For a three-hole widespread, pick the Delta Ara 3567-BLMPU-DST. For a channel spout, the 568LF-BLMPU. For a faucet out of the wall, the T3567LF-SSWL with its R3500-WL valve.
Plumbing Picks is reader-supported. As an Amazon Associate, we earn from qualifying purchases at no extra cost to you.
This guide compares three Delta Ara bathroom faucets using Delta’s own spec sheets.
Delta Ara compared (Delta spec sheets)
On a phone, swipe or scroll the table sideways to see every column.
| Model | Mount | Holes and spacing | Drain | Extra part needed |
|---|---|---|---|---|
| 3567-BLMPU-DST | Deck, two-handle widespread | 3, 4 to 16-in. centers | Metal pop-up | None |
| 568LF-BLMPU | Deck, single-handle channel spout | 1 or 3 (6-in. plate included) | Metal push pop-up | None |
| T3567LF-SSWL | Wall, two-handle | 3 in the wall | Sold separately | R3500-WL rough-in valve |
Ara is a Delta bath collection; its sheets show square bases, such as the 2-inch square base on the 568LF and the 2-1/8-inch square bases on the wall-mount trim. The standard single-hole Ara 567LF is covered in our single-hole bathroom faucet guide; this page covers the widespread, the channel-spout single-handle and the wall-mount version. Each Delta sheet lists a lifetime limited warranty on parts and finish for homeowners; commercial purchasers get 10 years in multifamily housing and 5 years for other commercial uses.
Delta Ara 3567-BLMPU-DST: two-handle widespread
Choose the 3567 for a three-hole sink with the handles spread 4 to 16 inches apart. Delta’s spec sheet (media.deltafaucet.com) lists a three-hole widespread for 4 to 16-inch centers, solid brass end valves, quarter-turn handle stops, interchangeable stems, diamond-coated ceramic cartridges with DIAMOND Seal, red and blue button indicators, 3/8-inch PEX supply tubes and a metal pop-up drain with a plated flange, listed on the drawing as part RP26533 if you ever need to replace it.
The sheet lists holes of 1-1/16 to 1-1/2 inches, a 2-1/4-inch maximum deck and a 2-1/2-inch minimum clearance to the backsplash. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 3567-BLMPU-DST, matte black.
Check Delta Ara 3567-BLMPU-DST widespread bathroom faucet on Amazon →
Delta Ara 568LF-BLMPU: single-handle channel spout
Choose the 568LF for an open channel spout instead of a closed tube. Delta’s spec sheet (media.deltafaucet.com) calls it a single-handle channel faucet and lists one or three-hole mounting with an optional 6-inch escutcheon included, the diamond-coated ceramic cartridge, a solid brass spout, 1/4-inch PEX supply tubes and a metal push pop-up drain with no lift rod hole. Delta says the handle returns to a neutral position when the valve is turned off.
The sheet lists a 1-1/8 to 1-1/2-inch hole, a 2-1/4-inch maximum deck and 2 inches of recommended backsplash clearance. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model 568LF-BLMPU, matte black.
Check Delta Ara 568LF-BLMPU channel spout bathroom faucet on Amazon →
Delta Ara T3567LF-SSWL: wall-mount trim
Choose the T3567LF-WL for a vessel or wall-hung sink with the faucet coming out of the wall. Delta’s spec sheet (media.deltafaucet.com) lists a three-hole, two-handle wall-mount trim with a solid brass body, quarter-turn stops, a rotating-cylinder control with ceramic discs, 1/2-inch NPT female inlets and a 1.2 gpm flow. It requires the separate R3500-WL rough-in valve, and the drain is sold separately; the drawing names an optional push pop-up drain, part 33W576, for that job.
Delta lists finished walls from 1/8 to 1-1/8 inches thick and a rough-in depth of 2-3/4 inches, plus or minus 1/2 inch. Wall-mount work means opening the wall, so plan it with the sink choice. On October 15, 2026, the standard new offer sold by Amazon.com showed limited stock with model T3567LF-SSWL, stainless finish.
Check Delta Ara T3567LF-SSWL wall-mount bathroom faucet trim on Amazon →
Deck or wall mount?
Deck mount. The 3567 and 568LF sit on the sink or counter. They are the simpler swap when you already have holes in the deck: count the holes, measure their spacing, and check the deck thickness against Delta’s 2-1/4-inch limit.
Wall mount. The T3567LF-WL comes out of the wall above the sink, which leaves the counter clear and suits a tall vessel bowl. It needs Delta’s R3500-WL rough-in valve inside the wall, set to the depth on the sheet, and a separate drain. For more wall-mount options, see our wall-mount bathroom faucet guide.
Vessel sinks. None of these Ara sheets is labelled as a vessel-height deck faucet, so with a vessel bowl check the spout height on the drawing against your bowl, or use the wall-mount trim. For other choices see our vessel sink guide.
Cartridges, handles and service
Cartridges. The 3567 widespread and 568LF list Delta’s diamond-coated ceramic cartridges, which Delta markets as DIAMOND Seal on the 3567. The wall-mount T3567LF-WL lists a rotating-cylinder control with ceramic discs instead. If a handle starts to drip later, those are the parts to look up by model number.
Handles. The widespread and wall mount turn a quarter turn from off to full on. The 568LF single handle, per Delta, returns to a neutral position when the valve is turned off. The 3567 has red and blue button indicators, and the 568LF comes with an optional red and blue indicator ring.
Supply lines. The widespread uses 3/8-inch PEX supply tubes and the single-handle 1/4-inch PEX tubes ending in 3/8-inch compression fittings. The wall mount has 1/2-inch NPT female inlets on the rough-in.
Picking by your sink
Look at the sink and the wall. If the counter already has three holes spread apart, the 3567 widespread fits anywhere from 4 to 16 inches center to center. If it has one hole, or three holes 4 inches apart and you want a single lever, the 568LF fits with or without its 6-inch plate. If the bowl sits on top of the counter or hangs on the wall and you are opening the wall anyway, the wall-mount trim keeps the counter clear.
Ara alongside other Delta collections
The Ara widespread shares its 4 to 16-inch spacing range with the Saylor widespread in our Delta Saylor guide, and both list a 2-1/4-inch maximum deck. Woodhurst, in our Delta Woodhurst guide, starts at 4-1/2 inches. All three list a metal pop-up drain and 1.2 gpm flow, so the choice comes down to the look and the handle shape. If you want the shower to match, the Saylor and Woodhurst guides also cover each collection’s Monitor shower trim.
Check these before you order
- Mount. Deck (3567, 568LF) or wall (T3567LF-WL).
- Spacing. 4 to 16-inch centers for the widespread.
- Deck. 2-1/4 inches maximum on the deck models.
- Wall valve. R3500-WL required for the wall-mount trim.
- Drain. Included on the deck models; separate for the wall mount.
- Finish. BL matte black, SS stainless.
Which Delta Ara should you buy?
For a three-hole widespread, the 3567-BLMPU-DST. For a channel spout on one or three holes, the 568LF-BLMPU. For a faucet out of the wall above a vessel or wall-hung sink, the T3567LF-SSWL with its R3500-WL valve. For other Delta faucets, see our Delta bathroom faucet guide.
Frequently asked questions
Does the Delta Ara wall-mount faucet include the valve?
No. Delta says the R3500-WL rough-in is required and sold separately; the drain is separate too.
What spacing fits the Delta Ara widespread?
4 to 16-inch centers.
Does the Delta Ara 568LF fit a three-hole sink?
Yes. Delta lists one or three-hole mounting with an optional 6-inch escutcheon included.
What flow rate are Delta Ara bathroom faucets?
1.2 gpm maximum at 60 psi.
What wall thickness does the Ara wall-mount trim fit?
1/8 to 1-1/8 inches, per Delta.
How we chose
This document-based guide makes no hands-on testing claim. We read Delta’s spec sheets for the Ara 3567, 568LF and T3567LF-WL. On October 15, 2026, we checked each linked standard new Amazon offer for model, seller, stock and an add-to-cart button. Read our selection method and about Plumbing Picks.
Primary sources
- Delta 3567-MPU-DST spec sheet (media.deltafaucet.com): widespread 4-16 in.
- Delta 568LF-MPU spec sheet (media.deltafaucet.com): channel spout.
- Delta T3567LF-WL spec sheet (media.deltafaucet.com): wall mount, R3500-WL.
