22 x 18 in. | 1 | 4 in. | Hangers drawn; shroud included |
| ModernLife K-77767-8 | 21-11/16 x 17-3/4 in. | 3, 8 in. widespread | 6-1/2 in. | Anchor holes drawn |
| Greenwich K-2031 | 20-3/4 x 18-1/4 in. | 1, plus soap hole | 3-1/4 in. | Wall hanger included; drilled for concealed arm carrier |
| Soho K-2084 | 20 x 18 in. | 1 | 4-7/8 in. | Drilled for concealed arm carrier |
A wall-mount sink hangs on the wall with no vanity or pedestal under it. That frees floor space and leaves knee room, and Kohler shows a recommended ADA layout on three of these sheets. The trade-off is that the wall has to carry the sink, so the mounting method matters as much as the size. Every sheet lists the KOHLER One-Year Limited Warranty.
Kohler Pinoir K-2035-1: oval sink with shroud
Choose the Pinoir K-2035-1 for a home bathroom where you want the drain and supplies hidden. Kohler’s spec sheet (resources.kohler.com) lists a combination of the K-2028-1 22-inch oval wall-mount basin and the K-2057 sink shroud, a single 1-3/8-inch faucet hole, an overflow, and recommended K-7605-P angle stops and K-8998 P-trap. The drawing shows the sink 22 inches wide and 18 inches from the wall, the rim 34 inches high, an 18 by 12-inch bowl with a 4-inch water depth, hangers on the wall, and a backing centerline 31-3/16 inches above the floor.
It also shows 1/2-inch anchor holes in the basin, 5/16-inch holes in the hangers, and the 3/8-inch hot and cold supplies drawn below the basin inside the shroud area.
The shroud is the piece that sits under the basin around the trap, so less plumbing shows. On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model 2035-1-0, white.
Check Kohler Pinoir K-2035-1-0 wall-mount sink on Amazon →
Kohler ModernLife K-77767-8: longest bowl, widespread
Choose the ModernLife K-77767-8 for a widespread faucet and the longest bowl here, at 20-1/2 inches. Kohler’s spec sheet (resources.kohler.com) lists a rectangular basin with an overflow, three faucet holes on 8-inch centers and a note that it coordinates with other ModernLife products. The drawing shows the sink 21-11/16 inches wide and 17-3/4 inches from the wall, the rim 34 inches high, two anchor holes 12-3/16 inches apart at 32-1/2 inches above the floor, and a 20-1/2 by 11-13/16-inch bowl that Kohler lists as 6-1/2 inches deep.
The supplies are drawn 6 inches apart, 11 inches below the rim. Kohler lists bowl depth on this sheet rather than water depth, so the number is not directly comparable with the other three.
On October 15, 2026, the standard new offer sold by Buildcom showed limited stock with model K-77767-8-0, white. The Amazon listing describes a lifetime warranty; Kohler’s sheet lists one year, and we go by Kohler.
Check Kohler ModernLife K-77767-8-0 wall-mount sink on Amazon →
Kohler Greenwich K-2031: commercial-style, with wall hanger
Choose the Greenwich K-2031 for a utility, shop or high-use restroom sink. Kohler’s spec sheet (resources.kohler.com) says it is made from premium materials that withstand high-volume usage, lists it at 20-3/4 by 18-1/4 inches, includes a wall hanger and is drilled for concealed arm carrier installation. Kohler also lists K-1808-P wall-mount sink brackets as a recommended accessory. The faucet is sold separately.
The technical table lists one 1-3/8-inch faucet hole and a 1-1/4-inch soap or lotion hole, a 3-1/4-inch water depth and a 10 by 15-inch bowl. The top view marks 1-1/4-inch locking device and leveling screw holes for the carrier arms, with the concealed arm holes 8-1/4 inches apart. The drawing shows the rim at 31 inches in its standard installation and 34 inches in the recommended ADA layout. Because the sheet mentions a wall hanger, concealed arm carrier holes and optional brackets, decide on the mounting method with your installer before you order.
On October 15, 2026, the standard new offer sold by Buildcom showed In Stock with model K-2031-0, white.
Check Kohler Greenwich K-2031-0 wall-mount sink on Amazon →
Kohler Soho K-2084: commercial-style, deeper bowl
Choose the Soho K-2084 for a commercial-style sink with a deeper bowl than the Greenwich. Kohler’s spec sheet (resources.kohler.com) lists premium materials that withstand high-volume usage, a 20 by 18-inch size, drilling for concealed arm carrier installation and a faucet sold separately. The technical table shows an 18 by 13-inch bowl with a 4-7/8-inch water depth, one 1-3/8-inch faucet hole and an overflow. The sheet lists white, biscuit and black.
The Soho sheet does not list a wall hanger or bracket, so plan on a concealed arm carrier in the wall. On October 15, 2026, the standard new offer sold by Buildcom showed In Stock with Kohler part 2084-0, white.
Check Kohler Soho K-2084-0 wall-mount sink on Amazon →
Check these before you order
- Backing in the wall. Wall-mount sinks need solid support. The Pinoir drawing marks a backing centerline; the Greenwich and Soho are drilled for a concealed arm carrier. Open walls make this much easier.
- Rim height. Kohler draws the rim at 34 inches for the ADA layouts. You can set it lower for a standard install, as the Greenwich standard drawing shows at 31 inches.
- Faucet drilling. Three sinks take a single-hole faucet; the ModernLife needs an 8-inch widespread faucet. See our single-hole bathroom faucet guide.
- Exposed plumbing. Without a vanity, the trap and supply stops show unless the sink has a shroud like the Pinoir.
- Hole for soap. Only the Greenwich lists a separate soap or lotion hole. On the others, use a wall-mounted or countertop soap dispenser instead.
Home bath or commercial restroom?
The Pinoir and ModernLife sheets read like home bathroom sinks: a shroud on the Pinoir, a widespread faucet and collection matching on the ModernLife. The Greenwich and Soho sheets both say they withstand high-volume usage and are drilled for concealed arm carriers, the kind of mounting used in commercial restrooms. Any of the four can work in a home if the wall support is right. For other brands and the American Standard wall-hung models we cover, see our wall-hung sink guide. For pedestal options in the same collections, see our Kohler pedestal sink guide.
Frequently asked questions
Do Kohler wall-mount sinks come with brackets?
It varies. The Greenwich lists an included wall hanger; the Pinoir drawing shows hangers; the Soho sheet lists none and is drilled for a concealed arm carrier.
How high should a wall-mount sink be?
Kohler draws the rim at 34 inches in its recommended ADA layouts.
Which Kohler wall-mount sink hides the plumbing?
The Pinoir K-2035-1 includes the K-2057 shroud.
Which Kohler wall-mount sink takes a widespread faucet?
The ModernLife K-77767-8, with three holes on 8-inch centers.
What warranty do these Kohler sinks have?
Each sheet lists the KOHLER One-Year Limited Warranty.
How we chose
This document-based guide makes no hands-on testing claim. We read and rendered Kohler’s spec sheets for the Pinoir K-2035-1, ModernLife K-77767-8, Greenwich K-2031 and Soho K-2084. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Kohler Pinoir K-2035-1 spec sheet (resources.kohler.com): basin + K-2057 shroud, 22 x 18, hangers.
- Kohler ModernLife K-77767-8 spec sheet (resources.kohler.com): 8 in. widespread, 6-1/2 deep.
- Kohler Greenwich K-2031 spec sheet (resources.kohler.com): wall hanger, concealed arm, soap hole.
- Kohler Soho K-2084 spec sheet (resources.kohler.com): concealed arm, 4-7/8 depth.
