For an 8-inch commercial sink, pick the Chicago 786-E35XKABCP (ceramic cartridges, 5-1/4-inch gooseneck) or the 786-GN8AE35ABCP for an 8-inch gooseneck. For a 4-inch lavatory, pick the 895-317XKABCP, or the 802-765ABCP metering faucet for a public restroom. For a mop sink, pick the 897-RCF. Buy by the full model number.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares five Chicago Faucets commercial models by where they are used, using Chicago’s spec sheets.
Chicago Faucets models compared (Chicago spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Type / centers | Spout and flow | Cartridge / handles |
|---|---|---|---|
| 786-E35XKABCP | Deck mount, 8 in. fixed | 5-1/4 in. rigid/swing gooseneck; 1.5 gpm aerator | Ceramic 1/4-turn; 4 in. wristblade |
| 786-GN8AE35ABCP | Deck mount, 8 in. fixed | 8 in. rigid/swing gooseneck; 1.5 gpm aerator | Quaturn compression; 4 in. wristblade |
| 895-317XKABCP | Deck mount, 4 in. fixed | 3-1/2 in. rigid/swing gooseneck; 2.2 gpm aerator | Ceramic 1/4-turn; 4 in. wristblade |
| 802-765ABCP | Deck mount, 4 in. fixed; metering | 2.2 gpm aerator | MVP metering; 2 in. push handles |
| 897-RCF | Wall mount, 8 in. (adjustable) | Service spout with vacuum breaker | Ceramic 1/4-turn; 2-3/8 in. levers |
Chicago Faucets makes commercial faucets; its site groups them into manual, metering and touchless faucets, lab fittings and other fittings. Its model numbers encode the body, spout and options, so buy by the full number; a change in one suffix can mean a different spout, aerator or handle.
Chicago 786-E35XKABCP: 8-inch deck faucet with ceramic cartridges
Choose the 786-E35XKABCP for a commercial sink with 8-inch deck holes where a short gooseneck is enough. The spec sheet (chicagofaucets.com) lists a deck-mounted manual faucet on 8-inch fixed centers, a 5-1/4-inch rigid/swing gooseneck, a pressure-compensating 1.5 gpm Softflo aerator, vandal-proof 4-inch wristblade handles with color-coded index, ceramic 1/4-turn cartridges, and Chicago’s ECAST cast-brass construction. It lists ADA ANSI/ICC A117.1, ASME A112.18.1/CSA B125.1, CALGreen compliance and WaterSense certification.
The Amazon listing title calls it a concealed kitchen sink faucet, but Chicago’s sheet describes a deck-mounted faucet; we rely on the sheet. On October 15, 2026, the standard new offer from eFaucets showed limited stock with model 786-E35XKABCP.
Check Chicago Faucets 786-E35XKABCP 8 in. deck faucet on Amazon →
Chicago 786-GN8AE35ABCP: 8-inch gooseneck for deeper basins
Choose the 786-GN8AE35ABCP when you need a taller spout to fill pots or reach a deep basin. Its spec sheet (chicagofaucets.com) lists the same 8-inch deck body and 1.5 gpm Softflo aerator with an 8-inch rigid/swing gooseneck, 4-inch wristblade handles and Quaturn compression cartridges instead of ceramic. It lists ADA, ASME A112.18.1/CSA B125.1, CALGreen and WaterSense.
On October 15, 2026, the standard new offer from eFaucets showed stock with model 786-GN8AE35ABCP.
Check Chicago Faucets 786-GN8AE35ABCP 8 in. gooseneck faucet on Amazon →
Chicago 895-317XKABCP: 4-inch lavatory gooseneck
Choose the 895-317XKABCP for a lavatory or hand sink with 4-inch centers. The spec sheet (chicagofaucets.com) lists a deck-mounted manual faucet on 4-inch fixed centers, a 3-1/2-inch rigid/swing gooseneck, a 2.2 gpm pressure-compensating Softflo aerator, 4-inch wristblade handles and ceramic 1/4-turn cartridges, with ADA and ASME A112.18.1/CSA B125.1 listed.
Note the flow: check your local code’s maximum lavatory flow before you buy, since a 2.2 gpm aerator may exceed it in some areas.
On October 15, 2026, the standard new offer from Team Pipe & Supply Co. showed stock with model 895-317XKABCP.
Check Chicago Faucets 895-317XKABCP 4 in. lavatory faucet on Amazon →
Chicago 802-765ABCP: metering lavatory faucet
Choose the 802-765ABCP for a public restroom where you want faucets that shut off on their own. The spec sheet (chicagofaucets.com) lists a deck-mounted metering faucet on 4-inch centers with an MVP metering cartridge and actuator, vandal-proof 2-inch MVP metering push handles and a 2.2 gpm Softflo aerator. The listing notes it replaces the 802-665ABCP.
Metering faucets run for a set time after each push. Check your local code’s limits for metering lavatory faucets as well as flow.
On October 15, 2026, the standard new offer from Team Pipe & Supply Co. showed stock with model 802-765ABCP.
Check Chicago Faucets 802-765ABCP metering faucet on Amazon →
Chicago 897-RCF: wall-mount service sink faucet
Choose the 897-RCF for a mop or service sink. Its spec sheet (chicagofaucets.com) lists a wall-mounted faucet with an 8-inch body and arms adjustable from 7-5/8 to 8-3/8-inch centers, integral supply stops, vandal-proof 2-3/8-inch levers, ceramic 1/4-turn cartridges and a vacuum breaker assembly. Our mop sink faucet guide compares it with T&S, Moen and Delta.
On October 15, 2026, the standard new offer from eFaucets showed limited stock with model 897-RCF.
Check Chicago Faucets 897-RCF service sink faucet on Amazon →
Warranties and ratings
All five sheets list a 5-year limited cartridge warranty, a lifetime limited faucet warranty and a 1-year limited finish warranty, a 20 to 125 psi rated operating pressure and a 40 to 140°F rated temperature. They also note compliance with the Buy American Act of 1933, which can matter on some public projects. Record the full model number with your building records so the right cartridge is ordered later.
Ceramic or Quaturn compression?
Chicago lists ceramic 1/4-turn cartridges on the 786-E35XKABCP, 895-317XKABCP and 897-RCF, and Quaturn compression cartridges on the 786-GN8AE35ABCP. Both are quarter-turn designs. Replacement cartridges are left- and right-hand specific per the sheets, so order the matching hand when you service one.
Matching the sink and holes
Handles and aerators
The sheets list three handle styles here: 4-inch vandal-proof wristblade handles on the 786 and 895 models, 2-3/8-inch vandal-proof levers on the 897-RCF, and 2-inch MVP metering push handles on the 802-765ABCP. Wristblade handles are long blades that can be pushed with a wrist or forearm rather than gripped; choose levers or push handles if your sink or code calls for them instead.
The spouted models list pressure-compensating Softflo aerators, 1.5 gpm on the 786 models and 2.2 gpm on the 895 and 802, so flow stays near its rating as pressure changes; confirm the aerator suits your local flow limit.
Count and measure the sink holes before ordering: 8-inch centers for the 786 models, 4-inch centers for the 895 and 802, and a wall-mount 8-inch body for the 897. For kitchen-style use at home, our commercial-style kitchen faucet guide covers residential pre-rinse styles, and our pre-rinse faucet guide covers restaurant units.
Frequently asked questions
Are Chicago Faucets good?
Chicago builds commercial faucets; these five sheets list a lifetime limited faucet warranty, a 5-year cartridge warranty and a 20 to 125 psi rating.
Do Chicago faucets meet ADA requirements?
All five sheets list ADA ANSI/ICC A117.1 among their codes; compliance still depends on how and where the faucet is installed.
Which Chicago faucet is for a lavatory?
The 895-317XKABCP (4-inch gooseneck) or the 802-765ABCP metering faucet, both on 4-inch centers.
Do Chicago faucets use ceramic cartridges?
Some do. The 786-E35XKABCP, 895-317XKABCP and 897-RCF list ceramic 1/4-turn cartridges; the 786-GN8AE35ABCP lists Quaturn compression.
What flow rate are Chicago faucets?
It depends on the aerator: 1.5 gpm on the two 786 models and 2.2 gpm on the 895 and 802, per the sheets.
How we chose
This document-based guide makes no hands-on testing claim. We read Chicago Faucets’ current spec sheets for the 786-E35XKABCP, 786-GN8AE35ABCP, 895-317XKABCP, 802-765ABCP and 897-RCF. On October 15, 2026, all five linked standard new offers showed stock or limited stock from eFaucets or Team Pipe & Supply Co. One 895-317ABCP listing was excluded because its part number did not match. Read our selection method and about Plumbing Picks.
Primary sources
- Chicago 786-E35XKABCP spec sheet (chicagofaucets.com): 8 in. deck, 5-1/4 in. gooseneck, 1.5 gpm, ceramic, wristblades, ratings, warranties, codes.
- Chicago 786-GN8AE35ABCP spec sheet (chicagofaucets.com): 8 in. deck, 8 in. gooseneck, 1.5 gpm, Quaturn compression.
- Chicago 895-317XKABCP spec sheet (chicagofaucets.com): 4 in. deck, 3-1/2 in. gooseneck, 2.2 gpm, ceramic.
- Chicago 802-765ABCP spec sheet (chicagofaucets.com): 4 in. deck metering, MVP cartridge, 2 in. push handles, 2.2 gpm.
- Chicago 897-RCF spec sheet (chicagofaucets.com): wall mount, adjustable arms, integral stops, VB assembly.
