For a simple lever, pick the Moen Sleek 7864SRS. For hands-free control, the 7864EWSRS MotionSense Wave. For a two-hole sink with the lever in the counter, the 7871SRS.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares three Moen Sleek kitchen faucets using Moen’s own spec sheets.
Moen Sleek kitchen faucets compared (Moen spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Control | Holes | Cartridge | Power |
|---|---|---|---|---|
| 7864SRS | Lever on the faucet body | 1 or 3 (deck plate included) | 1269 ceramic disc | None |
| 7864EWSRS | Lever plus MotionSense Wave sensor | 1 or 3 | 1255 Duralast | 6 AA batteries or optional AC adapter |
| 7871SRS | Separate in-deck lever | 2 | 1255 Duralast | None |
Sleek is a Moen kitchen collection of high-arc pull-down faucets. The three versions here share the same look but differ in how you control them: a lever on the body, a wave sensor, or a separate lever set into the counter. Each sheet lists Moen’s lifetime limited warranty to the original homeowner, 10 years in a multifamily installation and 5 years in a commercial one.
Moen Sleek 7864SRS: standard pull-down
Choose the 7864 for a one-hole or three-hole sink and a simple lever. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/7864sp.pdf) lists metal construction, one or three-hole installation with the deck plate included, flexible supply lines with 3/8-inch compression fittings, Duralock quick connect, a lever that operates with less than 5 pounds of force and 100 degrees of travel, stream or spray modes whether the wand is docked or pulled down, and a 1.5 gpm maximum flow at 60 psi.
The current sheet lists the 1269 ceramic disc cartridge, Power Clean spray, and PowerBoost, which Moen says increases the flow rate at the push of a button, plus the Reflex wand system with a 68-inch braided hose. Moen says the holes must be at least 1-1/2 inches across, and describes the high-arc spout as giving extra room for cleaning and filling large pots. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model 7864SRS, Spot Resist Stainless.
Check Moen Sleek 7864SRS pull-down kitchen faucet on Amazon →
Moen Sleek 7864EWSRS: MotionSense Wave touchless
Choose the 7864EW if you want to start the water with a wave of your hand. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/7864ewsp.pdf) lists two ways to control the faucet, a Wave sensor and the familiar handle, power from 6 AA batteries or an optional AC adapter with power splitter, the Reflex pulldown system with a 68-inch braided hose, Power Clean spray, Duralock quick connect and a 1.5 gpm flow.
It uses the 1255 Duralast cartridge, a lever with 100 degrees of travel and less than 5 pounds of force, and Moen notes the handle is designed to mount on the right side. The drawing shows status indications for AC in use, batteries in use, replace batteries and a connection problem, which help when the sensor stops responding. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model 7864EWSRS, Spot Resist Stainless. For other hands-free options, see our touchless kitchen faucet guide.
Check Moen Sleek 7864EWSRS MotionSense Wave kitchen faucet on Amazon →
Moen Sleek 7871SRS: two-hole with in-deck handle
Choose the 7871 if your sink or counter has two holes, or you want the lever off the spout. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/7871sp.pdf) lists a high-arc pull-down that installs through two holes at least 1-1/4 inches across, with the lever in its own hole. It lists the Reflex pulldown system, a 68-inch braided hose, PowerBoost spray, a 360-degree rotating spout, Duralock quick connect, 100 degrees of handle travel, the 1255 Duralast cartridge and a 1.5 gpm flow.
The sheet describes a pause feature that stops the water as the wand passes over the countertop when filling something outside the sink, and single-button switching between stream and spray. Maximum deck thickness is 2-1/2 inches. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 7871SRS, Spot Resist Stainless.
Check Moen Sleek 7871SRS two-hole kitchen faucet on Amazon →
Lever, sensor or in-deck handle?
Lever on the body (7864). The familiar layout: one lever on the faucet sets flow and temperature. It is the only one of the three with no power source and the simplest to install in one hole.
Wave sensor (7864EW). The sensor turns the water on and off without touching the faucet, while the lever still sets temperature. It needs batteries or the optional AC adapter, so plan where the battery box will sit under the sink; the drawing shows it on a 36-inch cable, and Moen sells the AC adapter with power splitter separately as part 169031. Our touchless guide compares other sensor faucets.
In-deck handle (7871). The lever sits in its own hole, at least 4-3/8 inches from the spout per the drawing. It needs two holes, which suits sinks that already have a second hole you would otherwise cover.
Sizes from the Sleek drawings
Moen marks the drawings “do not scale,” so use the printed numbers.
7864. 15-9/16 inches tall overall, 8-13/16 inches from the deck to the spray outlet, a 7-11/16-inch reach to the outlet and a 10-3/8-inch deck plate.
7864EW. About 16 inches tall (15.96 inches on the drawing), a 2-1/2-inch maximum deck, and a battery holder on a 36-inch cable. Moen lists the AC adapter with power splitter, part 169031, as sold separately.
7871. 15-1/2 inches tall, 8-3/4 inches from the deck to the outlet, a 7-3/4-inch reach, and a separate lever 4-1/8 inches tall, set at least 4-3/8 inches from the spout.
Check the overall height against any cabinet or shelf above the sink, and the outlet height against your tallest pot.
Cartridges and service
The 7864EW and 7871 sheets name the 1255 Duralast cartridge, while the current 7864 sheet names a 1269 ceramic disc cartridge. If you are replacing a cartridge in an older 7864, check the sheet version that matches your unit before ordering; our Moen cartridge guide explains how to tell common Moen cartridges apart. The pull-down hoses use Duralock quick connect fittings; for replacement hoses, see our Moen hose replacement guide.
Check these before you order
- Holes. One or three for the 7864; two for the 7871.
- Power. The 7864EW needs 6 AA batteries or an AC adapter.
- Handle side. Moen says the 7864EW handle mounts on the right.
- Deck. 2-1/2 inches maximum for the 7871.
- Cartridge. 1269 on the current 7864 sheet; 1255 on the others.
- Finish. SRS is Spot Resist Stainless on all three links.
Which Moen Sleek should you buy?
For a simple lever on one or three holes, the 7864SRS. For hands-free on and off, the 7864EWSRS. For a two-hole layout with the lever in the counter, the 7871SRS. For other Moen kitchen faucets, see our Moen kitchen faucet guide.
Frequently asked questions
What cartridge does the Moen Sleek kitchen faucet use?
The current 7864 sheet lists a 1269 ceramic disc cartridge; the 7864EW and 7871 sheets list the 1255 Duralast.
How is the Moen Sleek MotionSense faucet powered?
Moen lists 6 AA batteries or an optional AC adapter with power splitter.
How many holes does the Moen Sleek 7871 need?
Two holes at least 1-1/4 inches across.
What is the flow rate of Moen Sleek faucets?
1.5 gpm at 60 psi on all three sheets.
Does the Moen Sleek 7864 include a deck plate?
Yes. Moen lists the deck plate as included for three-hole installs.
How we chose
This document-based guide makes no hands-on testing claim. We read Moen’s spec sheets for the Sleek 7864, 7864EW and 7871. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button; the powered 7864EW is sold by Amazon.com. Read our selection method and about Plumbing Picks.
Primary sources
- Moen Sleek 7864 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/7864sp.pdf): pull-down, 1269.
- Moen Sleek 7864EW spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/7864ewsp.pdf): MotionSense Wave.
- Moen Sleek 7871 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/7871sp.pdf): two-hole.
