For a widespread sink, pick the Moen Weymouth TVS42108 with levers, or the TVS42114 with cross handles. For one hole, pick the S42107. For the kitchen, pick the S73004 pulldown.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares four Moen Weymouth faucets using Moen’s own spec sheets.
Moen Weymouth faucets compared (Moen spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Fits | Reach / height | Max deck | Cartridge |
|---|---|---|---|---|
| TVS42108 lever widespread | 3 holes, 8 to 16 in. | 5-3/4 in. / 7-1/2 in. | 1-1/4 in. (kit to 3 in.) | 1234 Duralast |
| TVS42114 cross widespread | 3 holes, 8 to 16 in. | 5-3/4 in. / 7-1/2 in. | 1-1/4 in. (kit to 3 in.) | 1234 Duralast |
| S42107 single-handle | 1 hole | about 5-9/16 in. / 7-13/16 in. | 2-1/2 in. | 1255 Duralast |
| S73004 pulldown kitchen | 1 hole | about 9 in. / 17 in. | 2-1/2 in. | 1255 Duralast |
Weymouth is a Moen collection with bath and kitchen faucets; the two-handle bridge kitchen faucet, the S73204, is in our bridge kitchen faucet guide and left out here. Each sheet below lists metal construction and a lifetime limited warranty against leaks, drips and finish defects, with shorter terms for commercial use.
Moen Weymouth TVS42108: widespread, lever handles
Choose the Weymouth TVS42108 for a widespread sink with lever handles, valve included. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/ts42114sp.pdf) covers both Weymouth widespreads, the TS42108 with lever handles and the TS42114 with cross handles, paired with the 9000 valve. It lists Duralock quick connect installation, 1/2-inch IPS connections, a metal pop-up waste, a 1234 Duralast cartridge and handles that turn 90 degrees to full on. It installs through three 1-1/8-inch minimum holes on 8- to 16-inch centers.
The drawing shows a 5-3/4-inch reach, a 7-1/2-inch spout height, 5-1/4 inches from deck to aerator and a 1-1/4-inch maximum deck, with service kit 175709 for decks from 1-1/2 to 3 inches. Moen lists ADA compliance for lever handles. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model TVS42108, chrome; the listing says the valve is included.
Check Moen Weymouth TVS42108 widespread faucet on Amazon →
Moen Weymouth TVS42114: widespread, cross handles
Choose the Weymouth TVS42114 for the same widespread faucet with cross handles. The same Moen sheet (maker page: assets.moen.com/shared/docs/product-specifications/ts42114sp.pdf) lists the TS42114 cross-handle version with identical spout dimensions, centers, deck range and cartridge. The drawing shows the cross handle 4 inches tall, the same as the lever. Note that Moen lists the ADA mark for lever handles, so if accessibility matters, pick the TVS42108 instead.
On October 15, 2026, the standard new offer sold by LGM Wholesale showed limited stock with model TVS42114, chrome; the listing says the valve is included.
Check Moen Weymouth TVS42114 cross-handle widespread faucet on Amazon →
Moen Weymouth S42107: single handle
Choose the Weymouth S42107 for a single-hole sink. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/s42107sp.pdf) lists a metal pop-up waste, flexible supplies with 3/8-inch compression fittings that connect directly to the stops, a lever with a 100-degree arc and a 1255 Duralast cartridge. It installs through one 1-1/8-inch minimum hole. The drawing shows a reach of about 5-9/16 inches, a 5-1/2-inch spout height, 5-1/4 inches from deck to aerator, a 7-13/16-inch overall height, a 2-1/2-inch maximum deck and 32-inch supplies, with 2-1/2 inches of recommended wall clearance.
On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model S42107, chrome.
Check Moen Weymouth S42107 single-handle faucet on Amazon →
Moen Weymouth S73004SRS: high-arc pulldown kitchen
Choose the Weymouth S73004 for a matching kitchen faucet with a tall high-arc spout; Amazon describes it as a shepherd’s hook. Moen’s spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/s73004sp.pdf) lists the Reflex pulldown system, Power Boost, Duralock quick connect installation, a metal four-function wand, a 68-inch braided hose, a 360-degree high-arc spout, a lever with a 100-degree arc, a 1255 Duralast cartridge and 1.5 gpm. It installs through one 1-1/2-inch minimum hole.
The drawing shows a 17-inch height, a reach of about 9 inches (8-31/32), 9-3/16 inches from deck to outlet and a 2-1/2-inch maximum deck. Measure the space under any cabinet above the sink. On October 15, 2026, the standard new offer sold by Amazon.com showed In Stock with model S73004SRS, Spot Resist Stainless.
Check Moen Weymouth S73004SRS pulldown kitchen faucet on Amazon →
Kitchen faucet features in plain terms
The S73004 sheet lists a few features with brand names, so here is what each one does according to Moen. Reflex is the pulldown system: Moen says it gives smoother operation, easy movement and secure docking of the wand back into the spout. Power Boost is a button: Moen says it provides boosted water performance with the push of a button.
The metal wand has four spray functions, and Moen says the faucet runs in stream or spray mode with the wand pulled out or docked. The lever needs less than 5 pounds of force to operate, and temperature is set across a 100-degree arc of handle travel. Duralock is Moen’s quick connect installation system. The pulldown uses a 68-inch braided hose, and Moen says the pullout wand gives the maneuverability for cleaning or rinsing while the high arc spout gives height and reach for large pots.
Supply lines and finishes
The bath sheets list 1/2-inch IPS connections on the widespread valves and flexible supplies with 3/8-inch compression fittings on the single-handle S42107, drawn 32 inches long. The kitchen faucet also uses flexible supply lines with 3/8-inch compression fittings. Check your shutoff valves before install day. On Amazon, Weymouth pieces appear in chrome (no suffix), Spot Resist Stainless (SRS), brushed gold (BG), brushed nickel (BN) and polished nickel (NL). Matching the suffix across the kitchen and bath keeps the metal tone the same, and the suffix is part of the part number when you order replacement handles later.
Check these before you order
- Hole pattern. The widespreads need three holes on 8 to 16-inch centers; the S42107 and S73004 need one hole.
- Deck thickness. The widespreads top out at 1-1/4 inches without kit 175709.
- Handle style. Moen lists ADA compliance for lever handles; the cross-handle TVS42114 is the style choice.
- Kitchen clearance. The S73004 stands 17 inches tall.
- Back clearance. Moen recommends 2-1/2 inches behind the S42107.
Which Weymouth faucet should you buy?
For a widespread bathroom sink, the TVS42108 and TVS42114 are the same faucet with different handles, and both come with the valve per the listings. For a single-hole sink, the S42107 matches them. In the kitchen, the S73004 carries the look over with a high-arc pulldown. The sheets also note there is more than one version of some models, so keep the box or model number for parts later. For other Moen collections, see our Moen Banbury guide, our Moen Brantford guide and our Moen kitchen faucet guide.
Frequently asked questions
Do Moen Weymouth widespread faucets include the valve?
The TVS models do; Moen pairs the TS42108 and TS42114 trims with the 9000 valve, and the Amazon listings say valve included.
What is the difference between TVS42108 and TVS42114?
The handles: lever on the 42108 and cross on the 42114; spout and fit are the same.
What cartridge does the Weymouth single-handle use?
The 1255 Duralast cartridge.
How tall is the Weymouth kitchen faucet?
17 inches on the S73004 drawing.
What hole spacing does the Weymouth widespread fit?
8 to 16 inches center to center.
How we chose
This document-based guide makes no hands-on testing claim. We read and rendered Moen’s spec sheets for the Weymouth TS42114/TS42108, S42107 and S73004. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. The S73204 bridge kitchen faucet is covered on a separate page. Read our selection method and about Plumbing Picks.
Primary sources
- Moen Weymouth TS42114/TS42108 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/ts42114sp.pdf): widespread, 9000 valve, kit 175709.
- Moen Weymouth S42107 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/s42107sp.pdf): single handle, 1255.
- Moen Weymouth S73004 spec sheet (maker page: assets.moen.com/shared/docs/product-specifications/s73004sp.pdf): pulldown, Reflex, Power Boost, 17 in.
