For a one-hole sink, pick the Moen Wynford 4500; for a centerset, the 4505; for a widespread with valve, the TV4520BN. For an M-CORE shower valve, the UT5500BN trim.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares four Moen Wynford products using Moen’s own spec sheets.
Moen Wynford compared (Moen spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Use | Holes | Flow | Cartridge |
|---|---|---|---|---|
| 4500 | Single-handle bathroom | 1 (3 with included plate) | 1.2 gpm | 1255 Duralast |
| 4505 | Two-handle centerset | 3, 4-in. centers | 1.2 gpm | 1234 |
| TV4520BN | Two-handle widespread with valve | 3, widespread | 1.2 gpm | 1234 Duralast |
| UT5500BN | Tub and shower valve trim | Wall, M-CORE valve | Per showerhead | 1213 volume, M-CORE |
Wynford is a Moen bath collection with bathroom sink faucets, shower trim and matching accessories. All three sink faucets are listed at 1.2 gpm with WaterSense certification. The sheets list Moen’s lifetime limited warranty; the 4505 and UT5500 sheets cover the original homeowner, with 10 years multifamily and 5 years commercial, and the 4500 and T4520 sheets the original consumer purchaser with 5 years commercial.
Moen Wynford 4500: single-handle bathroom faucet
Choose the 4500 for a one-hole sink, or three holes using the included plate. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/4500sp.pdf) lists metal construction, flexible supply lines with 3/8-inch compression fittings, a metal pop-up drain, an optional 3-hole deck plate in the box, a lever with 100 degrees of travel, the 1255 Duralast cartridge and a 1.2 gpm maximum flow.
Moen says it installs through one hole at least 1-1/4 inches across. The drawing shows an 8-5/8-inch height, 5 inches from the deck to the outlet, a 4-5/8-inch reach, a 2-1/2-inch square base, a 6-inch deck plate, a 2-1/2-inch maximum deck and 2 inches of recommended clearance to the backsplash so the handle can swing. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 4500, chrome.
Check Moen Wynford 4500 single-handle bathroom faucet on Amazon →
Moen Wynford 4505: two-handle centerset
Choose the 4505 for a standard three-hole centerset sink with two handles. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/4505sp.pdf) lists metal construction, 1/2-inch IPS connections, a metal pop-up drain, lever handles that turn 90 degrees to full on (hot counterclockwise, cold clockwise), the 1234 cartridge and a 1.2 gpm flow.
Moen says it installs through three holes at least 1 inch across, and the drawing shows 4-inch centers, 1/2-inch NPT inlets and a deck from 5/16 to 1-3/16 inches thick. The sheet warns there is more than one version of this model, so compare the drawing with your sink before ordering replacement parts for an older unit. The Amazon title does not use the Wynford name, but its model number 4505 matches Moen’s Wynford centerset sheet. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 4505, chrome.
Check Moen Wynford 4505 centerset bathroom faucet on Amazon →
Moen Wynford TV4520BN: widespread with valve
Choose the TV4520 for a widespread sink if you want the valve in the same box. The “TV” listing pairs the T4520 trim with its valve; Moen’s T4520 sheet (maker page: assets.moen.com/shared/docs/product-specifications/t4520sp.pdf) lists the 9000 and 69000 valves, Duralock quick connect, 1/2-inch IPS connections, lever handles (the T4524 version has cross handles) that turn 90 degrees to full on, hot and cold indicators, the 1234 Duralast cartridge and a 1.2 gpm flow.
Moen says the spout installs through a hole at least 1-1/8 inches across and the valves through 1-1/4-inch holes. The maximum deck is 1-1/4 inches, and Moen lists service kit 175709 for decks 1-1/2 to 3 inches thick. The sheet carries Moen’s M-Pact system mark. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model TV4520BN, brushed nickel.
Check Moen Wynford TV4520BN widespread bathroom faucet with valve on Amazon →
Moen Wynford UT5500BN: M-CORE tub and shower trim
Choose the UT5500 if your shower has, or will have, a Moen M-CORE 3-Series valve. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/ut5500sp.pdf) lists M-CORE 3-Series valve trim with an integrated diverter for the U232 and U362 series valves, which are not included. The lever lifts through 0 to 25 degrees to set volume and turns through 110 degrees from full cold to full hot, with an adjustable temperature limit stop to control maximum hot water temperature.
Moen says the pressure-balancing mechanism holds the selected temperature to within 2 degrees F, lists the 1213 ceramic disk volume control cartridge, and notes the trim is not compatible with back-to-back installations. Moen also states its M-CORE pressure-balance system can meet the ASSE 1016 temperature-variation requirements when tested as low as 1.5 gpm. The second handle is the integrated transfer valve: Moen says it rotates 360 degrees when used with three outlets and 120 degrees with two, with detents at each flow position.
The drawing shows a 6-3/8 by 10-1/8-inch escutcheon, with the two handles 4-1/4 inches apart and reaching about 2-3/4 and 3-1/2 inches out from the finished wall. Moen titles it “M-CORE 3-Series valve trim with integrated diverter,” which is why it has a second control where Posi-Temp single-handle trims have only one. On October 15, 2026, the standard new offer sold by Amazon.com was in stock with model UT5500BN, brushed nickel.
Check Moen Wynford UT5500BN M-CORE shower trim on Amazon →
Which sink faucet: single-handle, centerset or widespread?
Count the sink holes and measure the spacing from the center of the left hole to the center of the right. One hole: the 4500. Three holes in a centerset layout: the 4505, or the 4500 with its deck plate. Three holes spread wider: the TV4520, which comes with its valve. The 4500 uses the 1255 cartridge; the two-handle models use the 1234, which helps when ordering repair parts later, so note the model number from the box.
M-CORE versus Posi-Temp
The Moen shower trims on this site fit two different valve families. The UT5500 is M-CORE trim, and its sheet lists the U232 and U362 series M-CORE valves. Posi-Temp trims, like those in our Moen shower faucet guide, fit Posi-Temp valves instead. If you are replacing trim, check which valve is in the wall first; our Moen trim compatibility guide shows how.
Check these before you order
- Sink holes. One for the 4500; three for the 4505 and TV4520.
- Valve included. The TV4520 includes its valve; the UT5500 does not.
- Shower valve type. UT5500 needs an M-CORE U232 or U362 valve.
- Back-to-back. Moen says the UT5500 is not compatible with back-to-back installs.
- Cartridges. 1255 single-handle, 1234 two-handle, 1213 shower volume.
- Finish. Chrome and brushed nickel links here; match suffixes across the room.
Which Moen Wynford should you buy?
For a one-hole sink, the 4500. For a centerset with two handles, the 4505. For a widespread with the valve, the TV4520BN. For a tub and shower on an M-CORE valve, the UT5500BN. For other Moen bath options, see our Moen bathroom faucet guide.
Frequently asked questions
Does Moen Wynford shower trim include the valve?
No. The UT5500 sheet lists the M-CORE U232 and U362 series valves, sold separately.
What cartridge does the Moen Wynford single-handle faucet use?
The 4500 sheet lists the 1255 Duralast cartridge.
What is the Moen Wynford flow rate?
1.2 gpm maximum for the bathroom faucets.
Is the Moen 4505 a Wynford faucet?
Yes. Moen’s 4505 sheet is titled Wynford two-handle centerset.
Does the Wynford 4500 include a deck plate?
Yes, an optional 3-hole deck plate is included.
How we chose
This document-based guide makes no hands-on testing claim. We read Moen’s spec sheets for the Wynford 4500, 4505, T4520 and UT5500. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Moen Wynford 4500 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/4500sp.pdf): single-handle, 1255.
- Moen Wynford 4505 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/4505sp.pdf): centerset, 1234.
- Moen Wynford T4520 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/t4520sp.pdf): widespread trim, 9000 valve.
- Moen Wynford UT5500 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/ut5500sp.pdf): M-CORE trim.
